Staining of bacteria by fluorescently labeled bacteriophages

1
STAINING OF BACTERIA BY FLUORESCENTLY LABELED
BACTERIOPHAGES
by M.A.Khan, D.Sharma, D.Gahloth, B.M.J Pereira
Department of Biotechnology Indian Institute of
Technology Roorkee (IITR) Roorkee-247667,
Uttaranchal, INDIA e-mailmkhanfbs_at_iitr.ernet.in
2
Contents

• Basic Introduction
• Fluorescently labeled phages
• Introduction
• Methodology development
• Host range
• Detection of activated sludge bacteria
• Conclusions

3
Basic Introduction

• Bacteriophages are viruses of bacteria.
• Bacteriophages are extremely abundant and active
  member of the biological wastewater treatment
  system.
• Several bacterial species involved in biological
  wastewater treatment have a significant impact on
  process efficiency so the interaction of bacteria
  and their predators, such as phages, is of
  interest.
• Bacteriophages are environmentally important both
  in controlling bacterial numbers and in
  facilitating bacterial gene transfer.

4
What are Fluorescentlylabeled bacteriophages?

• Several fluorescent dyes can stain bacteriophage
  nucleic acid which can be easily visualized by
  epifluorescence microscope.
• DAPI
• Acridine orange
• FITC (flurescein-5-isothiocyanate)
• SYBR

5
Significance of Fluorescently labeled
bacteriophage

• They can be used to identify and quantify the
  specific strains of bacteria in aquatic samples.
• They can be applied to activated sludge system or
  any other natural environment where diverse kinds
  of bacteria exist.

6
Objectives

• To develop methodology to label bacteriophages
  isolated
• from activated sludge by fluorescent dyes.
• To evaluate the feasibility of the fluorescently
  labeled
• Phages to examine host range on several host
• bacteria.
• To evaluate the scope of for the detection of
  sensitive
• bacterial cells within mixed culture.
• (activated sludge samples)

7
Bacteriophage bacteria isolation method
Activated sludge mixed liquor
Elution of sludge particles by 10 beef extract
solution
Incubation
Plating method
Picking-up a colony streaking plating method
Centrifugation and filtration
Filtrate host bacteria
Purified isolate
Plaque formation test (observation of plaques)
Picking individual plaques and purification
8
Prerequisite of preparing Fluorescently labeled
Phages

• Selection of the phage-host system
• Preparation of high titer phage stock
• Purification of phage stock

9
P30- ?P30 phage-host system
characterization

• P30 host is a Gram-ve rods
• identified as Serratia marcescens
• Plaque formation time was rapid and
• reproducible
• Plaque size were big(2-3 mm)
• ?P30 is a DNA phage

10
Optimum growth conditions for (?P30, ?P35, ?P37
phages)

• Optimum time Optimum
  Lysis
• for adding phage temperature
  time
• ?P30 2 hrs 30?C
  67 hrs
•
  (complete)
• ?P35 1 hrs 30?C
  34 hrs
•
  (partial)
• ?P37 2 hrs 30?C
  34 hrs
•
  (partial)

11
Fluorescent labeling of phage
Host cells phage fluorescent dye
Treat lysate with DNase to release labeled
phages from the mixture PEG1M NaCl
Purification of labeled phage by
Ultra-filtration
Mixing with its host and visualize under
epifluroscent microscope
12
DAPI stained P30 host cells (control) without
phage
Purified DAPI labeled ?P30 phage particles after
Ultra filtration
10 µm
10 µm
Epifluroscent image, ?1000 Magnification
Epifluroscent image, ?1000 Magnification
13
Application of DAPI-labeled phage

• Detection of the host bacterial
• cells in pure culture
• Cross reactivity with
• other isolates (host range)

14
Purified phage particles infecting its host (pure
culture) after mixing
I
II
III
IV
15
?P30 cross infectivity with different activated
sludge isolates
16
Application of DAPI-labeled phage to activated
sludge samples

• Activated sludge samples host cells
• (with or without sonication)
• Activated sludge samples no host cells
• (with or without sonication)

17
P30 host Activated sludge sample labeled phage
stock
Bright field image,?1000 Magnification
Epifluroscent image, ?1000 Magnification
18
P30 host Activated sludge sample DAPI
labeled phage (100? dilution)
Epifluroscent image, ?1000 Magnification
19
DAPI-labeled phage application to activated
sludge samples(without added host cells)
20
Conditions of using FLP in activated sludge

• Viable host cells must be present in the
• samples
• Activated sludge samples should be
• well dispersed
• Fluorescently labeled phage particles
• should be well purified
• (free from residual dyes)

21
Conclusions

• Phage ?P30 DNA was labeled successfully by DAPI
  (1mg/l) and Acridine orange (50mg/l).
• DAPI labeled ?P30 phage particles were able to
  detect their unlabeled host cells in their pure
  culture.
• The bacteriophage particles did not lose their
  infectivity even after labeling their nucleic
  acid by DAPI (conc1mg/l).

22
Conclusions

• DAPI labeled phage particles can detect its host
  cells in the activated sludge samples.
• Cross reactivity of the labeled phage with other
  activated sludge isolates shows that it was
  specific for its host.

23
Thanks
