Title: Core Options FUNdamentals Let there be light
1Core Options FUNdamentalsLet there be light
- Using Core Options to enhance and improve your
quality improvement goals
2Agenda
- Set-up
- User Settings
- Facility Settings
- 1400 import file
- Help File
- F1 Key
- Measure Set Definitions
- General Abstraction Guidelines
- Algorithm Letter Assignments
- Import Module
- Abstract Module
- Data Submitter
- Reporting on Data Basics
- Report Module
- Basic Reports
- Export Module
- Basic Exports
- Templates Available
3Tips and Tricks
- Press F1 at any time when you are in a module to
access that portion of the user manual - If you are at the main screen, go to HelpgtTopics
to open the help file - Wherever there is a sign there are chapters
below the topic - Whenever you are on a form with multiple tabs the
exit button is always on the FIRST tab - Access www.coreoptions.com for this general
information. The username is coreclient and the
password is cods2005 - Submission Deadlines
- New Reporter Training Demo
- File Formats
- Web Reporter
- JCAHO Measure Set Definitions
- Data Reporting Requirements
4User Settings
- User Settings
- Always changing where your reports go to?
- Change default report settings
- ToolsgtOptions and SettingsgtUser Settings
- Select the 2nd tab
- Forgot your password
- Facility assigned administrator needs to give you
a new password - You are the administrator ?
- Call us and we can reset your password
5Facility Settings
- Selection of Measure Sets for a Facility
- Add a measure set
- Click on the New Measure Button
- Choose the measure set (Heart Failure) then
system (CMS) - We ask that you enter in each measure set for
EACH system you are collecting for - Another example, is if you will be participating
in BCBS and CMS, you will have 2 entries for CHF - Enable or disable sampling
- Select the 'Allow for Sampling for this measure
- Size is decided in the abstractor module
6Measure Settings
- Enables the user to customize the order of the
questions in the Abstractor module - ToolsgtOptions and SettingsgtMeasure Settings
- Select the performance measure set from the
drop-down menu - To change the order of the questions use the
mouse to highlight the appropriate question - To select consecutive questions, click the first
item, press and hold down SHIFT, and then click
the last item - Use the up and down arrow keys to move them
- The question order is NOT user specific. If you
have multiple users, you will need to get
together as a group to decide on an order, or you
will overwrite each others preferences
7Physician Settings
- Physician settings area allows the user to enter
and maintain basic information on individual
physician into Core Options - The specialty codes represent only the more
common categories and may not match your
specialty codes exactly - You have two options to enter in physician names
and specialties - Option 1 Enter in the name and specialty
manually. Physicians ID numbers contained within
a patient data import file (eg. the 1400 file)
will be copied into the Physician Settings area - Option 2 Create a separate import file
(Physician Demographic File Format 500) and
import in the file - For further information on the physician import
file check out http//www.coreoptions.com/members
/File20Formats.htm - This is a client restricted area. The username
is coreclient and the password is cods2005
8Import Module Import Process
- Select the Import Module
- Select Add Session
- Select Import Type Facility
- 1400 File, Facility ID
- Select Measure To Import
- You Can Select All At Once Or One At A Time
- Identify Date Format Type And Range
- Specific Date Range (Jan 1, 2006 To Jan 7, 2006)
- Monthly Date Range (Jan To Feb)
- Select The Import File
- Select Import The Data File Button
- Import Summary
- Apply Valid Records
9Import Module Troubleshooting records
- Do not capture excluded records
- Will not capture excluded records
- Will save space on network
- Browse/Report Data Tab
- Report vs. Browse
- Report options places them into a formatted
report with limited fields (Measure Set, Name,
Dates of Service and DOB) - Browse options allows you to select which fields
you want to view on screen it does not allow
for printing - New Records Added During Import
- Report Existing Records Not in Import
- Allows for you to see what new records were added
from your last import for this time period - Helpful when doing concurrent abstraction
10Help Screens
- Data Dictionary
- Algorithm Letter Assignments
- Measure Definitions
- General Abstraction Guidelines
- Report Definitions
- Medication Tables
- ICD-9-CM Codes for Focus Areas
- User Manual
11Abstract Module Reports
- Quick Reports
- Upper Right Hand Corner of the Main Abstract
