Introduction to DDI 3.0

• Sanda Ionescu
• ICPSR
• CESSDA Expert Seminar, September 2007

2
DDI Version 3.0

• Radically different.
• More complex
• (but certainly doable!)
• Brings important benefits.

3
Workshop Schedule

• 1430 1510 Overview (40)
• 1510 1535 Structure and Technical
• Mechanisms (25)
• 1535 1545 Break (10)
• 1545 1610 Study Unit Modules Content (25)
• 1610 1630 Variable Markup Example (20)
• 1630 1640 Break (10)
• 1640 1710 Grouping Modules Content and
• Examples (30)
• 1710 1730 Getting Started (20)

4
DDI 3.0

• Overview

5
DDI BackgroundDevelopment History

• 1995 A grant-funded project initiated and
  organized by ICPSR proposes to create a new
  standard for documenting social science data, to
  replace OSIRIS tagged codebooks.
• First drafts used SGML, then converted to
  Web-friendly XML.
• 2000 DDI Version 1.0 published as a mainly
  document- and codebook-centric standard.

6
DDI BackgroundDevelopment History

• 2003 DDI Version 2.0 published with extended
  scope
• Aggregate data coverage (based on matrix
  structure)
• Additional geographic representation to assist
  geographic search systems and GIS users
• Versions 1.0 through 2.1 (latest published) are
  backwards compatible, and based on the same
  structure.

7
DDI BackgroundDevelopment History

• February 2003 Formation of the DDI Alliance, a
  self-sustaining membership organization whose
  members have a voice in the development of the
  DDI specification.
• http//www.ddialliance.org/

8
DDI BackgroundDevelopment History

• Version 3.0
• 2004-2006 Planning and Development


• November 2006 Internal Review
• February 2007 Public Review
• July 2007 Candidate Draft Release
• http//www.ddialliance.org/ddi3/index.html

9
Benefits of using DDI as an XML-based standard

• Interoperability
• Enables seamless exchange and reuse by other
  systems.
• Repurposing
• Provides a core document from which different
  types of outputs can be generated.
• Value-added documentation
• Tagging carries intelligence in the document by
  describing content.
• Enhanced Data Discovery
• Increases precision and granularity of searches.
• Support for Data Analysis
• Variables description is accepted as input by
  online analysis systems.
• Multiple presentation formats
• ASCII text PDF HTML RTF.
• Preservation-friendly
• Non-proprietary format.

10
Why DDI 3.0?

• DDI 3.0 presents new features in response to
• Perceived needs of
• -Data users
• -Data producers
• -Data archivists/librarians
• Developments in documenting and archiving data
• Advances in XML technology

11
DDI 3.0 and the Data Life Cycle Model

• DDI Versions 1/2 were codebook-centric
• Closely followed the structure of traditional
  print codebooks.
• Captured data documentation at a single, frozen
  point in time archiving.

12
DDI 3.0 and the Data Life Cycle Model

• Version 3.0 is Life Cycle oriented
• -Designed to cover all stages in the life cycle
  of a data collection
• pre-production production
  post-production secondary use

13
Life Cycle Coverage in DDI 3.0
Planning for the Study Proposal / Design
Study Purpose / Outline Concepts Study
Population Author(s) Funding Sources
Version 3.1 Survey / Sample Design Pre-testing
14
Life Cycle Coverage in DDI 3.0

• Proposal becomes reality

Data Collection methodology sampling, time,
etc. Instrument characteristics
Questionnaire Data cleaning, weighting, coding,
etc.
15
Life Cycle Coverage in DDI 3.0

• Publishing the data

Physical representation Data format, Record
structure, Statistics.
Intellectual content Variables, Categories,
Codes.
16
Life Cycle Coverage in DDI 3.0

• Archiving / (Re)Distributing the data collection

Processing checks
Holdings, availability and access conditions
17
Life Cycle Coverage in DDI 3.0

• DDI becomes visible to the outside world

DDI Instance Pulls together all life cycle
stages Acquires its own identity as an
object Becomes a tool for data discovery and
analysis
18
Life Cycle Coverage in DDI 3.0

• Secondary use of data new conceptual framework

New DDI Instance New Purpose New Logical
Product New Physical Description of Data
19
DDI 3.0 and the Data Life Cycle Model

• Advantages of Life Cycle orientation
• Allows capture and preservation of metadata
  generated by different agents at different points
  in time.
• Facilitates tracking changes and updates in both
  data and documentation.

