Ubiquitous Home: Retrieval of Experiences in a Home Environment

1
Ubiquitous Home Retrieval of Experiences in a
Home Environment

• Gamhewage C. DE SILVA
• Toshihiko YAMASAKI
• Kiyoharu AIZAWA

2
Outline

• Introduction
• Ubiquitous Home
• Sensors and Data Acquisition
• Data Collection
• Retrieval
• Footstep segmentation, Video and Audio Handover
• Key frame Extraction, Audio Segmentation
• User Interaction
• User Study
• Discussion
• Future Work

3
Introduction
4
Introduction

• Automated capture of experience taking place at
  home is interesting.
• Ex. first footstep of a child
• Something is so important that people have a
  strong desire to include themselves in the
  experience, rather than carry a camera and shoot
  photos.

5
Introduction

• Capture and retrieval of experience in a home
  like environment is extremely difficult.
• Large number of cameras and microphones
• Continuous recording of data result in a very
  large amount of data
• Level of privacy
• Most difficult
• Retrieval and summarization of captured data
• Queries for retrieval could be at vary different
  levels of complexity

6
Introduction

• Multimedia retrieval for ubiquitous environments
  based solely in content analysis is neither
  efficient nor accurate
• Make use of supplementary data from other sensors
  for easier retrievalex. Proximity sensor, domain
  knowledge

7
Introduction

• The research combines two main areas
• Ubiquitous Environment
• Multimedia Retrieval

8
Ubiquitous Environment

• Providing services to the people in the
  environment by detecting and recognizing their
  actions.
• Storing and retrieval of media, in different
  levels from photos to experiences

9
Multimedia Retrieval

• Common approach is content analysis
• The use of context data where available can
  improve the performance greatly

10
Main work on this article

• Capturing and retrieval of personal experiences
  in a ubiquitous environment that simulates a
  home.
• Create electronic chronicle for capturing video
  using interactive queries
• Main data Video and Audio
• Context data from pressure based floor sensors to
  achieve fast and effective retrieval and
  summarization of video and audio data.
• Audio analysis and segmentation are used to
  complement context based retrieval.

11
Ubiquitous Home
12
Ubiquitous Home

• Sensors and Data Acquision
• Data Collection

13
Sensors and Data Acquisition

• Layout of ubiquitous home.

14
Sensors and Data Acquisition

• Images are recorded at the rate of five frames
  per second and stored in JPEG file format.
• Audio is sampled at 44.1kHz from each microphone
  and record into audio clip in mp3 file format and
  the duration is 1 minute.
• The floor sensors are point-based pressure
  sensors spaced by 180mm in a rectangular grid.
  The sample rate is 6Hz.
• Start state0, pressure over a threshold state1

15
Data Collection

• Students experiment
• Acquiring training data for actions and events
• Audio data are not available during the
  experiment
• Real-life experiment
• No manual monitoring of video was performed
  during the experiment
• The processing and analysis were performed offline

16
Retrieval
17
Retrieval

• Footstep Segmentation
• Video Handover
• Audio Handover
• Key Frame Extraction
• Audio Segmentation for Retrieval

18
Retrieval

• Only a few data sources will convey useful
  information at any given time.
• Automatically select sources that will convey the
  most amount of information based on context data.
• Only the selected sources will be queried to
  retrieve data and these data will be analyzed
  further for retrieval.

19
Retrieval
20
Footstep Segmentation

• Noise
• When there are footsteps on adjacent sensors
  (very small duration)
• Relatively small weight such as a leg of a stool
  is placed in a sensor. (periodically)
• Kohonen Self Organizing Maps (SOM)

21
Footstep Segmentation

• 3-stage Agglomerative Hierarchical Clustering
  (AHC) algorithm is used to segment sensor
  activations into footstep sequences of different
  persons

22
Agglomerative Hierarchical Clustering algorithm

• First stage
• Combine to form single footsteps
• Distance function for clustering is based on
  connectedness and overlap of duration

23
Agglomerative Hierarchical Clustering algorithm

• Second stage
• Combine to form path sequences based on
  physiological constraints
• Ex. Range of distance between steps, overlap of
  duration in two steps, constraints on direction
  change

24
Agglomerative Hierarchical Clustering algorithm

• Third stage
• Compensate for the frgmentation of individual
  path due to the absence of sensors in some areas
• Starting and ending timestamp, locations of the
  doors and furniture and information about places
  where floor sensors are not installed

25
Agglomerative Hierarchical Clustering algorithm
26
Footstep Segmentation

• Errors
• Some paths are still fragmented after clustering
  in the third stage
• There are some cases of swapping in paths between
  two persons when they walk close to each other

27
Video Handover

• Select cameras in a way that a good video
  sequence can be constructed.
• Position-based handover
• Based on simple view model, where the viewable
  region for each camera is specified in terms of
  floor sensor coordinates.

28
Position-based handover

• Create a video sequence that has the minimum
  possible number of shots.
• If the person can be seen from the previous
  camera, then that camera is selected.
• Otherwise, the viewable regions for the cameras
  are examined in a predetermined order and the
  first match is selected.

