Overview of Chemical and Biological WeaponsTerrorism

1
Overview of Chemical and Biological
Weapons/Terrorism

• Tucker Greene, MD, FAAEM, ACMT
• Cape Coral, FL

2
Introduction

• Long History of humans using both agents
• Precedents
• Ancient
• Middle Ages - Anthrax contaminated livestock
• Recent
• Southeast Asia Tricothecenes
• Iran/Iraq Sarin
• Arum Shryinko Tokyo subway attack

3
Introduction

• Agent Progression
• Chemical
• Industrial process
• Biological
• Agents, offspring
• toxins
• Different Results than predicted for both

4
Introduction

• Persistent v. Non-Persistent Biological
• Persistent Anthrax
• Non-Persistent Viruses
• Persistent v. Non-Persistent
• Persistent Mustard, VX
• Non Persistent Phosgene, CN

5
Introduction

• Stability or Infectivity
• Anthrax Spores stable, reasonably infective,
  lethal?
• Tularemia, Q-Fever, Brucellosis unstable, very
  infective, non-lethal

6
Introduction

• Biological Agents
• Mimic other natural diseases
• Usually incapacitating
• Chemical Agents
• Exaggerate or Isolate a particular clinical
  feature of chemical agents in general
• I.e organophosphates and nerve agents
• KEY Mechanism of Intoxication
• Dermal, Inhalation, Ingestion

7
(brief) History

• Definitions
• Kill Soman, VX
• Injure Phosgene
• Incapacitate CS, BZ
• Countermeasures
• Until WWI, US not concerned or interested

8
(brief) History

• Pre-WWI Developments
• Ancient hellebore, mandrake in water 1000-200
  b.c
• Recent
• 1700-1850 Chlorine, Mustard (dichloroehtylsulfid
  e), chloropicrin
• Civil War Dougherty Chlorine, 3 qts in shell

9
(brief) History

• Biological
• Mongols in Caffa 1346, bubonic plague bodies
• Spanish v French 1495, Leprosy Blood in Naples
  against French

10
Protection, Control

• US Civil War agreed but not adhered to
• Hoffman Respirator in 1866
• Archduke Francis murder in 1914, control among
  WWI participants

11
Protection, Control

• WWI Chemical
• German Wilhelm Gas cloud due to lack of shells
• Allies Chlorine response
• Biological
• Both sides attempting to use anthrax and
  glanders

12
US Chemical Warfare Service (CWS) and New Age

• Chemical Agents placed in Artillery Shells
• Cl2, Choropicrin, Mustard, Phosgene
• Biological Agents
• Ricin
• Brucellosis

13
US Chemical Warfare Service (CWS) and New Age

• Detection, Alarms, Treatment
• Human and Animal
• Treatment
• Inhalation
• Vomiting
• Venesection
• KI
• Steam Tents
• Skin ZnO, Starch, Boric Acid, Calamine

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
US Chemical Warfare Service (CWS) and New Age

• Biologicals get new start in late 1930s after
  skepticism
• Nuclear Age comes and biologicals take a back
  seat (where someone was sitting)
• Chemical Warfare takes second Priority
• Edgewood (Aberdeen), MD
• McClellan, AL
• Rocky Mountain, CO

22
US Chemical Warfare Service (CWS) and New Age

• Near ending of CWS
• Binary weapons
• Disposal at Sea
• Disseminated Danger of lesser nations?
• Johnston Atoll Destruction program

23
US Chemical Warfare Service (CWS) and New Age

• Gulf War
• Iraq with known biological and chemical weapons
• MARK I Kit
• 2-PAM, atropine, valium
• Pryidostigmine Bromide
• Kamisiyah arsenal detonation
• Mustard
• sarin

24
US Chemical Warfare Service (CWS) and New Age

• Aum Shinrikyo Cult
• Experiments with botulinum and anthrax in subways
  yields no impact
• Later sarin attack kills 50 but injures 5000

25
DEFENSE (WWI)

• Mask against Chemical Agents
• Plume identification
• Mobile Decontamination
• 5 of Division strength
• Psychological aspect of persistence mustard (low
  volatility, low dose effect, still used)
• Gas Mania

26
DEFENSE (WWI)

• Mustard
• Conjunctivitis
• Skin burns
• Inhalation (worse than phosgene and chlorine)
• Accounted for up to 30 of casualties but 1500
  deaths/52,900 US AEF Force deaths

