Probabilistic Verification of Discrete Event Systems

1
Probabilistic Verification of Discrete Event
Systems

• Håkan L. S. Younes

2
Introduction

• Verify properties of discrete event systems
• Probabilistic and real-time properties
• Properties expressed using CSL
• Acceptance sampling
• Guaranteed error bounds

3
The Hungry Stork
4
The Hungry Stork
System
The probability is at least 0.7 that the stork
satisfies its hunger within 180 seconds
5
Systems

• A stork hunting for frogs
• The CMU post office
• The Swedish telephone system
• The solar system

6
Discrete Event Systems

• Discrete state changes at the occurrence of
  events
• A stork hunting for frogs
• The CMU post office
• The Swedish telephone system
• The solar system

7
The Hungry Stork as aDiscrete Event System
hungry
8
The Hungry Stork as aDiscrete Event System
stork sees frog
hungry,hunting
hungry
40 sec
9
The Hungry Stork as aDiscrete Event System
stork sees frog
frog sees stork
hungry,hunting,seen
hungry,hunting
hungry
40 sec
19 sec
10
The Hungry Stork as aDiscrete Event System
stork sees frog
frog sees stork
stork eats frog
hungry,hunting,seen
not hungry
hungry,hunting
hungry
40 sec
19 sec
1 sec
11
Sample Execution Paths
stork sees frog
frog sees stork
stork eats frog
hungry,hunting,seen
not hungry
hungry,hunting
hungry
40 sec
19 sec
1 sec
12
Properties of Interest

• Probabilistic real-time properties
• The probability is at least 0.7 that the stork
  satisfies its hunger within 180 seconds

13
Properties of Interest

• Probabilistic real-time properties
• The probability is at least 0.7 that the stork
  satisfies its hunger within 180 seconds

14
Verifying Real-time Properties

• The stork satisfies its hunger within 180
  seconds

stork sees frog
frog sees stork
stork eats frog
hungry,hunting,seen
not hungry
hungry,hunting
hungry
40 sec
19 sec
1 sec
True!
15
Verifying Real-time Properties

• The stork satisfies its hunger within 180
  seconds

stork sees frog
Stork eats frog
not hungry
hungry,hunting
hungry
165 sec
30 sec
False!
16
Verifying Probabilistic Properties

• The probability is at least 0.7 that X
• Symbolic Methods
• Pro Exact solution
• Con Works for a restricted class of systems
• Sampling
• Pro Works for all systems that can be simulated
• Con Uncertainty in correctness of solution

17
Our Approach

• Use simulation to generate sample execution paths
• Use sequential acceptance sampling to verify
  probabilistic properties

18
Error Bounds

• Probability of false negative ?
• We say that P is false when it is true
• Probability of false positive ?
• We say that P is true when it is false

19
Acceptance Sampling

• Hypothesis The probability is at least ? that X

20
Acceptance Sampling

• Hypothesis Pr?(X)

21
SequentialAcceptance Sampling

• Hypothesis Pr?(X)

22
Performance of Test
23
Ideal Performance
24
Actual Performance
25
Graphical Representation of Sequential Test
26
Graphical Representation of Sequential Test

• We can find an acceptance line and a rejection
  line given ?, ?, ?, and ?

27
Graphical Representation of Sequential Test

• Reject hypothesis

28
Graphical Representation of Sequential Test

• Accept hypothesis

29
Continuous Stochastic Logic (CSL)

• State formulas
• Truth value is determined in a single state
• Path formulas
• Truth value is determined over an execution path

30
State Formulas

• Standard logic operators ?, ?1 ? ?2
• Probabilistic operator Pr?(?)
• True iff probability is at least ? that ? holds
• Pr0.7(The stork satisfies its hunger within 180
  seconds)

31
Path Formulas

• Until ?1 Ut ?2
• Holds iff ?2 becomes true in some state along the
  execution path before time t, and ?1 is true in
  all prior states
• The stork satisfies its hunger within 180
  seconds true U180 hungry

32
Expressing Properties in CSL

• The probability is at least 0.7 that the stork
  satisfies its hunger within 180 seconds
• Pr0.7(true U180 hungry)
• The probability is at least 0.9 that the
  customer is served within 60 seconds and remains
  happy while waiting
• Pr0.9(happy U60 served)

33
Semantics of Until

• true U180 hungry

hungry,hunting,seen
hungry
hungry,hunting
hungry
40 sec
19 sec
1 sec
True!
34
Semantics of Until

• true U180 hungry

hungry
hungry,hunting
hungry
165 sec
30 sec
False!
35
Semantics of Until

• happy U60 served

happy,served
served
happy,served
happy,served
17 sec
13 sec
5 sec
False!
36
Verifying Probabilistic Statements

• Verify Pr?(?) with error bounds ? and ?
• Generate sample execution paths using simulation
• Verify ? over each sample execution path
• If ? is true, then we have a positive sample
• If ? is false, then we have a negative sample
• Use sequential acceptance sampling to test the
  hypothesis Pr?(?)

