Title: Using Cold Fusion with Open Source Software


1
Using Cold Fusion with Open Source
SoftwareMaking the Marriage Work
  • Stephan Greene
  • Senior Systems Specialist, VA Linux Systems
  • Consultant, Washington Square Associates, Inc.
  • sgreene_at_patriot.net

2
Why Give This Talk?
  • Share our experience using Cold Fusion with
    several Open Source products
  • Benefits and Challenges
  • Contrast two different approaches to software

3
WSA
  • About WSA
  • IT Integrator and Engineering Services
  • 17 on Washington Technology Fast 50
  • http//www.washsq.com
  • Cold Fusion Experience
  • Data-driven Business Applications using Web
    Browser Clients, Dynamic Web Sites
  • Started Using Cold Fusion in 1996 (Version 1!)

4
Project Background
  • We werent trying to prove anything
  • Client Wanted a CF-based system on Solaris
    platform
  • Our Challenge Apply NT-based CF experience to a
    new platform
  • Experience with other nix (Linux)

5
What Is Open Source Software?
  • Software with publicly available source code
  • See www.fsf.org, www.opensource.org
  • Users contribute fixes and enhancements back to
    the community
  • May incorporate into commercial products and
    services per license
  • License terms govern reuse, resale
  • GPL, LGPL, BSD, artistic, Netscape/Mozilla, Sun
    Community, public-domain,...

6
Open Source Software Examples
  • Operating Systems
  • Linux, FreeBSD
  • Internet Servers/Daemons
  • BIND, Sendmail, Apache, Samba
  • Developer Tools Languages
  • gcc, emacs, Perl, Python, Tcl/Tk, XFree86
  • Applications
  • Mozilla, KDE, Gnome, MySQL, Postgres

7
Characteristics of Open Source
  • Rapid Development Cycles
  • Very frequent code releases
  • Users and Developers are responsive to bugs and
    new features
  • Worldwide scope
  • Often Standards-based
  • Amount of polish varies widely

8
Example Project
  • Data-Driven Web Site
  • Replace A Static site
  • Dynamic Page Content based on User Inputs
  • Non-Webmasters Maintain Content
  • Integrate with other dynamic elements

9
Project Architecture
  • Solaris platform (Sparc CPU)
  • Solaris 2.5.1 Operating System
  • Web Server
  • Cold Fusion Application Server
  • Back-End Database stores content
  • Supporting scripts and utilities
  • Other project elements

10
Project Architecture
Browser
Browser
Users
Developers Client
Apache
Browser
CF Server
Content Admin
MyODBC
CF Studio
MS Access
MySQL
MyODBC
Solaris
Win 9x/NT
Legend
Development Server
Developers
Open Source
Netscape
Closed Source
CF Server
Other App
External
MyODBC
Doesnt Matter
MySQL
Other DB
MySQL
Solaris
Server O/S
( Solaris, Linux, nix, NT,...)
Production Server
Scaling
11
Why Use Open Source Software?
  • It solved several problems threatening the
    success of the project!
  • Budget - Apache web server met all our needs
  • Feasibility - The commercial database we started
    with did not work with Cold Fusion
  • Support - Responsiveness of the community was
    vital to getting the database backend integrated
    and working

12
Getting CF Running on Solaris
  • Straightforward Installation
  • Solaris pkgadd tool
  • Web Server Integration
  • Netscape - handled by installation
  • Apache - recompile with Cold Fusion libraries
  • ODBC Databases
  • This was the trickiest part!
  • Differences between CF on Solaris and NT
  • Some developer training required

13
Backend Databases
  • Cold Fusion supports ODBC!
  • Database must run on Solaris, support ODBC
  • Candidates
  • Open Source Msql, MySQL, PostgreSQL
  • Commercial SQL Anywhere
  • Our pick MySQL
  • Sufficient features for this project
  • Another user had successfully used it with Cold
    Fusion and released the driver source code so we
    could use it ourselves.

14
More Tweaking...More Open Source
  • MySQL Installation
  • build / install binary
  • Getting the ODBC Driver built
  • Scott Weikart patch, FSF GNU Tools
  • gcc, egcs, make, gnuzip, g-tar
  • Debugging ODBC
  • odbctool
  • Learning the tricks
  • Thank heaven for mailing lists!

