Distributed Systems: Atomicity, decision making, snapshots

1
Distributed Systems Atomicity, decision making,
snapshots
2
Announcements

• Please complete course evaluations
• http//www.engineering.cornell.edu/CourseEval/
• Prelim II coming up this week
• Thursday, April 26th, 730900pm, 1½ hour exam
• 101 Phillips
• Closed book, no calculators/PDAs/
• Bring ID
• Topics
• Since last Prelim, up to (and including) Monday,
  April 23rd
• Lectures 19-34, chapters 10-18 (7th ed)
• Review Session Tuesday, April 24th
• during second half of 415 Section
• Homework 6 (and solutions) available via CMS
• Do it without looking at solutions. However, it
  will not be graded

3
Review What time is it?

• In distributed system we need practical ways to
  deal with time
• E.g. we may need to agree that update A occurred
  before update B
• Or offer a lease on a resource that expires at
  time 1010.0150
• Or guarantee that a time critical event will
  reach all interested parties within 100ms

4
Review Event Ordering

• Problem distributed systems do not share a clock
• Many coordination problems would be simplified if
  they did (first one wins)
• Distributed systems do have some sense of time
• Events in a single process happen in order
• Messages between processes must be sent before
  they can be received
• How helpful is this?

5
Review Happens-before

• Define a Happens-before relation (denoted by ?).
• 1) If A and B are events in the same process, and
  A was executed before B, then A ? B.
• 2) If A is the event of sending a message by one
  process and B is the event of receiving that
  message by another process, then A ? B.
• 3) If A ? B and B ? C then A ? C.

6
Review Total ordering?

• Happens-before gives a partial ordering of events
• We still do not have a total ordering of events
• We are not able to order events that happen
  concurrently
• Concurrent if (not A?B) and (not B?A)

7
Review Partial Ordering
Pi -gtPi1 Qi -gt Qi1 Ri -gt Ri1
R0-gtQ4 Q3-gtR4 Q1-gtP4 P1-gtQ2
8
Review Total Ordering?
P0, P1, Q0, Q1, Q2, P2, P3, P4, Q3, R0, Q4, R1,
R2, R3, R4
P0, Q0, Q1, P1, Q2, P2, P3, P4, Q3, R0, Q4, R1,
R2, R3, R4
P0, Q0, P1, Q1, Q2, P2, P3, P4, Q3, R0, Q4, R1,
R2, R3, R4
9
Review Timestamps

• Assume each process has a local logical clock
  that ticks once per event and that the processes
  are numbered
• Clocks tick once per event (including message
  send)
• When send a message, send your clock value
• When receive a message, set your clock to MAX(
  your clock, timestamp of message 1)
• Thus sending comes before receiving
• Only visibility into actions at other nodes
  happens during communication, communicate
  synchronizes the clocks
• If the timestamps of two events A and B are the
  same, then use the process identity numbers to
  break ties.
• This gives a total ordering!

10
Review Distributed Mutual Exclusion

• Want mutual exclusion in distributed setting
• The system consists of n processes each process
  Pi resides at a different processor
• Each process has a critical section that requires
  mutual exclusion
• Problem Cannot use atomic testAndSet primitive
  since memory not shared and processes may be on
  physically separated nodes
• Requirement
• If Pi is executing in its critical section, then
  no other process Pj is executing in its critical
  section
• Compare three solutions
• Centralized Distributed Mutual Exclusion (CDME)
• Fully Distributed Mutual Exclusion (DDME)
• Token passing

11
Today

• Atomicity and Distributed Decision Making
• What time is it now?
• Synchronized clocks
• What does the entire system look like at this
  moment?

12
Atomicity

• Recall
• Atomicity either all the operations associated
  with a program unit are executed to completion,
  or none are performed.
• In a distributed system may have multiple copies
  of the data
• (e.g. replicas are good for reliability/availabili
  ty)
• PROBLEM How do we atomically update all of the
  copies?
• That is, either all replicas reflect a change or
  none

13
Generals Paradox

• Generals paradox
• Constraints of problem
• Two generals, on separate mountains
• Can only communicate via messengers
• Messengers can be captured
• Problem need to coordinate attack
• If they attack at different times, they all die
• If they attack at same time, they win
• Named after Custer, who died at Little Bighorn
  because he arrived a couple of days too early!
• Can messages over an unreliable network be used
  to guarantee two entities do something
  simultaneously?
• Remarkably, no, even if all messages get
  through
• No way to be sure last message gets through!