Window - Limits Reports to the Filtered Records Only
- Algorithm letter assignment report
- Basic summary reports
- Error listings
- QID Number
- Core Options generated ID
- Linked to each record and is provided in Excel
feedback reports
12Algorithm Letter Assignments
- You want to become familiar with these letter
assignments to assist you in quality improvement - Each record will be eligible for each indicator
independent of the other. For example, a CHF
record has 4 indicators and will have a chance to
be in each indicator. - (A) - Category A-Missing or Invalid Measure
Population Data - Record contains missing information and is
incomplete - (B) - Category B-Not in Measure Population
- Record is excluded from the indicator and is not
included in rate calculations - An example would be a non-smoker is excluded from
PN-4, AMI-4 or CHF-4 - (C) Category C-Missing or Invalid Numerator Data
- Record is missing information that prevents it
from being assigned as either an E or D - (D) Category D-In Measure Population
- For rate based measures this is a record that
failed the numerator - For continuous variable measures this is a record
that met the initial measure population and will
have a corresponding time value in minutes. - (E) Category E-In Numerator Population
- For rate based measures this is a record that
meet the requirements for the numerator. - (Y) Category UTD Allowable Value Does Not Allow
Calculation of The Measure - For continuous variable measures Date, Time, or
Numeric data element with a value of 'UTD'
13Quick Report
- Run the rate measure summary quick report in the
Abstract Module to check for trends PRIOR to
submission to MHA - Allows for trending information at point of
abstraction - Provides abstractors the ability to look at
outliers most useful for continuous variable
measures
14Continuous Variable vs. Rate
- Continuous Variable Measures
- PN-5, AMI-7 and AMI-8
- Report the measurement value () for a clinical
process anywhere along a continuous scale - Measure Category Assignment always equal to D
- Measure Category Assignment of B excludes the
record from the indicator - Rate Based Measures
- All other indicators
- Describe the frequency () with which a clinical
event has occurred in a given patient population - Measure Category Assignments are D and E
- Numerator cases E
- Cases that fail the numerator have a D
- Rate is the number of E/(DE)
15Rate Based Reports
- PN-6 is a rate based measure
- Measure Category Assignments are D and E
- Numerator cases E
- Cases that fail the numerator have a D
- Rate is the number of E/(DE)
- Example
- Numerator is the number of records with a letter
assignment of E - Denominator is the number of records with a
letter assignment of D E - The difference between the two gives you the
number of records that failed to meet the
numerator or those with a letter assignment of D
16Continuous Variable vs. Rate Based Example
Antibiotic Timing (PN-5)
- PN-5 is a Continuous Variable Statement The
time, in minutes, from hospital arrival to
administration of first antibiotic for inpatients
with pneumonia. - PN5-A (Rate Based)
- Initial antibiotic received within 8 hours of
hospital arrival - PN5-B (Rate Based)
- Initial antibiotic received within 4 hours of
hospital arrival - PN5-C (Rate Based)
- Initial antibiotic received within 6 hours of
hospital arrival
17Continuous Variable Reports
- PN-5 is a continuous based measure
- Example
- Total Cases Number of records with a D
- Minimum/Maximum Record with the lowest/highest
time in minutes to initial antibiotic - Mean The average of all the total cases
- Median Core Options sorts the total cases and
picks the number in the middle (in the Jan. 2005
example it is returning the middle value of 15th
and 16th record. In the Feb 2005 example it will
return the value of the 15th record.) - Std. Dev Standard Deviation is a statistical
calculation of the sum of the total cases minus
the mean of all the cases divided by the number
of cases -1
18Using Core Options
- Report Module
- Run a JCAHO Summary Report each quarter
- Build Control Charts for presentations
- Run Individual Reports
- Use multi-level report capability
- Physician
- Admit Source
- Time to First Antibiotic Variables
- Export Module
- Identify Patient Level Trends
- Customize Reports
- Web Reporter
- JCAHO Comparative Data
19Report Module Basics
- Provides Rates Only No Patient Identifiers
- Summary Reports
- One Page Summaries
- Limited to One Level
- Applying Filters
- Use of Physician Specialties
20Report Module
- Summary Reports
- Available for each measure set
- Located at the bottom of the individual report
list - BC Summary
- For Michigan Clients participating in the Blue
