Model Checking Programs

1
Model Checking Programs

• Willem Visser, Klaus Havelund, Guillaume Brat
  and SeungJoon Park
• ASE 2000

2002/4/16 Geum-ja Lee
2
Contents

• Motivation
• Java PathFinder (JPF)
• Enabling Technologies
• Abstraction, static analysis, runtime analysis
• Applications of JPF Tools
• Conclusions and Future Work

3
Motivation(1/2)

• Model checking usually applied to designs
• Some errors get introduced after designs
• Design errors are missed due to lack of detail
• Sometimes there is no design
• More advantages of checking code
• No lack of examples and users
• Harder problem, therefore more novel solution
  required

4
Motivation(2/2)

• Can model checking find errors in real programs?
• Can model checker be used by programmer?
• Only if it takes real programs as input
• Why Java?
• Contained Important modern language feature
• Object-oriented, multi-threading
• Convenient breakdown into bytecode instruction

5
ProblemTranslation Gap
Programs Heap Allocation Objects Exception Real
s
Model Checker Input Guarded Commands Arrays Inte
gers Process
???
6
First version of JPF

• Translation from Java to Promela
• Drawback of source to source translation
• Language coverage
• Language feature is not same
• Source required
• Translation from bytecode
• Ex) BANDERA Tool

7
Java PathFinder (1/3)
Property (Java)
bytecode
Counter example Yes
Program (Java)
bytecode
JPF System Layout
8
Java PathFinder (2/3)

• Verification and testing environment for Java
  which integrates model checking,  program
  analysis and testing
• Properties
• invariants and deadlock
• LTL properties (integrated with Bandera)

9
Java PathFinder (3/3)

• MC-JVM
• Execute bytecode
• Added new feature
• Garbage collection
• Nondeterministic Environments
• Ex) Verify.Random(I), Verify.RandomBool(i)
• Structure State
• Explicit state model checking similar to Spin
• DFS algorithm
• Sacrificed speed in the process

10
Enabling Technologies

• Property Preserving Slicing
• Abstraction
• Static analysis
• Partial-order reduction
• Runtime analysis
• Deadlock detection
• State Compression

11
Predicate Abstraction

• Mapping of a concrete system to an abstract
  system, whose states correspond to truth values
  of a set of predicate
• Two methods
• Create abstract state-graph during model checking
• Create abstract transition system before model
  checking

12
JPF Predicate Abstraction

• Annotations used to indicate abstractions
• Abstraction.remove(x)
• Abstraction.remove(y)
• Abstraction.addBoolean(EQ,xy)
• Tool generates abstract Java program
• Using Standford Validity Checker(SVC)
• JVM is extended with nondeterminism
• to handle over approximation

13
Static Analysis

• Computing executable program slices
• Partial-order reduction technique
• Only one interleaving of independent statement is
  executed
• Determine safe statements globally independent

14
Runtime Analysis

• Observing an arbitrary execution trace
• Used algorithm
• Data race detection algorithm Eraser
• (at Compaq)
• Maintaining lock to variable
• Locking order analysis (LockTree)
• Potential deadlock detection

15
State Compression

• To ensure termination, revisited state must be
  known during explicit state MC
• Each state thread information static
  variables(in classes)dynamic variables(in
  objects)
• State storing
• Generalization of method from Spin
• Component of JVM state is stored separately
• Only indexes need to be compared

16
Applications JPF Tools(1/2)

• The Remote Agent Spacecraft Controller
• AI-based spacecraft controller
• LISP code
• Formally analyzed before and after flight
• Three component
• Executive system multi-threaded OS
• Planner, Recovery system exchange message
• Modeling
• Two component modeled (event, task)
• Based on suspicion from code review

17

• Abstraction process
• Remove counter variable
• Abstraction.remove(count)
• Abstraction.addBoolean
• (EQ,countevent1.count)
• Analysis
• Error using Eraser data algorithm

The RAX Error in Java
18
Applications JPF Tools(2/2)

• The DEOS Avionics Operating System
• Real-time OS with Error in time-partitioning of
  thread
• JPF1 verification
• C code -gt Promela
• Predicate abstraction by hand
• JPF2 verification
• Size - 14 Java classes (1000 lines),
• Environment reused (443 lines)
• Used Techniques - Partial-order reduction,
• Abstraction by tool
• Invariant error founded

19
Conclusions

• Model checking at code level is worthwhile
• Used Techniques to analyze Java software
• Abstraction
• static analysis
• runtime analysis

20
Future work

• Need to develop methods the construction of
  environment
• Measure are needed
• Ex) Coverage measure
• (branch, method, condition/decision)
