Functional design of Domain Tool

1
Functional design of Domain Tool

• UCL e2e monitoring workshop
• May 15th, 2003
• Victor Reijs
• victor.reijs_at_heanet.ie

2
Outline

• Co-operation environment...
• Environment of Domain Tool...
• Functions...
• Interfaces...
• Issues...

3
Co-operation environment

• I2 4 years ago talk on e2e problem
• NLM-HEAnet and VidiNet Chariot
• TF-NGN
• PERT
• Performance infrastructure
• NIMI
• GGF/OGSA
• E2E piPEs
• Monalisa, others?

4
Outline

• Co-operation environment...
• Environment of Domain Tool...
• Functions...
• Interfaces...
• Issues...

5
Environment of Domain Tool

• man
• machine
• developer
• administrator

User representation
Access interface
Domain Tool...
Inter-domain interface
Other Domain Tools
MP interface
Un-Instrumented networks
MP
Instrumented networks
6
Domain Tool block
Access interface
Inter-domain interface
Domain specific block...
API interface
Analyses aggregation
Driver interface
MP driver
MP specific block
Domain Tool
MP interface
7
Domain Specific block
Access interface
Inter-domain interface
Communication
AAA
Scheduler
Pathfinder
Aggregation
DBMS
Administration
Data analyses
Domain specific
API interface
8
Outline

• Co-operation environment...
• Environment of Domain Tool...
• Functions...
• Interfaces...
• Issues...

9
Functions

• Administration
• Communication
• AAA
• Scheduler
• Pathfinder...
• DBMS
• Aggregation
• Data Analysis

10
Administration

• knows what Domain Tool can do
• knows about the feature set of connected MPs
• keeps track of test functionalities available
  NMWG
• keeps track of other Domain Tools (JINI?)
• keeps track of users and AAA
• keeps track of aggregation functions
• keeps domain policies

11
Communication

• does communication to other Domain Tools
• schedules communication paths inside Domain Tool
• NIMI

12
Scheduler

• accepts information requests
• asks for path (using Pathfinder)
• does resource management of Domain Tool and MPs
• determines if test is needed (could be in
  Database)
• uses AAA towards MP specific block
• does test management (start, stop, abort, etc.)
• provides database exceptions/error information
• E2E piPEs

13
Pathfinder

• determines MPs in the e2e path
• determines the IP path
• for own domain finds MPs on path
• determines neighbor Domain Tool
• un-instrumented domain exists

14
DataBase Management System

• has (distributed) Domain Database
• knows if MPs have Local Database(s)
• uses AAA
• determines if data is available Test Arbiter
• OGSA

15
Aggregation

• has domain specific aggregation functions...
• aggregates test results for domain
• provides aggregated results
• provides aggregated exceptions/error information

16
Aggregation functions

• Statistical functions
• mean, percentile, standard deviation, etc. NMWG
• adding averages, concatenation, etc.

17
Data Analyses

• knows how to analyze the test results of MPs
• uses MP specific aggregation functions...
• anonymizes data
• provides MP results
• provides MP exceptions/error information
• test engine, E2E piPEs?

18
Outline

• Co-operation environment...
• Environment of Domain Tool...
• Functions...
• Interfaces...
• Issues...

19
Interfaces

• Access interface (XML, SOAP)
• user (man or machine)
• domain administrator
• MP developer
• Inter-domain interface (XML)
• Driver interface
• MP interface PMP, E2EpiPEs? (proprietary)
• API interface (XML?)
• data analyses
• aggregation functions

20
Outline

• Co-operation environment...
• Environment of Domain Tool...
• Functions...
• Interfaces...
• Issues...

21
Issues

• Chaining and/or referral (resilience)?
• Data and AAA
• 3 levels multi-domain, domain, MP
• Aggregation, Data Analyses, Scheduler
• Agree common/defined naming
• Work together!

22
Contact info

• Part of TF-NGN (TERENA/DANTE)
• Performance monitoring infrastucturehttp//www.da
  nte.net/tf-ngn/perfmonit/Nicolas Simas
  Nicolas.Simar_at_dante.org.uk
• PERThttp//www.dante.net/tf-ngn/pert/Victor
  Reijs victor.reijs_at_heanet.ie

23