27
DEFENSE (WWII)

• Germans thought US possessed secret gases beyond
  GAlt GBlt GD and feared reprisal
• Continued Vigilance
• Walt Disney example

28
Chemical Warfare and the HealthCare Provider
29
National Warfare Capability
30
Chemical Warfare Agents
31
(No Transcript)
32
Nerve Agents
33
Organophoshates

• History
• Ethanol Phosphoric Acid
• Tabun - GA
• Sarin - GB
• Soman- GD
• VX

34
Organophosphates

• Examples

35
Organophosphates

• Absorption
• inhalation
• dermal
• oral
• Activation
• ie parathion
• Metabolism
• cholinesterase

36
(No Transcript)
37
Organophosphates

• Mechanism of Toxicity

38
Organophosphates

• Clinical Effects

39
Organophosphates

• Clinical Effects
• Muscarinic (postganglionic parasympathetic)
• SLUDGE
• miosis, bronchorrhea, bradycardia
• Nicotinic (neuromuscular junction)
• Nicotinic (autonomic ganglion)

40
Organophosphates

• Management/Treatment
• Decontamination
• Stabilization
• Antidotes
• Atropine
• Pralidoxime

Pralidoxime
41
Organophosphates

• Delayed Toxicity
• Intermediate Syndrome
• Peripheral Neuropathy
• Tri -o-cresyl phosphate (TOCP)
• Tri -o-cresyl tolyl phosphate TOTP
• Neurotoxic Esterase

42
Organophosphates

• Delayed Toxicity
• Intermediate Syndrome
• Peripheral Neuropathy
• Tri -o-cresyl phosphate (TOCP)
• Tri -o-cresyl tolyl phosphate TOTP
• Neurotoxic Esterase

43
Organophosphates

• Laboratory
• Dont Need To Treat!!!
• Cholinesterase Levels
• RBC v Plasma
• Variation from Baseline

44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
Pretreatment

• Pyridostigmine (carbamate)
• Used in Gulf War

48
Vesicants
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
Sulfur Mustard
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
Phosgene
62
Lewisite
63
Inhalational Agents
64
Inhalational Agents

• Upper Airway
• Water soluble
• Middle Airway
• Alveolar
• Non-soluble in water
• Cellular Asphyxiants

65
Inhalational Agents
66
(No Transcript)
67
(No Transcript)
68
Inhalational Agents

• Cyanide Treatment
• Nitrites
• Thiosulfate
• Hydroxycobalamin
• Hyperbaric O2

69
Incapacitating Agents
70
Incapacitating Agents

• Anticholinergics
• LSD, other Indoles
• Opiates

71
Riot Control Agents

• Rapid Onset, Upper Airway and GI Symptoms
• CS (o-Chlorobenzylidene)
• CN (1-Chloroacetophenone)
• Other
• DM (Diphenylaminearsine)
• CR (Dibenzo(b,f)-14oxazepine
• CA (Bromobenzylcyanide)

72
Riot Control Agents

• CS
• Solid, low Vp
• Tear Gas
• Airway irritation
• Conjunctival tearing
• Dermal effects can cause blistering
• IV/Oral can liberate cyanide moeities

• CN
• Solid powder
• Same symptoms as CS
• Highly sensitizing to skin with deaths reported
  with large exposures

73
Riot Control Agents

• Treatment
• Alkaline decon of skin no hypochlorite
• Topical steroids for skin
• Local anesthetics for eyes

74
Field Management of Chemical Casualties

• Hot Zones
• Clean v Decontamination areas
• Counter-current or Reverse Airflow for
  Decontamination Areas
• Triage
• Potential ID
• Look for Combined Agents/Injuries
• Difficult to Treat Combinations

75
(No Transcript)
76
(No Transcript)
77
Decontamination

• Chemical
• Desirable Traits for Dermal Decon
• Physical Removal
• Aqueous
• Adsorbent

• Biological
• Dermal not as Important (T-2 is exception)
• Hypochlorite
• Environmental UV

78
BIOLOGICALS
79
History

• Secret US Weapons Program
• Response to Japan during WWII
• Stockpiling 400 kg anthrax bombs
• Experiments
• San Francisco (Serratia marcenscens)
• New York Subway (B. subtilis)
• African Americans exposed to Aspergillus f.

