Getting Started with Linux: Novells Guide to CompTIAs Linux Course 3060

1
Getting Started with Linux Novells Guide to
CompTIAs Linux (Course 3060)

• Section 2
• Use the Linux Desktop

2
Objectives

• Overview of the Linux Desktop
• Use the KDE Desktop Environment
• Use the GNOME Desktop Environment
• Access the Command-Line Interface from the Desktop

3
Introduction

• In Linux, the GUI is a normal application that
  you can choose whether or not to install
• You can configure most services in Linux by
  editing an ASCII text file, so you do not need a
  GUI if you want your computer to act only as a
  server
• Not installing a GUI has the following
  advantages
• Stability
• Performance
• Security

4
Overview of the Linux Desktop

• The base of any GUI on Linux is the X Window
  System (simply called X or X11)
• It allows you to control the input and output of
  several applications in different windows of a
  GUI
• Created in 1984 at MIT
• Initial goal enable graphical applications
  across a network, independent of hardware
• Graphical applications run in their own windows
• Text-based applications are carried out in a
  terminal window

5
Overview of the Linux Desktop (continued)

• X11 allows graphical applications to be displayed
  on any monitor, without running the apps on the
  machines to which these monitors are connected
• The basis is the separation into a server
  component and the application itself (client
  application)
• X server controls the graphical screen manages
  input devices and transmits their actions to the
  client
• The appearance of the window and the desktop is
  the task of the window manager
• XFree86 is a free implementation of the X server
• SLES defaults to using XFree86 4.x

6
Overview of the Linux Desktop (continued)
7
Overview of the Linux Desktop (continued)

• The communication between X server and X client
  uses TCP/IP
• Window managers are specialized client
  applications
• Provide control elements
• Manage virtual desktops
• Provide functionality of window frames
• X is not linked to any specific window manager
• SLES 9 has several window managers, including
  kwin (default), GNOME, and twm

8
Use the KDE Desktop Environment

• One of the most frequently used graphical desktop
  environments is KDE (installed by default)
• The following explains how to use KDE on SLES 9
• How to Log In
• How to Log Out
• How to Shut Down and Reboot the Linux System
• How to Identify KDE Desktop Components
• How to Manage Icons in the KDE Environment
• How to Use the Konqueror File Manager

9
How to Log In
10
How to Log In (continued)
11
How to Log In (continued)
12
How to Log Out

• At the bottom of the KDE menu, select Logout
• You can also right-click on the window background
  and select the same option from the popup menu
• A confirmation dialog box appears
• If you select Logout again, you are logged out
  and the login screen reappears, allowing you or
  another person to log in

13
How to Log Out (continued)
14
How to Shut Down and Reboot the Linux System

• If you are at the login screen, you can open the
  Menu menu and select from
• Session Type
• Restart X Server
• Shutdown Type (see Figure 2-6)
• Older computers have to be switched off manually
  when indicated to do so
• If you switch the machine off too soon, this
  could possibly lead to loss of data
• Always shut down your computer before you turn it
  off

15
How to Shut Down and Reboot the Linux System
(continued)
root password
16
How to Identify KDE Desktop Components

• After you log in, your system will by default
  start the KDE desktop environment it is composed
  of
• The Desktop
• The KDE Control Panel (Kicker)
• The KDE Menu (see Figure 2-8)
• Virtual Desktops
• By default, two virtual desktops are configured
• Increase the number of usable virtual desktops up
  to sixteen (use the KDE control center)

17
How to Identify KDE Desktop Components (continued)
18
How to Identify KDE Desktop Components (continued)

• The KDE menu consists of the following three
  sections
• Most Frequently Used Applications
• All Applications
• Actions
• A submenu in the KDE menu is marked by a small
  black arrow in the right-hand corner

19
How to Identify KDE Desktop Components (continued)
20
How to Manage Icons in the KDE Environment

• Three areas in your KDE environment contain
  icons
• Desktop
• Kicker
• KDE Menu

21
How to Manage Icons in the KDE Environment
Desktop

• There are several ways to create a new icon on
  your desktop
• To create an icon for an application on your
  desktop, do the following
• Select the item in your KDE menu
• Hold down the left mouse button, move the mouse
  pointer to free space on your desktop, and
  release the mouse button
• In the menu that appears, select Copy Here

22
How to Manage Icons in the KDE Environment Kicker

• You can add new programs to the control panel by
  right-clicking a free area of the panel and then
  selecting Add
• You can remove a program from the control panel
  by right-clicking its icon in the control panel
  and then selecting Remove program name
• You can move icons in the panel by holding down
  the middle mouse button or by choosing Move from
  the Context menu

23
How to Manage Icons in the KDE Environment KDE
Menu
24
How to Use the Konqueror File Manager
25
How to Use the Konqueror File Manager (continued)
26
Exercise 2-1 Explore Your KDE Desktop

