PM2.5 Model Performance: Lessons Learned and Recommendations

1
PM2.5 Model Performance Lessons Learned and
Recommendations

• Naresh Kumar
• Eladio Knipping
• EPRI
• February 11, 2004

2
Acknowledgements

• Atmospheric Environmental Research, Inc. (AER)
• Betty Pun, Krish Vijayaraghavan and Christian
  Seigneur
• Tennessee Valley Authority (TVA)
• Elizabeth Bailey, Larry Gautney, Qi Mao and
  others
• University of California, Riverside
• Zion Wang, Chao-Jung Chien and Gail Tonnesen

3
Overview

• Model Performance Issues
• Need for Performance Guidelines/Benchmarking
• Review of Statistics
• Summary

4
Model Performance Issues

• Evaluation of Modeling Systems
• Local vs. Regional Evaluation
• Daily/Episodic/Seasonal/Annual Averaging
• Threshold and Outliers
• What Species to Evaluate?
• Sampling/Network Issues

5
Examples from Model Applications

• Two applications of CMAQ-MADRID
• Southeastern U.S. (SOS 1999 Episode)
• Big Bend National Park, Texas (BRAVO) Four-Month
  Study
• Statistical performance for SO42, EC, OM, PM2.5

6
Application in Southeastern U.S.

• Southern Oxidant Study (SOS 1999)
• June 29 to July 10, 1999
• Meteorology processed from MM5 simulations using
  MCIP2.2
• Emissions files courtesy of TVA
• Simulation
• Continental U.S. Domain
• 32-km horizontal resolution without nesting

7
Application to Big Bend National Park
REMSAD
CMAQ-MADRID

• The Georgia Tech/Goddard Global Ozone Chemistry
  Aerosol Radiation Transport (GOCART) model
  prescribed boundary conditions for SO2 and SO42
  to the REMSAD domain.
• Preliminary Base Case simulation used boundary
  conditions as prescribed from a simulation of the
  larger outer domain by REMSAD.
• SO2 and SO42 concentrations were scaled at
  CMAQ-MADRID boundary according to CASTNet and
  IMPROVE Network observations.

8
BRAVO Monitoring Network
9
Local vs. Regional (SOS 1999)
10
Local vs. Regional (BRAVO)
11
Daily SO42 PO Pairs with Different Averaging
12
Daily SO42 PO Pairs for Each Month
13
Effect of Threshold
14
Mean-Normalized/Fractional Statistics
15
Need for Model Performance Guidelines

• If no guidelines exist
• Conduct model simulation with best estimate of
  emissions and meteorology
• Perform model evaluation using favorite
  statistics
• Difficult to compare across models
• State that model performance is quite good or
  adequate or reasonable or not bad or as
  good as it gets
• Use relative reduction factors
• With guidelines for ozone modeling
• If model didnt perform within specified
  guidelines
• Extensive diagnostics performed to understand
  poor performance
• Improved appropriate elements of modeling system
• Enhanced model performance

16
Issues with Defining Performance Guidelines for
PM2.5 Models

• What is reasonable, acceptable or good
  model performance?
• Past experience How well have current models
  done?
• What statistical measures should be used to
  evaluate the models?

17
Criteria to Select Statistical Measures I

• Simple yet Meaningful
• Easy to Interpret
• Relevant to Air Quality Modeling Community
• Properties of Statistics
• Normalized vs. Absolute
• Paired vs. Unpaired
• Non-Fractional vs. Fractional
• Symmetry
• Underestimates and overestimates must be
  perceived equally
• Underestimates and overestimates must be weighted
  equally
• Scalable biases scale appropriately in statistics

18
Criteria to Select Statistical Measures II

• Statistics that can attest to
• Bias
• Error
• Ability to capture variability
• Peak accuracy (to some extent)
• Normalizes daily predictions paired with
  corresponding daily observations
• Inherently minimizes effect of outliers
• Some statistics/figures may be preferable for
  EVALUATION, whereas others may be preferred for
  DIAGNOSTICS

19
Problems with Thresholds Outliers

• Issues with addressing low-end comparisons via
  threshold
• Instrumental uncertainty detection limit,
  signal-to-noise
• Operational uncertainty
• Additional considerations network, background
  concentration, geography, demographics
• Inspection for outliers
• Outlier vs. valid high observation
• Definition of outlier must be objective and
  unambiguous
• Clear guidance necessary for performance
  analysis.