20
DDI 3.0 and the Data Life Cycle Model

• Advantages of Life Cycle orientation
• Enables investigators, data collectors and
  producers to document their work directly in DDI,
  thus increasing the metadatas visibility and
  usability.
• Benefits data users, who need information from
  the full data life cycle for optimal discovery,
  evaluation, interpretation, and re-use of data
  resources.

21
New / Extended Functionalities in DDI 3.0
Questionnaire

• Versions 1/2
• No instrument coverage.
• Question text only as part of variable
  description.
• No documentation for question flow / conditions.
• Version 3.0
• Full description of instrument as a separate
  entity.
• Documents specific use of questions flow,
  conditions, loops.
• Compatible with Computer Assisted Interviewing
  software.

22
New / Extended Functionalities in DDI 3.0
Complex Data

• Versions 1/2
• Inadequate representation of complex /
  hierarchical data



• Version 3.0
• Detailed documentation for complex / hierarchical
  data
• Logical structure of records
• Record Types and Relationships
• Relevant variables key-link, case
  identification, record type locator
• Physical layout of records
• Single hierarchical file for all records,
  multiple rectangular files, relational database,
  etc.

23
New / Extended Functionalities in DDI 3.0
Aggregate Data

• Versions 1/2
• Initially designed for microdata only
• Aggregate data section added in V 2.1 to support
  limited representation (Census-type data,
  delimited files)
• Version 3.0
• Adds support for tabular, spreadsheet-type,
  representation of aggregate data
• Aggregate data transport option cell content may
  be included inline with the data item description


24
New / Extended Functionalities in DDI 3.0 Data
Transport

• Versions 1/2
• -None
• Version 3.0
• -In-line inclusion enabled for both aggregate
  data
• and microdata

25
New / Extended Functionalities in DDI 3.0
Longitudinal / Time Series / Cross-national
DataComparability

• Versions 1/2
• -None
• Version 3.0
• -Grouping structure documents studies related on
  one or several dimensions (time, geography,
  language, etc.) as well as their comparability

26
New / Extended Functionalities in DDI 3.0
Increased Multilingual Support

• Versions 1/2
• Limited
• ltanytag xmllanggt
• Version 3.0
• Support for multiple language use and
  translations
• ltInternationalStringType xmllang
  translated translatablegt
• ltVariablegt
• ltLabel xmllangger translatedfalse
  translatabletruegt
• Geburtsjahrlt/Labelgt
• ltLabel xmllangeng translatedtruegtYe
  ar of Birthlt/Labelgt
• lt/Variablegt

27
DDI 3.0 Specification Schema-based

• Versions 1/2
• DTD-based
• Version 3.0
• Schema-based
• Data typing supports machine actionability
• Use of namespaces supports
• Modularity
• Extensibility and reuse
• Alignment with / use of other standards

28
DDI 3.0 Specification Machine-actionable

• Versions 1/2
• Machine-readable
• Version 3.0
• Machine-actionable
• 1. Data typing increased use of controlled
  vocabularies and standard codes
• 2. Larger set of required elements
• Predictable content a more consistent
• base for programming

29
DDI 3.0 Modular Structure

• Version 1/2
• Single file, hierarchical design
• Version 3.0
• Modular design
• Facilitates reuse
• Facilitates versioning and maintenance
• Supports life cycle model
• Allows flexibility in organizing the DDI
  Instance
• Supports grouping and comparing studies
• Supports creation of metadata registries

30
DDI 3.0 Alignment with other metadata standards

• Versions 1/2
• MARC, Dublin Core (bibliographic standards)
• Version 3.0
• MARC, DC, but also
• SDMX (Statistical Data and Metadata Exchange)
• ISO 11179 (Metadata Registries)
• FGDC (Digital Geospatial Metadata)
• - ISO 19115 (Geographic Information Metadata)

31
DDI 1/2 or DDI 3.0?

• DDI 3.0 will not supersede DDI 2.1.
• Both versions will
• coexist
• continue to be maintained
• be used according to specific needs.
• All DDI 1/2 markup will not have to be migrated
  to Version 3.0.

