TCA LOG FILES

1
TCA LOG FILES
2
WHAT ARE THEY?

• Text files produced by TCA Programs
• They provide useful easy to read information
• They are proof of work completed by a survey crew

3
GEOMETRONICS

• Record a log file each time a program is used
• Log file is part of the field notes
• Log file is part of the documentation
• Log file can be proof of a staked position
• If a position is questioned by a contractor
• Can potentially save money in a claim
• Gives our people confidence in staked positions

4
PROGRAMS WITH LOG FILES
5
STAKEOUT LOG FILE SHORT VERSION
6
STAKEOUT LOG FILE LONG VERSION
7
SETS OF ANGLES LOG FILE
8
ROAD PLUS STAKEOUT LOG
9
ORI. HEIGHT TRANS LOG
Leica VIP Orientation Ht. Transfer V
2.22 Instrument TCA1800, Serial 419551,
98-TS11 User Templ. METERS Meas. File
FILE01.GSI Program Start 27/02/2001 at
0302 Station 201 E
2245698.848m N 154862.360m
Elev. 210.566m hi
1.680m Using Least-Squares Solution Station Ht.
210.535m Ori.Corr.
000'39" Std.Dev. Ht.
0.000m Std.Dev. Ori. 000'00" 1
point(s) measured Point Id.
Delta Hz Delta Ht Delta
Sd 1 102 000'00"
-0.000m 0.000m
10
TIE DISTANCE LOG
Leica VIP Tie Distance V 2.22 Instrument
TCA1800, Serial 419551, 98-TS11 User Templ.
METERS Meas. File FILE01.GSI Program Start
27/02/2001 at 0259 Station 201
E 2245698.848m N
154862.360m Elev.
210.566m hi 1.680m Point No. 1
103 E 2245780.229m N
154841.746m Elev.
209.738m Hr 1.503m Point No. 2
102 E 2245688.508m N
154918.960m Elev.
210.055m Hr 1.503m Point No. 1
103 Point No. 2 102 Hori. Dist.
119.895m Azimuth
31005'30" ëHeight
0.317m Slope Dist. 119.895m
11
ROAD PLUS SLOPE STAKE LOG
Point No. 537 Chainage 77330.000,
Offset 0.000m
HghtOffset 0.000m Staked
E 377671.434m, N 176339.170m
Elev. 136.335m Deltas
dCL Offset -19.196m
dXS HgtDiff -0.001m
dChainage 0.000m Point No.
538 Chainage 77330.000, Offset
0.000m HghtOffset
0.000m Staked E
377674.238m, N 176340.218m
Elev. 136.253m Deltas dCL
Offset -22.189m dCL
HgtDiff -136.253m
dChainage 0.008m
dCatch Offs -2.993m
dCatch HgtD 0.081m
dHinge Offs -13.889m
dHinge HgtD 5.529m
