Phx.MorphCan Aspect-OrientedProgramming solve
Microsofts growing software problem?

• Marc Eaddy
• Columbia University

2
Background

• The Phoenix Project
• Microsofts production-grade compiler,
  analysis,and tools infrastructure
• Will become backend for all Microsoft compilers
• Massive software project
• Currently 1.8M LOC (318K hand-written)

3
Problem

• Many Phoenix requirements cannot be cleanly
  separated using traditional OO techniques
  (inheritance and aggregation)
• Unanticipated requirements
• Requirements to satisfy multiple clients and
  scenarios
• Operational (orthogonal) requirements
• Traditional OO solutions resulted in increased
  software complexity
• Designs are complex and highly coupled
• Code is cluttered and difficult to write and
  maintain
• Many other groups at Microsoft are also
  struggling with this problem

4
Our goal
Phx.Morph

• Determine if Aspect-Oriented Programming (AOP)
  can improve Phoenix development

Our approach

1. Use Phoenix to develop an AOP solution
2. Then turn around and use the AOP solution to help
   develop Phoenix

5
Aspect-Oriented Programming

• Promise of greater separation of concerns
• AOP Open Classes Advice
• Open Classes (type changes)
• Advice (code changes)
• AspectJ is the canonical AOP specification and
  implementation

6
AOP buzzwords

• joinpoint an execution event
• function call, function execution, field access,
  exception, etc.
• advice code that the programmer wants to be
  called before, after, or instead of (around),
  some joinpoint
• pointcut a pattern for matching joinpoints
• e.g., System.Output.
• weaving transforming a program to call advice
  code

7
Weaving using Phx.Morph
Post-Link Step
Normal assemblies containing custom AOP attributes
Aspect Assemblies
Source Files
Original Program
WeavedProgram
Phx.Morph
Compiler
Original developer can be oblivious
8
Open Classes (OC)

• Ability to split a class definition into separate
  modules

• Similar to Partial Classes in C except
• post-link time can extend a class at any time
• works on assemblies no source reqd
• language agnostic
• We support adding fields, properties, methods,
  base interfaces, and base classes

9
Original class
10
Demo Adding foreach sugar

• using System.Collections
• using Phx.Morph.Attributes
• Extends("Node")
• class NodeEnumeratorAspect Node, IEnumerable
• Add
• public IEnumerator GetEnumerator()
• return new NodeEnumerator(this)

Class to extend
Add this iface
Add this method
11
NodeEnumerator

• public class NodeEnumerator IEnumerator
• Node node
• int index -1
• public NodeEnumerator(Node node)
• this.node node
• public object Current
• get return node.GetChild(index)
• public bool MoveNext()
• return index lt node.ChildCount
• public void Reset() index -1

12
foreach client
static void DumpNode(Node root, string indent)
if (root null) return
System.Console.WriteLine(indent root)
foreach (Node child in root)
DumpNode(child, indent " ")
New capability!
13
Adding the Visitor patternTraditional OO
OO design is tightly coupled and hard to maintain
14
Adding the Visitor patternOpen Classes
Open Classes design breaks the circular
dependency and centralizes the code
Depends On
15
Phoenix client extensibilityTraditional OO

• Client wants to attach custom data to an object
• Example IR-Longevity plug-in tracks compiler
  phase when an instruction is created

Clients extension object
16
Phoenix client extensibilityOpen Classes

• Weave Phx.dll
• To add BirthPhase field directly to Instr

Clients extension object

• Empowers clients
• High performance
• Type safe
• Dont have to wait for RDK drop
• Dont require help from Phoenix team

17
Advice

• Ability to inject code at specific points in a
  program
• profiling
• logging/tracing
• log field get/set
• dirty bit (persistence, synchronization)
• change notification (undo/redo/rollback)
• enforce invariants (non-null, const, data flow,
  Design by Contract)
• error checking/handling
• fault injection
• caching/memoization
• proxies/delegation
• etc. etc.

