The Nonlinear Patterns of North American Winter Climate associated with ENSO

1

• The Nonlinear Patterns of North American Winter
  Climate associated with ENSO
• Aiming Wu, William Hsieh
• University of British Columbia
• Amir Shabbar
• Environment Canada

2
ENSO El Niño Southern Oscillation
El Niño
La Niña
3
Atmos. Response to ENSO is nonlinear
Composite of Z500 and tropical precipitation
during El Niño (A) and La Niña (B) (from
Hoerling et al 1997 J. of Climate)

-

A

-

• La Niña El Niño
• Sign reversed
• Shifted eastward by 30-40(asymmetric)

B
-
4
Nonlinear Temperature Response to ENSO
-


Hoerling et al 1997 J. of Climate
5
Winter Precipitation Variability (Nov-Mar)
6
The Three Leading EOFs of SAT and Prcp
7
Objective of the Study

• If x is the ENSO index, how do we derive the
  atmos. response y ƒ(x) ?
• linear regression (or projection)
• y a x

x
x
-
-


-

• Linear method cannot extract asymmetric patterns
  between x and x
• Need a nonlinear method

8
Nonlinear projection via Neural Networks (NN
projection)

• x, the ENSO index
• h, hidden layer
• y, output, the atmos. response

A schematic diagram
Cost function J y y is minimized to
get optimal Wx, bx, Wh and bh (y is the
observation)
9
Data

• ENSO index (x)
• 1st principal component (PC) of the tropical
  Pacific SSTA
• Nov.-Mar.
• 1950-2001,monthly
• SST data from ERSST-v2 (NOAA)
• Linear detrend
• standardized

• Atmos. Fields (y)
• surface air temp. (SAT) and precip.(PRCP)
• From CRU-UEA (UK)
• Monthly,19502001, 1??1?
• Nov.-Mar. North America
• Anomalies (1950-01 Clim)
• Linear detrend
• PRCP standardized
• Condensed by PCA
• 10 SAT PCs (90) retained
• 12 PRCP PCs (60)

10
Significance by Bootstrap

• A single NN model may not be stable (or robust)
• Bootstrap randomly select one winters data 52
  times from the 52-yr data (with replacement) ?
  one bootstrap sample
• Repeat 400 times ? train 400 NN models ? average
  of the 400 models as the final solution

400 NN models
Given an x ? NN model ? y ? (combined with EOFs)
? atmosphere anomaly pattern associated with x
11
NN projecton in the SAT PC1-PC2-PC3 space

• Green 3-D
• Blue projected on 2-D PC plane
• C extreme cold state W extreme warm state
• Straight line linear proj.
• Dots data points

12
SAT anomalies

• as ENSO index takes on its
• (a) min.
• (d) max.
• (b) 1/2 min.
• (e) 1/2 max.
• (c) a-2?b
• (f) d-2?e
• Darker color ? above 5 significance

13
PCA on Lin. Nonlin. Parts of NN projection
NL NN LR
Linear regression
27
73
14
SAT and SLP Linear and Nonlinear Projections
15

• PC1 of Lin. part vs. ENSO index ? a straight
  line
• PC1 of Nonlin. part vs. ENSO index ? a quadratic
  curve
• ?A quadratic response

16
A polynomial fit
?1 , ?2 are x, x2 normalized, x is the ENSO
index
SAT
17
PRCP anomalies

• as ENSO index takes on its
• (a) min.
• (d) max.
• (b) 1/2 min.
• (e) 1/2 max.
• (c) a-2?b
• (f) d-2?e
• Darker color ? above 5 significance

18
Lin. nonlin. prcp. response to ENSO
LR NL NN
78
22
19
Prcp and SLP Linear and Nonlinear Projections
20
Lin. nonlin. prcp. PC1 vs. ENSO index
21
(No Transcript)
22
Forecast Skill in Linear and Nonlinear Models
?1 , ?2 are x, x2 normalized, x is the ENSO
index
23

• Summary and Conclusion
• N. American winter climate responds to ENSO in a
  nonlinear fashion (exhibited by asymmetric SAT
  and PRCP patterns during extreme El Niño and La
  Niña events).
• The nonlinear response can be successfully
  extracted by the nonlinear projection via neural
  networks (NN).
• NN projection consists of a linear part and a
  nonlinear part. The nonlinear part is mainly a
  quadratic response to the ENSO SSTA, accounting
  for 1/41/3 as much as the variance of the linear
  part.

24