Cross and Blue Shield Incentive Program - CMS/JCAHO Summary
- Will create a report that lists each indicator on
one spreadsheet
21Advanced Reporting
- Individual Reports
- Multi-level reports
- Attending Physician
- Source of Admission
- Filters
- Admit Source Equal to 7-Emergency room and Time
to First Antibiotic greater than 241 and less
than 481 - Series Reports
- Create a batch of reports
22Series Filter
- Series Filter
- Used best when running multiple reports in a
group, for example all PN reports, and you want
all the reports to have the same filter - For example, you want to run all PN reports for
just the emergency room - You could apply a report filter to EACH report in
the series looking at where Admission Source
equal to 7 OR - You could apply ONE series filter where
Admission Source equal to 7
23Series Reports
- Series Reports
- You can select multiple reports to run to one
workbook - Each report will have its own page
- Allows you to send one file to a workgroup or
physician - You can save the report to run as a series
- Saves filters and report levels
- Change the date and go
24All reports by physician
- Select the All HF Measures from the upper left
hand corner of the report module - Each measure set has its own group of reports so
you dont have to select each one individually - Click Run Selected Report
- On the Report Settings Tab you need to set EACH
report in the series to a two level report with
the first level being Physician-Attending and
the second is defaulted to Time Period - Save the report series with a name and click the
Save as New Series button - Click on the Report Output tab and select to
Excel
25What you get
- Once saved all you have to do is select the
report series from the upper left hand corner. - Changes the dates and go
26Example Saved Series
- This is a saved report we named Right Antibiotic
within 4 hours - Within each report we will create and save the
following filter statements that can be used
later - Run the PN-5 and PN-6 reports with the following
filters - PN-5a and PN-5b
- Where the PN-6a or PN-6b letter assignment is
equal to E - PN-6a and PN-6b
- Where Time to First Antibiotic is less than 241
27Step-by-Step Instructions
- Open the Report Module
- Select the following reports by double-clicking
on the report - PN-5a, PN-5b, PN-6a and PN-6b
- Select Run Selected Report
- Report Settings Tab
- Provide a name for the report in the Series Name
dialog box in the upper left hand corner - Set Report Filters
- Each report needs its own filter
- Select each report in the Report Settings Tab
- Report Filter for PN6 Reports Time to First
Antibiotic (Cont Var.) Less Than 241 - Report Filter for PN5 Reports PN-6a Letter
Assignment (Pntrnicu) Equal to E OR PN-6b Letter
Assignment (Pnicu) Equal to E
28Checking outliers
- After submission to MHA and hopefully prior to
the submission deadline for that quarter run the
following export to Excel - Pneumonia
- Recommended dataset Medical Record Number,
Account Number, Discharge Date, Physician
Attending, Time to First Antibiotic (Cont Var),
Antibiotics, Arrival Date, Arrival Time, PN-6A
and PN-6B letter assignments - Filter Statement for the value of PN-5 Letter
Assignment (Pnantib) equal to D and Time to First
Antibiotic (Cont Var) greater than 241and PN-6A
or PN-6B equal to D
29Step-by-Step Instructions
- Open the Export Module
- Select Pneumonia
- Set time frame
- Select fields to export
- Recommended data set Medical Record Number,
Account Number, Discharge Date, Physician
Attending, Time to First Antibiotic (Cont Var),
Antibiotics, Arrival Date, Arrival Time, PN-6A
and PN-6B letter assignments - Items on the left are fields that are relevant to
the pneumonia measure set - To select the fields move them to the right
- You can save this field list for future use by
clicking on the Save as Field List and giving it
a name - Create a report filter
- You can save this filter statement for future use
by clicking on the Save as Filter and giving it a
name - Select order
- Create export
- DBF Browse is just a really technical way to see
to the screen
30You have got to be kidding
- Your filter statement should look like this
- By default items are grouped with an And
statement. To add an Or variable, click in the
Or column. - You can add parentheses by double clicking in the
second column
31Data Submitter
- Select Time Frame
- Select Measure Set
- Add to Packet
- Repeat till all measure sets have been added
- Encrypt and Compress Data
- Click on the link to go to the Data Submission
Web Site - Using your keyboard select the CTRL-V keys
together to paste the file location into the
white dialog box - Click on the Upload Data Button