32
DDI 3.0

• Structure and Mechanisms

33
DDI 3.0 Modular Structure

• Building blocks of DDI 3.0
• Modules
• Schemes

34
DDI 3.0 Modular Structure

• Modules
• Document different aspects of a study, or group
  of studies, following the data through their life
  cycle (Conceptual Components, Data Collection,
  Logical Product, Physical Instance, etc.)
• Schemes
• Include collections of sibling objects that are
  traditionally components of a variable
  description Concepts, Universes, Questions,
  Variable Labels and Names, Categories, Codes.

35
DDI 3.0 Modular Structure

• Modules
• Can live independently (have their own schemas)
  or connected to one another within a hierarchical
  structure.
• Schemes
• Can live semi-independently (need a higher-level
  wrapper as they do not have their own schemas) or
  in-line within a Study Unit or Group module.

36
DDI 3.0 Modular Structure

• DDI 3.0 model a multi-branched hierarchy
• Module level

DDI Instance
Resource Package
Group
Study Unit
Subgroup
Study Unit
Conceptual Components
Data Collection
Archive
(Sub)group
Study Unit
Organizations
Study Unit
Subgroup
37
DDI 3.0 Modular Structure

• DDI 3.0 model a multi-branched hierarchy
• Within modules

Data Collection
Question Scheme
Processing
Methodology
Sampling
Time Method
Question Item
Question Item
Weighting
Coding
38
DDI 3.0 Modular Structure

• Relationships are established through
• In-line inclusion
• (Relational order is explicit)
• Referencing Internal
• External
• (Relational order is implicit)

39
DDI 3.0 Structural mechanisms

• Enable modular design and help actualize its
  benefits.
• Inheritance
• Referencing
• Identification

40
DDI 3.0 Inheritance

• Inheritance is based on the hierarchical
  structure of the model.
• In DDI 3.0 a number of elements are reused at
  different levels of the hierarchy.
• When the same element is present at multiple
  levels, lower levels inherit content from the
  upper levels, and only need to specify
  differences (local overrides).

41
DDI 3.0 InheritanceExample

• Instance Coverage Spatial 50 US states
• -Study Unit A no Spatial Coverage defined
• will be inherited
  from Instance
• -Study Unit B Coverage Spatial 48
  coterminous states
• supersedes
  definition in Instance

42
DDI 3.0 Referencing

• DDI 3.0 modular structure is dependent upon
  creating relationships by reference.
• Referencing implies bringing up the content of a
  DDI object within, or in association with,
  another object, by specifying its Unique
  Identifier.
• Identifiers are the key links between DDI objects.

43
DDI 3.0 ReferencingExample

• Data Collection Module
• Question Scheme Question ID Q1

• Text How many days in the past week did you
  watch the national network news on TV?

• Conceptual Components Module
• Concept Scheme Concept ID C1
• Description Exposure to national TV news

Logical Product Module Variable Scheme
Variable ID V1 Name V043014 Label Days
past week watch natl news on TV
Question Reference ID Q1
Concept Reference ID C1
44
DDI 3.0 ReferencingExample
45
DDI 3.0 Identification

• Consistency in building and using identifiers is
  needed for
• Proper functioning of reference systems, enabling
  a smooth exchange and reuse of existing metadata.
• Machine-actionability of DDI instances, allowing
  them to serve as a basis for running programs and
  processes.

46
DDI 3.0 Identification

• Element types used in the Identification system

47
DDI 3.0 IdentificationElement Types

• Non-identified elements
• Require context, which is provided by containing
  parents.
• Example codes within code schemes
• Are not reusable.
• Example variable and category statistics

48
DDI 3.0 IdentificationElement Types

• Identifiables
• Carry their own ID
• May be referenced / reused
• Cannot be versioned or maintained, except as part
  of a complex parent element
• (Example Variable a change implies a new
  version of the entire scheme).

49
DDI 3.0 IdentificationElement Types

• Versionables
• Carry their own ID
• Carry their own Version content changes are
  important to note
• (Example Concept may be independently
  versioned within a scheme).