29
Position-based handover
(1) The change of color of the arrow indicates
how the camera changes with the position of the
person. (2) It is possible to acquire a frontal
view due to the positioning and orientation of
cameras.
30
Audio Handover

• Dub the video sequences
• Not necessary to use all of them since a
  microphone can cover a larger region compared to
  a camera

31
Audio Handover

• Each camera is associated with one microphone for
  audio retrieval.
• Camera installed in a room
• From the microphone that is located in the center
  of that room
• Camera installed in the corridor
• From the microphone that is closet to the center
  of the region seen by that camera is selected

32
Audio Handover
(1) Minimize transitions between microphones (2)
Uniform amplitude level
33
Video Audio Handover
34
Key Frame Extraction

• The video sequence constructed using video
  handover has be sample to extract key frames.
• For complete and compact
• Minimize the number of redundant key frames while
  ensuring that important key frames are not missed

35
Key Frame Extraction
T is a constant time interval.
36
Key Frame Extraction

• Adaptive spatio-temporal sampling algorithm
• The time interval for sampling the next key frame
  is reduced with footstep, thereby sampling more
  key frames when there are more footsteps

37
Key Frame Extraction

• Evaluation
• The subjects extracted key frames form four video
  clips according to their own choice.
• Create average key frame sets which are used as
  ground truth for evaluation
• They voted for the key frame set that summarized
  the sequence best.

38
Key Frame Extraction
39
Key Frame Extraction
40
Audio Segmentation for Retrieval

• The floor sensors are unable to capture data when
  people are not treading on a floor area with
  sensors.
• They are not activated if the pressure on the
  sensors is not sufficiently large.
• Audio-based retrieval can also be conducted
  independently to support various types of queries.

41
Audio Segmentation for Retrieval

• The amount of audio to be processed is quite
  large.
• Tread-off
• Utilizing the redundancy to improve the accuracy
  of retrieval
• Minimizing processing by removing redundancy

42
Audio Segmentation for Retrieval

• Eliminate audio corresponding to silence.
• Compare the RMS power of the audio signal against
  a threshold value.
• RMS(Root Mean Square) is a statistical measure of
  the magnitude of a varying quantity.

43
Audio Segmentation for Retrieval

• Audio clips with one hour were extracted from
  different times of day.
• These clips were partitioned into frames having
  300 samples.
• Adjacent frames had a 50 overlap.
• The RMS value of each frame is calculated and
  recorded, and the statistics obtained for each
  clip.

44
Audio Segmentation for Retrieval

• Probabilistic distribution of the RMS values for
  different audio clips were not significantly
  different.
• Combine to a single probabilistic model for
  silence and noise

45
Audio Segmentation for Retrieval

• The threshold for each microphone is estimated by
  analyzing audio data for silence and noise for
  that microphone.
• Threshold value was selected to be at 99 level
  of confidence according to this distribution.
• Below 100 because false negatives(sound
  misclassified as silence) are more costly than
  false positives(silence misclassified as sound).

46
Silence Elimination

• First stage based on individual microphone
• If RMS value of each frame is large than the
  threshold, the frame is considered to contain
  sound.
• Sets of contiguous frames with duration less than
  0.1s are removed.
• Sets of contiguous frames with duration less than
  0.5s apart are combined together to form single
  segment.

47
Silence Elimination

• Second stage based on multiple microphones in
  close proximity to reduce false positives.
• For each microphone
• B(n) Binary sound segment function
• C(n) Cumulative sound segment function

48
Silence Elimination

• Binary sound segment function
• B(n) 1 if there is sound in the n-th second of
  audio stream
• B(n) 0 otherwise
• For the set of microphones in the same room

49
Silence Elimination

• Noise
• random
• It is less likely that noise in sound segments
  from different microphones occur simultaneously.
• Small duration

50
Silence Elimination

• Voting algorithm to determine the sound segment
  function - S(n)
• S(n) 1 if C(n) convolution M(n) gt ceil(k/2)
• S(n) 0 otherwise
• M(n) 111
• K number of microphones installed in the location

51
Audio Segmentation for Retrieval

• Video is retrieved from all cameras in the room
  for each sound segment.
• The video created by handover is extended to
  include the time during which sounds were present
  before the start of the footstep sequence

52
User Interaction
53
User Interaction
54
User Study-Real-Life Experiment
55
User Study

• 1st requirement study
• 2nd
• Given a demonstration on how to use the system
• Summit their own queries
• Select video clips that they would like to keep
• 3rd feedback about the system

56
Discussion
57
Discussion

• Issues Related to Capture
• Algorithm for Retrieval
• Real-Life Experiment

58
Issues Related to Capture

• Continuous capture
• The research was carried out at a different
  location from the home-like environment.
• Experiments with families are quite difficult to
  arrange and the cost of losing important data due
  to algorithms with sufficient accuracy is quite
  high.
• Problem large amount of disk space

59
Issues Related to Capture

• Some of microphones seem to be redundant, given
  their range and directivity.
• Save disk space
• Floor sensors are more expensive and difficult to
  maintain
• Movement of furniture

60
Algorithm for Retrieval

• The accuracy of footstep segmentation
  deteriorates when the number of persons in the
  house is large and with the movement of furniture
• Video handover can be improved by considering
  occlusion by other persons when selecting the
  camera.
• For audio handover, smoother transitions are
  possible by looking for silence near the point of
  microphone change.

61
Algorithm for Retrieval

• Key frame extraction
• Human-human and human-object interaction
• Audio-based video retrieval will retrieved false
  result if the house is located at a place where
  loud sounds can enter the house from outside

62
Real-Life Experiment

• The subjects in students experiments were
  independent in their actions.
• The behavior of the family in the real-life
  experiment was in the form of a group.
• Accuracy of footstep segmentation is decreased.

63
Future Work
64
Future Work

• Further clustering of floor sensor data and
  classification of audio data.
• Face detection

65
Thank you
