Title: Aquifer%20Test%20Analysis%20Carter%20Lake,%20Iowa


1
Aquifer Test AnalysisCarter Lake, Iowa
  • Luca DeAngelis, P.E., P.G.
  • Hydrologist
  • Layne Western

2
Introduction
  • The community of Carter Lake plans to pump
    groundwater from an alluvial aquifer to maintain
    a desired level of a lake near Kiwanis Park.
  • Layne Christensen Company (Layne) was retained by
    Carter Lake to estimate percentage of water from
    current production well that is obtained from
    induced infiltration from lake.
  • Objective
  • Estimate distance from lake for future wells that
    will be least affected by infiltration from the
    lake

3
Outline
  • General Carter Lake Water Balance
  • Layne Activities
  • Conclusions

4
Water Balance
Streamflow (Qi)
Equation Form
5
Water Balance
  • Inflows
  • Stream flow into lake 0
  • Mean annual precipitation 31 inches (precip
    onto lake)
  • Runoff Drains an area of 1,930 acres
  • Groundwater flux into ?
  • Outflows
  • Groundwater flux out ?
  • Lake evaporation 40 inches per year
  • Overall balance
  • Runoff function of precip USGS (5 in/year)
  • Groundwater flux -220 acre feet (72 million
    gallons)
  • Loss to lake evap -1,082 acre feet (300
    million gallons)
  • from USACE 84 - 85 study
  • USGS publication (1951-1980 data)

6
Layne Field Activities
  • Rehabilitation of the existing production well.
  • Installation of three (3), two (2) inch diameter
    observation wells.
  • Implementation of a seven (7) day aquifer test.

7
Aerial photograph Carter Lake, Iowa showing
Carter lake and location of production well.
8
Aerial photograph of Carter lake indicating wells
9
Site Geology
  • 0 7 feet Silty clay
  • 7 15 feet Fine sand
  • 15 20 feet Blue clay
  • 20 43 feet Fine sand
  • 43 58 feet Gravel and coarse sand
  • 58 60 feet Blue clay (confining unit)
  • 60 93 feet Fine to coarse sand, with some
    small gravel
  • 93 feet Bedrock (Limestone).
  •
  • Depth to water was measured in the test well and
    the observation wells at approximately 15 feet
    below ground surface (bgs). Depth to water was
    consistent thought the Site.

10
Pump Test
  • Pump Well 82-1 at rate of 1,070 gpm
  • Pumped continuously for 7 days
  • Monitored water levels in wells (pump and
    observation)
  • Used pressure transducers and manual measurements

11
Analytical Methods
  • Cooper-Jacob (1946) distance drawdown/time
    drawdown method. This method is applicable for
    confined or unconfined aquifers and was developed
    with the following assumptions
  • The aquifer is confined
  • The aquifer has a seemingly infinite areal
    extent
  • The aquifer is homogeneous, isotropic, and of
    uniform thickness over the area influenced by the
    test
  • Prior to pumping, the potentiometric surface of
    the aquifer is nearly horizontal
  • The aquifer is pumped at a constant discharge
    rate
  • The well penetrates the entire thickness of the
    aquifer and receives water by horizontal flow
    and
  • Drawdown data is corrected for the dewatering of
    the aquifer (unconfined systems only).

12
Plot of Observation Well OW50
13
Constant Rate Example
14
Drawdown Response in Observation Wells(Lin-Log
Scale)
15
Aquifer Test Analysis Results
  • Pumping rate 1,070 gallons per minute
  • Transmissivity 21,500 square feet per day
  • Hydraulic conductivity 715 feet per day
  • Storativity coefficient .001
  • Distance to source of recharge 400 feet
  • Percentage of water derived from
  • source of recharge 45 percent

16
Aerial photograph of Carter lake indicating wells
and calculated recharge boundary.
17
Conclusions
  • Using USACE numbers lake needs to add 400
    million gallons per year of water to maintain
    level (runoff or supplemental pumping)
  • Existing production well estimated to be at 400
    feet from a source of recharge boundary (lake).
  • Current pumping at existing production well
    results in induced infiltration from lake of 45
  • New wells should be located further south of
    existing well at a greater distance from lake to
    reduce infiltration of lake water resulting in
    increased recharge of lake.
  • 200 feet south Induced infiltration 30
  • 400 feet south Induced infiltration 15

18
QUESTIONS?