50
DDI 3.0 IdentificationElement Types

• Maintainables
• Are higher level DDI objects
• Are both identifiable and versionable
• Can also be published and maintained as separate
  entities
• (Example all modules, schemes, comparison maps)

51
DDI 3.0 Identification Structure

• Maintainable elements
• URN and / or ID Identifying Agency
• Versioning
  Information
•
  Version
•
  Version Date
•
  Version
  Responsibility
•
  Version
  Rationale
• Versionable elements
• URN and / or ID Versioning Information
• Identifiable elements
• URN and / or ID

52
DDI 3.0 Identification StructureNon-specified
Identification information is inherited from the
levels above.

• Example 1
• Inheritance is assumed.
• Maintainable Variable Scheme
• ID VarScheme_AIdentifying Agency ICPSR
• Version 1.0
• Identifiable Variable
• ID Var_1
• Identifying Agency
• Version

53
DDI 3.0 Identification StructureNon-specified
Identification information is inherited from the
levels above.

• Example 2
• Inheritance is applied by default
• Maintainable Logical Product
• ID LogicalProd_Y
• Identifying Agency ICPSR
• Version 1.0
• Maintainable Variable Scheme
• ID VarScheme_A
• Identifying Agency
• Version

• Example 1
• Inheritance is assumed
• Maintainable Variable Scheme ID VarScheme_A
• Identifying Agency ICPSR
• Version 1.0
• Identifiable Variable
• ID V1
  Identifying Agency
• Version

54
DDI 3.0 Identification Structure IDs

• Uniqueness of Identifiers is necessary for both
  internal and external referencing
• 1) All IDs MUST be unique within a
  maintainable
• 2) All maintainables MUST have unique IDs
  across an Agency

55
DDI 3.0 Identification Structure Creating
unique Identifiers

• A DDI Instance may include multiple
  maintainables
• at different hierarchical levels
• Instance (maintainable) unique ID within
  Identifying Agency
• Study Unit (maintainable) unique ID within
  Identifying Agency
• Logical Product (maintainable) unique ID
  within Identifying Agency
• Variable Scheme (maintainable)
  unique ID within Identifying Agency

56
DDI 3.0 Identification Structure Creating
Unique Identifiers
Markup

• Instance_A (unique at ICPSR)
• StudyUnit_1
• Logical Product_1
• VariableScheme_1
• Variable_1

• Instance_B (unique at ICPSR)
• StudyUnit_1
• Logical Product_1
• VariableScheme_1
• Variable_1

Post-markup Variable ID Instance_AStudyUnit_1Log
icalProduct_1VariableScheme_1Variable_1 Instance_B
StudyUnit_1LogicalProduct_1VariableScheme_1Variabl
e_1
57
DDI 3.0 Identification Structure URNs

• Have a fixed structure and MUST include object
  ID, Identifying Agency, and Version.
• For versionable and identifiable elements, the
  containing maintainable is specified.
• Take precedence when both a URN and the
  Identification sequence are used for the same
  object.
• May be constructed post-markup from the
  Identification sequence.

58
DDI 3.0 IdentificationURN Structure
Identifying Agency
Object ID
Object Version

• Examples
• Maintainables
• urnddi3.0StudyUnitddialliance.org
  StudyUnit_ID1.0
• Versionables
• urnddi3.0ConceptSchemeddialliance.orgConceptS
  cheme_ID1.0
• ConceptConcept_ID
  2.1
• Identifiables
• urnddi3.0VariableSchemeddialliance.orgVariabl
  eScheme_ID1.0
•
  VariableVariable_ID

Object name
59
DDI 3.0 Referencing

• Reference structure
• URN, and/or
• Referenced objects ID Identifying Agency
  Version
•
  Containing Module ID
•
  Containing Scheme ID

60
DDI 3.0 Reuse of Information

• Referencing
• Mechanisms for REUSE
• Inheritance
• Reuse of Information
• Facilitates development of documentation
  throughout the study life cycle
• Promotes interoperability and standardization
  across organizations
• Saves markup time and effort
• Reduces the risk of human entry error
• Provides a basic level of implicit comparability

