Incremental Integration of Probabilistic Models Learned from Data

1
Incremental Integration of Probabilistic Models
Learned from Data

• Jian Xu (Louisiana State U)
• Pedrito Maynard-Zhang (Amazon.com)
• Jianhua Chen (Louisiana State U)

2
Outline

• Incremental integration problem
• Existing batch integration approach
• BN incremental integration
• Pros, cons, and experiments
• BN subtraction
• Conclusion and future work

3
Motivating Scenario
Symptoms, history, and test results
Expert k knowledge en route
Integrated model for diagnosis

Expert j knowledge arrived at time tj
Doctors own knowledge in this domain
Represented as probability models that are
learned from data

Expert i knowledge arrived at time ti
4
Incremental Integration Problem
integration algorithm
t1
learning algorithm
BN1
t2
BN2
learning algorithm

tn

aggregateBN
BNn

learning algorithm
?
learningalgorithm
optimalBN
M samples generated from the true BN
not possible in practice
5
Outline

• Incremental integration problem
• Existing batch integration approach
• BN incremental integration
• Pros, cons, and experiments
• BN subtraction
• Conclusion and future work

6
MC Batch Integration

• Maynard-ReidChajewska01 shows that if sources
  learn joints using MLE, then LinOP is the correct
  integration algorithm where the weights are
  percentage of data seen.
• For BN integration, they adapt the MDL learning
  algorithm
• Use LinOP to approximate the needed statistics
  since data is unavailable
• Use the estimated fraction of data expert i saw
  as the weight ai

7
MC Batch Integration Algorithm

• Select a BN most likely to have generated data
  using MDL and LinOP
• Search over structures by adding, deleting, and
  reversing edges
• Score using LinOP-based MDL
• Parameterize using LinOP
• Use random restart to avoid getting stuck in a
  local maximum

8
Outline

• Incremental integration problem
• Existing batch integration approach
• BN incremental integration
• Pros, cons, and experiments
• BN subtraction
• Conclusion and future work

9
Batch-Based Strawman 1

• Algorithm
• Wait for all models to arrive
• Apply batch algorithm
• Drawbacks
• Must store all models
• Can do nothing while waiting for models
• May not be able to tell when all models have
  arrived
• Models may never stop arriving (e.g., periodic
  reports)

10
Batch-Based Strawman 2

• Algorithm
• Store each model that arrives
• Apply batch algorithm to all stored models after
  each new arrival
• Drawbacks
• Must store all models
• Roughly O(i) time to add the ith model, and O(n2)
  total for n models

11
Incremental Integration Algorithm

• Integrate the first group of sources to arrive.
  Consider this intermediate result to be an
  aggregate source BN
• Assign new weight to aggregate source by making
  the number of samples it has seen the sum of
  the number of samples that all involved sources
  have seen
• When new BNs come, integrate them with the
  current aggregate BN

12
Source Definition

• Tuple ltp, M, , essgt where
• p BN representing sources beliefs
• M number of samples distribution is based on
• , ess parameters defining prior over space of
  distributions
• prior over the sample space
• ess number of "virtual" samples distribution
  space prior is based on

13
Incremental Integration Algorithm

• 1. DM ? ltpD, 0, pD, essDgt
• 2. loop
• (a) wait until a new group g of sources Sg
  S1, , Skg arrive with associated weights and
  cumulative estimated sample size M.
• (b) DM ? lt pD, MD, pD, essD gt where
• pD ? the integration of pD and Sg using the
  batch integration algorithm and MD/(MDM) as the
  aggregated sources weight, and
• MD ? MD M.
• 3. until no new sources arrive
• 4. return DM.

g
g

14
Justification

• We show algorithm is order-independent when
  applied to joint distributions
• Order-independence property holds approximately
  for BNs
• Approximation due to generalization and greedy
  optimization search

15
Outline

• Incremental integration problem
• Existing batch integration approach
• BN incremental integration
• Pros, cons and experiments
• BN subtraction
• Conclusion and future work

16
Structure of Asia BN
Visit to Asia
Smoking
Lung Cancer
Tuberculosis
Bronchitis
Abnormality in Chest
Dyspnea
X-Ray
17
Pro Performance

• Anytime response
• Most up-to-date aggregate model always available
• Efficient integration
• Typically, fewer sources involved in each
  iteration
• Total integration time is O(n) for n sources
• Idle time utilization
• Can take advantage of wait times to do
  integration, reducing the total wall-clock time
  for integration
• Space saving
• Space only required for the current aggregate
  model and arriving sources

18
Time Comparison
Comparing total integration time of incremental
and batch integration algorithms as the number of
sources increases from 1 to 15 for fixed source
sizes of 201000
19
Pro Accuracy

• Incremental integration accuracy relatively close
  to batch integration accuracy
• Difference introduced by local optima in search
  space
• Difference generally decreases with larger source
  size

20
Accuracy Comparison
Comparing incremental, batch, and source accuracy
over time when incrementally combining sources of
size 50
21
Con Bias Inertia

• Bias introduced via local optima in search space
• Inertia incoming sources with small weights
  unable to change aggregate significantly after a
  point
• Inertia cut both ways bias in aggregate can be
  countered and held at bay by accurate sources
  with relatively large weights

22
Bias Inertia
Effect of a highly weighted, inaccurate source
arriving early third among 10 lower weight,
higher accuracy sources
23
Con Sensitivity to Order

• Different source orderings can result in markedly
  different results, even for same-size or
  same-weight sources
• The accuracy of the sources also matters less
  accurate sources can introduce bias which is then
  subject to the inertia effect
• Source ordering-bias tradeoff
• If bad sources arrive early, bias they introduce
  easier to undo, but bias also easier to introduce
  in the first place
• If bad sources arrive late, they are less likely
  to introduce bias, but bias more difficult to
  undo once introduced

24
Outline

• Incremental integration problem
• Existing batch integration approach
• BN incremental integration
• Pros, cons and experiments
• BN subtraction
• Conclusion and future work

25
BN Subtraction

• Scenarios
• Incorporating updates
• De-duplicating shared BNs
• Algorithm Incremental integration algorithm, but
  use negative weights for BNs to remove

26
Outline

• Incremental integration problem
• Existing batch integration approach
• BN incremental integration
• Pros, cons and experiments
• BN subtraction
• Conclusion and future work

27
Conclusion

• Incremental algorithm supports anytime
  querying, utilizes idle time, and saves space
• The result of incremental integration of joint
  distributions is independent of the source order
• Experiments show BN integration result depends on
  source order to a degree mainly due to bias
  introduced by greedy optimization and maintained
  by an inertial effect
• Reduction of accuracy of incremental algorithm
  may be acceptable

28
Future Work

• Optimally grouping sources to minimize the total
  integration time (we only explored the extreme of
  integrating one source at a time)
• Reducing high computation cost due to the heavy
  reliance on BN inference
• seek faster inference algorithm, e.g.,
  approximate
• organize the sources into hierarchical
  integration tree, which allows parallel,
  distributed integration
• Subtraction experiments
• Detecting shared sources

29
Acknowledgment

• Work partially supported by
• NSF grant ITR-0326387
• AFOSR grants FA9550-05-1-0454, F49620-03-1-0238,
  F49620-03-1-0239, and F49620-03-1-0241

30
Thank you!