18
Demo Logging reflection usage

• Want to log a message whenever we use the
  Reflection API
• Self-weave Phx.Morph.dll

19
Logging advice

• using Phx.Morph.Aop
• using Phx.Morph.Attributes
• public class LogReflectionAspect
• Advice(AdviceType.before, "call(System.Reflec
  tion..)")
• static public void LogReflection(Signature
  string signature,
• SourceLocation.WithinSignature string
  withinSignature,
• SourceLocation.FilePath string
  filePath,
• SourceLocation.Line uint line)
• System.Console.WriteLine()
• System.Console.WriteLine("Called 0()",
  signature)
• System.Console.WriteLine(" inside
  0()", withinSignature)
• System.Console.WriteLine(" File 0,
  Line 1",
• System.IO.Path.GetFileName(filePath),
  line)

20
Weaved result

• IL_0065 ldarg.0
• IL_0066 call class System.Reflection.Assembly
  System.Reflection.AssemblyLoad(string)

21
Weaved result

• IL_0065 ldarg.0
• IL_0066 ldstr "System.Reflection.Assembly.Load"

• IL_006b ldstr "Phx.Morph.ReflectionHelpers.Load
  Assembly"
• IL_0070 ldstr "c\\phx\\rdk\\samples\\Morpher\\
  Phx.Morph\\ReflectionHelpers.cs"
• IL_0075 ldc.i4 0xfb
• IL_007a call void LogReflectionExtLogReflecti
  on( string,
•
  string,
•
  string,
•
  uint32)
• IL_007f call class System.Reflection.Assembly
  System.Reflection.AssemblyLoad(string)

22
Logging output

• Called System.Reflection.Assembly.Load()
• inside Phx.Morph.ReflectionHelpers.LoadAssembly
  ()
• File ReflectionHelpers.cs, Line 251
• Called System.Reflection.Emit.AssemblyBuilder.Defi
  neDynamicModule()
• inside Phx.Morph.Attributes.AttributeHelper.Cre
  ateTypeBuilder()
• File AttributeHelper.cs, Line 499
• Called System.Reflection.Emit.ModuleBuilder.Define
  Type()
• inside Phx.Morph.Attributes.AttributeHelper.Cre
  ateTypeBuilder()
• File AttributeHelper.cs, Line 504
• etc

23
Demo Enforcing invariants

• Supporting const-ness at runtime
• Person teacher new Person()
• teacher.Salary 25000
• teacher.IsConst true
• teacher.Salary 1000000
• Caveat Must weave all clients

New!
Invariant violated!
24
Invariant aspect

• Extends("Person")
• class InvariantAspect
• Add
• public bool IsConst
• Advice(AdviceType.before, "set(Person.)")
• void CheckIsConst(
• SourceLocation.WithinSignature string
  withinSignature,
• This object This)
• if (IsConst)
• System.Console.WriteLine(
• "Person '0' violated IsConst constraint
  inside 1",
• This, withinSignature)

25
Phx.Morph implementation

• Built using Phoenix
• MorphPlugin plugs into PEREW and uses Phx.Morph
  to perform weaving

Phx.Morph
Editors Open Classes, weaving
AOP Joinpoints, pointcuts,
PEREW Assembly Re-Writer
Attributes Custom AOP attributes
MorphPlugin
Phoenix Core API
26
Current limitations

• Managed-code only
• Cannot access private members
• Limited aspect instantiation model
• Instance advice methods are imported
• Static advice methods are referenced
• Not yet implemented
• Cant import a method with multiple return
  statements
• Around advice
• Many pointcuts not implemented (including cflow)
• Aspect composition and precedence
• Access to some joinpoint context (Args, Target,
  thisJoinPoint)