- Click on the Please wait Button
32Submission Feedback Reports
- Will receive the feedback reports within 24-48
hours - Delays may occur the closer to the deadline
- Consist of 3 tabs
- First tab is a summary tab
- Second tab is a letter assignment tab
- Third tab will contain any edits that remain that
you need to review - Feedback reports do not contain any patient
identifiers. - Type or paste the QID number into the Find button
in the main abstract module after selecting the
right measure and time frame
33CHF-1 Template Instructions
- We have developed a template for those records
that have failed the CHF-1 indicator. To perform
the export needed for the template you need to - Select Heart Failure
- Chose your fields Recommended dataset - Medical
Record Number, Account Number, Discharge Date,
Physician Attending, All Discharge Instructions
Question Answers - Filter Statement for the value of HF-1 Letter
Assignment (Hfdischins) equal to D - Copy your export into our template and then sort
the resulting summary
34Differences between Core Options Reporter and
Web Reporter
- Core Options Reporter
- Real time data reporting
- Ability to produce complex multi-level reports
- Filtering capability enhanced by the ability to
save queries for future use in the exporter - Summary reports for JCAHO/CMS measure sets
- Web Reporter
- Core Options Web Reporter can be accessed from
the Help menu - HelpgtCore Options on the Web
- Comparison data from JCAHO and Core Options
released quarterly - Limited filters available only in trending and
Core Options comparative reports - Reports are limited to indicators
35Web Report Types
- JCAHO Comparative Data
- Individual reports only
- Comparative data received directly from JCAHO
- Core Options Comparative Data
- Both individual and summary reports
- Only data from Core Options Clients
- Trending Data
- Your own data
- Limited filtering capability
- Recommend limited use
36Measure Builder
- The intent of the Measure Builder Module is to
- Provide a means to gather data and information to
develop a custom measure. - Generate reports on the data for supporting
continuous quality improvement activities.
37Measure Builder Overview
- New Measure Set
- Filter Criteria
- Mortality
- Define population
- Outcomes
- Inclusions
- Exclusions
- Existing Measure Set
- Process Steps
- CHF Order Set
38Existing MeasureStandard Question Type
- Step by Step Instruction
- ToolsgtOptions and SettingsgtMeasure Builder
- Enable Core Measures
- Select Embedded Measure Set
- Click Next
- Add Question
- Select Optional, Required or Preferred
- Select Question Type
- Click Next
- Select Questions for Abstraction
- Move question from left to right
- Exit Measure Builder
- Enable Custom Measure Set in Facility Settings
39Existing MeasureCustom Question Type
- Step by Step Instruction
- ToolsgtOptions and SettingsgtCustom Look-Up
- Add Choice
- Add Items
- Exit Look-Up Module
- Go to Measure Builder
- Enable Core Measures
- Add Question
- Select Optional, Required or Preferred
- Select Single Answer Drop-Down Type
- Select Look-Up Choice
- Select Questions for Abstraction
- Exit Measure Builder
- Enable Custom Measure Set in Facility Settings
40Custom Question Type
- Step by Step Instruction
- ToolsgtOptions and SettingsgtCustom Look-Up
- Add Choice
- Unit
- Add Items
- Unit 1
- Unit 2
- Unit 3
- Unit 4
- Other
41Custom Measure
- Step by Step Instruction
- Data Element Worksheet
- Define Measure Set
- Define Questions and Reponses
- Define custom look-up choices
- Define criteria for measure set
- Add questions
- Select for abstraction
- Enable custom measure set
42Mortality
- Add Measure
- Select Add New
- Provide name and description
- Select next
- Filter Statement
- Select next
43Add Mortality Review
- Go to Facility Settings
- ToolsltOptions and Settings
- Add Measure
- Select mortality review
- Decide if you want to sample
- Import Data
- Will import only those records with a discharge
status equal to 20
44Abstracting Custom Measure Sets
- Practice, Practice, Practice.
- Use the blank abstraction tool first to work out
any process differences - Using Report Module
- Custom Numerator and Denominator
- Rate of CHF deaths
- Using Export Module
- Pull lists
45Resources
- Core Options Home Page
- Core Options Resource Page
- Reporter Training Project
- Data Reporting Requirements
- On-Line Client Access Page
- Username coreclient
- Password cods2005
- Data Page
- Quartile Reports
- Web Reporter Guide
- Data Submission
- How to Read a Control Chart
- Support Page
- Reporter Demo
- Submission Deadlines
46Questions?
Teresa Osieczonek E-mail tosieczonek_at_mha.org P
hone (517) 886-8399
Laurie Morris E-mail lmorris_at_mha.org Phone
(517) 886-8209
