DATA MINING

1
DATA MINING

• Patrick J. Gallagher
• March 21, 2006

2
What is Data Mining?
3
DEFININTION

• The automated extraction of hidden predictive
  information from (large) databases.

4
DATA MINING TECHNIQUES

• CLASSICAL
• 1. Statistics
• 2. Nearest Neighborhoods 3. Clustering
• NEXT GENERATION
• 1. Decision Trees
• 2. Neural Networks
• 3. Rule Induction

5
THE CLASSICS

• Techniques discussed will be those that have been
  used for decades
• They have also used almost all of the time on
  existing business problems

6
1. STATISTICSWHAT IS IT
7
STATISTICS branch of mathematics concerning the
collection and the description of data
8

• Born of real world problems from business,
  biology and gambling
• Knowing statistics helps the average business
  person make better decisions by allowing them to
  figure out risk and uncertainty when all facts
  either arent known or can be collected
• Has been around for a long, long time (easily a
  century)

9
HISTOGRAMSSTATISTICAL SUMMARIZATION
10
Database Information
ID NAME Prediction Age Balance Income Eyes Gender
1 Amy NO 62 0 Medium Brown F
2 Al NO 53 1,800 Medium Green M
3 Betty NO 47 16,543 High Brown F
4 Bob YES 32 45 Medium Green M
5 Carla YES 21 2,300 High Blue F
6 Carl NO 27 5,400 High Brown M
7 Donna YES 50 165 Low Blue F
8 Don YES 46 0 High Blue M
9 Edna YES 27 500 Low Blue F
10 Ed NO 68 1,200 Low Blue M
11
This histogram shows the number of customers with
various eye colors. As you can see, the
histogram can show important information about
the database.
12
WHAT QUESTIONS CAN STATISTICS ANSWER?
13

• What patterns are there in my database?
• What is the chance that an event will occur?
• What patterns are significant?
• What is a high level summary of the data that
  gives me some idea of what is contained in my
  database

14
NOT ALL HISTOGRAMS ARE THIS SIMPLE
15
Complex histograms provide more information
(Predictors)
16
SUMMARY STATISTICS

• Max - max value of predictor
• Min - minimum value of predictor
• Mean - average value of predictor
• Median - value for a given predictor that divides
  the database as nearly as possible into two
  databases of equal number of records.
• Mode common value for the predictor
• Variance measure of how spread out the values
  are from the average value

17
STATISTICS FOR PREDICTIONPrediction ?

• A Regression
• B Simulation
• C Decision

18
PREDICTION REGRESIONA
19
LINEAR REGRESSION

• One predictor and a prediction. The relationship
  between the two can be mapped on a two
  dimensional space and the records plotted for the
  prediction values along the Y axis and the
  predictor values along the X axis
• Seeks to build a predictive model that is a line
  that maps between each predictor value to a
  prediction value.

20
Sample Linear Regression Predictive Model

• The line will take a given value for a predictor
  and map it into a given value for a prediction
• Equation is Predictionabpredictor
• Trick with predictive modeling is to find the
  model that best minimizes the error

21
2. NEAREST NEIGHBORWhat does it mean?
22
Nearest Neighbor

• In order to predict what a prediction value is in
  one record look for records with similar
  predictor values in the historical database and
  use the prediction value from the record that it
  nearest to the unclassified record

23
NEAREST NEIGHBOR EXAMPLE ?
24
EXAMPLE

• Determining that people in your
• neighborhood have an income of over
• 100,000 per year
• NEAREST NEIGHBOR ASSUMES
• Your income is also over 100,000

25

• Prediction for a prediction value in one record
  is determined by looking for similar predictor
  values in the historical database and use the
  prediction value from the record that is nearest
  to the unclassified record
• (ex salaries of people in your neighborhood)
• The techniques are among the easiest to use and
  understand because the techniques work similar to
  the ways a person thinks
• Are among the oldest techniques used in data
  mining.