14
Replica Consistency Problem -Concurrent and
conflicting updates

• Imagine we have multiple bank servers and a
  client desiring to update their back account
• How can we do this?
• Allow a client to update any server then have
  server propagate update to other servers?
• Simple and wrong!
• Simultaneous and conflicting updates can occur at
  different servers?
• Have client send update to all servers?
• Same problem - race condition which of the
  conflicting update will reach each server first

15
Two-phase commit

• Since we cant solve the Generals Paradox (i.e.
  simultaneous action), concurrent and conflicting
  updates may be sent by clients, lets solve a
  related problem
• Distributed transaction Two machines agree to do
  something, or not do it, atomically
• Algorithm for providing atomic updates in a
  distributed system
• Give the servers (or replicas) a chance to say no
  and if any server says no, client aborts the
  operation

16
Framework

• Goal Update all replicas atomically
• Either everyone commits or everyone aborts
• No inconsistencies even in face of failures
• Caveat Assume only crash or fail-stop failures
• Crash servers stop when they fail do not
  continue and generate bad data
• Fail-stop in addition to crash, fail-stop
  failure is detectable.
• Definitions
• Coordinator Software entity that shepherds the
  process (in our example could be one of the
  servers)
• Ready to commit side effects of update safely
  stored on non-volatile storage
• Even if crash, once I say I am ready to commit
  then a recover procedure will find evidence and
  continue with commit protocol

17
Two Phase Commit Phase 1

• Coordinator send a PREPARE message to each
  replica
• Coordinator waits for all replicas to reply with
  a vote
• Each participant replies with a vote
• Votes PREPARED if ready to commit and locks data
  items being updated
• Votes NO if unable to get a lock or unable to
  ensure ready to commit

18
Two Phase Commit Phase 2

• If coordinator receives PREPARED vote from all
  replicas then it may decide to commit or abort
• Coordinator send its decision to all participants
• If participant receives COMMIT decision then
  commit changes resulting from update
• If participant received ABORT decision then
  discard changes resulting from update
• Participant replies DONE
• When Coordinator received DONE from all
  participants then can delete record of outcome

19
Performance

• In absence of failure, 2PC (two-phase-commit)
  makes a total of 2 (1.5?) round trips of messages
  before decision is made
• Prepare
• Vote NO or PREPARE
• Commit/abort
• Done (but done just for bookkeeping, does not
  affect response time)

20
Failure Handling in 2PC Replica Failure

• The log contains a ltcommit Tgt record.
• In this case, the site executes redo(T).
• The log contains an ltabort Tgt record.
• In this case, the site executes undo(T).
• The log contains a ltready Tgt record
• In this case consult coordinator Ci.
• If Ci is down, site sends query-status T message
  to the other sites.
• The log contains no control records concerning T.

• In this case, the site executes undo(T).

21
Failure Handling in 2PC Coordinator Ci Failure

• If an active site contains a ltcommit Tgt record in
  its log, then T must be committed.
• If an active site contains an ltabort Tgt record in
  its log, then T must be aborted.
• If some active site does not contain the record
  ltready Tgt in its log then the failed coordinator
  Ci cannot have decided to commit T. Rather than
  wait for Ci to recover, it is preferable to abort
  T.
• All active sites have a ltready Tgt record in their
  logs, but no additional control records. In this
  case we must wait for the coordinator to recover.

• Blocking problem T is blocked pending the
  recovery of site Si.

22
Failure Handling

• Failure detected with timeouts
• If participant times out before getting a PREPARE
  can abort
• If coordinator times out waiting for a vote can
  abort
• If a participant times out waiting for a decision
  it is blocked!
• Wait for Coordinator to recover?
• Punt to some other resolution protocol
• If a coordinator times out waiting for done, keep
  record of outcome
• other sites may have a replica.

23
Failures in distributed systems

• We may want to avoid relying on a single
  server/coordinator/boss to make progress
• Thus want the decision making to be distributed
  among the participants (all nodes created
  equal) gt the consensus problem in distributed
  systems.
• However depending on what we can assume about the
  network, it may be impossible to reach a decision
  in some cases!

24
Impossibility of Consensus

• Network characteristics
• Synchronous - some upper bound on
  network/processing delay.
• Asynchronous - no upper bound on
  network/processing delay.
• Fischer Lynch and Paterson showed
• With even just one failure possible, you cannot
  guarantee consensus.
• Cannot guarantee consensus process will terminate
• Assumes asynchronous network
• Essence of proof Just before a decision is
  reached, we can delay a node slightly too long to
  reach a decision.
• But we still want to do it.. Right?

