Sanjay Gandhi Postgraduate Institute of Medical Sciences

1
Sanjay Gandhi Postgraduate Institute of Medical
Sciences
Lucknow
2
Department of Cardiovascular Thoracic
SurgeryandTelemedicine network at SGPGIMS
Welcomes participants in this presentation
3
"Birth defect of Heart, its Presentation and
Treatment"

• Nirmal Gupta
• Head
• Department of Cardiovascular and Thoracic Surgery
• SGPGIMS, Lucknow. U.P.

4
Magnitude Birth defects of Heart in India

• Every year 2 lakh children are born with
  congenital heart defects
• At least 60,000 of these need treatment in the
  1st year of life
• Only 5000 get treatment because of lack of
  awareness amongst public in general and GPs
  delayed diagnosis
• Poor socio-economic status of families delayed
  treatment

5
Current facilities

• Requires highly trained and dedicated team of
  diagnostic facilities, Surgeons and Nurses
• Poor availability of facilities even in best
  hospitals
• Not a financially viable option for private
  setups
• Lack of trained manpower in the country (only 5
  dedicated units other than SGPGIMS)

6
SYMPTOMS

• "Birth defects of Heart, its Presentation and
  Treatment"

7

• Neonatal History
• Cyanosis
• Failure to thrive
• Exercise intolerance
• Shortness of breath
• Syncope
• Palpitation
• Chest pain

8
NEONATAL HISTORY

• Cyanosis, shortness of breath.
• Did the child need to stay in the hospital after
  maternal discharge?

9

• Neonatal history
• Cyanosis
• Failure to thrive
• Exercise intolerance
• Shortness of breath
• Syncope
• Palpitation
• Chest pain

10
CYANOSIS

• gt 5g/dl of deoxygenated Hb
• False positive........... polycythemia
• False negative...........anemia
• Pathophysiology leading to cyanosis
• Obstruction of systemic venous blood flow to the
  lungs
• Shunting of deoxygenated blood to left heart
• Desaturation of systemic arterial blood

11

• Neonatal history
• Cyanosis
• Failure to thrive
• Exercise intolerance
• Shortness of breath
• Syncope
• Palpitation
• Chest pain

12
FAILURE TO THRIVE

• Poor cardiac output and increased myocardial
  energy consumption coupled with poor feeding due
  to S.O.B.

13

• Neonatal history
• Cyanosis
• Failure to thrive
• Shortness of breath
• Exercise intolerance
• Syncope
• Palpitation
• Chest pain

14
EXERCISE INTOLERANCE

• Baby................ poor ability to suck and
  feed
• Child.................sedentary
• Pathophysiology leading to exercise intolerance
• Poor cardiac output.
• Increased energy consumption by an overworked
  heart.

15

• Neonatal history
• Cyanosis
• Failure to thrive
• Exercise intolerance
• Shortness of breath
• Syncope
• Palpitation
• Chest pain

16
SHORTNESS OF BREATH

• Some children may be short of breath without
  appearing in distress "Happily tachypnoec"
• Pathophysiology of S.O.B.
• Increase pulmonary blood flow
• Interstitial edema
• Decreased oxygen diffusion
• Hypoxemia

17

• Neonatal history
• Cyanosis
• Failure to thrive
• Shortness of breath
• Exercise intolerance
• Syncope
• Palpitation
• Chest pain

18
SYNCOPE

• Pathophysiology
• Inability to increase cardiac output suddenly due
  to restricted left ventricular outflow, e.g.
  severe aortic stenosis, IHSS.
• Abnormal vasomotor tone resulting in
  vasodilatation when vasoconstriction is needed to
  maintain adequate blood pressure.

19

• Neonatal history
• Cyanosis
• Failure to thrive
• Exercise intolerance
• Shortness of breath
• Syncope
• Palpitation
• Chest pain

20
PALPITATION

• Pathophysiology
• Irregular rhythm
• Tachycardia
• Awareness of normal rate and rhythm.

21

• Neonatal history
• Cyanosis
• Failure to thrive
• Exercise intolerance
• Shortness of breath
• Syncope
• Palpitation
• Chest pain

22
CHEST PAIN

• Rarely cardiac in origin.
• Look for extra cardiac causes
• Skin,
• Musculoskeletal,
• Costochondral joints,
• Pleural membranes,
• Pericardium,
• Referred pain

23
SIGNS

• "Birth defects of Heart, its Presentation and
  Treatment"

24
SIGNS

• Inspection
• Palpation
• Auscultation

25
INSPECTION

• Does the child appear ill?
• Decreased tissue oxygenation due to poor cardiac
  output or severe cyanosis
• Respiratory distress due to pulmonary edema or
  hypoxemia.
• Cyanosis
• Edema
• Distended neck veins due to increased right heart
  pressure leading to systemic venous congestion
• Clubbing of digits
• Chronic peripheral tissue hypoxemia

