Using the Instrumental Variables Technique in Educational Research

1
Using the Instrumental Variables Technique in
Educational Research

• By
• Larry V. Hedges
• Northwestern University

2
Outline

• The place of IV in educational research
  methodology
• The classical econometric justification of IV
• The modern statistical approach to IV and causal
  inference
• Implementing IV analyses
• What can go wrong
• Practical problems in IV

3
Disclaimer

• This talk is intended to be non-technical,
  therefore
• No matrix algebra will be used
• Some technical details will be glossed over
• For example, I will speak of bias and accuracy in
  situations where the actual moments of estimates
  do not exist
• The object is to build intuition and
  understanding not to be rigorously technically
  correct

4
Estimating Treatment Effects

• Consider treatment assignment (dummy variable) X
  and outcome Y
• Regress Y on X
• Yi ß0 ß1Xi ei
• The estimate of ß1 is just the difference between
  the mean Y for X 1 (the treatment group) and
  the mean Y for X 0 (the control group)
• Thus the OLS estimate is
• ß1

5
Estimating Treatment Effects(With Random
Assignment)

• If the treatment is randomly assigned, then X is
  uncorrelated with e (X is exogenous)
• If X is uncorrelated with e if and only if
• But if , then the mean difference is
• ß1 ß1
• This implies that standard methods (OLS) give an
  unbiased estimate of ß1, which is the average
  treatment effect
• That is, the treatment-control mean difference is
  an unbiased estimate of ß1,

6
What goes wrong without randomization?(Simple
Case)

• If we do not have randomization, there is no
  guarantee that X is uncorrelated with e (X may be
  endogenous)
• Thus the OLS estimate is still
• ß1
• If X is correlated with e, then
• Hence does not estimate ß1, but some
  other quantity that depends on the correlation of
  X and e
• If X is correlated with e, then standard methods
  give a biased estimate of ß1

7
What goes wrong without randomization?

• When you regress Y on X, Y ß0 ß1X e and
• the OLS estimate of ß1 can be described as
• But since X and e are correlated, bOLS does not
  estimate ß1 but some other quantity that depends
  on the correlation of X and e

8
Instrumental Variables

• Natural experiments are naturally occurring
  situations where we want to know the effect of
  variable X on Y and there is a variable Z related
  to X, but not e
• Another way so say this is Z effects Y only
  through X
• This variable Z is called an instrumental
  variable
• It can be shown that
• is an unbiased estimator of ß1 in large samples
  but not in small samples (bIV is consistent)

9
Instrumental Variables

• One way to see this is in terms of two regression
  equations
• Yi ß0 ß1Xi ei
• Xi ?0 ?1Zi ?i
• Note that, in this model X is endogenous (may be
  correlated with e)
• The instrumental variables model requires that
• 1. ?1 ? 0 so that Z predicts X, and
• 2. Z uncorrelated with e (Z is exogenous) Cove,
  Z 0

10
Instrumental Variables

• You can see the logic of IV as follows

11
Instrumental Variables

• Recall the two regression equations
• Yi ß0 Xiß1 ei
• Xi ?0 Zi?1 ?i
• This is why instrumental variables methods are
  associated with simultaneous equations methods in
  econometrics
• In this formulation, Zi and Xi can be vectors, so
  you can have
• several X variables, only some of which are
  endogenous and
• several Z variables only some of which are
  instruments (but you must have more instruments
  than endogenous X variables)
• The instrumental variables model requires that ?1
  ? 0 and Z uncorrelated with e

12
Instrumental Variables

• Remember To be an instrument Z must be
• Relevant (Z must be related to the endogenous
  variable X)
• Exogenous (Z must be related to the outcome Y
  only through X)
• Failure of either condition is a problem!
• But both conditions can be hard to satisfy at the
  same time