80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
Use of Biological Weapons

• Methods of Delivery
• Food
• Water
• Air

• Requirements
• Ease of Production
• Lethality/Incapacitation
• Particle size
• Ease of Dispersion
• Stability

84
Use of Biological Weapons

• Tactical Concerns
• Hard to Trace or Fingerprint
• Terrorism as we now have known the anthrax cases

• Advantage/Disadvantage
• Predominantly concerns of the pathogen occurring
  in aggressors
• Persistence
• Insidious, low cost, minimal detection

85
Biological Agents

• Anthrax
• Plague
• Tularemia
• Brucellosis
• Q Fever

• Smallpox
• Viral Encephalitides
• Viral Hemorrhagic Fevers
• Toxins
• Plants
• Animals
• Mycotoxins

86
Anthrax

• History
• Bacillus anthracis
• Zoonoticgoats sheep, cattle, swine, horses
• 5th and 6th plagues of Exodus
• Isolated 1876 Koch
• Vaccine 1881 Pasteur

• Organism
• 1-5 mic x 5-10 mic
• Capsule forms in presence of CO2, HCO3
• Sporulation occurs in dead tissue exposed to
  oxygen

87
Anthrax

• Epidemiology
• 1958 20-100,000 cases worldwide
• Since 1970 one case/decade
• Woolsorters Disease

• Pathogenesis
• Antiphagocytic Capsule
• Lethal Toxin
• Edema Toxin
• Mechanism by cell binding and then active toxin

88
Anthrax

• Clinical Disease
• Cutaneous
• Inhalational
• Gastointestinal
• Meningeal

• Diagnosis
• CLINICAL SUSPICION OF EXPOSURE

89
Anthrax

• Treatment
• Pen G
• Doxycycline
• Ciprofloxacin
• Many other possibly effective

• Recombinants may possess resistance as the native
  vegetative state has lactamases

90
Plague

• History
• Pandemics of the 6th, 14th, 20th century
• 24 Million died from 1346-1352
• Endemic throughout history
• Zoonotic
• Enzoontic
• Epizootic

• Infectious Agent
• Yersinia pestis
• Gram-neg, non-sporulating, coccobacillus
• pH 6 antigen induced at low pH for virulence
• Antiphagocytic capsule
• Complex interspecies toxins

91
Plague

• Epidemiology
• Oriental rat flea most common vector
• Multiple animals serve as vectors
• US rat squirrel fleas
• Endemic in Western US

• Pathogenesis
• 1-10 organism can infect via bites
• Multiple Virulence factors
• Spread via lymph
• Sepsis occurs when untreated to all organs

92
Plague

• Clinical Features
• 80 as bubonic form
• 10 as sepsis
• 10 as pulmonary
• As warfare agent presentation would be bubonic
  and pulmonary

• Generally present as gram negative infection with
  plague specific features

93
Plague

• Diagnosis
• Differential
• Cat Scratch
• Tularemia
• LGV
• Chancroid
• TB
• Streptococccal
• Rickettsiae

• Lab Confirm
• Aspiration of Bubo
• Wright-Giemsa, Gram Stain

94
Plague

• Treatment
• Isolation for first 48 hrs of treatment
• Streptomycin, ceftriaxone, chloramphenical,
• Doxycyclcine all acceptable
• If treated early, buboes do not require drainage
• Postexposure Prophylaxis Doxycycline
• Immunization high risk individuals

95
Tularemia

• History
• Discovered in 1911 in Tulare County, California
  by McCoy
• Edward Francis discovered deer fly transmission
• High infectivity after aerosolization

• Agent
• Francisella tularensis
• Obligate aerobe, coccobacillus
• Two biovars US isolate highly virulent for
  rabbits, humans

96
Tularemia

• Epidemiology
• Principle reservoir is the tick in the US
• Abdominal Pain, Pharyngitis, from contaminated
  water in areas where water mammals live (non-US)

• Pathogenesis
• Possibly capsular
• Unclear, no toxins
• Spreads through skin, mucous membranes, GI
• 5-10 organisms
• Humoral response by MHC II mediated T-cell
  immunity

97
Tularemia

• Clinical Features
• Incubation 3-6 day
• Ulceroglandular 75
• Skin or mucous membranes, nodes gt1cm
• Typhoidal 25
• Smaller nodes
• Non-mucous membranes