15
CF Startup
  • !/bin/sh
  • start - setup environment and run Cold Fusion
    servers
  • ...
  • ODBCHOME/opt/coldfusion/odbc
  • ODBCINI/opt/coldfusion/odbc/odbc.ini
  • ...
  • MySQL
  • MYSQL_HOSTxyz.foo.bar
  • MYSQL_LOG"dtSO,/tmp/myodbc.log"
    uncomment for debugging
  • ...
  • VAR_LIST"LD_LIBRARY_PATH CFHOME CFUSER ODBCHOME
    ODBCINI SYBASE SQLANY SATMP ORACLE_HOME
    INFORMIXDIR INFORMIXSERVER II_SYSTEM MYSQL_HOST
    MYSQL_PWD MYSQL_LOG MYSQL_HOME MYSQLHOME
  • ...

16
ODBC Configuration
  • ODBC Data Sources
  • ...
  • PROJECT1MySQL
  • ...
  • ODBC
  • Trace0
  • TraceFile/tmp/odbctrace.out
  • TraceDll/opt/coldfusion/lib/odbctrac.so
  • InstallDir/opt/coldfusion/odbc
  • ...
  • PROJECT1
  • DescriptionPROJECT1
  • Driver/usr/local/mysql/lib/libmyodbc_mysql.so
  • SERVERlocalhost
  • ...

17
CF on Solaris Tips n Tricks
  • File Permissions
  • Learn new switches in CF tags - CFFILE Upload,
    Create
  • File Permissions!
  • Migrating Data from Access to MySQL
  • File Permissions!!
  • CF 3.1 bugs and work-arounds
  • FILE PERMISSIONS !!!

18
File Naming and Permissions on Solaris
  • Unix handles file names and permissions
    differently than NT
  • Names are case sensitive
  • Files must be readable (sometimes writeable) by
    the web and CF server processes
  • Directories must be readable, executable
    (sometimes writeable) by web and CF server
    processes
  • Enforce Coding Conventions
  • Useful commands chmod, chown, chgrp

19
ltCFFILE ACTION"UploadWritegt
  • Use CFFILE with the Upload action to upload a
    file specified in a form field to a directory on
    the Web server. Note that the MODE attribute
    applies only to ColdFusion on Solaris.
  • Syntax
  • ltCFFILE ACTION"Upload"
  • FILEFIELD"formfield"
  • DESTINATION"directory"
  • NAMECONFLICT"behavior"
  • ACCEPT"file_extension"
  • MODE"permission"
  • ATTRIBUTES"file_attributes"gt

20
Migrating Database from Access to MySQL
  • Developers use Access to design and prototype
    database tables
  • Use exportsql VBA script to export table
    definitions and text content
  • Modify defaults to support our data structures
  • Import from Unix command line
  • mysql -pltpwdgt ltdatabasegt lt project.sql
  • Export Tables via ODBC

21
CF 3.1 Problems and Workarounds
  • Cfserver lockups and core dumps
  • Watchdog script detects lockup, restarts server
    without requiring root access by users
  • Upgrade to CF 4 is the real fix!
  • Cannot create MySQL data sources in CF admin
    screens
  • Edit odbc.ini manually
  • Transactions Table Locking
  • Use CFLOCK tag in applications

22
Whats Great About CF on Solaris?
  • Good application on Great server platform
  • CF Studio
  • Cross-platform CF coding
  • Excellent remote administration via admin web
    page and ssh/telnet
  • CF Studio works with NT and Solaris servers
  • CF Server 4.0 is MUCH Better than 3.1

23
Whats Not So Great About CF on Solaris?
  • Its a port
  • Windows Registry Emulator
  • Allaires documentation and support is better for
    NT but improving
  • Add-on packages work better on NT
  • Verity
  • Bugs and Memory Leaks?