13
ExampleExperiments with imperfect compliance

• Effect of intent to treat, versus treatment on
  the treated
• Intent to treat estimate
• Compare Y for all those assigned to treatment 1
  to those assigned to treatment 0
• This estimates the causal effect on Y of
  assignment to treatment
• It does not measure the effect of actually
  receiving the treatment unless there is perfect
  compliance
• Experimental methods cannot estimate the effect
  of receiving the treatment, because that cannot
  be randomly assigned (without perfect compliance)
• For example, families that use vouchers may be
  systematically different than those who do not in
  ways that affect Y

14
ExampleExperiments with imperfect compliance

• Voucher experiments
• We may want to know the causal effect of using
  vouchers
• But not all families assigned vouchers use them
• Because use of vouchers is not randomly assigned,
  it may be correlated with residuals
• Random assignment to receive vouchers (is?) an
  instrument because
• Voucher assignment is related to voucher use
• Voucher assignment may affect school achievement
  only through voucher use

15
ExampleExperiments with imperfect compliance

• This same idea can be applied to study the effect
  of receiving treatment (the effect of treatment
  on the treated) in many settings
• It can also be used to study the effect of the
  active ingredients in imperfectly implemented
  treatments
• It can (more cautiously) be used to study effects
  of a treatment where there is an instrument that
  does not arise via random assignment

16
Other examples of IV Studies
17
Estimating Causal Effects

• The Rubin-Holland-Rosenbaum model starts with 2
  potential responses for each unit
• r1i outcome unit i experiences in treatment 1
• r0i outcome unit i experiences in treatment 0
• The causal effect of treatment 1 versus 0 on unit
  i is defined as
• ti r1i r0i
• You cant estimate ti directly, but you can
  estimate the average causal effect in some
  circumstances, like a randomized experiment

18
Estimating Causal Effects (Randomized
Experiments)

• Let Z 0, 1 be a variable that expresses
  treatment assignment
• In a perfectly implemented randomized experiment,
  treatment assignment (Z) is uncorrelated with
  both r1i and r0i, so
• Er1i treatment 1 (Z 1) Er1i
• Er0i treatment 0 (Z 0) Er0i
• Thus Er1 Z 1 Er0 Z 0 Er1 r0

• So the estimate of the treatment effect
  is unbiased

19
Estimating Causal Effects (IV Studies)

• Consider IV within randomized experiments
• Random assignment Z, with endogenous X (believed
  to be the efficacious causal component of
  treatment)
• We want to know the causal effect of the
  endogenous variable X on outcome Y
• For example
• Effect of voucher use in randomized choice
  studies
• Effect of treatment implementation
• Effect of using specific instructional methods

20
Estimating Causal Effects (IV Studies)

• IV can estimate causal effects of X on Y, if the
  following assumptions hold
• SUTVA
• Random assignment of Z
• Exclusion restriction (exogeneity of Z)
• Nonzero causal effect of Z on X
• Monotonicity (no defiers)
• Then the IV estimate is an estimate of the
  average treatment effect for those who comply
  with assignment

21
Units Reaction to Treatment

• We can characterize units reaction to treatment
  into four categories
• Compliers (do what they are assigned to do)
• Always takers (get treatment regardless of
  assignment)
• Never takers (never get treatment regardless of
  assignment)
• Defiers (always do the opposite of what is
  assigned)
• Note that we ruled out defiers by hypothesis
• Note that we cannot necessarily identify
  individuals are which

22
Estimating Causal Effects (IV Studies)

• Note that the causal effect of treatment on
  always takers and never takers is 0 by definition
• We can also see the IV estimate as the ratio of
  two causal effects (two intent to treat
  estimates)

23
Carrying Out IV Analyses

• Recall the description of IV in terms of two
  regression equations
• Yi ß0 ß1Xi ei
• Xi ?0 ?1Zi ?i
• Two-stage least squares estimation involves
• Regressing X on Z to get estimates of X
• Regressing Y on to get an estimate of ß1
• Specialized programs are also available in many
  packages (e.g., STATA or SAS)
• There are also other, more complex procedures
  (such as LIML)