25
Distributed Decision Making Discussion

• Why is distributed decision making desirable?
• Fault Tolerance!
• A group of machines can come to a decision even
  if one or more of them fail during the process
• Simple failure mode called failstop (different
  modes later)
• After decision made, result recorded in multiple
  places
• Undesirable feature of Two-Phase Commit Blocking
• One machine can be stalled until another site
  recovers
• Site B writes prepared to commit record to its
  log, sends a yes vote to the coordinator (site
  A) and crashes
• Site A crashes
• Site B wakes up, check its log, and realizes that
  it has voted yes on the update. It sends a
  message to site A asking what happened. At this
  point, B cannot decide to abort, because update
  may have committed
• B is blocked until A comes back
• A blocked site holds resources (locks on updated
  items, pages pinned in memory, etc) until learns
  fate of update
• Alternative There are alternatives such as
  Three Phase Commit which dont have this
  blocking problem
• What happens if one or more of the nodes is
  malicious?
• Malicious attempting to compromise the decision
  making
• Known as Byzantine fault tolerance. More on this
  next time

26
Introducing wall clock time

• Back to the notion of time
• Distributed systems sometimes needs more precise
  notion of time other than happens-before
• There are several options
• Instead of network/process identitity to break
  ties
• Extend a logical clock with the clock time and
  use it to break ties
• Makes meaningful statements like B and D were
  concurrent, although B occurred first
• But unless clocks are closely synchronized such
  statements could be erroneous!
• We use a clock synchronization algorithm to
  reconcile differences between clocks on various
  computers in the network

27
Synchronizing clocks

• Without help, clocks will often differ by many
  milliseconds
• Problem is that when a machine downloads time
  from a network clock it cant be sure what the
  delay was
• This is because the uplink and downlink
  delays are often very different in a network
• Outright failures of clocks are rare

28
Synchronizing clocks

• Suppose p synchronizes with time.windows.com and
  notes that 123 ms elapsed while the protocol was
  running what time is it now?

Delay 123ms
p
What time is it?
0923.02921
time.windows.com
29
Synchronizing clocks

• Options?
• p could guess that the delay was evenly split,
  but this is rarely the case in WAN settings
  (downlink speeds are higher)
• p could ignore the delay
• p could factor in only certain delay, e.g. if
  we know that the link takes at least 5ms in each
  direction. Works best with GPS time sources!
• In general cant do better than uncertainty in
  the link delay from the time source down to p

30
Consequences?

• In a network of processes, we must assume that
  clocks are
• Not perfectly synchronized.
• We say that clocks are inaccurate
• Even GPS has uncertainty, although small
• And clocks can drift during periods between
  synchronizations
• Relative drift between clocks is their precision

31
Temporal distortions

• Things can be complicated because we cant
  predict
• Message delays (they vary constantly)
• Execution speeds (often a process shares a
  machine with many other tasks)
• Timing of external events
• Lamport looked at this question too

32
Temporal distortions

• What does now mean?

p

0
a
d


e
b
c



p

1
f

p

2
p

3
33
Temporal distortions
What does now mean?

p

0
a
d


e
b
c



p

1
f

p

2
p

3
34
Temporal distortions
Timelines can stretch caused by
scheduling effects, message delays, message loss

p

0
a
d


e
b
c



p

1
f

p

2
p

3
35
Temporal distortions
Timelines can shrink E.g. something lets a
machine speed up

p

0
a
d


e
b
c



p

1
f

p

2
p

3
36
Temporal distortions
Cuts represent instants of time. But not
every cut makes sense Black cuts could occur
but not gray ones.

p

0
a
d


e
b
c



p

1
f

p

2
p

3
37
Consistent cuts and snapshots

• Idea is to identify system states that might
  have occurred in real-life
• Need to avoid capturing states in which a message
  is received but nobody is shown as having sent it
• This the problem with the gray cuts

38
Temporal distortions
Red messages cross gray cuts backwards

p

0
a
d


e
b
c



p

1
f

p

2
p

3
39
Temporal distortions
Red messages cross gray cuts backwards In
a nutshell the cut includes a message that was
never sent

p

0
a

e
b
c



p

1
p

2
p

3
40
Who cares?

