PRINCIPLES OF DETECTION OF RADIATION INJURES

1
PRINCIPLES OF DETECTION OF RADIATION INJURES
2
Accidental dosimetry
BIOLOGICAL DOSIMETRY
PHYSICAL DOSIMETRY
CLINICAL DOSIMETRY
CYTOGENETIC DOSIMETRY Dicentrics, FISH, PCC, MNA
DOSE RECONSTRUCTION, Personal Dosimeters
NAUSEA, VOMITING, BLOOD CELLS COUNTS, SKIN
REACTIONS...
OTHER BIOINDICATORS
3
Physical dosimetry
4
Instruments for detecting and measuring radiation

• Survey meters
• Geiger-Mueller (GM) instruments
• Ionization chamber instruments
• Scintilation instruments
• Laboratory counters
• Personnel dosimeters
• Photographic film dosimeters
• Thermoluminescent dosimeters
• Pocket dosimeters

5
Primary use of radiation instrument

• Level of radioactive contamination
• Radiation dose rate in area
• Identity and quantity of radioactive material
• Accumulated dose to individuals in area

Survey meters
Laboratory counters
Personnel dosimeters
6
Personnel dosimeters
Electronic dosimeter
Film badge
TLD
7
Photographic film dosimeters

• Advantages
• Permanent record
• Energy and nature of exposure
• Cost

• Disadvantages
• Energy dependence
• Fading
• Size

8
Thermoluminescent dosimeters
9
Pocket dosimeters
10
Digital pocket dosimeter
11
Clinical dosimetry
12
Clinical and laboratory sings of acute radiation
syndrome

• Prodromal clinical effects
• Time of onset
• Degree of symptoms
• Haematological changes
• Lymphocyte counts
• Leukocytes counts
• Biological dosimetry

13
Clinical dosimetry at radiation vomiting
Crude estimate of absorbed dose obtainable from
clinical presentation

• Vomiting
• Onset 2 h after exposure or later
• Onset 1-2 h after exposure or later
• Onset earlier than 1 h after exposure
• Onset earlier than 30 min after exposure

MILD ARS (1-2 Gy)
MODERATE ARS (2-4 Gy)
SEVERE ARS (4-6 Gy)
VERY SEVERE ARS (6-8 Gy)
14
Radiation dose under 5 Gy

• No immediate life-threatening hazard exists
• Prodromal symptoms of moderate severity
• Onset gt 1 hour
• Duration lt 24 hours

15
Fatal radiation

• Nausea and vomiting within minutes (during the
  first hour)
• Within hours (on the first day)
• Explosive bloody diarrhoea
• Hyperthermia
• Hypotension
• Erythema
• Neurological signs

16
Triage categories of radiation injuries
according to early symptoms
17
Guide for management of radiation injuries on
the basis of early symptoms
18
Clinical signs of skin injury depending on dose
of radiation exposure
19
Laboratory dosimetry using early changes in
lymphocyte counts
20
Change of lymphocytes counts depending on dose of
acute whole body exposure
21
Laboratory dosimetry using granulocyte counts
22
Cytogenetic dosimetry
23
Cytogenetic dosimetry

• Analysis of chromosomal aberrations in peripheral
  blood lymphocytes - widely used biological
  dosimetry method for assessing radiation dose,
  especially useful
• in persons not wearing dosimeters while exposed
  to radiation
• in cases of claims for compensation for
  radiation injuries not supported by unequivocal
  dosimetric evidence
• for validation of occupational radioprotection
  cases involving suspected low-dose exposures

24
Biophysical background to chromosome damage
High LET



Low LET
25
Classification of chromosomal aberrations
Asymmetrical (UNSTABLE)
Breaks
Symmetrical (STABLE)
Centric Ring
Inversion
Intrachange
Interchange
Translocation
Dicentric
26
Biological dose assessment using standard
dicentric analysis

• Introduced by M. Bender in 1964
• Isolated lymphocytes stimulated by
  phytohaemagglutin (PHA) into mitosis
• Arrest of metaphase using colchicine
• Scoring of dicentric chromosome aberrations in
  metaphase spreads

27
Dicentric chromosome aberrations in metaphase
spreads
dic
f
dic
f
f
f
28
Dose curves at high LET and low LET radiation
Y AaD bD2
29
Dose curves at acute and chronic exposure
Gamma rays, X-rays acute exposure (Low LET)
? particles Fast neutrons (High LET)
Y c aD
Y c aD bD2
Effect
Dicentric yield
Y c aD
Gamma rays X-rays chronic exposure (Low LET)
Dose
30
Dose estimation of a partial body radiation
exposure (non-uniform irradiation)
31
Dicentric assay

• Most accurate method for dose estimation with
  sensitivity threshold of about 0.1 Gy for whole
  body low LET radiation
• Especially useful
• in cases where dosimeter not used, e.g.
  radiation accident
• to support physical dosimetry results in
  radiation protection and safety practice
• to determine partial body exposure not detected
  by locally placed dosimeter