24
Whats Great About CF with Open Source Software?
  • Integration using Standards-Based Software
  • HTTP, ODBC, SQL
  • Extends Capabilities of Each Product
  • Cold Fusion Developers Pre-Disposed to Share
  • Custom CF Tags and Libraries
  • Contributions to Various Forums and on-line
    Communities

25
Whats Not So Great About CF with Open Source
Software?
  • Limited Allaire Support
  • Other than Apache, Open Source Software generally
    Not Supported by Allaire
  • Allaire and Allaire Partners Unaccustomed to Open
    Source Business Models
  • CF Server, Studio Are Not Open Source
  • Dont Expect To Change, But It Doesnt Matter!
  • Allaire is beginning to support Open Source
    platforms (Linux)

26
Looking Towards the Future
  • Better support for Unix
  • Linux Port
  • Native code without Registry Emulation, etc...?
  • Competition - the Application Server space is
    heating up
  • Acceptance in Unix Community
  • Cost
  • Religious opinions
  • Development tools and cross-platform coding

27
Cold Fusion and Open Source
  • It Works!
  • Combining Cold Fusion and Open Source software
  • Met our needs
  • Met our customers needs

28
Packages and Tools We Used
  • Apache
  • MySQL
  • MyODBC, iodbc
  • GNU/FSF gcc, egcs, make, gtar, etc...
  • Linux Open Source concept and MySQL test bed

29
Links
  • Open Source http//www.opensource.org
  • GNU/FSF http//www.fsf.org
  • MySQL http//www.mysql.com
  • Scott Weikarts libmysqlodbc driver
    ftp//ftp.igc.org/pub/myodbc
  • Apache http//www.apache.org
  • Open Source Software for Solaris
    http//www.sunfreeware.com
  • General Sun Help http//www.sunhelp.com
  • Allaire http//www.allaire.com
  • Washington Square Associates, Inc.
    http//www.washsq.com
  • Me http//ww2.washsq.com/sgreene/
    sgreene_at_patriot.net

30
Cold Fusion and Linux
  • Allaire working on Linux port of CF Server
  • Part of CF 5.0 release (Fall 1999?)
  • Probably a native port
  • No registry emulator!
  • Today - Linux stub
  • Allows a Linux box running Apache to link to a NT
    or Solaris CF Server

31
Cold Fusion Linux Stub
  • Allaire provides an Apache dynamic module to
    connect to a Cold Fusion server
  • Requires
  • RedHat 5.2
  • Apache 1.3.x with mod_so enabled
  • libstdc
  • An accessible CF 4.x server (NT or Solaris)
  • http//forums.allaire.com/devconf/Index.cfm?Messag
    e_ID256760

32
Installing the Linux Cold Fusion Stub
  • Build and install mod_coldfusion.so per
    instructions in README
  • httpd.conf
  • LoadModule coldfusion_module libexec/mod_coldfusio
    n.so
  • Edit /opt/coldfusion/cfremote.ini
  • Edit ltCF Servergt/opt/coldfusion/cfdist.ini and
    run /opt/coldfusion/bin/cfdist
  • Check logs for successerror messages

33
Using the Linux Cold Fusion Stub
  • Need an exact mirror of ALL .cfm, .html, images,
    etc. from the back-end CF server on the Linux
    system
  • Easiest via NFS export
  • Windows File Sharing (smbmount)
  • ftp, mirror, rsync
  • Apache hands off Cold Fusion calls to the real
    CF Server using cfdist

34
Observations on the Linux Cold Fusion Stub
  • For Now - Limited Practical Use
  • Might make sense to integrate a Linux-based web
    site with a back-end fielded database on a
    Solaris or NT system.
  • If most/all of site is on Cold Fusion, there may
    be less reason to front it with a Linux web
    server
  • Gets Cold Fusion in front of community
  • Especially businesses considering using Linux

35
Using Open Source Software in Commercial
Environment
  • Skepticism on practicality, performance, support,
    value
  • Open Source software rapidly gaining mind share
  • Strong business value IF IT WORKS
  • Have a respected champion
  • Be prepared to do plenty of integration, testing,
    and repeat selling

36
Predictions on Cold Fusions Future in the Linux
World
  • IMHO
  • Cold Fusions real strength is the developer tool
    (CF Studio) and its integration with CF Server.
  • Linux port is for Server, not Studio
  • A Linux port of CF Server is likely to appeal to
    business users who want a powerful, stable,
    cost-effective web server
  • CF is less likely to compete with Perl and PHP
    among traditional Linux web developers
Write a Comment
User Comments (0)
About PowerShow.com
