Numerical-Precision-Optimized Volume Rendering

1
Numerical-Precision-Optimized Volume Rendering
Sqeeze
Ingmar Bitter Neophytos Neophytou Klaus
Mueller Arie Kaufman
2
Numerical-Precision-Optimized Volume Rendering
Sqeeze
Ingmar Bitter Neophytos Neophytou Klaus
Mueller Arie Kaufman
3
Outline

• Numerical precision - a rendering resource

4
Outline

• Numerical precision - a rendering resource
• Fixed-point arithmetic

5
Outline

• Numerical precision - a rendering resource
• Fixed-point arithmetic
• Reverse order precision analysis
• Compositing, shading, gradients, classification,
  sampling/splatting, sample/splat location

6
Outline

• Numerical precision - a rendering resource
• Fixed-point arithmetic
• Reverse order precision analysis
• Compositing, shading, gradients,
  classification,sampling/splatting, sample/splat
  location
• Results

7
Outline

• Numerical precision - a rendering resource
• Fixed-point arithmetic
• Reverse order precision analysis
• Compositing, shading, gradients, classification,
  sampling/splatting, sample/splat location
• Results
• Conclusions

8
Numerical Precision A Resource

• Double precision computation for all ideal?

9
Numerical Precision A Resource

• Double precision computation for all ideal?
• slower then all other alternatives
• not possible on graphics cards (at least for now)
• expensive on custom chip implementations
• and most importantly
• not needed to create best possible images!!

10
Numerical Precision A Resource

• Double precision computation for all ideal?
• slower then all other alternatives
• not possible on graphics cards (at least for now)
• expensive on custom chip implementations
• and most importantly
• not needed to create best possible images!!
• reasons predominantly 8-bit displays (per
  channel)
• limited range intervals
  throughout

11
Current Status

• Stable volume rendering pipeline both CPU and
  GPULL94, Lev88, MJC02, Wes90, EKE01, RSEB00
• Interpolation before classification, even for
  splatting MMC99
• Caching optimized for volume renderingKni00,
  LCCK02, PSL98
• Precision-limited rendering systems ATI,
  NVidia,VolumePro PHK99, VizardII MKW02,
  UltraVis Kni00
• Completely fixed final output image display bit
  precision
• 8 bits per RGB color channel on CRTs and LCDs
• 8 bits max in DVI standard
• SGIs 12 bit color displays are nearly extinct
• Radiologists requirements are not mass market,
  same analysis applies

12
OpenGL Arithmetic 121?

• Representation 0, 255 ? a b 255
• Computation a0, 255 b0, 255 gtgt 8
• 254 ? wrong
• ? 1 mult, one shift
• Alternatively tmp a0, 255 b0, 255
  128 result (tmp(tmp gtgt
  8)) gtgt 8
• 255, correct
  Bli95
• ? 1 mult, 2 adds, 2 shifts

13
OpenGL Arithmetic 121?

• Representation fixed-point I.Fb
• I.Fb I integer bits, F fraction bits
• 8 bits ? 1.7b fixed point number
• then a b 11.7b 128
• Computation a1.7b b1.7b gtgt 7
• 128 ? correct
• ? 1 mult, one shift
• ? one fewer bit of resolution, but OK (we will
  see)

14
Reverse Order Precision Analysis
Ray Casting
Splatting

• Unified ray casting and splatting pipelines
• Composite creates the final image

Sample Location
Splat Location
Sample
Splat
Classify
Gradient
Shade
Composite
15
Reverse Order Precision Analysis
Ray Casting
Splatting

• Unified ray casting and splatting pipelines
• Composite creates the final image
• Precision requirements propagate backwards

Sample Location
Splat Location
Sample
Splat
Classify
Gradient
Shade
Composite
16
Compositing - Math

• Pre-(alpha)-multiplied colors
• C aC aR, aG, aB
• Alpha correction (r samples per unit)
• Tcorrected (1- a)r

