Application of bibliometric analysis Thed van Leeuwen CWTS Leiden University

1
Application of bibliometric analysisThed van
LeeuwenCWTSLeiden University

• DAIR-Workshop, 5 november 2008

2
Contents

• Introduction of CWTS and bibliometrics
• Part I Various databases
• Differences between Web of Science and Scopus
• Adequacy of citations indexes
• Part II Various indicators one can encounter
• ISI Impact Factors calculation and validity
• International rankings
• The H-index and its limitations
• Part III Various methodological issues
• Journal field normalization
• Citation Windows Impact Measurement
• Typology of the studies
• Methodology of the studies

3
Introduction of CWTS and bibliometrics
4
Introduction of CWTS

• CWTS is a research institute at Leiden University
  Faculty of Social Sciences.
• CWTS is/was based mainly on contract research,
  but still produces roughly 10 papers in
  scientific journals per year.
• Currently in a transformation process, based on a
  mix of public funding and contract research,
  focused on both fundamental research in the field
  and service contracts.

5
The work of CWTS

• CWTS conducts from the early 1990s large scale
  bibliometric research performance analyses that
  accompany research assessments by review
  committees
• Many of these studies had a disciplinary
  character, initiated by the VSNU.
• A revision of the evaluation protocol (SEP) in
  2003 caused a shift of the analyses to
  university- or institute-initiated studies.

6
Introduction of bibliometrics

• Bibliometrics can be defined as the quantitative
  analysis of science and technology performance
  and the cognitive and organizational structure of
  science and technology.
• Basic for these analyses is the scientific
  communication between scientists through (mainly)
  journal publications.
• Key concepts in bibliometrics are output and
  impact, as measured through publications and
  citations.
• Important starting point in bibliometrics
  scientists express, through citations in their
  scientific publications, a certain degree of
  influence of others on their own work.
• By large scale quantification, citations indicate
  influence or (inter)national visibility of
  scientific activity.

7
CWTS data system

• CWTS has a full bibliometric license from Thomson
  Reuters Scientific to conduct evaluation studies
  using the Web of Science
• Our database covers the period 1981-2007.
• Some characteristics
• 27.000.000 publications
• 500.000.000 million citation relations between
  source papers
• 48.000.000 authors (incl variations)
• 28.000.000 million addresses, some 90 cleaned up
  over the last 10 years.
• Contains reference sets for journal and field
  citation data

8
Part IVarious databases
9
Differences between Citation Indexes
implications for bibliometric studies

• Martijn S. Visser and Henk F. Moed

10
Multidisciplinary Citation Indexes

• Web of Science
• since 1963, formerly produced by ISI
• ca. 9,000 Journals are indexed

• Scopus
• launched by Elsevier in 2004
• ca. 15,000 journals, conf papers and other

• Google Scholar
• launched in 2004
• coverage unclear

11
Disciplinary distribution of journals in WoS

• Roughly 5.000 journals from natural-, life-,
  medical- and technical sciences.
• Roughly 2.500 journals from the social- and
  behavioral sciences.
• Roughly 1.500 journals from the humanities.

12
Contents

• Comparing Web of Science and Scopus on a paper by
  paper basis
• RAE 2001 Coverage differences in a practical
  situation
• Implications for bibliometric studies case study
  in the field of oncology (SCImago)

13
Comparing WoS Scopus

• Time period 1996 2006
• Snapshot in time
• Only citeable documents
• Matching algorithm

14

Matching WoS with Scopus on a paper by paper basis
Scopus
Intersection 9.4 M
15
I From a WoS perspective

• To what extent are citeable documents (articles,
  letters, notes and reviews) in journals processed
  for the WoS covered by Scopus?

16
Scopus coverage of WoS papers increases over time
17
Incomplete coverage of WoS journals decreases
over time
In 2005 82 of WoS journals were completely
covered in Scopus
In1996 55 of WoS journals were completely
covered in Scopus
WoS Journals
WoS journals not covered by Scopus at all
18
II From a Scopus perspective

• To what extent are citeable documents (articles,
  notes, letters, reviews, conference papers) in
  sources processed for the Scopus not covered by
  Web of Science? (Scopus Surplus)

19
NATURAL AND LIFE SCIENCES
20
ENGINEERING SCIENCES, SOCIAL SCIENCES HUMANITIES
21
III From an external perspective

• To what extent are documents in an external file
  processed for the WoS and/or Scopus?