27
Related work
Real (shipped) products
IBM WebSphere HyperProbes
AspectJ
BEA JRockit JVM
JAsCo
PROSE
IBM Eclipse
JBoss (J2EE)
JMangler
DynAOP
Products
EAOP
Steamloom
Spring (J2EE)
CeaserJ
Jakarta Hivemind
JAML
Java
.NET
Phx.Morph
AspectC
Rapier.NET
Aspect
C
No real products
Loom.NET
AspectC
AspectDNG
FeatureC
Weave.NET
Meta.NET
Wool
Other
XWeaver
Eos
Aspect.NET
Aspects
PostSharp
AspectS
SetPoint
CLAW
AOPHP
ComposeStar
Apostle
Hyper/J
SourceWeave.NET
PHPaspect
Pythius
DemeterJ
AopDotNetAddin
PEAK
AOP.NET
Encase
Composition Filters
AspectScheme
AspectL
AOP-Engine
AspectCocoa
Concern Manipulation Environment
AspectR
Italics Microsoft-sponsored (although none are
shipped)
28
Why our work is interesting

• Built using Phoenix Microsofts
  production-grade compiler, analysis and tools
  infrastructure
• Capable of weaving very large programs (e.g.,
  Phoenix itself, which is 1.8M LOC)
• Evolves in parallel with Phoenix and the Common
  Language Runtime (performance improvements, bug
  fixes, API evolution, etc.)
• Used by Phoenix to solve real business
  requirements
• Phoenix is real software
• Hampered by traditional OO techniques
• Weve started using AOP to develop Phoenix

29
Conclusions

• Our goal was to determine if AOP would improve
  Phoenix development
• Re-implemented a Phoenix plug-in to use Open
  Classes instead of the OO extension API
• Began prototyping grafting adapter interfaces
  onto Phoenix classes to integrate with another
  library
• We validated the feasibility of using Phx.Morph
  on Phoenix itself

30
Future work

• Work on Microsofts key blocking issues
• Debugability
• Maintainability
• Performance
• Versioning
• Serviceability
• Explore more AOP scenarios
• compile-time (ala Partial Classes for C)
• Makes it easier for Phoenix to use their own
  extensions
• Easily separate hand-written code from generated
  code (code behind)
• load-time
• Needed to fully support compile-time weaving
• runtime (dynamic weaving)
• Useful for on-the-fly debugging and rapid
  prototyping
• Improve ease-of-use
• IDE integration, projecting aspects into source
  code

31
Acks

• Many thanks to the Phoenix team!
• Mentor Weiping Hu
• Andy Ayers
• Julian Burger
• Jan Gray
• John Lefor
• Paddy McDonald
• Chuck Mitchell

32
Contact

• Marc Eaddy me133_at_columbia.edu

33
CLR wish list

• New partial metadata keyword
• Extends the C Partial Classes concept beyond
  compile time and makes it language neutral
• Compiler support Class definition class source
  files partial class source files partial
  classes defined in referenced assemblies
• Runtime support Combines partial classes at
  load-time
• Complete CodeDOM API
• Express all C and C/CLI language constructs
• Express complete syntax tree (including comments
  and whitespace)
• Parsers for C and C/CLI
• Weaving at runtime
• Ability to add fields, methods, etc. after
  load-time (ModuleLoadFinished)
• Fix ICorProfiler.SetFunctionReJIT (dont want to
  use out-of-process debugger API solution)
• Support for JIT deoptimization

34
More future work

• Next step is a proof-of-concept
• Determine small piece of Phoenix to aspectualize
• Design aspect solution
• Implement remaining required AOP functionality
• Modify Phoenix build process to perform post-link
  weaving step
• Explore more AOP scenarios
• compile-time (ala Partial Classes for C)
• Makes it easier for Phoenix to use their own
  extensions
• Easily separate hand-written code from generated
  code (code behind)
• load-time
• Needed to fully support compile-time weaving
• runtime (dynamic weaving)
• Useful for on-the-fly debugging and rapid
  prototyping
• Improve ease-of-use
• IDE integration, projecting aspects into source
  code