• Suppose, for example, that we want to do
  distributed deadlock detection
• System lets processes wait for actions by other
  processes
• A process can only do one thing at a time
• A deadlock occurs if there is a circular wait

41
Deadlock detection algorithm

• p worries perhaps we have a deadlock
• p is waiting for q, so sends whats your state?
• q, on receipt, is waiting for r, so sends the
  same question and r for s. And s is waiting on
  p.

42
Suppose we detect this state

• We see a cycle
• but is it a deadlock?

p
q
Waiting for
Waiting for
Waiting for
r
s
Waiting for
43
Phantom deadlocks!

• Suppose system has a very high rate of locking.
• Then perhaps a lock release message passed a
  query message
• i.e. we see q waiting for r and r waiting for
  s but in fact, by the time we checked r, q was
  no longer waiting!
• In effect we checked for deadlock on a gray cut
  an inconsistent cut.

44
Consistent cuts and snapshots

• Goal is to draw a line across the system state
  such that
• Every message received by a process is shown as
  having been sent by some other process
• Some pending messages might still be in
  communication channels
• A cut is the frontier of a snapshot

45
Chandy/Lamport Algorithm

• Assume that if pi can talk to pj they do so using
  a lossless, FIFO connection
• Now think about logical clocks
• Suppose someone sets his clock way ahead and
  triggers a flood of messages
• As these reach each process, it advances its own
  time eventually all do so.
• The point where time jumps forward is a
  consistent cut across the system

46
Using logical clocks to make cuts
Message sets the time forward by a lot

p

0
a
d


e
b
c



p

1
f

p

2
p

3
Algorithm requires FIFO channels must delay e
until b has been delivered!
47
Using logical clocks to make cuts
Cut occurs at point where time advanced

p

0
a
d


e
b
c



p

1
f

p

2
p

3
48
Turn idea into an algorithm

• To start a new snapshot, pi
• Builds a message Pi is initiating snapshot k.

• The tuple (pi, k) uniquely identifies the
  snapshot
• In general, on first learning about snapshot (pi,
  k), px
• Writes down its state pxs contribution to the
  snapshot
• Starts tape recorders for all communication
  channels
• Forwards the message on all outgoing channels
• Stops tape recorder for a channel when a
  snapshot message for (pi, k) is received on it
• Snapshot consists of all the local state
  contributions and all the tape-recordings for the
  channels

49
Chandy/Lamport

• This algorithm, but implemented with an outgoing
  flood, followed by an incoming wave of snapshot
  contributions
• Snapshot ends up accumulating at the initiator,
  pi
• Algorithm doesnt tolerate process failures or
  message failures.

50
Chandy/Lamport
w
t
q
r
p
s
u
y
v
x
z
A network
51
Chandy/Lamport
w
t
I want to start a snapshot
q
r
p
s
u
y
v
x
z
A network
52
Chandy/Lamport
w
t
q
p records local state
r
p
s
u
y
v
x
z
A network
53
Chandy/Lamport
w
p starts monitoring incoming channels
t
q
r
p
s
u
y
v
x
z
A network
54
Chandy/Lamport
w
t
q
contents of channel p-y
r
p
s
u
y
v
x
z
A network
55
Chandy/Lamport
w
p floods message on outgoing channels
t
q
r
p
s
u
y
v
x
z
A network
56
Chandy/Lamport
w
t
q
r
p
s
u
y
v
x
z
A network
57
Chandy/Lamport
w
q is done
t
q
r
p
s
u
y
v
x
z
A network
58
Chandy/Lamport
w
t
q
q
r
p
s
u
y
v
x
z
A network
59
Chandy/Lamport
w
t
q
q
r
p
s
u
y
v
x
z
A network
60
Chandy/Lamport
w
t
q
q
r
p
s
u
y
v
x
z
s
z
A network
61
Chandy/Lamport
w
x
t
q
q
r
p
u
s
u
y
v
x
z
s
z
v
A network
62
Chandy/Lamport
w
w
x
t
q
q
r
p
z
s
s
v
y
u
r
u
y
v
x
z
A network
63
Chandy/Lamport
w
t
q
q
p
Done!
r
p
s
r
s
u
t
u
w
v
y
v
y
x
x
z
z
A snapshot of a network
64
Whats in the state?

• In practice we only record things important to
  the application running the algorithm, not the
  whole state
• E.g. locks currently held, lock release
  messages
• Idea is that the snapshot will be
• Easy to analyze, letting us build a picture of
  the system state
• And will have everything that matters for our
  real purpose, like deadlock detection