22
Coverage differences in a practical case 2001
RAE papers

• Up to 4 publications of every active faculty
  staff member
• Time Period 1994/1996 2000
• Papers assigned to units of assessment

23
Only small overall coverage differences
24
Coverage differences for Units of Assessments
(Sciences)

• Scopus WoS gt 3
• Nursing
• Clinical Dentistry
• Civil Engineering
• Other Studies and professions allied to Medicine
• Computer Science
• Mineral and Mining Engineering

• Wos Scopus gt 3
• Pharmacology
• Food Science and Technology
• Physics
• Anatomy

25
Why are the differences relatively small?

• Best papers are more likely to be published in
  high impact journals which tend to be processed
  by both indexes
• British academics may not often use sources
  solely processed by Scopus

26
Need to characterize the surplus coverage of
Scopus

• Geographical location
• Language
• References
• Citedness

27
Case study for journals in Oncology

• Cooperation between SCImago and CWTS (Carmen
  Lopez Illescas)
• Comparison between Scopus and Web of Science
• Comparison on a journal-by-journal basis

28
Overlap from a WoS perspective
29
Overlap from a Scopus perspective
30
Characterization of Scopus surplusLanguage and
Publisher country
31
Characterization of Scopus surplusother
journal properties
32
Main characteristics Scopus surplus

• More journals in non-English languages
• More recently established
• Less often refereed
• Relatively low impact factors

33
Implications for bibliometric studies

• Web of Science tends to select only journals with
  sufficient high impact (research front)
• Scopus tends to be more representative of the
  total of scientific literature
• The position of the Western World in Scopus is
  probably less dominant

34
Strong relationship between nr WoS and Scopus
papers for the 50 most productive countries
35
Average Citation rate in WoS and Scopus for the
50 most productive countries
36
Negative relationship between number of papers in
Scopus surplus and average citation rate
37
Effect of Scopus surplus

• Countries that profit most in terms of percentage
  of published documents tend to show a decline in
  their average citation rate
• Keeping in mind the RAE outcomes, the effect of
  the extension is also that the countries
  publishing relatively often in non-English
  journals, show a decline in their average
  citatioin rate
• Conclusion More is not necessarily better !

38
Discussion

• Citation indexes (will) adopt a more inclusive
  coverage policy in which citation impact is less
  important as a criterion for selection.
• This will have implications
• for the way bibliometric assessments of research
  performance have to be carried out
• for the interpretation of bibliometric
  indicators and rankings derived from these
  databases

39
Discussion

• Should bibliometric studies aim for widest
  possible coverage?
• - It depends on what you want to measure.

• How should one deal with possible bias as a
  result of changing coverage policies?

• Define sub-universes (journal sets) of
  publications and citations (e.g. national
  /international)

40
Adequacy of citation indexes implications for
bibliometric studies
41
How to tackle this issue ?

• We conduct analyses on the adequacy of the
  citation indexes across disciplines based on
  reference behavior of researchers themselves.
• The degree of referring towards other indexed
  literature indicates the importance of journal
  literature in the scientific communication
  process.

42
The medical Life sciences
43
The natural sciences
44
The technical sciences
45
The social and behavioral sciences
46
The humanities
47
Overall WoS coverage by main field
48
Conclusions on adequacy issue

• We can clearly conclude that the application of
  bibliometric techniques, solely based on WoS (but
  very likely also Scopus) will not be valid for
  some of the soft fields in the social sciences
  and the humanities.
• That is why the tool box has to be extended !

49
Part IIBibliometric indicators one encounters
in the field
50
Some basic indicators are

• P number of publications in journals processed
  for the Web
• of Science.
• C number of received citations, excl.
  self-citations.
• CPP mean number of citations per publication,
  excl. self-
• citations
• Pnc percentage of the publications not cited
  (within a
• certain time-frame !!!)
• SC percentage self-citations related to an
  output set.