61
DDI 3.0 Modules

• Content, Markup Examples

62
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Resource Package
Concepts
Study Unit
Subgroup
Study Unit
Sub(Group)
Data Coll.
Logical Pr.
etc
63
Other specialized DDI 3.0 modules

• Aggregate Data
• NCube Logical Product
• Inline NCube Record Layout
• NCube Record Layout
• Tabular NCube Record Layout
• Inline Microdata
• Dataset
• User-specific Markup Templates
• DDI Profile

64
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
65
DDI 3.0

• Modules used to mark up a simple study

66
DDI 3.0 modules for documenting a single,
survey-type study
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
67
DDI 3.0 modules for documenting a single,
survey-type study

• Instance
• Study Unit
• Conceptual Component
• Data Collection
• Logical product
• Physical Data Product
• Physical Instance
• Archive
• Organizations

• Reusable
• XHTML

68
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
69
DDI Instance -- wrapper for all modules --

• Identification
• URN
• Identification Sequence
• Name
• Citation ( optional DC Elements)
• Coverage
• Topical
• Spatial
• Temporal
• Group (module) repeatable
• Resource Package (module) - repeatable
• Study Unit (module) - repeatable
• Other Material(s)
• Note(s)
• Translation Information

70
Coverage in DDI 3.0

• Study American National Election Study (ANES),
  2004
• Topical Coverage
• Subject
• Historical and Contemporary Electoral Processes
• Keyword
• Electoral campaigns
• Political attitudes
• Political participation
• Spatial Coverage
• Description United States
• Top level nation
• Lowest level congressional district
• Temporal Coverage
• Date 2004

71
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
72
Study Unit -- documents a single study --

• Identification, Other Material(s), Note(s)
• Citation
• Abstract
• Universe Reference
• Funding Information
• Purpose
• Coverage
• Analysis Unit
• Embargo
• Conceptual Component (module)
• Data Collection (module)
• Logical Product (module)
• Physical Data Product (module)
• Physical Instance (module)
• Archive (module)
• Organizations (module)

73
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
74
Conceptual Component-- lists concepts and
universes --

• Identification, Other Material(s), Notes
• Coverage
• Concept Scheme or Reference to External Scheme
• Vocabulary describes vocabulary used
• Concept
• Label
• Description
• Similar Concept
• Difference
• Concept Group
• Concept Reference (nestable)
• Universe Scheme or Reference to External
  Scheme
• Universe
• Human Readable
• Machine Readable
• Subuniverse
• Subuniverse

75
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
76
Data Collection

• Identification, Other Material(s), Note(s)
• Coverage
• Methodology
• Time Method
• Sampling
• Collection Event
• Data Collector
• Data Source
• Collection Date (s)
• Mode of data collection
• Question Scheme lists actual questions
• Instrument documents question flow, conditions
• Processing Event
• Control and cleaning operations
• Weighting
• Data Appraisal Information
• Coding

77
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
78
Logical Product-- documents intellectual content
of data --

• Identification, Other Material(s), Note(s)
• Coverage
• Category Scheme or Reference to external
  category scheme
• Category
• Label
• Derivation (if applicable)
• Definition
• Code Scheme or Reference to external code
  scheme
• Category Scheme Reference
• Hierarchy Type
• Level (in the hierarchy)
• Code
• Category Reference
• Value
• Code (nestable)
• Variable Scheme or Reference to external
  variable scheme

79
Logical ProductVariable Scheme Variable

• Variable or Reference to an externally
  documented variable
• Identification
• Name
• Label
• Definition
• Universe Reference
• Concept Reference
• Question Reference
• Embargo Reference
• Response Unit
• Analysis Unit
• Representation
• Imputation
• Derivation
• Coding Instructions
• Value Representation
• Text

80
Logical ProductVariable Scheme Variable Group

• Variable Group
• Type
• Label
• Definition
• Universe Reference
• Concept Reference
• Variable Reference (lists variables in the group)
• Variable Group Reference (allows nesting of
  groups)
• Variable Group Reference (use for externally
  documented Variable Group)

81
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
82
Physical Data Product-- Describes Physical
Layout of Data --

