Preparation of SDTreated MiniPool Blood Products

1
Preparation of SD-Treated Mini-Pool Blood
Products

• Magdy El Ekiaby, MD
• Shabrawishi Hospital BTC HTC
• Cairo, Egypt

2
Definition

• Preparation of virally inactivated, SD-treated
• cryoprecipitate,
• plasma,
• and cryo-poor plasma
• by blood establishments

3
Objectives

• Easy-to-use, cost/effective, reliable, and
  affordable technology
• Implementation by blood establishment with
  minimum infrastructure investment
• It should fit blood establishments that can
  prepare and test blood components following good
  practices

4
Project elements

• GMP production of plasma and its components in
  blood establishments
• Development and adaptation of SD virus
  inactivation procedures into blood establishments
• Introducing principles of quality assurance and
  quality control to ensure effective uniform final
  product

5
SD mini-pool virus inactivation technology

• Solvent-Detergent virus inactivation a gold
  standard and a robust technology
• Long clinical experience with SD-treated products
• Inactivation of lipid enveloped viruses (most
  pathogenic TTV)
• Less risk for transmission of non-enveloped
  viruses due to the mini-pool size

6
SD mini-pool current options developed

• Viral inactivation step-
• 2 TnBP, 37C
• 1 TnBP 1 Triton X45, 31C
• Solvent-Detergent removal-
• 3 oil extractions with Castor/Soya Bean Oil
• /- SDR/C18 chromatography adsorption step
• Performed in a closed sterile disposable
  processing system with equipment that is
  routinely used in blood establishments

7
Equipments

• Laminar air flow cabinet for aseptic environment
• Syringe pump for SD addition under controlled
  flow-rate, volume, and duration
• Shaker for controlled and reproducible mixing of
  SD agents
• Shaker incubator -
• Control mixing of SD plasma/cryoprecipitate
  under optimal temperature
• Control mixing of oil and plasma/cryoprecipitate
  for SD removal under optimal temperature

8
Reagents

• TnBP
• Triton X45
• Soya Bean oil
• /- C18/SDR

9
The Disposable

• Interconnected patented closed sterile bag system
  formed of-
• 2 bags for mixing SD with plasma, cryo-poor
  plasma or cryoprecipitate and perform virus
  inactivation
• 3 oil extraction bags for removal of solvent and
  detergent
• Inlets to the bags for addition of SD and oil
• The inlets are protected with caps and clamps
• Double clamps on the connecting lines between
  bags to segregate the different processing steps
  and control the transfer of the plasma component
  from one bag to the next

10
Virus inactivation bags
1st stage

• Viral inactivation performed
• - in two stages
• And using oval bags to avoid dead-ends and poor
  mixing
• FOR OPTIMAL GUARANTEE OF VIRUS KILL

2nd stage
11
SD Removal bags

• Funnel Shape bag where plasma component is mixed
  with Soya Bean oil to remove SD
• There is an inlet line for addition of the oil
• The funnel shape design of the bag allows for
  accurate separation of the plasma from the oil
• The process may be repeated for 2-3 times for
  removal of TnBP Triton after virus inactivation
  step.

12
One SD technique for three plasma components
13
(No Transcript)
14
SD-Cryoprecipitate
15
(No Transcript)
16
(No Transcript)
17
VWF in SD-treated cryoprecipitate
Collaborative study with Professor Jenny
Goudemand and Dr. Claudine Caron,
CHRU, Lille, France
18
(No Transcript)
19
(No Transcript)
20
No detrimental impact of SD on VWF in cryo

• No significant changes in
• VWFAg
• VWFRCo
• VWF CB
• VWF multimers including the highest MW gt 15 mers

21
Residual TnBP and Triton X-45

• TnBP lt 10 ppm
• Triton X-45 lt 100 ppm

22
Viral validation study of SD in the disposable
system

• Performed at Texcell/Pasteur Institute
• Spiking studies using-
• HIV1, relevant virus
• Pseudo Rabies Virus (PRV) as a model of Herpes
  Virus
• Bovine Viral Diarrhea Virus (BVDV) as a
  recognized model for HCV
• gt4 log reduction of the 3 viruses in two minutes

23
Technical Steps of Mini-Pool SD Virus
Inactivation Cryoprecipitate
24
Cryoprecipitate preparation

• The usual blood bank techniques
• At the final step of separation of the
  cryoprecipitate from cryo-supernatant plasma, we
  almost completely remove all the plasma (almost
  dry cryoprecipitate)
• Re-suspend the cryo in 8 ml of 5 glucose saline
  (total volume 10 ml)
• Thaw the prepared cryoprecipitate units at 31C
  and pool 40 in one disposable ( 3200 4000 IU
  FVIII in 400 ml volume)

25

• Aseptic Pooling of 40 plasma depleted
  cryoprecipitate units (thawing pooling) 2
  hours
• SD treatment SD extraction 2 hours each
• Aseptic dispensing into final bag
• QC Factor VIIIc, sterility testing
• Labeling

26
(No Transcript)
27
SD-plasma depleted cryoprecipitate
characteristics (1)

• Suspended in 5 glucose saline
• Mean 8-10 IU FVIII/ml-
• Volume of 200 IU FVIII will be 20-25 ml.
• The product will be stored frozen at lt-20C or
  colder for one year from date of preparation
• Mean clottable fibrinogen 15-20 mg/ml

28
Plasma depleted SD-cryoprecipitate
characteristics (2)

• VWF data
• RCo 6 8.88 IU/ml
• CBA 5 10.6 U/ml
• Ag 9.24 11 IU/ml
• Multimers
• gt15 mers as in starting cryo
• gt10 mers as in starting cryo
• ABO iso-agglutinins
• Anti-A titer 0-1
• Anti-B titer 0 1/8
• Jenny Goudemand, Claudine Caron, CHRU, Lille,
  France

29
Clinical Use

• The product can be used in the treatment of the
  following conditions-
• Hemophilia A
• vWD
• Fibrinogen deficiency
• Severe post partum hemorrhage
• DIC
• FXIII deficiency ???

30
Future developments

• Mini-pool preparation of the following solvent
  detergent treated plasma products prepared from
  plasma-
• PCC
• FIX
• FVII
• FXI
• FV

31
Collaborators

• Thierry Burnouf
• Miryana Radosevich
• Hadi Goubran

• Makram El Sayed
• George Gorgy
• Nermin Nabil
• Khaled Fathy
• Ahmed Abdalla