17
Compositing - Math

• Pre-(alpha)-multiplied colors
• C aC aR, aG, aB
• Alpha correction
• Tcorrected (1- a)r
• With back-to-front compositing
• CCompositingBuffer Tcorrected Cfront
• TCompositingBuffer Tcorrected
  aCompositingBuffer 1-Tcorrected
• perform multiplication N times per pixel
• ? correct solution needs N F r bits
  precision

T/CCompositingBuffer
Tcorrected, Cfront
T/CCompositingBuffer
18
Compositing Precision Theory

• 8-bit destination resolution
• therefore all partial results can be rounded
• drop all bits not contributing to the 8 most
  significant bits (MSB)
• Adding N 2p samples
• allows 8p bits to influence the 8 MSB
• Conversion from aCompositingBufferC to C for
  display (division)
• allows 8p more bits to influence the 8 MSB
• Conversion from acorrectedC to C for display
• allows r times as many bits to influence the 8
  MSB
• Sufficient resolution is r 2 (8p) for C, r
  (8p) for a
• 32/16 bits for C/aCompositingBuffer for 2563
  volumes and no super-sampling
• 608 bits for 51222048 volumes and 16 samples per
  voxel

19
Compositing Precision Theory

• 8-bit destination resolution
• therefore all partial results can be rounded
• drop all bits not contributing to the 8 most
  significant bits (MSB)
• Adding N 2p samples
• allows 8p bits to influence the 8 MSB
• Conversion from aCompositingBufferC to C for
  display (division)
• allows 8p more bits to influence the 8 MSB
• Conversion from acorrectedC to C for display
• allows r times as many bits to influence the 8
  MSB
• Sufficient resolution is r 2 (8p) for C, r
  (8p) for a
• 32/16 bits for C/aCompositingBuffer for 2563
  volumes and no super-sampling
• 608 bits for 51222048 volumes and 16 samples per
  voxel

20
Compositing Precision Theory

• 8-bit destination resolution
• therefore all partial results can be rounded
• drop all bits not contributing to the 8 most
  significant bits (MSB)
• Adding N 2p samples
• allows 8p bits to influence the 8 MSB
• Conversion from aCompositingBufferC to C for
  display (division)
• allows 8p more bits to influence the 8 MSB
• Conversion from acorrectedC to C for display
• allows r times as many bits to influence the 8
  MSB
• Sufficient resolution is r 2 (8p) for C, r
  (8p) for a
• 32/16 bits for C/aCompositingBuffer for 2563
  volumes and no super-sampling
• 608 bits for 51222048 volumes and 16 samples per
  voxel

21
Compositing Precision Theory

• 8-bit destination resolution
• therefore all partial results can be rounded
• drop all bits not contributing to the 8 most
  significant bits (MSB)
• Adding N 2p samples
• allows 8p bits to influence the 8 MSB
• Conversion from aCompositingBufferC to C for
  display (division)
• allows 8p more bits to influence the 8 MSB
• Conversion from acorrectedC to C for display
• allows r times as many bits to influence the 8
  MSB
• Sufficient resolution is r 2 (8p) for C, r
  (8p) for a
• 32/16 bits for C/aCompositingBuffer for 2563
  volumes and no super-sampling
• 608 bits for 51222048 volumes and 16 samples per
  voxel

22
Compositing Precision Theory

• 8-bit destination resolution
• therefore all partial results can be rounded
• drop all bits not contributing to the 8 most
  significant bits (MSB)
• Adding N 2p samples
• allows 8p bits to influence the 8 MSB
• Conversion from aCompositingBufferC to C for
  display (division)
• allows 8p more bits to influence the 8 MSB
• Conversion from acorrectedC to C for display
• allows r times as many bits to influence the 8
  MSB
• Sufficient resolution is r 2 (8p) for C, r
  (8p) for a
• 32/16 bits for C/aCompositingBuffer for 2563
  volumes and no super-sampling
• 608 bits for 51222048 volumes and 16 samples per
  voxel

