Managing Efficiency, Processes

1
Managing Efficiency, Processes Productivity
2
Work Study

• generic term for management services and system
  engineering techniques, used to investigate
• methods of performing work (method study) and
  improve its efficiency and economy
• the time taken to do it (work measurement) with a
  view to rationalization, routinisation,
  utilisation, cost and incentive improvement
• the worker-work system-technology relationship
  how this is best designed and improved
  (ergonomics and the human-machine-information
  interfaces)

3
Productivity

• a measure of performance.
• broadly a ratio of output to input, i.e.
  comparing amount produced (output) with resources
  used (input)
• materials, machinery, labour, capital, energy
  --- a combination
• What improvements have there been over the last
  50 years in
• construction productivity
• payroll processing
• Car servicing
• banking
• How do we evaluate productivity levels and
  identify areas for improvement?

4
A work study curriculum - 1

• historical development commitments of Work
  Study
• basic concepts, objectives and procedures
• Method Study approaches and tools of Method
  Analyst
• Flow Diagrams Process Charts etc
• Critical questioning techniques
• Work Measurement and calculating times for Jobs
• Defining job elements calculating
• performance rating and standard/basic times
• Determining allowances fatigue, unavoidable
  avoidable delays, extra allowances
• various incentive plans

5
A work study curriculum - 2

• examining worker-machine relationships
• workload line balancing staff/machine
  inefficiencies
• material handling, human controls, tools and
  devices
• Workstation layout design (EU work-station
  directive)
• Occupation Health Safetysignals, reaction
  times, eyes, backs, RSI safety criteria,
  preventing accidents
• Ergonomics human-machine-environment interfaces
• use of visual displays for dynamic information
• Designing for lighting systems, industrial
  noise, thermal controls, vibration etc
• Systems analysis the human-machine information
  system
• data capture and processing
• design of the user interface
• Business process re-engineering (BPR)

6
System relationships
Process analysis
Engineer workflows
Design work station information arrangements
Method study
Plant layout
Jobs
Time study
Work breakdowns
Incentive rewards
standard times
7
Nature of the Theory

• organised common sense, human ingenuity
  creation of tools
• functional and assumed to be neutral/unemotional
• critical questioning taking nothing for granted
• focus on efficiencies, utilisation and costs
• predictability and control over quality
• maximise use (utilisation) of compliant labour
  capital - unit costing
• machine economic man vs. social/sentient

Separation of worker from means of production
8
Opposition to Work Study

• All work is different - idiographic vs/
  nomothetic
• Large firm/employer and large engineered systems
  only
• Work study is obsolete
• It is exploitative of workers
• It has never been and never will be accepted here

Is this so? What is the evidence of work study in
the world around you
9
Pioneers of efficiency measurement systems

• Gunpowder manufacture
• Chinese ceramics industry
• Adam Smith observations of French - pin making
• Pioneers of agrarian and industrial revolutions
• Abraham Derby Josiah Wedgwood
• Madame Guillotine, Springfield Rifle
• F W Taylor at Bethlehem Steel work
• Henry Gantt
• Frank and Lillian Gilbreth
• Time and motion study
• Charles Bedaux
• Work measurement

10
Methods, times and systems for performance

• improve methods - get it right
• Method study
• O M Ergonomics
• Industrial systems engineering
• define maintain work standards
• incentive schemes e.g. piece work measured day
  work
• human-computer interface systems analysis
  design
• rationalisation, automation substitution of
  machine technologies for people

Braverman and de-skilling in the labour process
11
Method study

• Select job/process to be examined observe
  current performance
• high process cost, bottlenecks, tortuous route,
  low productivity, erratic quality
• Record document facts
• activities performed
• operators involved - how etc
• equipment and tools used
• materials processed or moved
• apply critical examination - challenge job
  components necessity (purpose, place, sequence,
  method).
• develop alternative methods present proposals
• document as base for new work system
• Install, monitor (slippage) maintain

Process re-engineering? Risk assessment for
safety?
12
ASME Symbols and Process Charting
Operation
Move
Delay
Store
Inspect/ process
Decision
13
Traditional OM critical examination questions

• Purpose
• What, Why, What else might Should be done ?
• Place
• Where, Why, Where else Where should it be done
  ?
• Sequence
• When, Why then, When else could When should ?
• People
• Who, Why, Who else might should do it?
• Method
• How, Why, How else could, How else should

• a sound reason for every activity
• no assumptions so double check
• quality, safety and health must not compromised

14
Other types of process modelling

• multiple activity charts
• string diagrams
• 3-dimensional models
• recording methods - video,etc
• computer-based modeling

15
Measuring Work

• Why define/measure work?
• standard, reliable methods
• control performance quality
• obtain predictability
• defined labour costs performance
• set pay rates provide data for effort-reward
  relationship
• Why set standard times
• assumptions about competent, motivated workers
• be clear about "allowances" fatigue