51
ISI Impact Factors calculation and validity
52
Methodology ISIs classical IF

• The ISI Impact Factor (IF) is defined as the
  number of citations received by a journal in year
  t, divided by the number of citeable documents in
  that same journal in the years t-1 and t-2,

• Or, as a Formula

Citations in year t Number of
citeable documents in t-1 t-2
53
Practical exercise on IF

• Here we get to the first practical exercise of
  the afternoon
• Read the Science commentary on Impact Factors.
• Calculate the Impact Factor for the Lancet
• Discuss the results.

54
Share citations-for-free for The Lancet

• ISI Method
• Citations in 2000 .
• Citeable documents in 98 and 99
• 14037 (c)
• 957 (a)

• Publications Citations
• 9091 1992
• Article 784 2986
• Note 144 593
• Review 29 232
• Sub-total 957 (a) 7959 (b)
• Letter 4181 4264
• Editorial 1313 905
• Other 1421 909
• Total 7872 14037 (c)

IF14.7

• CWTS Method
• Citations to Art/Not/Rev in 2000 .
• Art/Not/Rev in 98 and 99
• 7959 (b)
• 957 (a)
• Citations to Art/Let/Not/Rev in 2000 .
• Art/Let/Not/Rev in 98 and 99
• 79594264 .
• 9574181

IF8.3
IF2.4
55
ISI Impact Factors

• From 1995 onwards CWTS has analyzed the uses and
  validity ISI Journal Impact Factor (IF).
• Most important points of criticism were

• Calculated erroneously.

• Not sensitive for the composition of the journal
  in terms of the document types.

• Not sensitive for the science fields a journal is
  attached to

• Based on too short citation windows.

56
Distribution of citations used for the
calculationof the IF value of The Lancet

• The red area indicates citations for free,
  while the blue area indicates correct citations

• The IF-score of The Lancet is seriously
  overrated by the scientific audience of the
  journal.

57
Impact Factoren voor Br. J. Clin. Pharm. en Clin.
Pharm. Ther.

• The graph shows the correct and erroneous impact
  factors of BJCP and CPT

• In the case of CPT, citations to published
  meeting abstracts are included, while BJCP has
  stopped publishing of meeting abstracts !

58
Document types and fields
Field Journal IF JFIS
The IF is for 02, JFIS covers 98-02
59
Fields and Citation windows
60
Citation measurement of IF

• 1999 2000 2001 2002 2003 2004
  2005 2006

• 1999
• 2000
• 2001
• 2002
• 2003
• 2004
• 2005
• 2006

1999 2000 2001
2000 2001 2002
2001 2002 2003
2002 2003 2004
2003 2004 2005
2004 2005 2006
2005 2006
2006
61
CWTS answer to the problems of the IF

• This indicator is the JFIS, the Journal-to-Field
  Impact Score.
• The JFIS solves the problems of the Impact
  Factor, as
• the calculation of JFIS is based on equally large
  entities,
• document types are taken into account,
• JFIS is field-normalized, and finally,
• based on longer citation windows (1-4 years)

62
Citation measurement of JFIS
Citation-window 1999 2000 2001
2002 2003 2004 2005 2006

• 1999
• 2000
• 2001
• 2002
• 2003
• 2004
• 2005
• 2006

1999 2000 2001 2002 2000 2001
2002 2001 2002 2002
2000 2001 2002 2003 2001 2002
2003 2002 2003 2003
2001 2002 2003 2004 2002 2003
2004 2003 2004 2004
2002 2003 2004 2005 2003 2004
2005 2004 2005 2005
2003 2004 2005 2006 2004 2005
2006 2005 2006 2006
63
Practical exercise on journal impact measures

• Here we get to the second practical exercise of
  the afternoon
• Consider the application of journal impact
  measures in evaluation procedures, and try to
  think of possible advantages/disadvantages.
• Discuss the results.

64

• Topic within the Netherlands, research
  performance evaluation studies are performed on a
  regular basis.

• The Dutch Pediatrics Society (NVKG) evaluated the
  Dutch pediatric centers on the basis of mean IF
  values related to their output.