• Identification, Other Material(s), Note(s)
• Logical Product Reference
• Gross Record Structure
• Records Per Case
• Variable Quantity
• Logical Record Reference
• Physical Record Reference
• Related Logical Records
• Record Layout
• Data Item
• Variable Reference
• Physical Location
• Value Location
• StartPosition
• Width

83
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
84
Physical Instance-- Documents a specific data
file ---

• Identification, Other Material(s), Note(s)
• Citation
• Coverage
• Physical Data Product Reference
• Data File Identification
• Location
• URI
• Gross File Structure
• Creation Software
• Case Quantity
• Overall Record Count
• Statistics
• Logical Product Reference
• Variable Statistics
• Variable Reference
• Total Responses
• Summary Statistics
• Category Statistics
• Value

85
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
86
Archive

• Identification, Other Material(s), Note(s)
• Archive Specific
• Item
• Location
• Call Number
• URI
• Format
• Media
• Availability Status
• Access
• Confidentiality Statement
• Access Permission
• Restrictions
• Citation Requirement
• Deposit Requirement
• Access Conditions
• Disclaimer
• Contact
• Funding Information

87
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
88
Organizations

• Identification
• Organization
• URL
• Individual
• Individual
• Organization
• Title
• Language
• Role
• Entity Reference
• Organization Reference
• Individual Reference
• Description
• Period
• Relation
• Organization Reference
• Individual Reference
• Description
• Period

• Name
• Description
• Location
• Telephone
• E-mail
• Relation

89
DDI 3.0 Markup Example

• A Survey Variable

90
Version 2.1 vs. Version 3.0 Example A survey
variable

• ASCII codebook

91
Version 2.1 vs. Version 3.0 Example A survey
variable in Version 2.1
Data Description Variable
92
Version 2.1 vs. Version 3.0 Example A survey
variable in Version 2.1
nameV043015
93
Version 2.1 vs. Version 3.0 Example A survey
variable in Version 3.0
Logical Product Variable Scheme
Conceptual Component Concept Scheme Universe
Scheme
Data Collection Question Scheme
Logical Product Code Scheme
Logical Product Category Scheme
Physical InstanceStatistics
94
Version 2.1 vs. Version 3.0 Example A survey
variable in Version 3.0
Logical Product Category Scheme ID Category ID
Conceptual Component Concept Scheme Concept
ID Universe Scheme (Sub)Universe ID
Logical Product Variable Scheme ID Variable ID
Logical Product Code Scheme ID Code
Data Collection Question Scheme ID Question ID
Physical Instance Statistics Variable
Statistic Category Statistics
95
DDI 3.0 Markup A Survey VariableConcept

• Concept Attention to
• Presidential Campaign
• on National TV

Conceptual Component Concept Scheme Concept
96
DDI 3.0 Markup A Survey VariableConcept
97
DDI 3.0 Markup A Survey VariableUniverse
Conceptual Component Universe
Scheme(Sub)Universe
(A7How many days in the PAST WEEK did you watch
the NATIONAL network news on TV? 0-7 8DK 9RF)
98
DDI 3.0 Markup A Survey VariableUniverse
99
DDI 3.0 Markup A Survey VariableQuestion ID,
Question Text
Data CollectionQuestion Scheme Question Item
100
DDI 3.0 Markup A Survey VariableQuestion ID,
Question Text

• Other Response Domains

101
DDI 3.0 Markup A Survey VariableVariable name,
label, type of physical representation
Logical Product Variable Scheme Variable
102
DDI 3.0 Markup A Survey VariableVariable name,
label, type of physical representation

• Other types of Representation

103
DDI 3.0 Markup A Survey VariableCategory
labels, missing data information
Logical Product Category Scheme Category
104
DDI 3.0 Markup A Survey VariableCategory
labels, missing data information
missingtrue
105
DDI 3.0 Markup A Survey VariableCategory Values
Logical Product Code Scheme Code
106
DDI 3.0 Markup A Survey VariableCategory Values
107
DDI 3.0 Markup A Survey VariableStatistics
Physical Instance Statistics Variable
Statistics Category Statistic
108
DDI 3.0 Markup A Survey VariableStatistics
109
DDI 3.0 Markup A Survey Variable Logical
Product Module
110
DDI 3.0 MarkupModules used in a full variable
description

• Concept
• Universe
• Question
• Values
• Value Labels
• Variable name
• Variable label
• Statistics
• Location
• Physical Data Product

111
DDI 3.0 Modular ApproachAdvantages

• Modules and schemes can be independently
  maintained.
• Pieces of information can be reused without being
  repeated.

