Policy-Based Management with SNMP and Comparison
with COPS-PR

• Steve Waldbusser
• waldbusser_at_nextbeacon.com
• 5/16/01

2
Policy Based Management

• A policy binds an action (simple or complex) to a
  filter rule that determines what elements the
  action should be applied to
• I.e. if (an element has certain characteristics)
  then (apply operation to that
  element)
• Alternately if (policyFilter) then (policyAction)

3
A Conceptual policy
Trunk AND Ethernet AND 100Mb
Trunk Ethernet Gold 100Mb
Trunk ATM Gold 45Mb
Trunk Ethernet 100Mb
Access Ethernet Gold 10Mb
Access Ethernet Silver 10Mb
AutonegotiateOff
AutonegotiateOff
Access Ethernet 10Mb
Trunk Ethernet Silver 100Mb
Access Ethernet Gold 100Mb
Trunk Frame 45Mb
Access Frame Gold 512Kb
AutonegotiateOff
Access Frame Silver 512Kb
Access Frame 128Kb
Access Ethernet Bronze 10Mb
Access Ethernet Gold 10Mb
4
A Conceptual policy
Ethernet AND Access AND Gold
Trunk Ethernet Gold 100Mb
Trunk ATM Gold 45Mb
Trunk Ethernet 100Mb
Access Ethernet Gold 10Mb
Access Ethernet Silver 10Mb
DSCP 5
Access Ethernet 10Mb
Trunk Ethernet Silver 100Mb
Access Ethernet Gold 100Mb
Trunk Frame 45Mb
Access Frame Gold 512Kb
DSCP 5
Access Frame Silver 512Kb
Access Frame 128Kb
Access Ethernet Bronze 10Mb
Access Ethernet Gold 10Mb
Access Ethernet Gold 10Mb
Access Ethernet Gold 10Mb
DSCP 5
DSCP 5
.
5
The Policy-Based Management MIB

• The Policy Management MIB (PM MIB) provides a way
  to describe and install policies for any domain
• QOS
• Security
• Routing
• etc.
• PM MIB Policies can manage any type of element
• Interfaces
• Circuits
• Queues
• Processes
• Software
• others...

6
PM MIB Goals

• Leverage existing infrastructure and tools
• Resulting simplicity will accelerate time to
  market
• Leverage existing MIBs
• Dont start from scratch in our data models
• Flexibility for real-world policy
• Simple or complex filters
• Simple or complex actions
• Meet operational requirements
• Policy-based management is very different
• End-users will need new tools and practices

7
Policy Operation
Policies
(Usually local operations in which SNMP packets
on network are unnecessary)
Existing SNMP MIBs
8
Elements of the Policy MIB Architecture

• PolicyScript Language
• Interpreted language that policy filters and
  actions are expressed in
• Accessor Function Library
• Standard set of library functions available for
  PolicyScript code
• PM MIB
• Objects and attributes that describe policies,
  schedules and supporting information

9
PolicyScript Language

• Least Common Denominator of C, Perl, C, TCL,
  Python, and Javascript
• No pointers, structures, typed variables,
  objects, classes, etc.
• Does contain expressions, variables, looping

10
Accessor Function Library

• Library of 41 standard functions for policy
  processing
• Convenience SNMP Functions
• getvar, exists, setvar, searchcolumn,
  setRowStatus, counterRate, ...
• General SNMP Functions
• newPDU, readVar, writeVar, snmpsend
• Policy Functions
• roleMatch, elementName, setScratchPad,
  getScratchPad, signalException, getParameters
• Utility Functions
• regexp, regexp_replace, oidlen, oidncmp,
  insubtree, subid, substr, ...
• Library Functions
• strncmp, strncasecmp, strlen, random, sprintf,
  sscanf
• Extensible
• Vendors and others can add new accessor functions
  (e.g., setCLI())

11
policyFilter PseudoCode

• Pseudocode
• (is an ethernet
• AND is operational
• AND gets gold or silver service)
• Scripted As
• (getvar(ifType.) ethernet-csmacd
• getvar(ifOperStatus.) up
• (roleMatch("gold") roleMatch("silver")))

12
Execution Example

• Filter(getvar(ifType.) ethernet-csmacd
• !(roleMatch("gold")
• roleMatch("silver")))
• Action
• setvar(ifAdminStatus., down(2), Integer)

13
Example Policy

• Web Hosting Provider gives shell accounts but
  prohibits long-running programs
• Filter // if it's an application and it's //
  consumed more than 5 minutes of CPU time
  (getvar("hrSWRunType.") 4 // app, not OS
  or driver getvar("hrSWRunPerfCPU.") gt
  30000) // 300 seconds
• Action // Kill it setvar("hrSWRunStatus.",
  invalid(4), Integer) // invalid(4) kills it

14
MIB Objects

• Policy Table Contains filter, action, scheduling
  info, execution instructions, debugging info,
  etc.
• Policy installation consists of creating rows in
  this table

...

• Other Tables in PM MIB for scheduling, roles and
  capabilities, operational tools, debugging, etc.

15
Protocol Interaction
Initial Configuration

• No Polling
• No Traps

Manager
Config Req (Get/Getnext)
Config Data
Policy Installation (Set)
Managed System
Ack
16
Protocol Interaction
Policy Change

• No Polling
• No Traps

Manager
Policy Install/Modify (Set)
Ack
Managed System
17
Protocol Interaction
Config State Change

• No Polling
• No Traps

State Change (Inform)
Manager
Ack
Managed System
Policy Install/Modify (Set)
Ack
18
Features of Policy MIB

• Scripting
• Very flexible and understandable way to express
  policy
• IT Personnel like the power of scripting
• Much more flexible than string matching
• Policies based on operational status
• Capabilities, status of interface, utilization,
  etc.
• Allows much more rich sets of policies than using
  human-input strings
• Scheduling
• Business calendars M-F 9-5 or Last Friday of
  every month
• Videoconference from 12PM to 1PM
• Conflict resolution
• Follows a precedence tree to find best policy in
  case of conflict
• COPS punts conflict resolution to the manager
• Error Recovery
• Scripting allows you to fallback to an alternate
  mechanism, an alternate policy, or to raise an
  alarm

19
Operational Requirements

• Tools for Policy Creation
• Need to allow an engineer to test a policy
• Answer question will this filter match the
  proper elements?
• Tools for Ongoing Operations
• Notifications if a policy undergoes errors
• When debugging a problem, want to know what
  policies are managing this element
• May want to disable a policy on an element so
  operator can take back control (limp-home mode)
  until policy is fixed
• Must document this ad-hoc decision

20
Advantages of the PM MIB

• Built with existing infrastructure and tools
• Leverages existing MIBs
• Flexibility
• Complete Architecture
• Includes operational tools