26
SIGNS

• Inspection
• Palpation
• Auscultation

27
PALPATION

• Peripheral perfusion, normal 1-2 seconds.
• Reflection of cardiac output.
• FABA,
• Normal full
• Diastolic runoff bounding
• Poor stroke volume thready

28
PALPATION ( Contd.)

• Precordium
• Increased cardiac output, ventricular hypertrophy
  hyperactive
• Highly turbulent blood flow thrill
• Indicators of ventricular hypertrophy or atrophy
  RV, LV impulses
• Aortic stenosis, turbulent blood flow in
  ascending aorta Suprasternal notch thrill?
• Hepatomegaly, check below right and left costal
  margins.

29
SIGNS

• Inspection
• Palpation
• Auscultation

30
AUSCULTATION

• LUNGS
• Pulmonary edema rales, crackles
• HEART
• First heart sound (S1)
• Closure of atrio-ventricular valves.
• Second heart sound (S2)
• A2 closure of aortic valve
• P2 closure of pulmonary valve
• Single S2 absent pulmonary or aortic component
  or delayed closure of A2 superimposing P2
• inaudible P2 in TGA
• Does the splitting of S2 vary with respiration?
• Added sounds
• Gallop rhythm S3, S4

31
AUSCULTATION (Contd.)

• Murmurs
• Grade 1-6, one being the softest and six being
  the loudest.
• By definition grade four murmur is associated
  with a palpable thrill.
• Systolic murmur
• Holosystolic
• Shunting of blood between two structures , the
  pressure in one structure is higher than the
  other throughout systole
• Harsh VSD
• Soft Atrio-ventricular valve regurgitation
• Ejection
• Increase in blood flow turbulence as systole
  progresses due to an increasing amount of blood
  flow through a restricted orifice
• Aortic stenosis
• Pulmonary stenosis
• Small VSD

32
AUSCULTATION (Contd.)

• Mid-systolic
• Increase volume of blood flowing through normal
  valves
• ASD
• Anemia
• Diastolic murmur
• Early
• Regurgitant blood flow from aorta or pulmonary
  artery into the ventricles
• Aortic insufficiency
• Pulmonary insufficiency
• Late
• Austin Flint murmur
• Aortic regurgitation blood flow causes vibration
  of left ventricular free wall
•
•  Systolic and diastolic murmur
• Pressure difference between two structures during
  systole and diastole.
• PDA Shunts and collaterals

33
Congenital Heart Diseases and their Treatment

• "Birth defects of Heart, its presentation and
  treatment"

34
Normal heart and its ECHO
35
Atrial Septal Defect ASD
36
Coarctation of aorta
37
Ventricular Septal Defect VSD
38
Patent Ductus Arteriosus PDA
39
Pulmonary Stenosis PS
40
Aortic Stenosis AS
41
Atrio-Ventricular Canal A-V Canal Defect
42
Tetralogy of Fallot TOF
43
Transposition of Great Arteries TGA
44
Transposition of Great Arteries D-TGA
45
Truncus arteriosus Truncus
46
Tricuspid Atresia TA
47
Pulmonary Atresia PA
48
Total Anomalous Pulmonary Venous Drainage TAPVD
49
Hypoplastic Left Heart Syndrome HLHS
50
Ebsteins Malformation Ebsteins
51
General guidelines

• At birth
• Blueness at birth or immediately after
• Murmur of the heart
• Rapid breathing
• Low blood pressure

52
General guidelines

• At 2 6 months
• Difficulty in feeding- baby is unable to suck
  properly, sweats or starts rapid breathing while
  feeding
• Blue nails and toes and fainting spells
• Inadequate weight gain
• Recurrent chest infections

53
General guidelines

• In first 3 years of life
• Fainting spells
• Abnormal heart beats
• Child avoids rigorous activities
• Unable to play with his mates

54
General guidelines for couples

• Drugs to avoid during pregnancy
• Strict NO to Isoretinoin, Thalidomide,
  Estrogens, Oral contraceptives, ACE inhibitors,
  Chloramphenicol, Chlorpropamide, Erythromycin,
  Tetracycline and Haloperidol.
• Anti-cancer drugs and Phenytoin are harmful but
  benefits outweigh the side effects.
• Epinephrine, Ephedrine, B-blockers and
  Promethazine do not pose any significant risk,
  though the research is inadequate

55
In the end

• There are a million times more patients in India
  with congenital heart diseases than polio, but
  the governments budget for the treatment of
  congenital heart diseases is miniscule in
  comparison

56

• .so the gap is of more than billions magnitude

57
Thanks for your attention friends
Can I have your questions, please.