112
DDI 3.0 Modular ApproachReusing information
113
Variable Markup in Version 2-- carries redundant
information--
114
Variable Markup in Version 3.0 Modular Approach
Reusing Information
115
DDI 3.0

• Grouping

116
DDI 3.0 Groups

• Entirely new feature in DDI 3.0.
• Designed to document and compare related studies.

117
DDI 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
118
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
119
Group-- documents families of studies --

• Identification, Other Material(s), Note(s)
• Citation
• Abstract
• Universe
• Funding Information
• Purpose
• Coverage
• Universe Reference
• Conceptual Component (module)
• Data Collection (module)
• Logical Product (module)
• Archive (module)
• Organizations (module)
• Study Unit (module)
• Group (module)
• Comparative (module)

120
DDI 3.0 Grouping Attributes

• Set of mandatory attributes indicate the nature
  of the relationships among group members
• Group parameters
• Time
• Instrument
• Panel (population of respondents)
• Geography
• Datasets
• Language

121
DDI 3.0 Grouping Attributes Example
122
DDI 3.0 Types of Groups

• Groups of studies may be
• Formal (by design)
• Designed to be compared (longitudinal,
  time-series, or cross-national studies)
• Documented and compared through use of
  Inheritance
• Informal (ad-hoc)
• Decision to group and compare is taken
  post-production, or after the fact.
• Comparability documented in the Comparative
  module

123
Formal Groups Inheritance

• Example 1 Time-series Same questions repeated
  over time, same resulting variables.

Group (Studies A-C) Temporal Coverage_G11991-1993
Data Collection Question Scheme Logical
Product Variable Scheme
Study A Temporal Coverage 1991 (Replace
RefG_1) Physical Data Product Physical Instance
Statistics
Study B Temporal Coverage 1992 (Replace
RefG_1) Physical Data Product Physical Instance
Statistics
Study C Temporal Coverage 1993 (Replace
RefG_1) ....... Physical Data Product Physical
Instance
Study A Temporal Coverage 1991 (Replace
RefG_1) Physical Data Product Physical
Instance
Study B Temporal Coverage 1992 (Replace
RefG_1) Physical Data Product Physical
Instance
124
Formal Groups InheritanceAttributes Add,
Replace, Delete.

• In a complex grouping structure inheritance paths
  may become quite intricate.
• ID attributes ADD, REPLACE and DELETE are
  introduced to resolve potential inheritance
  ambiguities
• ADD empty -gt flags element as a new addition.
• REPLACE ReferenceType -gt referenced element
  is being replaced at the lower level (local
  override).
• DELETE ReferenceType -gt referenced element is
  being deleted at the lower level.

125
Formal Groups Inheritance

• Example 2 Time-series Same core questions
  repeated over time, different topical modules
  added to each iteration.

Group (Studies A-C) Data Collection Core
Questions(Q1-Q50) Logical Product Core Variables
(V1-V50)
Study A Topical Module Health Status Data
Collection ADD Questions (Q51A-Q80A) Logical
Product ADD Variables (V51A-V80A)
Study B Topical Module Gun Control Data
Collection ADD Questions (Q51B-Q80B) Logical
Product ADD Variables (V51B-V80B)
etc
126
Formal Groups Inheritance

• Example 3 Any group by design some questions
  are not asked in some iterations.

Group (Studies A-E) Data Collection All
Questions (Q1-Q100) Logical Product All
Variables (V1-V100)
Group (Studies C-E) Data Collection DELETE
Questions Q60-Q69 Logical Product DELETE
Variables V60-V69
Study B Data Collection DELETE Question
Q55 Logical Product DELETE Variable V55
Study A
Study C
Study D
Study E
127
Formal Groups Inheritance

• Example 4 (SOEP, Germany) Longitudinal Same
  variables, with different name each year.