37
Verification of Nested Probabilistic Statements

• Suppose ?, in Pr?(?), contains probabilistic
  statements
• Pr0.8(true U60 Pr0.9(true U30 hungry))
• Error bounds ? and ? when verifying ?

38
Verification of Nested Probabilistic Statements

• Suppose ?, in Pr?(?), contains probabilistic
  statements

39
Modified Test

• Find an acceptance line and a rejection line
  given ?, ?, ?, ?, ?, and ?

40
Modified Test

• Find an acceptance line and a rejection line
  given ?, ?, ?, ?, ?, and ?

Accept
Continue sampling
Reject
41
Verification of Negation

• To verify ? with error bounds ? and ?
• Verify ? with error bounds ? and ?

42
Verification of Conjunction

• Verify ?1 ? ?2 ? ? ?n with error bounds ? and ?
• Accept if all conjuncts are true
• Reject if some conjunct is false

43
Acceptance of Conjunction

• Accept if all conjuncts are true
• Accept all ?i with bounds ?i and ?i
• Probability at most ?i that ?i is false
• Therefore Probability at most ?1 ?n that
  conjunction is false
• For example, choose ?i ?/n
• Note ?i unconstrained

44
Rejection of Conjunction

• Reject if some conjunct is false
• Reject some ?i with bounds ?i and ?i
• Probability at most ?i that ?i is true
• Therefore Probability at most ?i that
  conjunction is true
• Choose ?i ?
• Note ?i unconstrained

45
Putting it Together

• To verify ?1 ? ?2 ? ? ?n with error bounds ?
  and ?
• Verify each ?i with error bounds ? and ?
• Return false as soon as any ?i is verified to be
  false
• If all ?i are verified to be true, verify each ?i
  again with error bounds ? and ?/n
• Return true iff all ?i are verified to be true

Fast reject
46
Putting it Together

• To verify ?1 ? ?2 ? ? ?n with error bounds ?
  and ?
• Verify each ?i with error bounds ? and ?
• Return false as soon as any ?i is verified to be
  false
• If all ?i are verified to be true, verify each ?i
  again with error bounds ? and ?/n
• Return true iff all ?i are verified to be true

Rigorous accept
47
Verification of Path Formulas

• To verify ?1 Ut ?2 with error bounds ? and ?
• Convert to disjunction
• ?1 Ut ?2 holds if ?2 holds in the first state,
  or if ?2 holds in the second state and ?1 holds
  in all prior states, or

48
More on Verifying Until

• Given ?1 Ut ?2, let n be the index of the first
  state more than t time units away from the
  current state
• Disjunction of n conjunctions c1 through cn, each
  of size i
• Simplifies if ?1 or ?2, or both, do not contain
  any probabilistic statements

49
Example
hungry

• Verify Pr0.7(true U180 hungry) inwith ? ?
  0.1 and ? 0.1

Simulator
50
Example
hungry

• Verify Pr0.7(true U180 hungry) inwith ? ?
  0.1 and ? 0.1

hungry
40
hungry, hunting
19
hungry, hunting, seen
1
hungry
Total time 0 sec
Total time 40 sec
Total time 59 sec
Total time 60 sec
51
Example
hungry

• Verify Pr0.7(true U180 hungry) inwith ? ?
  0.1 and ? 0.1

hungry
63
hungry, hunting
25
hungry, hunting, seen
2
hungry,tired
93
hungry
Total time 88 sec
Total time 90 sec
Total time 183 sec
Total time 0 sec
Total time 63 sec
52
Example
hungry

• Verify Pr0.7(true U180 hungry) inwith ? ?
  0.1 and ? 0.1

Property holds!
53
Summary

• Algorithm for probabilistic verification of
  discrete event systems
• Sample execution paths generated using simulation
• Probabilistic properties verified using
  sequential acceptance sampling

54
Future Work

• Apply to hybrid dynamic systems
• Develop heuristics for formula ordering and
  parameter selection
• Use verification to aid policy generation for
  real-time stochastic domains
