WaterBase Free, Open Source Software for Integrated Water Resources Management

1
WaterBase Free, Open Source Software for
Integrated Water Resources Management
Chris George and Luis Leon
2
WaterBase

• Drought
• Flood
• Pollution
• Water-borne disease
• Sediment
• Water quality

3
Its not just for drinking

• Litres of water needed to make
• 1 litre of petrol 2.5
• 1 litre of biofuel 1000
• 1 cotton T-shirt 2700
• 1 kilo of wheat 4000
• 1 kilo of beef 16000
• Wealthier people consume 3000 litres per day

4
WaterBase

• Water management is critical
• Must be at basin level
• Based on public/private partnership
• Requires
• Expertise
• Information
• Modelling Decision support
• Community involvement

5
Modelling River Basins

• Terrain (shape of the land)
• Soil
• Landuse (vegetation)
• Climate (rainfall, temperature, humidity, )
• Model a computer program that can simulate the
  natural processes involved
• Expertise

6
Resources Available WWW Data

• DEM 90m SRTM (srtm.csi.cgiar.org)
• Shuttle Radar Topographic Mission
• World wide coverage (V3 pit filled)

Tile download
Direct FTP Download
7
Resources Available WWW Data

• Land GLCF (glcf.umiacs.umd.edu)
• Global Land Cover Classification
• Satellite raster (1km resolution)

8
Resources Available WWW Data

• Soil FAO/UNESCO (www.fao.org)
• Digital Soil Map of the World
• 15 000 000 (raster 5x5 arc-minute)

9
Model Philosophy

• Readily available input
• Physically based
• Computer efficient
• Comprehensive Process Interactions
• Simulate Management

10
(No Transcript)
11
Upland Processes

• Weather
• Hydrology
• Sedimentation
• Plant Growth
• Nutrient Cycling
• Pesticide Dynamics
• Management
• Bacteria

12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Management

• Crop Rotations
• Removal of Biomass as Harvest/ Conversion of
  Biomass to Residue
• Tillage / Biomixing of Soil
• Fertilizer Applications
• Grazing
• Pesticide Applications
• Irrigation
• Subsurface (Tile) Drainage
• Water Impoundment (e.g. Rice)

23
Management

• Urban Areas
• Pervious/Impervious Areas
• Street Sweeping
• Lawn Chemicals
• Edge of Field Buffers

24
(No Transcript)
25
WaterBase

• Support for Integrated Water Resources Management
• Using free, open source software
• An international network of users and developers

26
Why Open Source?

• Free
• Secure no supplier dependence
• Encourages involvement and sense of ownership
  internationalization
• Support network via internet
• High quality
• Good maintenance
• Open standards interoperability
• Examples Linux Apache GRASS

27
WaterBase

• Three phases
• First tool available MWSWAT
• Network of partners (current)
• Seek funding for development of
• Tools
• Training materials and technical documentation on
  the internet
• Data repository design and implementation

28
First tool MWSWAT

• Based on MapWindow GIS system http//www.mapwindow
  .com
• Uses SWAT (Soil and Water Assessment Tool)
  http//www.brc.tamus.edu/swat
• Distribution internet and DVD

29
Preparation for SWAT

• Start with a DEM, a Digital Elevation Map (a
  grid, or 2-D array, of heights).
• This DEM has some 3.4 million values, 83.3m
  apart.

30
Preparation for SWAT

• 2. Calculate stream reaches. (Uses David
  Tarbotons Taudem software.).

31
Preparation for SWAT

• 3. Mark outlet(s) and calculate sub-basins

32
Preparation for SWAT

• 4. Add landuse map (another grid). Here
  resolution roughly 10 times DEMs.

33
Preparation for SWAT

• Add soil map (another grid). Here resolution
  roughly 80 times DEMs.

34
Preparation for SWAT

• 6. Calculate HRUs Hydrological Response
  Units unique combinations of sub-basin, landuse,
  soil and slope. Small ones omitted using
  thresholds. (Here 79 retained from 326.)

35
Preparation for SWAT

• 7. Add weather data from weather stations (can
  be automatic) and weather generator.
• 8. Set start and end dates, and some SWAT
  parameters.
• 9. Write SWAT input files (here 620) and
  database tables.
• 10. (Optionally) edit SWAT input files and
  tables.
• 11. Run SWAT.
• 12. Examine SWAT outputs.

36
SWAT Outputs

• Runs typically over several years
• Inputs and outputs (daily/monthly/yearly) per
  subbasin
• Water flow
• Sediments
• Nutrients
• etc

37
Model Output
Reach file
output.rch

• Output
• Extract from reach output
• Outlet at any sub-basin (swat2dat utility)
• Import (i.e. spreadsheet) plot

38
Scenarios

• Typical use will be what if we change
• Temperatures
• Rainfall patterns
• Water management (reservoirs sewage treatment
  )
• Landuse (urban development plant trees
  cultivate new areas )
• Crop management (crop type tillage practices )
• Identify hotspots

39

• Thanks to...
• David Lam David Swayne (NWRI UG)
• Daniel Ames, Chris Michaelis, Allen Anselmo
  (MapWindow Team)
• Raghavan Srinivasan (SWAT)
• Gary Bowen (TRCA)
• Karim Abbaspour (EAWAG)
• Dagny Janowska (BIAD)

40
Join us!

• http//www.waterbase.org
• waterbase.contact_at_waterbase.org