26
NEAREST NEIGHBORPREDICTION TECHNIQUEUSES

• Business
• Stock Market Data

27
PREDICTIONIN NEAREST NEIGHBOR MEANS

• Objects that are NEAR to each other will have
  similar prediction values as well.
• Thus if you know the prediction value of one of
  the objects you can predict it for its nearest
  neighbor.

28
BUSINESS

• Text Retrieval This particular technique is used
  to find other documents that share important
  characteristics with those documents that have
  been marked as interesting.

29
STOCK MARKET DATA

• The input data is just a long series of stock
  prices over time without any particular record
  that could be considered to be an object.
• Example
• Predictor Values
• 10 12 14 15 10 13 11 14 15
• Prediction Value
• 11 (10th number)

30
3. CLUSTERINGWhat does it mean?
31
CLUSTERING

• Clustering is a method which like records are
  grouped together in order to give the end user a
  high level view of what is going on in the data
  base and business.

32
CLUSTERINGIn the real world

• Two clustering systems are the PRIZM system from
  Claritias Corporation and MicroVision from
  Equifax Corporation. These companies have
  grouped the population by demographic information
  into segments that they believe are useful direct
  marketing and sales.

33
NAME INCOME AGE EDUCATION VENDOR
Blue Blood Estates Wealthy 35-54 College Claritas Prism
Shot Gun and Pickups Middle 35-64 High School Claritas Prism
Southside City Poor Mix Grade School Claritas Prism
Living Off the Land Middle Poor School Age Families Low Equifax MicroVision
University USA Very Low Young- Mix Medium - High Equifax MicroVision
Sunset Years Medium Seniors Medium Equifax MicroVision
34
CLUSTERING VS NEAREST NEIGHBOR

• Nearest Neighbor
• Used for prediction as well as consolidation
• Space is defined by the problem to be solved.
  (Supervised learning technique)
• Generally only uses distance metrics to determine
  nearness.

• Clustering
• Used mostly for consolidating data into a
  high-level view and general grouping of records
  into like behaviors.
• Space is defined as default n-dimensional space,
  or is defined by the user or is a predefined
  space driven by past experience. (Unsupervised
  learning technique)
• Can use other metrics besides distance to
  determine nearest of two records for example
  linking two points together.

35
What are the two main types of Clustering
techniques?
36

• HIERARCHICAL
• NON-HIERARCHICAL
• CLUSTERING

37
HIERARCHYofCLUSTERS
38
NON- HIERARCHIAL CLUSTERING

• 1. Single Pass Methods
• 2. Reallocation Methods

39
Hierarchical Clustering

• It is created by starting either at the top and
  subdividing (dividing clustering) or starting at
  the bottom with as many clusters as there are
  records and merging (agglomerative clustering).
• Has advantage over non-hierarchical in that the
  clusters are solely by the data and that the
  number of clusters can be increased or decreased
  by simply moving up and down the hierarchy.

40
NEXT GENERATION

• Represent the most often used techniques that
  have been developed over the past two decades of
  research.
• It can be used for either discovering new
  information within large databases or for
  building predictive models.

41
NEXT GENERATION

• 1. DECISION TREES
• 2. NEURAL NETWORK
• 3. RULE INDUCTION

42
DECISION TREESWhat are they ?
43
DECISION TREES

• A predictive model that, as its name implies, can
  be viewed as a tree. Specifically, each branch
  of the tree is a classification question and the
  leaves of the tree are partitions of the dataset
  with their classification

44
DECISION TREE EXAMPLE
45
DECISION TREE HISITORY

• Similar technologies have been around for almost
  20 years and early versions of the algorithms
  date back in the 1960s
• Originally, these techniques were developed for
  statisticians to automate the process of
  determining which fields in their database were
  actually useful or correlated with the particular
  problem that they were trying to understand.

46
DECISION TREE USES

• EXPLORATION looks at predictors and values that
  are chosen for each split of the tree. Often
  times, these predictors provide usable insights
  or propose questions that need to be answered.
• DATA PREPROCESSING can be used on the first
  pass of data mining to create a subset of useful
  predictors that can be used in neural networks,
  nearest neighbor and normal statistical routines.
• PREDICTION used as a by product by
  statisticians because decision trees are used for
  exploratory analysis.

