Application of QbD Principles for Biotech

1
Application of QbD Principles for Biotech
Biological Products
AAPS ISPE Present USFDA Pharmaceutical Quality
Initiatives Implementation of a Modern Risk Based
Approach

• Steven Kozlowski, M.D., Director
• Office of Biotechnology Products OPS/CDER

3/1/07
2
Overview

• Definitions
• Relevant Product Attributes
• Hypotheticals Cases
• Implementation Plans

3
What is Quality by Design?

• Quality
• Good pharmaceutical quality represents an
  acceptably low risk of failing to achieve the
  desired clinical attributes.
• Quality by Design (QbD)
• Means that product and process performance
  characteristics are scientifically designed to
  meet specific objectives, not merely empirically
  derived from performance of test batches.

Janet Woodcock (2004)
4
ICH Q8 Design Space
Product Understanding
Quality by Design
Process Understanding
Moheb Nasr
5
ICH Q8 Design Space
Product Understanding
Quality by Design
Process Understanding
Moheb Nasr
6
ICH Q8 Process Analytical Technology (PAT)

• A system for designing, analyzing, and
  controlling manufacturing through
• timely measurements (i.e., during processing)
• of critical quality and performance attributes of
  raw and in-process materials and processes
• with the goal of ensuring final product quality.

7
Process Importance

• Quality cannot be tested into a product but it
  must be built into the product process
• End product testing vs real time release
• For biotech
• lower heterogeneity
• greater risk of later steps changing product
• process control specs low hanging fruit
• The product is the processa biologics mantra

8
Traditional Paradigm
Variability
Raw Material
Product
Jon Clark
9
Dynamic System
Manufacturing Process
Raw Material
Endpoint Response
Input Response
Measurement Dependant Process Variables
Jon Clark
10
Target Critical Quality Attributes
CQA
Range
Process Designed to Limit Product Variability
Range of Raw Material and Facility Attributes
Jon Clark
11
Overview

• Definitions
• Relevant Product Attributes
• Hypotheticals Cases
• Implementation Plans

12
Structure of complex molecules

• 1? structure
• higher order structure
• post-translational modifications
• heterogeneity

Monoclonal Ab MW 150,000 Da
13
Attributes Combinatorics

• 2 x 6 x 4 x 4 x 5 x 5 x 2 9600

• (9600)2 108

14
Laurence J. Peter, American business humorist

• Some problems are so complex
• that you have to be highly intelligent
• and well informed
•

just to be undecided about them.
15

• Nothing is more difficult, and therefore more
  precious, than to be able to decide.
• Napoleon Bonaparte
• Even a correct decision is wrong when it was
  taken too late.
• Lee Iacocca

16
Functional Event Sequence Diagram
Oxidation Site 1
17
Event Tree (Quantification)
End State
Oxidation Site 1
Low Level
No Impact
Scenario
Detectable
18
Assigning Probabilities

• Actual Data
• Similarity Method
• Same Product
• Models (animals, bioassays)
• NASA Ground tests
• Related Product or Component
• Direct Data (clinical)
• Models (animals, bioassays)
• Probabilistic Structure Analysis
• e.g. probability of docking to all known
  receptors
• Far off

19
Biological Activity Matrix
20
Evolution of Monoclonal Antibodies
21
Overview

• Definitions
• Relevant Product Attributes
• Hypotheticals Cases
• Implementation Plans

22
Biotechnology Process Control
Many steps controlled by volume or time
Turbidity Conductivity
Chromatography Columns
Harvest
D02 pH
Fermentor
280nm ABS Conductivity
23
Upstream Scenarios

• Clementschitsch Bayer Microbial Cell Factories
  May 2006
• Paramagnetism (oxygen/mass balance)
• Dielectric Spectroscopy (biovolume)
• 2D Fluor NIR Spectroscopy
• Mass Spectroscopy (volatile organics)

24
Hypothetical Downstream

• Early product characterization
• Sub-potent charge variant
• Impurities A B

• Risk Ranking
• Buffer pH
• Column Load
• Buffer salt conc.

25
Designing Spaces
Comparability between clinical to-be marketed
process/material
Ranges used in clinical studies
Ranges to achieve small-scale column
performance
Linkage between small-scale experiments and
to-be-marketed process

• charge distribution
• impurity A removal
• impurity B removal

QbD
Linkage between column performance measures
product performance
Multivariate studies at small-scale
26
String Theory
Linear flow rate
Buffer ions
?
Column washes
Equilibration
Lifetime
27
Challenges
Operating parameters may no longer be relevant
Relevant Material Attributes
PAT
Input parameters may not detect
Real time measurement used for control
28
Platonic PAT
All clinically relevant material attributes are
measured and controlled in real time at the
correct process step on all the material
29
Scotty, Beam me down!

• Rathore et al. BioPharm Int Aug 2006
• Refolding by HPLC
• Diafiltration to surrogate
• 280 nm collection vs purity input
• Science not Nomenclature Relief
• Backward, Narrow, Inward PAT
• Maes Liedekerke JPI Sept/Oct 2006

30
Implementation

• Benefit from other OPS knowledge
• e.g. ONDQA pilot
• Participation in agency CRADAs for QbD
• Structure
• Mixture of research/reviewers and full time
  reviewers
• Experience with new technologies,
  fermentation/purification
• Expertise in biological characterization
• Engineer proteins for quality as well as S E
• desired product

31
Small Steps

• Product Testing
• If no likely impact on S and E dont include as a
  specification (no rejection limit)
• Process Changes
• Strategy to assess risk
• Platform Strategies
• monoclonal antibodies may share a great deal of
  structure
• efficient use of prior knowledge
• long history of a regulatory path for
  modular/generic validation (Mab PTC)
• Possible complex API pilot
• Need to consider discuss further

32
Credits

• Barry Cherney
• Patrick Swann
• Moheb Nasr
• Keith Webber
• Ajaz Hussain

• Jon Clark
• Chris Watts
• Ali Afnan
• Chris Joneckis
