Shadow Profiling: Hiding Instrumentation Costs with Parallelism

1
Shadow ProfilingHiding Instrumentation Costs
with Parallelism

• Tipp Moseley
• Alex Shye
• Vijay Janapa Reddi
• Dirk Grunwald
• (University of Colorado)
• Ramesh Peri
• (Intel Corporation)

2
Motivation

• An ideal profiler will
• Collect arbitrarily detailed and abundant
  information
• Incur negligible overhead
• A real profiler, e.g., using Pin, satisfies
  condition 1
• But the cost is high
• 3X for BBL counting
• 25X for loop profiling
• 50X or higher for memory profiling
• A real profiler, e.g. PMU sampling or code
  patching, satisfies condition 2
• But the detail is very coarse

3
Motivation
Bursty Tracing (Sampled Instrumentation),Novel
Hardware,Shadow Profiling
VTune, DCPI, OProfile, PAPI, pfmon, PinProbes,
Pintools, Valgrind, ATOM,
4
Goal

• To create a profiler capable of collecting
  detailed, abundant information while incurring
  negligible overhead
• Enable developers to focus on other things

5
The Big Idea

• Stems from fault tolerance work on deterministic
  replication
• Periodically fork(), profile shadow processes

Time CPU 0 CPU 1 CPU 2 CPU 3
0 Orig. Slice 0 Slice 0
1 Orig. Slice 1 Slice 0 Slice 1
2 Orig. Slice 2 Slice 0 Slice 1 Slice 2
3 Orig. Slice 3 Slice 3 Slice 1 Slice 2
4 Orig. Slice 4 Slice 3 Slice 4 Slice 2
5 Slice 3 Slice 4
6 Slice 4
Assuming instrumentation overhead of 3X
6
Challenges

• Threads
• Shared Memory
• Asynchronous Interrupts
• System Calls
• JIT overhead
• Overhead vs. Number of CPUs
• Maximum speedup is Number of CPUs
• If profiler overhead is 50X, need at least 51
  CPUs to run in real-time (probably many more)
• Too many complications to ensure deterministic
  replication

7
Goal (Revised)

• To create a profiler capable of sampling detailed
  traces (bursts) with negligible overhead
• Trade abundance for low overhead
• Like SimPoints or SMARTS (but not as smart )

8
The Big Idea (revised)

• Do not strive for full, deterministic replica
• Instead, profile many short, mostly deterministic
  bursts
• Profile a fixed number of instructions
• Fake it for system calls
• Must not allow shadow to side-effect system

Time CPU 0 CPU 1 CPU 2 CPU 3
0 Orig. Slice 0 Slice 0 Spyware
1 Orig. Slice 1 Slice 0 Spyware
2 Orig. Slice 2 Slice 0 Slice 1 Spyware
3 Orig. Slice 3 Slice 1 Spyware
4 Orig. Slice 4 Slice 1 Spyware
9
Design Overview
10
Design Overview

• Monitor uses Pin Probes (code patching)
• Application runs natively
• Monitor receives periodic timer signal and
  decides when to fork()
• After fork(), child uses PIN_ExecuteAt()
  functionality to switch Pin from Probe to JIT
  mode.
• Shadow process profiles as usual, except handling
  of special cases
• Monitor logs special read() system calls and
  pipes result to shadow processes

11
System Calls

• For SPEC CPU2000, system calls occur around 35
  times per second
• Forking after each puts lots of pressure on CoW
  pages, Pin JIT engine
• 95 of dynamic system calls can be safely handled
• Some system calls can be allowed to execute (49)
• getrusage, _llseek, times, time, brk, munmap,
  fstat64, close, stat64, umask, getcwd, uname,
  access, exit_group,

12
System Calls

• Some can be replaced with success assumed (39)
• write, ftruncate, writev, unlink, rename,
• Some are handled specially, but execution may
  continue (1.8)
• mmap2, open(creat), mmap, mprotect, mremap, fcntl
• read() is special (5.4)
• For reads from pipes/sockets, the data must be
  logged from the original app
• For reads from files, the file must be closed and
  reopened after the fork() because the OS file
  pointer is not duplicated
• ioctl() is special (4.8)
• Frequent in perlbmk
• Behavior is device-dependent, safest action is to
  simply terminate the segment and re-fork()

13
Other Issues

• Shared Memory
• Disallow writes to shared memory
• Asynchronous Interrupts (Userspace signals)
• Since we are only mostly deterministic, no longer
  an issue
• When main program receives a signal, pass it
  along to live children
• JIT Overhead
• After each fork(), it is like Pinning a new
  program
• Warmup is too slow
• Use Persistent Code Caching CGO07

14
Multithreaded Programs

• Issuefork() does not duplicate all threads
• Only the thread that called fork()
• Solution
• Barrier all threads in the program and store
  their CPU state
• Fork the process and clone new threads for those
  that were destroyed
• Identical address space only register state was
  really lost
• In each new thread, restore previous CPU state
• Modified clone() handling in Pin VM
• Continue execution, virtualize thread IDs for
  relevant system calls

15
Tuning Overhead

• Load
• Number of active shadow processes
• Tested 0.125, 0.25, 0.5, 1.0, 2.0
• Sample Size
• Number of instructions to profile
• Longer samples for less overhead, more data
• Shorter samples for more evenly dispersed data
• Tested 1M, 10M, 100M

16
Experiments

• Value Profiling
• Typical overhead 100X
• Accuracy measured by Difference in Invariance
• Path Profiling
• Typical overhead 50 - 10X
• Accuracy measured by percent of hot paths
  detected (2 threshold)
• All experiments use SPEC2000 INT Benchmarks with
  ref data set
• Arithmetic mean of 3 runs presented

17
Results - Value Profiling Overhead

• Overhead versus native execution
• Several configurations less than 1
• Path profiling exhibits similar trends

18
Results - Value Profiling Accuracy

• All configurations within 7 of perfect profile
• Lower is better

19
Results - Path Profiling Accuracy

• Most configurations over 90 accurate
• Higher is better
• Some benchmarks (e.g., 176.gcc, 186.crafty,
  187.parser) have millions of paths, but few are
  hot

20
Results - Page Fault Increase

• Proportional increase in page faults
• Shadow/Native

21
Results - Page Fault Rate

• Difference in page faults per second experienced
  by native application

22
Future Work

• Improve stability for multithreaded programs
• Investigate effects of different persistent code
  cache policies
• Compare sampling policies
• Random (current)
• Phase/event-based
• Static analysis
• Study convergence
• Apply technique
• Profile-guided optimizations
• Simulation techniques

23
Conclusion

• Shadow Profiling allows collection of bursts of
  detailed traces
• Accuracy is over 90
• Incurs negligible overhead
• Often less than 1
• With increasing numbers of cores, allows
  developers focus to shift from profiling to
  applying optimizations