• Multiple Const/Syst complaints
• Fever
• HA
• Chills
• Abdominal pain
• Fluctuant Lymph nodes (drainage)

98
Tularemia

• Diagnosis
• Difficult serology and growth medium procedures
• ELISA most reliable

• Treatment
• Streptomycin
• Aminoglycosides
• Chloramphenicol
• Tetracyclines
• Prophylaxis
• Doxycycline

99
Brucellosis

• Agent
• Non-toxic, nonsporulating,aerobic, Gram-neg,
  coccobacilli
• 6 species with several biovars
• Unusual LPS component of cell membrane

• History
• Zoonotic infection
• Domestic
• Wild
• Animal Products, contact with infected animals,
  aerosols
• Relapsing Fever, associated with ruminant
  abortion
• US actively developed warfare agent with Brucella

100
Brucellosis

• Epidemiology
• Transmission at abortion, slaughter, and milk
• Highly infectious in lab workers who work with
  the Brucella
• Fewer than 200 fatal cases/yr in US

• Pathogenesis
• Enter thru skin, GI, mucous membranes
• Phagocytized by WBC but carried to lymph nodes
• Placenta may carry 1010 bacteria/gram

101
Brucellosis

• Clinical Features
• diverse, variability
• 3d to weeks incubation
• Neuropsychiatric along with fever, cough,
  arthritis
• Mild lab abnormalities

• Diagnosis
• Serum agglutination
• PCR
• IgG

102
Brucellosis

• Treatment
• Doxycycline
• Streptomycin
• Aminoglycosides
• Prophylaxis
• Prevention (no-vaccine)
• Doxycycline

103
Q Fever

• History
• 1937 discovery
• Zoonotic
• Coxiella Burnetii
• 50 g of dried powder equal to casualty rate of
  anthrax or tularemia
• Multiple wars with soldiers infected from living
  in barns, near livestock

• Agent
• Close relative of Legionella, not true
  rickettsiae
• Obligate intracellular pathogen
• Spore-like formation
• Phase I/II

104
Q Fever

• Epidemiology
• Extremely infectious
• Single organism capable of disease
• Multiple hosts, arthropod to human
• Human infection from livestock same as
  Brucellosis but also shed in urine
• Urine persistence can infect from objects such as
  straw

• Pathogenesis
• Inhalation of aerosols
• Phagocytosis with eventual lysis and release

105
Q Fever

• Clinical Features
• Incubation 10-40 days
• Asymptomatic seroconversion
• Acute Disease
• Chill,rigors,retroorbital HA
• Fever, myalgias
• Chronic endocarditis

• Diagnosis
• Serological
• Comp Fixation
• Indir Flour Ab
• ELISA

106
Q Fever

• Treatment
• Tetracyclines
• Macrolides
• Quinolones in chronic disease
• Prophylaxis
• Vaccine
• Doxycycline

107
Smallpox

• Variola ds-DNA, Orthopox Virus
• Major 30 mortality, Asia, Africa
• Minor 1 mortality, Europe, South America
• Possible to recover Smallpox from preserved
  cadavers or recombinant with monkeypox

108
Smallpox

• Pathogenesis and Clinical Features
• Highly stable and infective for long periods
  outside of host
• Fever, followed by rash 3-6 days later
• Rash period is infective, lymphoid dissemination
• Head to toe spread
• Incubation avg 12 days
• Sx fever, delerium, backache, cough (aerosol)
• Hemorrhagic and Flat-type higher mortality

109
Smallpox

• Diagnosis and Treatment
• Dx Guarnieri bodies viral aggregation
• Distinguish subclinical Smallpox from Varicella
• Quarantine for 3 days for rash development post
  exposure
• Vaccines
• Vaccinia
• VIG within 7 days of disease care if recently
  vaccinated

110
Viral Encephalitides
111
(No Transcript)
112
Viral Encephalitides

• Zoonotic viruses
• Aerosolization transmission as well as insect
  route of biological warfare agent a source of
  concern
• Each VE has distinct but similar incubation,
  symptoms and mortality
• Vaccines key to management of VEE, WEE, EEE

113
Viral Hemorrhagic Fevers
114
(No Transcript)
115
Toxins
116
(No Transcript)
117
pg607
118
Toxins

• General Discussion and Overview
• Mechanism of Toxicity
• Diagnosis/Recognition
• Treatments/Antidotes