23
Compositing Precision Practice

• No alpha correction (r 1) 2 (8p) bits
• Iso-surface rendering using old fashioned
  OpenGL
• store not aC but C in frame buffer (8p)
• bright colors 5p
• at most 8 non-zero samples per ray (p3) 538
  bits
• ? standard 24 bit RGBA frame buffer is
  adequate
• Fog visualization
• what matters is the ability to see objects though
  volumetric fog (substance with low opacity)
• visual experiments show 15 fractional bits are
  sufficient

24
Compositing Precision Practice

• No alpha correction (r 1) 2 (8p) bits
• Iso-surface rendering using old fashioned
  OpenGL
• store not aC but C in frame buffer (8p)
• bright colors 5p
• at most 8 non-zero samples per ray (p3) 538
  bits
• ? standard 24 bit RGBA frame buffer is
  adequate
• Fog visualization
• what matters is the ability to see objects though
  volumetric fog (substance with low opacity)
• visual experiments show 15 fractional bits are
  sufficient

25
Compositing Precision Practice

• No alpha correction (r 1) 2 (8p) bits
• Iso-surface rendering using old fashioned
  OpenGL
• store not aC but C in frame buffer (8p)
• bright colors 5p
• at most 8 non-zero samples per ray (p3) 538
  bits
• ? standard 24 bit RGBA frame buffer is
  adequate
• Fog visualization
• what matters is the ability to see objects though
  volumetric fog (substance with low opacity)
• visual experiments show 15 fractional bits are
  sufficient

26
Compositing Precision Practice

• No alpha correction (r 1) 2 (8p) bits
• Iso-surface rendering using old fashioned
  OpenGL
• store not aC but C in frame buffer (8p)
• bright colors 5p
• at most 8 non-zero samples per ray (p3) 538
  bits
• ? standard 24 bit RGBA frame buffer is
  adequate
• Fog visualization
• what matters is the ability to see objects though
  volumetric fog (substance with low opacity)
• visual experiments show 15 fractional bits are
  sufficient

27
Compositing Precision Practice

• No alpha correction (r 1) 2 (8p) bits
• Iso-surface rendering using old fashioned
  OpenGL
• store not aC but C in frame buffer (8p)
• bright colors 5p
• at most 8 non-zero samples per ray (p3) 538
  bits
• ? standard 24 bit RGBA frame buffer is
  adequate
• Fog visualization
• what matters is the ability to see objects though
  volumetric fog (substance with low opacity)
• visual experiments show 15 fractional bits are
  sufficient

28
Compositing Precision Practice

• No alpha correction (r 1) 2 (8p) bits
• Iso-surface rendering using old fashioned
  OpenGL
• store not aC but C in frame buffer (8p)
• bright colors 5p
• at most 8 non-zero samples per ray (p3) 538
  bits
• ? standard 24 bit RGBA frame buffer is
  adequate
• Fog visualization
• what matters is the ability to see objects though
  volumetric fog (substance with low opacity)
• visual experiments show 15 fractional bits are
  sufficient

29
Compositing Conclusion
Least-significant-bit-fog at various bit
precisions
8
10
12
14
15
16
5123 dataset r 2

• Preferred bit-aware back-to-front compositing
  equations
• aC1.15b T1.15bsample C1.15bsample
• T1.15b T1.15bsample

30
Shading - Math

• PhongCcolor kambient OobjectColor
  IlightIntensity kdiffuse O Si Ii
  (NLi) kspecular Si Ii (RLi)r
• k ? 0,1 kambient kdiffuse
  kspecular 1
• OobjectColor (8 bit) and IlightIntensity ? 0,1
• NLi and RLi ? -1,1, but ? 0,1 after
  clamping
• PhongCcolor ? 0,1 (possibly clamping Si)

31
Shading - Analysis

• PhongCcolor needs to be as precise as 1.15b
• Use 16.16b for all multiplications 0,1) 0,1
• sufficient precision and no overflow

32
Shading New Computation

• Replace specular exponentiation with recursive
  multiplies
• repeatedly multiply number with itself
• works for all exponents r2n
• when r26 (16 bit precision), then max error lt
  0.005
• better results than Knittels parabola
  approximation