• CWTS was asked to benchmark this method, in order
  to indicate possible flaws of the used method.

65
Results Case II Different measures, different
conclusions
--------------------------------------------------
--------------------------------------------------
--------------------------------------------------
AMC WKZ ERAS AZL -------------------------------
--------------------------------------------------
--------------------------------------------------
------------------- ENDOCRINOLOGY 28 / 1.86 46 /
2.23 64 / 2.21 23 / 1.22 GASTROENTEROL 35 /
2.64 IMMUNOLOGY 31 / 4.38 82 / 3.24 46 /
2.94 ONCOLOGY 61 / 2.39 42 / 2.11 METABOLISM
178 / 2.36 72 / 2.06 23 / 1.45 -----------------
--------------------------------------------------
--------------------------------------------------
-------------------------------
Output vs. IF
--------------------------------------------------
--------------------------------------------------
--------------------------------------------------
--- AMC WKZ ERAS AZL ----------------------------
--------------------------------------------------
--------------------------------------------------
------------------------- ENDOCRINOLOGY 28 /
0.71 46 / 1.25 64 / 1.25 23 / 0.59 GASTROENTEROL
35 / 1.35 IMMUNOLOGY 31 / 1.78 82 / 1.10 46
/ 1.10 ONCOLOGY 61 / 1.23 42 /
1.06 METABOLISM 178 / 0.80 72 / 0.87 23 /
0.53 ---------------------------------------------
--------------------------------------------------
--------------------------------------------------
--------
Output vs. JFIS
--------------------------------------------------
--------------------------------------------------
--------------------------------------------------
AMC WKZ ERAS AZL -------------------------------
--------------------------------------------------
--------------------------------------------------
------------------ ENDOCRINOLOGY 28 / 0.38 46 /
1.22 64 / 1.25 23 / 0.73 GASTROENTEROL 35 /
0.98 IMMUNOLOGY 31 / 1.22 82 / 1.17 46 /
0.97 ONCOLOGY 61 / 1.40 42 / 1.09 METABOLISM 17
8 / 0.88 72 / 0.88 23 / 0.27 --------------------
--------------------------------------------------
--------------------------------------------------
-----------------------------
Output vs. Actual Field-Normalized Impact
66
International rankings of university performance
67
Various academic rankings

• ARWU or Shanghai Ranking
• Thes Ranking
• CHE Excellence Ranking
• CWTS University Ranking

68
Composition of Shanghai ranking

• Nobel prizes and field medals by alumni 10.
• Nobel prizes and field medals by staff 20
• Highly cited staff in 21 disciplines 20
• Articles published in Nature Science 20
• Articles published in citation indexes 20
• Per capita performance on those indicators 10

69
Composition of THES ranking

• Academic peer review 40.
• Employer review 10
• Faculty Student ratio 20
• Citation per faculty 20
• International faculty 5
• International students 5

70
Composition of CHE ranking

• Size indicator output volume in citation
  indexes.
• Perception indicator citations (in relation to
  an international standard)
• Beacon indicator Number of often-cited staff
  Nobel prize winners at the university
• Europe indicator number of projects in the Marie
  Curie research promotion programme of the EU
• No weights are indicated, rankings are applied on
  four fields (biology, chemistry, mathematics,
  physics), data delivered by CWTS.

71
Important CWTS standard indicators

• CPP/JCSm ratio between real, actual impact, and
  mean journal impact.
• CPP/FCSm ratio between real, actual impact, and
  mean field impact.
• JCSm/FCSm ratio between journal impact, and
  field impact, indicative for the quality of the
  journal package in the field

72
Composition of CWTS ranking

• Yellow ranking by size, the number of
  publications.
• Green ranking by size-independent,
  field-normalized citation impact (Crown
  indicator).
• Orange ranking by the size-dependent brute
  force impact indicator, the multiplication of P
  with the universitys field-normalized average
  impact
• Blue ranking by the simple citations-per-public
  ation indicator (CPP) 0
• Pink ranking by the simple citations-per-publica
  tion indicator (CPP) for the top-50 ranking
  institutes on size !

