Brushless Motors

1
Brushless Motors
2

• A servosystem is capable of transforming
• any mathematical function
• into a mechanical movement
• it can replace mechanical elements, such as cams
• and cam shafts, indexing gears, differentials,
  etc.
• A servosystem consists of a servomotor with its
  control unit.
• Servosystems can be used for
• Positioning the position, linear or angular,
  follows a predetermined position function.
• Speed control the motor speed follows a
• predetermined speed function.
• Torque control the torque of the motor follows a

• predetermined acceleration function.
• Hybrid control the system alternates between
• different kinds of control

3

• The servomotor, which is a permanently magnetized
  brushless AC motor, is a
• relatively new type of motor.

24 slots 2 rotor poles
4
(No Transcript)
5
Electro-Magnetic Flux Distribution
21 slots 8 rotor poles
6
Brushless Solution ProsCons

• Velocity (no sparks at the commutator)
• Efficiency (Torque/Inertia)
• Weight
• Dimensions
• Thermical Dissipation
• Acoustic Noise
• Maintenance
• MTBF

Disadvantages Cost
7
Thermical Behaviour
1. BL-Servo with MP
2. DC-Servo with MP
3. AC-Servo (ASM squirrel cage)
8

• Two brushless motors types exist
• (they differ in stator windings, permanent
  magnets lay-down, statoric field wave shape)
• AC brushless
• with sinusoidal field (fcem)
• DC brushless
• with trapezoidal field (fcem)

9
Permanent Magnets (PM) types

• Ferrite low cost,
• low Kt, torque loss 0.2/K,
• demagnetization temperature 150C
• Samarium Cobalt (Sm2Co17) high cost,
• high Kt, torque loss 0.04/K,
• demagnetization temperature gt150C
• (example Danaher HD series, Rockwell MPG series)
• Neodimium Iron Boron (NdFeB) medium cost,
• higher Kt, torque loss 0.09/K,
• demagnetization temperature gt150C
• (example Danaher HR series, Rockwell H, Y, 1326,
  MPL series)

10
Magnetism

• NdFeB (vs. SmCo)
• higher energy content
• worse thermical reversibility
• lower Curie temperature
• lower cost
• corrosion (not present with SmCo)
• bigger resistance in W,
• that in turn limits eddy currents

11
Temperature that causes para-magnetic behaviour
(i.e. weak magnetisation)
SmCo vs. NdFeB
12

• The permanent magnets lay-out on the rotor
  surface depends on AC or DC brushless, Kt,
  Cogging Torque (coppia di impuntamento).

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
Servo System Electrical Scheme
17
(No Transcript)
18
PTC Resistor

• Positive Thermal Coefficient resistor, used as a
  sensor
• inside the motor,
• in order to stop the driver/controller
• in case of too-high temperature (before to burn
  the motor)

19
Servo Motor Shapes and Air Cooling
20
(No Transcript)
21
Direct Drive Solution

• Problem
• Motor shaft elastical torsion (i.e. its
  flexibility)
• resonance frequency
• limited band-width
• low gains in the control loop
• poor kinematic performances

22
Direct Drive Solution (contd)

• Possible Solutions
• Digital Filters (only for constant resonance
  frequencies)
• High Stiffness Motors (a high inertia would not
  solve the problem)
• Torque Motors (Motori Coppia) with
• low velocity
• high stiffness
• they dont need gearboxes (i.e. they are
  direct-drive)

23
Direct Drive Solution (contd)

• Once solved the resonance frequency problem, the
  control loop gains can be increased and thus a
  good accuracy in the position sensor becomes
  mandatory
• Resolver
• 6 arc min 0.1 degrees
• SinCos Encoder
• 0.01 arc sec 2.8E-6 degrees
• or 1nm for linear encoders (righe ottiche)

24
Position Sensors used in theBrushless Motors
25
Resolver

• Characteristics
• linearity 0. 1 - 0.5
• resolution 0. 1 - 0.5
• sensitivity 5 - 10mV/ (Vref 20V)
• frequency 20KHz

26
Resolver (contd)
27
Resolver (contd)

• Pro
• absolute in one turn
• low cost
• robust
• Cons
• sinusoidal 20KHz reference voltage
• non-linear output
• brushes in some (old) versions
• It has been the standard position sensor
• on brushless motors

28
Encoder
29
Encoder (contd)
30
Encoder (contd)
31
Encoder (contd)

• Encoder types
• Absolute
• Battery Back Up
• One-Turn Absolute
• Multi-Turn
• Incremental
• SinCos
• (resolver output, encoder design,
• precise as an encoder)

e.g. Stegmann mounted on Rockwell MPL motors
32
Degree of Protection IPXY (e.g. IP65)  Digit 1
(X) Solid Objects Protection   0 Non
Protected 1 Protected against solid objects gt
than 50 mm 2 Protected against solid objects gt
than 12 mm 3 Protected against solid objects gt
than 2.5 mm 4 Protected against solid objects gt
than 1 mm 5 Dust Protected 6 Dust Tight   Digit 2
(Y) Water Protection   0 Non Protected 1 Protecte
d against dripping water 2   Protected against
dripping water when tilted to worse case
opening 3 Protected against spraying
water 4 Protected against splashing
water 5 Protected against water jets 6 Protected
against heavy seas 7 Protected against the
effects of immersion 8 Protected against
submersion
