Corporate Presentation Template

1
Missiles and Fire Control
Sustaining the Force Invention to Innovation
12 - 13 Jun 2008
Rick Edwards Vice President Tactical Missiles
Combat Maneuver Systems
2
Tactical Weapons
Rockets Missiles MLRS ATACMS DAGR GMLRS HELLFIRE
II JCM/JAGM Longbow Missile Javelin AGS
LRLAP Ground Platforms HIMARS FCS MULE FCS
CCD SMSS Warrior FLIP M270A1/B1
Rocket Science on Wheels
843128 RUSI -1 11/15/2009 2
3
The success of the past

• Can we afford the proven model ?
• Invention has driven.
• Low observables
• Reactive armour
• Millimetre wave radar
• Given Time and Money
• Better, Faster and Cheaper as a business
  imperative.

4
Intelligent Vehicles
MULE
SMSS
CCD
Pulling Future Technology Forward for the
Warfighter
843128 RUSI -1 11/15/2009 4
5
Vehicle Integration
Warrior FLIP
MULE
EEU
HIMARS
SMSS
843128 RUSI -1 11/15/2009 5
6
FCS Multifunctional Utility Logistics Equipment
(MULE)
Status
Description

• PoP Nov 2003 Mar 2013
• Deliverables
• Prototypes 16 (2010-2012)
• Risk Mitigation Engineering Evaluation Unit
  (EEU)
• Testing underway successful autonomous step
  climb and gap crossing

Transport
ARV A (LT)
Countermine

• 3 Variants With Common Chassis
• Weight 3 1/2 Tons
• ANS and RSTA Sensors
• Weapons (ARV-A (LT))
• Line-of-sight Gun
• Javelin

MULE Prototyping Video
Capabilities

• Support Infantry in Dismounted Operations
• Transport 2 Squads Worth of Gear and Supplies
  (2000 lbs)
• Provide Immediate, Heavy Firepower
• Detect, Mark and Neutralize Mines
• Extraordinary Mobility

7
FCS Centralized Controller Device (CCD)

• Provides FBCT dismounted soldier a common device
  to remotely control Class I UAV, UGVs, UGS,
  NLOS-LS, and select MGV functions
• Four spirals starting with COTS, evolving to
  objective
• Spiral 3 qualified to support EBCT fielding
• Partnered with iRobot and Honeywell

Description
Capabilities

• Human Factors design optimized for complex
  control of 17 platforms
• Access to FCS Battle Command Network and
  situational awareness
• Single enclave for either classified or
  unclassified processing
• Anti-tamper features
• Modular architecture accommodates technology
  insertion
• Evolving to 6 lbs by Spiral 4

CCD Video
8
Squad Mission Support System (SMSS)
Range 100 miles on road / 50 ml cross
country Guidance Driven, tele-operated,
autonomous, supervised autonomy Weight 5,000
lb (2268 kg) Payload 1,300 lb (590kg) Vertical
Step 22 in (56 cm) Gapes 27.5 in (0.7
m) Variants Transport, armed reconnaissance
Status
Description

• To participate in the Army Expeditionary Warrior
  Experiment (AEWE) - Fort Benning Nov-Dec 2008
• 2 vehicles with Soldiers in the loop
• Supervised Autonomy
• Tele-operated
• Autonomous obstacle negotiation
• Network Architecture Node
• Transport and Armed Reconnaissance versions

Capabilities

• Versatile Special Ops Forces/Light Forces
  applications/capabilities
• Drivable/Supervised Autonomy
• Equipment Transport
• Heavy Weapons Platform
• RISTA
• Water purification and storage
• Battery recharge
• Tactical Relevance 1000 lb () payload
• Transportability UH-60 slingload
• Affordable
• Multiple roles / missions

SMSS Video
9
Moving from Invention to Innovation

• Traditional invention model
• The need for Innovation
• Horizontal Integration
• Innovation from SMEs
• Skunk Works approach
• The upcoming war for talent
• The numbers
• Unlocking innovation for the Millennial
  generation

10
BattPack

• Dismounted Soldiers can be expected to carry as
  much as 40 pounds of batteries to support
  mission-essential equipment
• Portable, rechargeable power wherever a Soldier
  needs it
• Built for the field water resistant, shock
  vibe-proof, EMP protected
• Capable of
• Jumpstarting military vehicles
• Recharging military vehicle batteries /
  recharged from a military vehicle
• Powering standard 28 VDC Military electronic
  equipment
• Accepts wide range AC or DC for recharge, from
  both civilian and military power sources
• Multiple units can be interconnected to boost
  power energy storage
• Meets two-person lift-and-carry requirements

11
Rapid Prototype . . . Concept to Warfighter

• Adopted a Systems Engineering approach to
  define turret subsystems
• No Lockheed Martin hardware on the turret
• Used the LMUK INSYS Rapid Prototyping
  capability to build the LM WFLIP turret
  demonstrator and integrated key subsystems
• 33 weeks to live fire
• 52 weeks to manned firing (Exceeded Warrior SRD
  Objective Accuracy Requirement)
• Assembled a world class supply chain and brought
  world class partnering skills Worked
  interactively to reduce interface issues
• Matured and integrated the WFLIP Electronic
  Architecture
• Developed a high fidelity dynamic simulation to
  optimise system performance and conduct trades
• Modeled WR Base Overhaul Process to demonstrate
  how the planned upgrade could be incorporated
  into the Warrior Base Overhaul process

WFLIP Video
WFLIP Prototyping Video
Excellence in Rapid Prototyping
843128 RUSI -1 11/15/2009 11
12
Summary

• LM Is Taking Vehicle Integration Expertise Into
  the AFV Market
• Rapid Prototyping Is Key To Reducing Risk In an
  Accelerated programmeme Environment
• World Class Partners - Our Innovative Approach To
  Partnering Puts Our Suppliers In The Design and
  Development Process
• Speed and Innovation Have Been Key To Recent
  Warrior FLIP Hardware Demonstrations

843128 RUSI -1 11/15/2009 12
13
Lockheed Martin Missiles and Fire Control P. O.
Box 650003 Dallas, Texas 75265-0003
14

• Extraordinary Mobility in Complex Terrain
• 3 MULE Variants on a Common Chassis
• Transport Hauls 2 Squads Gear or 2,000 lbs
  Payload
• ARV-A(L) Delivers Sensors and Firepower
• Countermine Detects Buried Mines in Roads
• Engineering Unit Undergoing Extensive Testing
• On Track to Deliver 16 Prototypes in 2011 and
  Test in 2011-12

843128 RUSI -1 11/15/2009 14
15

• CC Provides Unprecedented Capability in Hands of
  FBCT Dismounted Soldier
• CC is a Single, Common Device to Remotely
  Control 17 Manned / Unmanned Systems
• Accesses FCS Battlefield Network, Provides
  Dismounted Soldier with Situational Awareness

843128 RUSI -1 11/15/2009 15
16

• Light Forces are the First Ones Sent to the Point
  of Action. Their Equipment Must be Deployable and
  Flexible.
• Squad Mission Support System (SMSS) is Designed
  to Give Units a Highly Transportable, Mission
  Configurable System That Will Ease the Burden of
  the Soldier.
• The SMSS can Carry Ammunitions, Weapons,
  Explosives, Heavy Equipment (Such as Additional
  Robots), Medical Supplies, and Camouflage, Cover,
  and Concealment Materials.
• Sling Load UH-60, V-22, and CH-47 Transportable.
• The SMSS Will not Change a Units Missions or its
  Tactics. It Will Enhance its Ability to Execute
  Both.

843128 RUSI -1 11/15/2009 16