73
Practical exercise on rankings

• Here we get to the third practical exercise of
  the afternoon
• Which disadvantages can you think of, when
  considering the indicators used in the various
  rankings ?
• Discuss the results.

74
The H-Index and its limitations
75
The H-Index, defined as

• The H-Index is the score that indicates the
  position at which a publication in a set, the
  number of received citations is equal to the
  ranking position of that publication.
• Idea of an American physicist, J. Hirsch, who
  published about this index in the Proc. NAS USA.

76
Examples of Hirsch-index values

• Environmental biologist, output of 188 papers,
  cited 4,788 times in the period 80-04.
• Hirsch-index value of 31
• Clinical psychologist, output of 72 papers, cited
  760 time sin the period 80-04.
• Hirsch-index value of 14

77
Problems with the H-Index

• For serious evaluation of scientific performance,
  the H-Index is as indicator not suitable, as the
  index
• Is insensitive to field specific characteristics
  (e.g., difference in citation cultures between
  medicine and other disciplines).
• Does not take into account age and career length
  of scientists, a small oeuvre leads necessarily
  to a low H-Index value.

78

• Actual versus field normalized impact (CPP/FCSm)
  displayed against the output.
• Large output can be combined with a relatively
  low impact

79

• H-Index displayed against the output.
• Larger output is strongly correlated with a high
  H-Index value.

80
Part III Methodological issues
81
Journal Field Normalization
82
Network of publications (nodes) linked by
citations (edges)
Lower citation-density Higher
citation-density e.g., applied research, e.g.,
basic natural social sciences medical research
FCSm
JCSm
CPP
Values for normalization
83
Calculating the JCSm FCSm

• --------------------------------------------------
  --------------------------------------------
• Type publ. Journal Journal
  citations
• year category until 1999
• --------------------------------------------------
  --------------------------------------------
• I review 1996 CANCER RES Oncology 17
•
• II note 1997 J CLIN END Endocrinology
  4
•
• III article 1999 J CLIN END Endocrinology
  6
• IV article 1999 J CLIN END Endocrinology
  8
• --------------------------------------------------
  --------------------------------------------

84
Calculating the JCSm FCSm 2

• --------------------------------------------------
  ---------------
• CPP JCS FCS
• --------------------------------------------------
  ---------------
• I 17 16.9 23.7
•
• II 4 3.1 3.0
•
• III 6 4.8 4.1
•
• IV 8 4.8 4.1
• --------------------------------------------------
  ---------------

85
Practical exercise on calculating CWTS normalized
indicators

• Here we get to the fourth practical exercise of
  the afternoon
• How would one calculate the CWTS normalized
  indicators CPP/JCSm and CPP/FCSm ?
• Show the outcomes and discuss the results.

86
Calculating the JCSm FCSm 3

• The mean citation score is determined as
• 17 4 6 8
• CPP ------------------ 8.8
• 1 1 1 1

The mean journal citation score as (1
x 16.9) (1 x 3.1) (2 x 4.8) JCSm
-------------------------------------- 7.4
1 1 2
CPP / JCSm (8.8 / 7.4) 1.19
The mean field citation score as
(1 x 23.7) (1 x 3.0) (2 x 4.1)
FCSm --------------------------------------
8.7 1 1 2
CPP / FCSm (8.8 / 8.7) 1.01
87
Citation Windows Impact Measurement
88
Citation measurement and windows

• Publication years, fixed citation window.
• Publications of 1994, with three citation
  years (namely 1994, 1995, en 1996), followed by
  1995, with three years, etc.
• Blocks of publication years with a window
  decreasing in length.
• Publications of 1994-1997, with citation
  window of 4 years (1994-1997), 3 years
  (1995-1997), 2 years (1996-1997), and 1 year.