33
Shading New Computation

• Replace specular exponentiation with recursive
  multiplies
• repeatedly multiply number with itself
• works for all exponents r2n
• when r26 (16 bit precision), then max error lt
  0.005
• better results than Knittels parabola
  approximation

Knittels parabola
pow
r2n
34
Shading - Conclusion

• Preferred bit-aware Phong shading equation
• C16.16b k16.16bambient O0.8bobjectColor
  I16.16blight k16.16bdiffuseO0.8b
  Si I16.16bi (N16.16bL16.16bi)
  k16.16bspecular Si I16.16bi (R16.16bL16.16bi)2
  n

35
Gradients - Math

• Gx 0.5 sample(x1,y,z) - 0.5 sample(x-1,y,z)
• Gy 0.5 sample(x,y1,z) - 0.5 sample(x,y-1,z)
• Gy 0.5 sample(x,y,z1) - 0.5 sample(x,y,z-1)

36
Gradients - Analysis

• G G1.Fb
• Discrete nearest gradient vector neighbors
• sin f 1/2F, sin f f ? f 1/2F
• Maximum error for specular intensity, large r
• r 64, 164 ! 1, but 164 (1- 1/2F)64
• error of 22, 6.1, 1.6, 0.4for F of 8,
  10, 12, 14

f
37
Gradients - Analysis

• 5123-sized spheres with Phong highlights
• 4, 6, 8, 10, 12, 14 bit gradients
• Diffuse artifacts for 4 and 6 bits
• Specular artifacts up to 10 bits

6
4
8
12
10
14
12
10
14
38
Gradients - Conclusion

• Thus, 12 bits dynamic range is needed
• Now consider normalization
• reduces I.Fb to 1.Fb
• up to I bits will be added to the fractional part
• Volume samples often have 12 bits
• Gx,y,z with 12.12b minimum representation
• Gx,y,z with 16.16b preferred representation
• leaves room for interpolation bits in
  normalization

39
Classification Prelims and Recaps

• Use of T instead of a is more efficient in
  compositing operation
• Largest visual precision/quantization error
  occurs at high transparencies (low opacities)
• need more bits for T than for C, just to be sure
• Want transfer function lookup table to be
  cache-friendly
• power-of-2 RGBA-tuple alignment
• Would like to use pre-integrated classification
  for color and opacity transfer functions EKE01,
  MGS02

40
Classification Prelims and Recaps

• Use of T instead of a is more efficient in
  compositing operation
• Largest visual precision/quantization error
  occurs at high transparencies (low opacities)
• need more bits for T than for C, just to be sure
• Want transfer function lookup table to be
  cache-friendly
• power-of-2 RGBA-tuple alignment
• Would like to use pre-integrated classification
  for color and opacity transfer functions EKE01,
  MGS02

41
Classification Prelims and Recaps

• Use of T instead of a is more efficient in
  compositing operation
• Largest visual precision/quantization error
  occurs at high transparencies (low opacities)
• need more bits for T than for C, just to be sure
• Want transfer function lookup table to be
  cache-friendly
• power-of-2 RGBA-tuple alignment
• Would like to use pre-integrated classification
  for color and opacity transfer functions EKE01,
  MGS02

42
Classification Prelims and Recaps

• Use of T instead of a is more efficient in
  compositing operation
• Largest visual precision/quantization error
  occurs at high transparencies (low opacities)
• need more bits for T than for C, just to be sure
• Want transfer function lookup table to be
  cache-friendly
• power-of-2 RGBA-tuple alignment
• Would like to use pre-integrated classification
  for color and opacity transfer functions EKE01,
  MGS02

43
Classification - Math

• Desired lookup table entries
• R1.8bG1.8bB1.8bT1.16b ? 5.5 bytes
• Common lookup table entries
• R0.8bG0.8bB0.8ba0.8b ? 4 bytes

44
Classification - Math

• Desired lookup table entries
• R1.8bG1.8bB1.8bT1.16b ? 5.5 bytes
• Common lookup table entries
• R0.8bG0.8bB0.8ba0.8b ? 4 bytes
• Better lookup table entries
• R0.8bG0.8bB0.8bsqrt(a)0.8b ? spreads low a
• Computed lookup after T 1-(sqrt(a)2)
• R0.8bG0.8bB0.8bT1.16b ? squaring doubles
  precision