24
What Can Go Wrong In the Use of IV

• Failure of the assumptions!
• Failure of exogeneity (Z influences Y though
  other variables than X)
• Failure of relevance (Z has only a weak relation
  to X)
• Both of these kinds of failures are quantitative,
  not qualitative
• Choice of instruments may involve a tradeoff
  between these two kinds of failures
• But also, IV is a large sample procedure, even
  when assumptions are met it is only guaranteed to
  be unbiased in large samples

25
Violation of IV Assumptions

• It is important to distinguish between two
  situations
• 1. The assumption of exogeneity is met exactly
  and the relevance may be small (but nonzero)
  weak instruments
• In this case the only bias is due to small
  sample bias in estimation
• 2. The exogeneity assumption is not met exactly
• In this case there is additional (large sample)
  bias due to direct causal effect of Z on Y
• The analysis of bias is quite different in these
  two cases!

26
Exogenous, but Weak Instruments

• Even when assumptions are perfectly met, IV is
  not unbiased in small (finite) samples
• Finite sample bias can be non-negligible (e.g.,
  20 - 30), even when the sample size is over
  100,000 if the instrument is weak (Z is only
  weakly correlated with X)
• The relative bias of bIV (versus bOLS) is
  approximately 1/F where F is the F-statistic for
  testing the relation between the instrument (Z)
  and endogenous variable (X)
• A small value of F, even if it is large enough to
  be statistically significant signals possible
  large bias in bIV

27
Exogenous, but Weak Instruments

• Measuring strength of instruments The
  concentration parameter
• One interpretation of the concentration parameter
  is related to the F-test statistic in the
  regression of X on Z is a test of the hypothesis
  that ? 0
• k(F 1) estimates ?
• where k is the number of instruments
• The accuracy of bIV (2SLS) estimate depends on ?,
  (? functions like a sample size)

28
Testing for Weak Instruments

• It is not sufficient that the relation between Z
  and X is statistically significant
• Need to test whether ?/k exceeds a threshold
  (below which instruments are weak enough to
  imperil inference)
• Two definitions of weak enough to imperil
  inference, and both can be tested with first
  stage F for relation of Z and X (Stock Yugo,
  2005)
• 1. Bias of bIV exceeds 10 of the bias of bOLS
• Requires F gt 10
• 2. Actual level of 5 significance test exceeds
  15
• Requires F gt 24

29
Exogenous, but Weak Instruments

• Exact (small sample) results are available, but
  very complex (almost to the point of being
  uninformative)
• In general, more instruments increases the
  relevance of the instrument set (increases the
  first stage F)
• But, too many instruments increases small sample
  bias (compared to few instruments)
• In general it is best to have as few instruments
  as possible, and for them to be strongly
  correlated with X (the endogenous variable)

30
There are Several IV Methods

• I focused on 2SLS, the most widely used IV method
• There are more complex competitors, such as the
  Limited Information Maximum Likelihood (LIML)
  estimation
• Analyses of these methods are difficult too.
  Large sample methods can help, but
• There are at least 4 different large sample
  (asymptotic) models for analyzing IV (and they
  often give different results)
• One of these suggests that 2SLS is equivalent to
  LIML
• Small sample studies (not definitive) suggest
  that LIML may be superior to 2SLS in small samples

31
There are Several IV Methods

• But the full story is not completely clear (e.g.,
  how much this finding depends on normality) and
  it is not simple
• Although it is generally found that 2SLS has
  particularly poor finite sample behavior, each
  alternative estimator seems to have its own
  pathologies when instruments are weak. (Andrews
  Stock, 2005, p. 2)

32
Failure of Exogeneity

• Let H be the direct causal effect of Z on Y
• Then if the exclusion restriction (exogeneity) is
  violated, the (large sample, large ?) bias in bIV
  is
• This shows that bias is reduced when the
  instrument is relevant (strong correlation
  between Z and X), so the odds of being a
  noncomplier are small