89
Citation measurement with fixed window

• Citation years
• 1994 1995 1996 1997 1998 1999
  2000 2001

• 1994
• 1995
• 1996
• 1997
• 1998
• 1999
• 2000
• 2001

1994 1995 1996
1995 1996 1997
1996 1997 1998
1997 1998 1999
1998 1999 2000
1999 2000 2001
2000 2001
2001
90
Citation measurement with year blocks
Citation years 1994 1995 1996
1997 1998 1999 2000 2001

• 1994
• 1995
• 1996
• 1997
• 1998
• 1999
• 2000
• 2001

1994 1995 1996 1997 1995 1996
1997 1996 1997 1997
1995 1996 1997 1998 1996 1997
1998 1997 1998 1998
1996 1997 1998 1999 1997 1998
1999 1998 1999 1999
1997 1998 1999 2000 1998 1999
2000 1999 2000 2000
1998 1999 2000 2001 1999 2000
2001 2000 2001 2001
91
Typology of studies
92
Typology of studies

• We distinguish various levels of analysis
• Macro-level, e.g. country comparison for the EU,
  Dutch Observatory of ST
• Meso-level, e.g. disciplinary evaluation of
  physics research in the Netherlands
• Micro-level, e.g. analysis of research
  institutes, programmes, or groups
• Nano-level, e.g. analysis of individual
  researchers.

93
Types of data collection

• We distinguish various types of data collection
• Address based, e.g. country or institute
  comparisons. Here we select publications from the
  data-base starting from country or institute
  names
• Author name based, e.g. various evaluation
  procedures. Here we select publications from the
  database, the result is verified by the
  researchers themselves
• Publication list based, e.g . various evaluation
  procedures. For example, matching a list
  retrieved from Metis with the WoS.

94
Methodology of studies
95
Functions of applying bibliometrics

• Using bibliometrics as a diagnostic tool, we can
  distinguish two main functions

• Mainly descriptive (e.g., on German
• medical sciences, but also CWTS
• benchmark studies).

• Mainly evaluative (e.g., studies for
• VSNU, the Dutch Association of
• Universities).

96
Goals of applying bibliometrics

• Using bibliometrics to measure output and impact,
  we can distinguish two main goals

• Gaining insight in the research potential of
  entities or a complete organization.

• Gaining insight in the past performance of
  entities or a complete organization.

97
Choices and consequences

• The final choice for a certain approach or type
  of study is mainly customer driven.

• Depending on the goals one wants to achieve
  (evaluation of research (groups), description of
  the scientific profile of an institute or
  university, etc.), specific approaches fit the
  raised questions.

98
Models of bibliometric analysis

• In our analyses, we can roughly distinguish
  between two different types of models

• Top-Down approach

• Bottom-Up approach

In the next section, we will further explain
these two different approaches.
99
The building blocks of an organization

• University
• Laboratories / research groups
• Researchers (in these
• laboratories)
• Scientific publications

100
Top Down Approach
CWTS compilation of address-based publication set
101
Bottom Up Approach
Author verification of scientific publications
102
Top Down Approach (modified)
CWTS compilation of address-based publication
set, verification by client
103
Bottom Up Approach (modified)
Client compilation of verified set of
scientific publications
104
Combining approach with goal
105
Combining approach with function
106
Possible results

• Often, bibliometric results combine the scores of
  an organization with the distribution over fields
  of scientific activity.
• A common misunderstanding is to link, mentally,
  the scores of a unit (that fits the name of the
  field) to that field.

107
Research profile

• Profile of an academic medical center
• Impact at average level in three fields

108
Differences between organizational units and
fields
Dept. of Chemistry
Dept. of Physics
C-IV
P-III
P-IV
C-III
P-I
C-I
C-II
P-II
Chemical Engineering
Physics
Chemistry
109
Choices and consequences

• The crucial role of the verification of
  publication output is shown.
• Depending on the goals and functions related to
  the application of bibliometric analysis, a
  specific approach fits the raised questions best.

110
Conclusions

• Within a Top Down approach, evaluation is
  excluded as an option.
• Within a Top Down approach, insight in research
  potential is only partially.
• The Bottom Up approach provides the most insight
  for evaluative purposes, on both the level of
  past performance as well as research potential.

111
Practical exercise on methodology

• Here we get to the final practical exercise of
  the afternoon
• Which disavantages/disadvantages can you think
  of, when considering the two different
  bibliometric approaches Top Down versus Bottom Up
  ?
• Discuss the results.

112

• End of the workshop
• For questions regarding the contents of the
  workshop, mail to leeuwen_at_cwts.nl