45
Classification - Conclusion
Foot with least-significant-thin-tissue-fog
a0.8b
sqrt(a)0.8b
a0.16b

• Preferred bit-aware lookup table entries
  R0.8bG0.8bB0.8bsqrt(a)0.8b

46
Sample Interpolation - Math

• sample voxel0 (1-w) voxel1 w
• sample w (voxel1 - voxel0) voxel0
• Requirements
• Gx,y,z, derived from samples, need 12 bit dynamic
  range
• samples need 12 bit values for transfer function
  lookup
• cover both low and high dynamic range
  neighborhoods
• Therefore, sample12.12b is a minimum requirement
• integer part comes from voxels ? voxel12.0b
• fractional part comes from interpolation ? w1.12b

47
Sample Interpolation - Conclusion

• Preferred bit-aware sample interpolation
• sample12.12b w1.12b (voxel112.0b -
  voxel012.0b) voxel012.0b
• Splats start on voxels, need no interpolation
• splat12.0b voxel12.0b

48
Sample Location - Math
k

• k-th sample location startPos Sk Vinc
• Perspective rays need to differ enough to allow
  1024 rays across 60 degrees, or 0.05?
• sin f (k 1/2F) / k, sin f f ? f 1/2F
• F 6, 12, 16 ? f 0.9?, 0.05?, 0.0009?
• Also, need to address 2048 slices (integer
  positions) ? 11bits
• Thus, need overall 11.12b

f
49
Sample Location - Conclusion

• Preferred bit-aware sample location
• perspective projection
• sampleLocation11.12b startPos11.12b S
  Vinc1.12b
• parallel projection sampleLocation11.6b (0.9? OK)

50
Splat Scan Conversion - Math

• Splats project onto image grid ? reverse rays
• Allow as many as 2048 splat rays across 60
  degrees, or 0.025?
• Hence, twice the ray casting precision
• one extra fractional bit F13
• Also address 2048 slices (11bits)
• Thus, need overall 11.13b

f
51
Splat Scan Conversion - Conclusion

• Preferred bit-aware splat scan conversionsplatLo
  cation11.13b startVoxelPos11.13b S
  Vinc1.13b
• Splats are usually pre-transformed and stored in
  bucket lists (one per sheet-buffer)
• Preferred voxel location sheet buffer
  formatx11.13b u8.0b y11.13b v8.0b (64 bits
  total)
• x, y location on splat plane
• u index into pre-integrated splat table
• v voxel value

u
(x, y) y)
52
Results

• Summary of minimum precision requirements

Rendering Stage Input Output
Sample locations N/A 11.12b
Sample interpolation 12.00b 12.12b
Classification 12.00b 4 0.8b
Gradients 12.12b 1.12b
Shading 1.12b 1.15b
Compositing 1.15b 1.15b
53
Results

• Restricted iso-surface rendering
• texture map volume rendering can be done using
  plain OpenGL or Direct X and 8 bit frame buffers
• General volume rendering, all pipeline stages
• 32 bit single precision floating point format
• 16.16b fixed point format (up to 4x faster in our
  tests)
• Pentium allows 2 simple 32-bit integer ops
  per clock cycle

54
Conclusions

• 8 bits per RGB channel on final display
• Analysis of requirements by back propagation
• Sufficient precision computations using
• either 32 bits single precision floating point
  format
• or 16.16b fixed point format
• Voxel location sheet buffer x11.13bu8.0by11.13bv8.
  0b
• Transfer functions stored as R0.8bG0.8bB0.8bsqrt(a
  )0.8b
• Compositing/fragment buffer R1.15bG1.15bB1.15bT1.1
  5b

55
Acknowledgements

• Hewlett Packard Laboratories
• ONR grant N000140110034
• NSF CAREER grant ACI-0093157
• DOE grant MO-068
• Thanks to Tom Malzbender and Michael Meissner for
  technical discussions.
• Thanks to Ronald Summers for resources.