32
Limitations of dicentric analysis for dose
estimation

• Dicentrics are unstable and lymphocytes carrying
  aberration elimininated with time (average
  lifetime 150-220 days, depending on dose), hence
  can underestimate magnitude of dose
• Method useful only within few months of
  irradiation

33
Translocation assay

• In retrospective dosimetry and chronic exposure
  reciprocal translocations used for dose
  assessment
• Translocations considered stable in cell division
  so yield should not fall with time
• Typically detected using specific whole
  chromosome DNA hybridization probes and FISH
  methodology

34
Stable chromosome aberration analysis with
G-banding
An idiogram showing the banding patterns of
individual chromosomes by fluorescent and Giemsa
staining
A normal G banded male karyotype
35
Stable chromosome aberration analysis with FISH
Translocation
Deletion
36
Applicability of stable chromosome aberration
analysis for biological dosimetry

• Method based on scoring stable chromosome
  aberrations (translocations and insertions)
  detected with fluorescent in-situ hybridization
  of whole chromosomes
• Requires complex procedures and technical
  equipment
• May be use decades after exposure

• Sensitivity threshold a few cGy but method not
  feasible for doses less than 0.2 Gy because of
  expense and time needed for analysis
• Spontaneous level of stable chromosome
  aberrations not well established

37
Premature chromosome condensation (PCC) assay

• Initially introduced by Johnson and Rao (1970)
• Mitotic-inducer cells (i.e. CHO) isolated using
  chemical (colcemid) and physical (rapid shaking
  of flask) technique
• Test cells (i.e. human lymphocytes) fused with
  CHO cells using polyethylene glycol (PEG)
• Interphase DNA of test cells condense into
  chromatid/chromosome-like structures (46 for
  non-irradiated human cells)

38
PCC technique
CHINESE HAMSTER OVARY (CHO) CELLS (Grown in
BrdU) COLCEMID MITOTIC SHAKE
OFF (METAPHASE CELLS)
FUSE IN PEG
PERIPHERAL BLOOD
CHO
LYMPHOCYTES
FICOL SEPARATION
Incubate 1 h (MediumPHAColcemid)
PCC
39
PCCs and FISH
Irradiated cells with excess break
Unirradiated control
40
Estimation of irradiated body fractions
41
Applicability of PCC assay for biological
dosimetry

• Dose estimates obtainable within 48 hours of
  receipt of blood in laboratory
• Radiation induced mitotic delay does not
  interfere with assay since performed on
  interphase nuclei and does not require cell
  division
• Method envisioned applicable after partial-body /
  supra-lethal exposure and improves detection
  level of lower doses

42
Micronucleus assay
Cytochalasin B
43
Micronucleus and nucleoplasmic bridges in
binucleated cells
B
A
44
Micronucleus assay with pancentromeric probe
A
B
centromere positive
centromere negative
45
Application of micronucleus assay for biological
dosimetry

• Micronucleus not specific to radiation exposure
• Discrimination between total and partial body
  exposure more difficult
• High doses of radiation interfere with cell
  division
• High baseline frequency and age dependency make
  reliability of assay questionable

46
Glycophorin A (GPA) somatic cell mutation assay

• Performed by two-color immunofluorescence flow
  cytometry on peripheral blood erythrocytes
• Based of measuring N/0 variants of erythrocytes,
  which display phenotype consistent with loss of
  expression of GPA (M) allele
• Can be performed only on individuals
  heterozygous at this locus that codes for the N/M
  blood group antigens (approximately half of
  population)
• Prompt but requires complex and expensive
  equipment
• Sensitivity threshold about 0.2-0.25 Gy

47
Application of GPA assay for biological
dosimetry
Relationship between glycophorin A mutant
frequency in red blood cells and radiation dose
for about 1200 A-bomb survivors
48
Biophysical assays - ESR (electron spin
resonance)

• Persistent free radicals formed in solid matrix
  biomaterial (e.g. dental enamel, nail clippings,
  hair) from accidentally exposed victim can be
  detected via ESR
• Measurements provide reliable biophysical dose
  estimates and partial body exposure information
• In some circumstances, certain clothing material,
  particularly hard plastics and buttons, may be
  measured and absorbed dose estimated

49
Characterization of biological dosimetry methods

50
Summary of lecture

• In radiation accidents, important to estimate
  the absorbed doses in victims to plan appropriate
  medical treatment
• In most accidents, physical dosimetry of
  absorbed dose is not possible. Even where
  possible, important to confirm the estimates by
  other methods
• Most commonly used method cytogenetic analysis
  of chromosomal aberration in peripheral blood
  lymphocytes using dicentrics, translocations, PCC
  and micronuclei assays

51
Lecture is ended
THANKS FOR ATTENTION
In lecture materials of the International Atomic
Energy Agency (IAEA), kindly given by doctor
Elena Buglova, were used