47
DECISION TREE ALGORITHMS

• ID3
• CART
• CHAID

48
ID3

• Developed in late 1970s by J. Ross Quinlan
• First Decision Tree algorithm
• Based on previous inference systems and concept
  learning systems from decades preceding.
• Initial used for game playing strategies for
  chess games.
• Picks predictors and splitting values based on
  gain and information that the split/s provide.
• The difference between the entropy of the
  original segment and the accumulated entropies of
  the resulting split segments.

49
ID3 to C4.5 ENHANCEMENTS

• Predictors with missing values can still be used.
• Predictors with continuous values can be used.
• Pruning is introduced
• Rule derivation

50
CART

• Stands for Classification and Regression Trees
• Data exploration and prediction algorithm
  developed by Leo Breiman, Jerome Friedman,
  Richard Olshen and Charles Stone.
• Each predictor is picked on how well it teases
  apart the records with different predictions.

51
CHAID

• Stands for Chi Square Automatic Interaction
  Detector
• Similar to CART
• It builds a decision tree
• Different from CART
• In the way it chooses its splits.

52
2. NEURAL NETWORKSWhat is it?
53
NEURAL NETWORK

• Computer programs implementing sophisticated
  pattern detection and machine learning algorithms
  on a computer to build predictive models from
  large historical databases.

54

• Artificial neural networks derive their name from
  their historical development which started off
  with the premise that machines could be made to
  think if scientists found ways to mimic the
  structure and functioning of the human brain on
  the computer.
• Greatest breakthroughs in neural networks in
  recent years have been in there application to
  more mundane real world problems like customer
  response prediction or fraud detection.
• They technically are considered to learn and
  make better predictions by detecting patterns
  using analogies in similar ways that humans do.

55
NEURAL NETWORKUSES

• Clustering
• Outlier Analysis
• Example Wine Distributor
• Wine distributor store stands out as making
  significantly lower profit. Upon further
  examination the distributor was delivering
  product but not collecting payment.
• Feature Extraction

56
Neural Networks(Components)

• Node- corresponds to the neuron in the human
  brain.
• Link- it corresponds to the connections between
  neurons.

57
NEURAL NETWORKSample
58
NEURAL NETWORKTYPES

• Back Propagation- refers to the propagation of
  the error backwards from the output nodes through
  the hidden layers and to the input layer.
• Kohonen Feature Maps- developed in the 1970s and
  are feed forward Neural Network generally with no
  hidden layer.
• - Used for unsupervised learning and clustering.
• Radial Basic Function represent a hybrid
  between nearest neighbor and neural network
  classification.
• - Used for supervised and learning

59
3. RULE INDUCTIONWhat is it?
60
RULE INDUCTION

• Is one of the major forms of data mining
• and the most common form of knowledge
• discovery in unsupervised learning systems.
• It mines for a rule that is interesting.

61

• It is a massive undertaking were all possible
  patterns are systematically pulled out of the
  data and then an accuracy and significance are
  added to them that tell the user how strong the
  pattern is and how likely it is to occur again.
• Rule induction systems are highly automated and
  are probably the best of data mining techniques
  for exposing all possible predictive patterns in
  a database

62
Neural NetworkVSRule Induction

• NEURAL NETWORKS
• Extremely proficient and saying exactly what must
  be done in a predictive task with little
  explanation.
• Example- Who do I give
• credit to and who do I
• deny credit to.

• RULE INDUCTION
• When used for prediction, they are like having a
  committee of trusted advisors each with a
  slightly different opinion as to what to do but
  relatively well grounded reasoning and a good
  explanation for why it should be done.

63
What is a RULE?

• if this and this and this then this.
• EXAMPLES
• - If paper plates then plastic forks.
• - If dip then potato chips.

64
Presenter

• Dr. Balaji Padmanabhan
• Assistant Professor of Operations and Information
  Management
• The Wharton School, University of Pennsylvania
• Teaches
• Enabling (Information) Technologies
• Data Mining / Decision Support Systems
• Introduction to the Computer as an Analysis Tool
