Middle Ordovician to Late Silurian Geology

1
Middle Ordovician to Late Silurian Geology

• Eastern United States

2
Middle Ordovician

• Shallow water limestones and dolomites of Great
  American Bank change
• Mudcracks stromatolites disappear
• Beds become thinner
• Fauna increases in abundance diversity
• Brachs, bryos, trilos, corals, molluscs, etc.
• Volcanic ashes appear

3
Middle Ordovician

• Limestones abruptly overlain by black shale (10s
  to 100s meters)
• Shale is black from organic matter
• Fauna is very restricted
• Graptolites, few cephalopods trilos

4
Middle Ordovician

• Black shales succeeded by 100s of meters of
  interbedded shale and immature litharenites
  (Flysch)
• Sandstones have very distinctive sedimentary
  structures

5
Structures in Sandstones

• Sharp, erosional base
• Contact with underlying shale is abrupt
• Tops are commonly gradational into overlying
  shales

6
Structures in Sandstones

• Basal erosion surfaces commonly show Flute Casts
• Flutes show direction of current from East!
• Flutes widen in downcurrent direction

7
Structures in Sandstones

• Graded Bedding within sandstone beds
• Graded interval may be overlain by Ripples
  Small Scale Cross Stratification
• Tops of beds grade into overlying shale

8
Structures in Sandstones

• Sharp, erosional base /- Flute Casts
• Internally graded
• Graded interval may have ripples /- small scale
  cross stratification near top
• Sequence repeats countless times
• Bouma Sequence

9
Middle to Late Ordovician Flysch

• Thick sequences of interbedded dark, graptolitic
  shales and immature, litharenites
• Commonly deformed
• Deformation may have been syndepositional

10
Late Ordovician to Middle Silurian Molasse

• Molasse 100s to 1000s of meters thick
• Red shales
• Red shales with red sandstones
• Quartz arenites and quartz pebble conglomerates
• Follows Deformation

11
Molasse

• Interbedded red shales and sandstones
• Sandstones are thicker than in flysch
• Sandstones show different sedimentary structures
• Shales may have mudcracks

12
Molasse Sandstones

• More quartz-rich sublitharenites
• 10s of centimeters to several meters thick,
  each.
• Bases are erosional grain size fines upward, but
  not as single graded beds
• Large small scale cross stratification planar
  stratification

13
Upper Molasse

• Red Molasse passes upward into White Molasse
• Quartz arenites and quartz pebble conglomerates
• May have marine fossils

14
An Example of Facies in the White Molasse
East quartz pebble conglomerates Shawangunk
Conglomerate
Central Quartz arenites Tuscarora Sandstone
West Interbedded quartz arenites dark grey
shales Tuscarora Sandstone
15
Review of Sedimentary Sequence

• Molasse (top) red sandstones and shales
• White Molasse (top)
• Red Molasse
• Late Ordovician to Silurian
• Flysch immature sandstones and dark shales
• Middle to Late Ordovician
• Flysch Molasse Clastic Wedge
• Black Shales starved basin
• Middle Ordovician
• Limestones (base) Great American Bank
• Cambrian to Middle Ordovician

16
Tectonic Interpretations of the Sedimentary
Sequence

• Great American Bank Passive Margin (Base)
  tectonically quiet Pre-orogenic
• Black Shales Starved Basin early orogenic
  subsidence
• Flysch Synorogenic
• Molasse (Top) Post Orogenic
• Red Molasse erosion of orogen
• White Molasse transgression and reworking of
  Red Molasse

17
But, what does it mean?

• Great American Bank
• Passive Margin Opening of Iapetus
• Middle Ordovician Limestone
• Facies indicate increased depth
• Transgression?
• Increased Subsidence?
• Volcanic ashes indicate proximity of volcanic
  source
• Passive Margin replaced by Starved Basin
  increased subsidence

18
But, what does it mean?

• Flysch indicates new sediment source to the east
  high relief, low grade metamorphics volcanics
• Syndepositional deformation indicates Orogeny
• Taconic Orogeny
• Molasse post-orogenic destruction of Taconic
  Mountains
• Queenston Clastic Wedge

19
What is a Clastic Wedge?

• Wedge-shaped mass of sediment shed from mountains
• Wedge is thicker and coarser grained close to
  source
• Wedge gets thinner and finer grained away from
  source
• Usually made of flysch molasse

20
Taconic Orogeny

• Subduction begins somewhere in Iapetus
• Subduction creates island arc Taconia
• Subduction closes part of Iapetus
• Taconia is accreted to North America
• Subduction begins beneath new eastern margin of
  North America (?) Andean-type convergent margin
  (?)

21
Sedimentary Responses to Tectonic Processes

• For every tectonic event, there is a sedimentary
  response
• Passive Margin/Thermal Subsidence thick wedge
  of limestones, quartz arenites, other quartz-rich
  sandstones
• Sinking of passive margin black shales
• Approach of island arc or other landmass
  immature sandstones
• Erosional destruction of orogen - molasse

22
Top Ten Signs You Are Experiencing Orogeny

• 10) You get that sinking feeling.
• Apparent transgression caused by increased
  subsidence
• 9) The sky is falling, and it isnt snow!
• Volcanic ashes appear in sequence
• 8) You get the munchies for more sediment.
• Formation of Starved Basin
• 7) People say your sediments are so immature!
• 6) You feel the need to dump your garbage on
  others.
• Formation of Clastic Wedge

23
Top Ten Signs You Are Experiencing Orogeny

• 5) You definitely get bent out of shape.
• Folding
• 4) You cant deny that you have faults.
• Thrust faulting
• 3) You intrude where you are not welcome.
• Igneous Intrusions (/- lava flows)
• 2) You get all hot and bothered.
• Regional Metamorphism
• 1) Youre caught in a cover-up, trying to hide
  your true inclinations.
• Formation of Unconformities (especially angular)