• It is possible to administer SLES 9 without a
  graphical user interface
• However, sometimes a GUI is much more convenient
  than a pure text console
• The purpose of this exercise is to familiarize
  you with KDE

27
Use the GNOME Desktop Environment

• Both GNOME and KDE are comfortable desktop
  environments
• Like KDE, GNOME supports drag and drop
• Numerous programs are specifically designed for
  GNOME
• To use the GNOME desktop environment, you need to
  know the following
• How to Start GNOME
• How to Navigate in GNOME
• How to Manage Icons in GNOME
• How to Use the GNOME File Manager (Nautilus)

28
How to Start GNOME

• At login screen, select Session Type gt GNOME from
  the Menu drop-down list

29
How to Start GNOME (continued)
30
How to Navigate in GNOME

• Top panel
• Applications menu for launching applications
• Actions menu for basic actions (such as logging
  out)
• The Nautilus file manager (house icon)
• The terminal emulation window (monitor icon)
• A clock
• A speaker icon for volume
• A menu listing all open windows
• Bottom panel
• An icon to close all open windows
• A task manager
• A pager for the four virtual desktops

31
How to Navigate in GNOME (continued)

• Double-clicking an icon to start a program
• Set preferences for the desktop environment by
  selecting the Start Here icon
• To quit Actions gt Log Out in the GNOME panel

32
How to Navigate in GNOME (continued)
33
How to Manage Icons in GNOME

• You can find icons in the following three areas
  on your desktop
• Desktop
• Panel
• Application Menu

34
How to Manage Icons in GNOME Desktop

• There are several ways to create a new icon on
  your desktop
• To create an icon for an application on your
  desktop, select the item in your Applications
  menu, drag it to a free space on your desktop,
  release the mouse button then select Copy Here

35
How to Manage Icons in GNOME Panel

• You can add new programs to the control panel by
  right-clicking a free area of the panel and then
  selecting Add to Panel
• From the submenus displayed, select the
  application you want to add
• You can remove a program from the control panel
  by right-clicking its icon in the control panel
  and then selecting Remove from Panel
• You can move icons in the panel by holding down
  the right mouse button and selecting Move from
  the context menu

36
How to Manage Icons in GNOME Application Menu

• To add an entry to a menu, do the following
• Double-click the Start Here icon on the desktop
  the Start Here location appears
• In the file manager window, double-click the icon
  that represents the menu (Applications or Menu
  SuSE) to which you want to add the launcher
• Select File gt Create Launcher a Create Launcher
  dialog box is displayed
• Enter the properties of the launcher in the
  Create Launcher dialog box then select OK

37
How to Use the GNOME File Manager (Nautilus)
38
How to Use the GNOME File Manager (Nautilus,
continued)
39
Exercise 2-2 Explore Your GNOME Desktop

• Whether you use KDE or GNOME is entirely a matter
  of personal preference
• The purpose of this exercise is to familiarize
  you with the GNOME desktop

40
Access the Command-Line Interface from the Desktop

• Virtual terminals were created in Linux to allow
  a user to run tasks in parallel
• With virtual terminals, you can work in Linux as
  if you had several classic terminals available at
  the same time
• By default, you have six virtual terminals
  (F1F6) running on your computer
• Press Ctrl Alt Fx to switch between
  individual terminals
• Press Ctrl Alt F7 to switch back to your GUI

41
Access the Command-Line Interface from the
Desktop (continued)

• You can determine the terminal currently being
  used from the tty (teletype) number (tty1tty6)
• When you switch to a virtual terminal, a login
  prompt appears
• Welcome to SUSE LINUX Enterprise Server 9 (i586)
  - Kernel 2.6.4-27-
• default (tty1).
• da10 login
• To log out enter exit

42
Access the Command-Line Interface from the
Desktop (continued)

• Besides using the virtual terminals, you can
  start a terminal emulation (called Konsole) from
  your KDE desktop Kicker by selecting the icon
  shown below
• The terminal opens inside a window with options
  you can select to modify the display of the
  terminal

43
Exercise 2-3 Access the Command Line Interface

• SLES 9 does not need a GUI for its administration
• Even with a graphical desktop environment
  running, you can switch to the text consoles any
  time if you like to
• This exercise shows you how

44
Summary

• You can interact with a Linux system using a
  graphical user interface (GUI) or command-line
  interface
• The Linux GUI is provided by the X Window System,
  which consists of an X server, window manager,
  and client applications
• A desktop environment such as KDE or GNOME can be
  used to standardize the X Window System
• The KDE Control Panel at the bottom of the KDE
  desktop may be used to start applications, switch
  virtual desktops, or open the KDE menu

45
Summary (continued)

• The top panel in the GNOME desktop may be used to
  start applications, whereas the bottom panel may
  be used to switch virtual desktops or control
  applications
• You can obtain a command-line interface in SLES
  by interacting with one of six virtual terminals
• To switch from a command-line interface to a GUI
  interface, you can use the Ctrl Alt F7 key
  combination