• Toyota Avensis 10000 mile service
• MOT testing
• Service times queue management
• Banks
• Airline check-in
• Call centres
• Out-sourcing service level agreements
• Work-load balancing
• Work related bonuses

16
Work Measurement

• techniques to establish the time for a qualified,
  motivated worker to carry out a task at a
  defined rate of working.
• time Study
• establish standard times - management knowledge
• rate operator performance - criteria for
  appraisal
• gather information to calculate production
  capabilities data for capacity planning.
• define/cost work content of finished goods and
  services e.g. for charging estimating

17
A Time Study

• select job identify the work tasks
• check the method - is it efficient/agreed?
• start a Time Study sheet break work task into
  "units"
• several times with a stop watch for a sample of
  workers, time measure
• completion times for each unit of work in the job
  sequence
• average for each worker
• determine apply worker effort rating for each
  worker (BSI scale)
• Apply fatigue, personal other allowances
• From the observation data (worker average times)
  calculate standard time for the task
• Assumes set sequence, routine work cycle (all
  workers), little discretion, 100 effort rating -
  trained/qualified, motivated/committed, working
  at normal pace not fatigued
• Fix standard time and enter into measured work
  manual/database

18
Example standard time calculation
19
Incentive Schemes

• What are incentives?
• Effort-reward relationships
• Economic orientation motivation
• Time rates of pay assumptions/requirements
• Piecework
• Measured day work
• Group Schemes
• Incentive scheme problems
• Criticism and prevalence

• cost savings ?
• economy of operation ?
• easily understood ?
• maintain safety standards ?
• equitable to all ?
• control and improve effectiveness standards ?
• common goal ?

20
Process Analysis and BPR

• Management services business process
  re-engineering
• how work is done data for planning, staffing
  control functions.
• applied across a wide range of industrial/commerci
  al activity manufacturing, office, service
  industries, facilities layout, materials
  handling, logistics, IT and IS
• Identify process components interrelationships
  (inputs, processes/transformations, rules,
  outputs, interfaces
• break down the process into its logical sub
  processes (work breakdown structure)
• map using
• process flow charts etc
• describe the business process jobs at sub
  process levels
• document for capacity planning, quality (zero
  defects process orientation, inspection),
  operator intervention, safety, accounting/cost,
  planned maintenance, JIT purposes

Clearly represented in the development and
adoption of on-line computer systems
21
From Work Study to Systems Analysis and Design
22
Analysis, Design, Build Projects
23
System Development Costs
24
Modelling the Information System
Our 'model' of the information system

• Requirements
• information processing functions
• data to store

Input - triggers activities
Output to activities which use the processed
information
Data items
25
Data Flow Modelling (DFDs)

• Data flows across the system boundary within
  the system
• Processes (functions that process data)
• Data stores
• Sources/sinks (external entities)
• Functional decomposition (levels
  modularisation)
• Do not show
• Time (when things happen sequence)
• Decisions (see process specification)
• System boundary
• Diagrams - better than narrative
• CASE tools to draw and record details

26
Context DFD - Level 0
27
Level 1 DFD
28
DFDs - Levelling
Consistency of data flows between levels. Are
the diagrams consistent?
29
Logical Data Modelling

• data captured by the system
• Analyse the data entities, attributes and
  relationships
• Entitiesthings (physical or conceptual) of
  interest that the system needs to store
  information about.
• AttributesThe data items stored in each
  occurrence of an entity
• Relationshipshow the data in one entity may be
  related (for functional purposes) to another)
• Create database schema for developers and DB
  managers
• system processes use the data - jobs,
  calculations, reports
• maintain the access rules, security and integrity
  of the data

30
Events acting on data
applies
interviewed
final accept/reject
enrols/pays
assessed
graduates
leaves

• Identify all processes
• Map against the LDM
• Data updates
• Referential integrity validation
• Menus, screens, reports

31
Example Dabbs plc

• Customers place sales orders
• A single order may contain several products
• Each customer is in one of 500 areas
• Each customer is serviced by one of 6 depots
• Each customer is allocated a depot depending on
  their area location
• All products are stocked at all depots

32
Entity occurrence - 1

• Entity Footballer
• Occurrence David Beckham
• Attributes
• DOB, height, weight, position, skills, goals
  scored, next of kin, address, salary, contract
  dates, sending-offs, number of international caps
• Relationships with
• Games, team sheets, payments, club TV
  appearances, insurance policies, contracts,
  agents, injuries, treatments

33
Entity occurrence - 2

• Entity Patient
• Occurrence Chris Woodhead
• Attributes
• Name, age, address, NHS number, allergies,
  next-of-kin, medical conditions, treatments,
  private health care
• Relationships with
• Treatments, appointments, medical conditions,
  allergies, GP, clinics, medical staff, private
  health payments