20
Review of Statistics

• Ratio of Means (Bias of Means) or
  Quantile-Quantile Comparisons
• Defeats purpose of daily observations completely
  unpaired
• Hides any measure of true model performance
• Normalized Mean Statistics (not to confuse with
  Mean Normalized)
• Defeats purpose of daily observations Equally
  weighs all errors regardless of magnitude of
  individual daily observations
• Masks results in bias (e.g., numerator zero
  effect)
• Based on Linear Regressions
• Slope of Least Squares Regression Root
  (Normalized) Mean Square Error
• Slope of Least Median of Squares Regression
  (Rousseeuw regression)
• Can be skewed neglects magnitude of
  observations good for cross-comparisons.
• Fractional Statistics
• Taints integrity of statistics by placing
  predictions in denominator not scalable

21
Bias Statistics

• Mean Normalized Bias/Arithmetic Bias Factor
• Same statistic ABF is the style for symmetric
  perception
• ABF 21 for 100 MNB, ABF 12 for 50 MNB
• MNB in can be useful during diagnostics due to
  simple and meaningful comparison to MNE, but the
  comparison is flawed.
• The statistics give less weight to
  underpredictions than to overpredicitions.
• Logarithmic Bias Factor/Logarithmic-Mean
  Normalized Bias
• Wholly symmetric representation of bias that
  satisfies all criteria
• Can be written in factor form or in
  percentage form

22
Error Statistics

• Mean Normalized Error
• Each data point normalized with paired
  observation
• Similar flaw as Arithmetic Mean Normalized Bias
  The statistic gives less weight to
  underpredictions than to overpredicitions.
• Logarithmic Error Factor/Logarithmic-Mean
  Normalized Error
• Satisfies all criteria
• Comparisons between logarithmic-based statistics
  (bias and error) are visibly meaningful when
  expressed in factor form

23
Comparing Bias and Error Statistics Based on
Arithmetic and Logarithmic Means
24
Mean Normalized/Fractional Statistics
25
Logarithmic/Arithmetic Statistics
26
Logarithmic/Arithmetic Statistics
Note MNB/ABF MNE use 95 data interval. FB,
FE, LMNB/LBF and LMNE/LEF use 100 of data.
27
Relating Criteria for LBF/LMNB and LEF/LMNE

• Criterion for Logarithmic EF/MNE can be
  Established from Criterion for Logarithmic BF/MNB
• For example Error twice the amplitude of Bias
• Logarithmic Bias Factor/Logarithmic-Mean
  Normalized Bias
• LBF 1.251 to 11.25 LMNB 25 to -20
• Logarithmic Error Factor/Logarithmic-Mean
  Normalized Error
• LEF 1.56 LMNE 56

28
Relating Criteria for LBF/LMNB and LEF/LMNE

• Criterion for Logarithmic EF/MNE can be
  Established from Criterion for Logarithmic BF/MNB
• For example Error twice the amplitude of Bias
• Logarithmic Bias Factor/Logarithmic-Mean
  Normalized Bias
• LBF 1.501 to 11.50 LMNB 50 to -33
• Logarithmic Error Factor/Logarithmic-Mean
  Normalized Error
• LEF 2.25 LMNE 125

29
Variability Statistics

• Coefficient of Determination R2
• Should not be used in absence of previous
  statistics
• Coefficient of Determination of Linear
  Regressions
• Least Squares Regression through Origin Ro2
• Used by some in global model community as a
  measure of performance and ability to capture
  variability
• Least Median of Squares Regression
• More robust, inherently minimizes effects of
  outliers
• Comparison of Coefficients of Variation
• Comparison of Standard Deviation/Mean of
  predictions and observations
• Other statistical metrics?

30
Summary Items for Discussion

• What spatial scales to use for model performance?
• Single Site Local/Region of Interest
• Large Domain/Continental
• What statistics should be used?
• What are the guidelines/benchmarks for
  performance evaluation?
• Should the same guidelines be used for all
  components
• Sulfate, Nitrate, Carbonaceous, PM2.5
• Ammonium, Organic Mass, EC, Fine Soil, Major
  Metal Oxides
• How are network considerations taken into account
  in guidelines?
• Should models meet performance guidelines for an
  entire year and/or other time scales (monthly,
  seasonal)?
• Should there be separate guidelines for different
  time scales?
• Statistics based on daily PO pairs
• Average daily results to create weekly, monthly,
  seasonal or annual statistics

31
More Examples

• More examples of Comparison of Statistics
• Fractional
• Arithmetic-Mean Normalized
• Logarithmic-Mean Normalized

32
Mean Normalized/Fractional Statistics
33
Logarithmic/Arithmetic Statistics
34
Mean Normalized/Fractional Statistics
35
Logarithmic/Arithmetic Statistics
36
Mean Normalized/Fractional Statistics
37
Logarithmic/Arithmetic Statistics
