Scheduling Resource Management in Distributed
Systems Rajesh Rajamani, raj_at_cs.wisc.edu http//
www.cs.wisc.edu/condor May 2001
2
Outline

• Hi-throughput computing and Condor
• Resource Management in distributed systems
• Matchmaking
• Current research/Misc.

3
Power of Computing environments

• Power Work / Time
• High Performance Computing
• Fixed amount of work how much time?
• Traditional Performance metrics FLOPS, MIPS
• Response time/latency oriented
• High Throughput Computing
• Fixed amount of time how much work?
• Application specific performance metrics
• Throughput oriented

4
In other words

• HPC - Enormous amounts of computing power over
  relatively short periods of time
• () Good for applications under sharp time
  constraint
• HTC - Large amounts of computing power for
  lengthy periods
• () What if u want to simulate 1000 applications
  on ur latest DSP chip design over the next 3
  months??

5
The Condor Project

• Goal - To develop, implement, deploy, and
  evaluate mechanisms and policies that support
  High Throughput Computing (HTC) on large
  collections of distributively owned computing
  resources

6
More about Condor

• Started in late 80s
• Principal Investigator - Prof.Miron Livny
• Latest version 6.3.0 released
• Supports 14 different platforms (OS Arch)
  including Linux, Solaris and WinNT
• Currently employs over 20 students and 5 staff
• We write code, debug, port, publish papers and
  YES, we also provide support !!!

7
Distributed ownership of resources

• Underutilized - 70 of CPU cycles in a cluster go
  waste
• Fragmented - Resources owned by different people
• Use these resources to provide HTC, BUT without
  impacting QOS available to owner
• Achieved by allowing the user to set access
  policy using control expressions

8
Access policy

• Current state of the resource (eg, keyboard idle
  for 15 minutes or load average less than 0.2)
• Characteristics of the request (run only jobs of
  research associates)
• Time of day/night that jobs can be run

9
What happens when u submit a job
Central Manager
2. Submitting machine sends Classad of the job
Resources announce their properties periodically
3. Matchmaker Notifies parties of a match
Submitting machine
Available resource
4. Parties negotiate
1. User submits a job
10
Important Mechanisms
Mechanism For
Matchmaking Resource Management
Checkpointing Saving the state of a job
Bypass Remote system calls
DAGMAN Automatic job submission based on dependency graph
Master-Worker Exploiting task level parallelism
11
Condor Architecture

• Manager
• Collector Database of resources
• Negotiator Matchmaker
• Accountant Priority maintenance
• Startds ( Represent owners of resources)
• Implement owner's access control policy
• Schedds ( Represent customers of the system)
• Maintain persistent queues of resource requests

12
Condor Architecture, cont.
13
Power of Condor

• Solves NUG30 Quadratic assignment problem, posed
  in 1968 over a period of 6.9 days, delivering
  over 96,000 CPU hours by commandeering an average
  of 650 machines !!!
• Compare this with the RSA-155 problem posed in
  1977 and solved using 300 computers (over a
  period of 7 months) in the last 90s. If you were
  to use the same amount of resources as that used
  to solve NUG30, this couldve been done in 2
  weeks !!!
• It (Chorus production) was done in parallel on
  machines in the computer center running XXX, and
  on the office machines under Condor. The latter
  did about 90 of the work! -
• - Helge MEINHARD
• (EP division, CERN)

14
Resource management using Matchmaking

• Opportunistic Resource Exploitation
• Resource availability is unpredictable
• Exploit resources as soon as they are available
• Matchmaking performed continuously
• As against a centralized scheduler which
  wouldve to deal with -
• Heterogeneity of resources
• Distributed Ownership - widely varying allocation
  policies
• Dynamic nature of the cluster

15
Classified Advertisements

• A simple language used by resource providers and
  customers to express their properties/requirements
  to the Collector
• Uses a semi-structured data model gt no specific
  schema is required by the matchmaker, allowing it
  to work naturally in a heterogeneous env
• Language folds query language into the data
  model. Constraints may be expressed as attributes
  of the classad
• Should conform to advertising protocol

16
Matchmaking with Classads

• 4 steps to managing resources -
• Parties requiring matchmaking advertise their
  characteristics, preferences, constraints, etc.
• Advertisements matched by a Matchmaker
• Matched entities are notified
• Matched entities establish an allocation through
  a claiming process - could include
  authentication, constraint verification,
  negotiation of terms etc
• Method is symmetric

17
Classad example

• Sample classad of a Job
• Type Job
• Owner run_sim
• Constraint
• other.Type Machine
• Arch INTEL
• Opsys Solaris251
• Other.Memory gt Memory

• Sample classad of a workstation
• Type Machine
• OpSys Linux
• Arch INTEL
• Memory 256 M
• Constraint true

18
Example Classad (workstation)

• Type Machine
• Activity Idle
• Name crow.cs.wisc.edu
• Arch INTEL
• OpSys Solaris251
• Kflops 21893
• Memory 64
• Disk 323496 //KB
• DayTime 36107

19
Example Classad (contd.)

• ResearchGrp miron, thain, john
• Untrusted bgates, lalooyadav,
  thief
• Rank member(other.Owner, ResearchGrp)10
• Constraint !member(other.Owner, Untrusted)
  Rank gt 10 ?true false //To prevent
  malicious users

20
Example Classad (Submitted job)

• Type Job
• QDate 886799469
• Owner raman
• Cmd run_sim
• Iwd /usr/raman/sim2
• Memory 31
• Rank Kflops/1e3 other.Memory/32
• Constraint other.Type Machine
  OpSys Solaris251 Disk gt 10000
  other.Memory gt self.Memory

21
Matchmaking

• Evaluates expressions in an environment that
  allows each classad to access attributes of the
  other
• Other.Memory gt self.Memory
• References to non-existent attribute evaluates to
  undefined
• Considers pairs of ads incompatible unless their
  Constraint expressions both evaluate to true
• Rank is then then used to choose among compatible
  matches
• Both parties are notified about the match - could
  generate and hand-off session key for
  authentication and security

22
Separation of Matching and Claiming

• Weak consistency requirements - Claiming allows
  provider and customer to verify their constraints
  with respect to their current state
• Claiming protocol could use cryptographic
  techniques (authentication)
• Principals involved in a match are themselves
  responsible for establishing, maintaining and
  servicing a match

23
Work outside the Condor kernel- New challenges

• Mulitlateral Matchmaking - Gangmatching
• IO regulation and Disk allocation - Kangaroo
• User interfaces - ClassadView
• Grid applications - Globus
• Security

24
Summary

• Matchmaking provides a scalable and robust
  resource management solution for HTC environments

• Classads are used by workstations and jobs
• Matchmaker forms the match and informs the
  parties, who in turn invoke the claiming protocol
• The parties are responsible for establishing,
  maintaining and servicing a match
• Questions ?

25
Gangmatch request

• Type Job
• Owner raj
• Cmd run_sim
• Ports
• Label cpu
• ImageSize 28 M
• //Rank and constraints ,
• Label License
• Host cpu.Name
• //Rank and constraints