33
Failure of Exogeneity

• Failure of exogeneity may introduce large biases
  that are hard to quantify precisely because they
  depend on unobservables
• Usually, this assumption will be (somewhat) false
• The best we can do is often to be skeptical and
  to make sure exogeneity is highly plausible in
  the setting to which we apply IV

34
IV Can Provide Valid Estimates

• There are applications in which IV does provide
  credible estimates
• Kruegers (1999) IV estimate of the effects of
  actual class size on achievement using
  randomization as an instrument
• Howell et al.s (2000) IV estimate of the effects
  of using school vouchers on achievement using
  randomization as an instrument
• Bloom et al.s (1997) IV estimate of the effects
  of JTPA on earnings using randomization as an
  instrument

35
Practical Problems with IV

• How do we know if Z is exogenous?
• Isnt randomization always a good instrument?
• No!
• Consider a randomized experiment to change
  instruction (using many sites or schools)

36
Practical Problems with IV

• Z is assignment to treatment to change
  instruction
• X is a measure of the instruction targeted by
  treatment
• Is Z relevant (a strong instrument)?
• Hard to tell a priori (e.g., if Z is
  dichotomous, X is continuous, Z may not explain
  much variance in X)
• Is Z (exogenous)?
• Why should Z not influence Y through other
  unmeasured instructional practices?

37
Practical Problems with IV

• Possible Solution
• Include other instructional practices as
  covariates or endogeneous variables
• But the number of instruments must exceed the
  number of endogenous variablesnow we need more
  instruments
• We could include Z-by-site interactions as
  instruments
• But now we have increased the number of
  instruments, which may increase bias

38
Practical Problems with IV

• Assignment may have direct effects on Y if
  volunteers want the treatment (Shadish, Cook,
  Campbell, 2002)
• Assignment may influence units to get
  alternatives
• Tutoring
• Teacher induction
• Health care
• After school programs
• Assignment may have a discouraging effect on
  control group

39
Conclusions

• IV can make possible estimates of causal effects
  without random assignment in some cases
• But it is no panacea
• Often, it will be difficult to find instruments
  that are both relevant (strong enough) and
  exogenous
• IV estimation is a complicated subject and good
  theory for all of the relevant issues is not
  available
• For example, all of the theory I have mentioned
  assumes simple random sampling so it does not
  take clustered sampling (of the kind in most
  education experiments) into account

40
Select Bibliography

• Causal Inference
• Rubin, D. B. (1974). Estimating causal effects in
  randomized and non-randomized studies. Journal of
  Educational Psychology, 66, 688-701.
• Angrist, J. D., Imbens, G. W., Rubin, D. B.
  (1996). Identification of causal effects using
  instrumental variables. Journal of the American
  Statistical Association, 91, 444-455.
• Imbens, G. W. Angrist, J. D. (1994).
  Identification and estimation of local average
  treatment effects. Econometrica, 62, 467-475.
• Natural Experiments
• Angrist, J. D. Krueger, A. B. (2000).
  Instrumental variables and the search for
  identification From supply an demand to natural
  experiments. The Journal of Economic
  Perspectives, 15, 69-85.

41
Select Bibliography

• Weak Instruments
• Bound, J., Jaeger, D. A., Baker, R. M. (1995).
  Problems with instrumental variables estimation
  when the correlation between the instruments and
  the endogenous explanatory variable is weak,
  Journal of the American Statistical Association,
  90, 443-450.
• Staiger, D., Stock, J. H. (1997). Instrumental
  variables regression with weak instruments.
  Econometrica, 65, 557-586.
• Nelson, C. R. Startz, R. (1990). Some further
  results on the exact small sample properties of
  the instrumental variable estimator.
  Econometrica, 58, 967-976.
• Stock, J. H., Wright, J. H., Yogo, M. (2002). A
  survey of weak instruments and weak
  identification in generalized method of moments.
  Journal of Business and Economic Statistics, 20,
  518-529
• Buse, A. (1992). The bias of instrumental
  variable estimators. Econometrica, 60, 173-180.