(No name)
ADD Name only
128
Formal Groups Inheritance

• Example 5 (SOEP, Germany) Longitudinal In 2002
  variable Income changes currency from DM to
  Euro change in question wording.

(No question)
ADD question only
129
Formal Groups Inheritance

• Example 5 (SOEP, Germany) continued These
  variables also change names every year

130
Formal Groups Inheritance

• Example 5 (SOEP, Germany) the final picture
  information is inherited down the hierarchy.

131
Inheritance in Formal Groups

• Simplification of DDI Instances common metadata
  is only entered once.
• More efficient means of documentation for new
  additions, only differences need to be specified.
• Relational information embedded in the
  inheritance structure comparison becomes
  machine-actionable.

132
DDI Version 3.0 Modules-- Structural Overview --
DDI Instance
Study Unit
Group
Conceptual Component
Conceptual Component
Data Collection
Data Collection
Logical Product
Logical Product
Physical Data Product
Archive
Physical Instance
Comparative
Archive
Study Unit
Group
Organizations
133
Comparative -- documents comparability in ad-hoc
groups --

• Identification, Note(s)
• Comparison Description (human-readable)
• Concept Map
• Source Scheme Reference
• Target Scheme Reference
• Item Map
• Source Item
• Target Item
• Map Type
• Difference
• Variable Map
• Question Map
• Category Map
• Code Map
• Universe Map

134
DDI 3.0 Using the Comparative Module

• Instructions on how to use the Comparative
  Module and build comparison maps
• DDI 3.0 User Guide, pp. 45-49.
• http//www.ddialliance.org/D
  DI/ddi3

135
Producing DDI 3.0 markup

• Getting started

136
DDI 3.0 Tools projects

• DDI Toolkit
• Core library for developing open source tools
• Version 1/2 lt-gt Version 3.0 converters
• DDI 3.0 URN resolution tool
• DDI 3.0 validation tool
• Version 3.0 stylesheets with display and editing
  layers
• Grouping tool
• Concept management tool
• Registry applications

137
Producing DDI 3.0 markup-- Getting started --

• Software to assist in document creation
• DeXtris
• XML browser
• Converts DDI 1/2 to DDI 3.0
• http//www.opendatafoundation.org/tools/dextris

138
DDI 3.0 Tools Using Dextris
139
DDI 3.0 Tools Using Dextris
140
DDI 3.0 Tools Using Dextris
141
DDI 3.0 Tools Using Dextris
142
DDI 3.0 Tools Using Dextris
143
DDI 3.0 Tools Using Dextris
144
DDI 3.0 Tools Using Dextris
145
DDI 3.0 Tools Using Dextris
146
DDI 3.0 Tools Using Dextris
147
Producing DDI 3.0 markup-- Getting started --

• Software to assist in document creation
• SPSS system to DDI 3.0 converter
• (See description and link on DDI 3.0 Proof of
  Concept page)
• http//www.ddialliance.org/DDI/ddi3/proof
  .html

148
Producing DDI 3.0 markup-- Getting started --

• XML editors
• oXygen
• Create new DDI instance
• Edit/update DDI instance
• Validate DDI instance
• View schemas

149
DDI 3.0 Viewing Schemas in oXygen
150
DDI 3.0 Viewing Schemas in oXygen
151
Producing DDI 3.0 markup-- Getting started --

• Other tools to assist in producing DDI 3.0
  markup
• DDI core template
• Version 3.0 documentation
• Module descriptions
• Field level documentation
• DDI Help Center
• http//www.ddialliance.org/ddi3/index.html

152
Producing DDI 3.0 markup -- Using multiple
modules --

• Resource
• Getting Started with DDI 3.0
• http//www.ddialliance.org/DDI/ddi3/gett
  ing-started.html

153
DDI Version 3.0Displaying Markup

• Stylesheets
• Basic
• Web presentation in XHTML
• Enhanced
• Adds graphics for presenting frequencies
• Automated calculation of valid percentages
• http//www.ddialliance.org/DDI/ddi3/proof.html

154
DDI Version 3.0Questions? Comments?

• Sanda Ionescu sandai_at_umich.edu
• DDI Users Listserv
• ddi-users_at_icpsr.umich.edu
• http//www.ddialliance.org/codebook/listserv.html


155
The End
