Fca Lang

1
Fca Lang

• A language for
• Formal Concept Analysis

2
Note

• Le slide sono scritte in inglese
• Privilegia la semplicità
• Linguaggio tecnico affermato
• Amplia gli orizzonti di progetto
• Slides written in english
• Keep it simple
• Leading technical language
• Widenin project horizion.

3
About Formal Concept Analysis

• FCA, acronym of Formal Concept Analysis is a way
  to represent an manipulate knowledge. The
  tecnique has solid math foundation.. ( p.o.set,
  lattice, .. )
• Simply we represent a Formal Context as
• Context lt Extent, Intent, Relation gt
• Extent set of objects of the context
• Intent set of attributes in the context
• Relation between some objects and attributes

4
FCA Example

• Context animals
• Objects LION,FINCH,EAGLE,HARE,OSTRICH
• Attributes preying,flying,bird,mammal
• Relation different representation ( tabular,
  line diagram )
• Concepts
• Knowledge represented by connections ( like human
  mind )
• subconcept-superconcept relation between flying
  and bird

5
Initial language spec.

• How represent and manipulate knowledge ?
• First seems important to represent the static
  model of a
• Context lt Extent, Intent, Relation gt
• In second Stage we will desire operating on the
  model
• Dynamic Operations ( later .. )
• Idea ( Static model ).
• context (
• extent ( ... ) , // Objects ( a list of )
• intent ( ) , // Attributes ( a list of )
• relate ( ... ) // Couples Obj-Atr ( list of
  )
• )

6
Language Specification

• VT (, ), , , context, extent, intent, relate
• VN SCOPE, CONTEXT, EXTENT, INTENT, RELATE,
  OBJLIST, ATRLIST, CNNLIST, OBJ, ATR, CNN, ID
• PR
• SCOPE CONTEXT
• CONTEXT context ( EXTENT , INTENT ,
  RELATE )
• EXTENT extent ( OBJLIST
• INTENT intent ( ATRLIST
• RELATE relate ( CNNLIST
• OBJLIST OBJLIST ,
• OBJ )
• ATRLIST ATRLIST ,
• ATR )
• CNNLIST CNNLIST ,
• CNN )
• OBJ ID
• ATR ID
• CNN ( OBJ , ATR )

7
Language refination

• Note the list Production
• xxxLIST xxxLIST , xxx )
• Its LL(1) parser want to know the next token
  to select the action to do.
• xxxList and xxx are similar.
• It can be refined
• xxxLIST xxx ( , xxxLIST ) )
• Now its LL(0) the parser can choose with only
  the current token.
• There are three similar production Obj, Atr and
  ID. Why ?
• In future implementation we may change syntax (
  and semantic ) of Obj and Atr.
• For example we may associate a data structure to
  the Obj, and a web reference to either Obj both
  Atr.

8
Prolog Parser

• context(extent(E),intent(I),relate(R)) -
• isObjList(E),
• isAtrList(I),
• isCnnList(R).
• isObjList().
• isObjList(HT)-
• isObj(H),
• isObjList(T).
• isAtrList().
• isAtrList(HT)-
• isAtr(H),
• isAtrList(T).
• couples ( Obj, Atr)
• isCnnList().
• isCnnList(X,YT)-
• isCnn(X,Y),

• SCOPE CONTEXT
• CONTEXT context ( EXTENT , INTENT , RELATE
  )
• EXTENT extent ( OBJLIST
• INTENT intent ( ATRLIST
• RELATE relate ( CNNLIST
• OBJLIST OBJLIST ,
• OBJ )
• ATRLIST ATRLIST ,
• ATR )
• CNNLIST CNNLIST ,
• CNN )
• OBJ ID
• ATR ID
• CNN ( OBJ , ATR )
• ID a-zA-Z ( a-zA-Z 0-9 )

9
About Automatic Tools

• Javacc
• Simple to generate scanner parser
• Learning time 5 hrs
• Complex code, no structure, no apt
• Mantenaince time non predictable
• Javacc jjTree
• Simple to generate scanner, parser apt
• Learning time 10 hrs
• More complex code
• Manteinance time better, but not predictable

FcaParser.jj
FcaTreeParser.jjt
10
Achitecture Strategy
Tokens
Characters
APT
scanner
parser

• Classical Architecture
• Robustness Diagram ( BCE )
• Boundary InputStream
• Controllers Scanner, Parser.
• Entities Characters, Tokens, Nodes.
• Implementation
• Handwritten Scanner Parser
• Scanner with Automa (DFA)
• Parser recursive-descent
• Tokens with type, text and position

Robustness Diagram
11
Architecture Strategy (2)

• Tree Description
• Apt Nodes DefaulMutableTreeNode (swing)
• Easy to represent via a java built-in class
  JTree
• Visitor one for validation, others for modeling
  data
• Further different implementations

12
Apt Example

• Once parsed a source we obtain an APT.
• A well-formed APT should looks like this.
• Taxonomy
• Context
• Extent
• Obj1, .., ObjN
• Intent
• Atr1, .., AtrN
• Relate
• Cnn1, .., CnnN

13
Architectural Overview
14
Scanner implementation

• TokenBuilder tBuild new Token Builder()
• Vector tokens new Vector()
• Automa automa new Automa()
• for ( int i0 iltsrc.length i)
• automa.input(srci)
• automa.changeState()
• switch (automa.MemoryOut())
• case ( Automa.START )
• tBuilder.initToken( srci )
• // noBreak
• case ( Automa.CONT )
• tBuilder.addChar( srci )
• switch (automa.TokenOut())
• case ( Automa.CHAR )
• tokens.addCharTok( tBuild.getToken( i ) )
• case ( Automa.WORD )
• tokens.add( tBuild.getToken( i ) )

• Scanner controlled by DFA
• one input the current char
• one memory output
• set in memory the token initial positon in the
  source
• continue to memorize char (token incrementally
  build)
• one token output to say
• If there is a token
• What token out.

15
DFA details

• Has a finite number of Inputs
• private static final int CH_SKIP 0
• private static final int CH_TOK 1
• private static final int CH_LET 2
• private static final int CH_NUM 3
• private static final int CH_EOF 4
• private static final int CH_INV 5
• Has also a finite number of States
• private static final int S_INV -1
• private static final int S_INIT 0
• private static final int S_CHAR 1
• private static final int S_WORD 2
• private static final int S_END 3
• And a finite number of Outputs
• private static final int T_NONE 0
• private static final int T_CHAR 1
• private static final int T_WORD 2

16
Parser Implementation

• scope()
• context()
• context()
• read(context)
• extent()
• read(,)
• intent()
• read(,)
• relate()
• extent()
• read(extent)
• read(()
• objList()
• objList()
• obj()
• Token t readNext()

SCOPE CONTEXT CONTEXT context ( EXTENT
, INTENT , RELATE ) EXTENT extent (
OBJLIST INTENT intent ( ATRLIST RELATE
relate ( CNNLIST OBJLIST OBJ ( , OBJLIST
) ) ATRLIST ATR ( , ATRLIST ) ) CNNLIST
CNN ( , CNNLIST ) ) OBJ ID ATR
ID CNN ( OBJ , ATR ) ID a-zA-Z
( a-zA-Z 0-9 )

• Recursive-Descent parser is easy to implement
• One method for every production types
• One function to read next Token
• read(String tokContent) Token
• read(int tokType) Token
• If needed one function to look ahead
• lookAhead(int howMany) Token
• NOTE
• read increment an internal parse index
• lookAhedd NO !

17
Prototyping a first application

• The first application architecture is like this
• A frame for interacting with users
• A listener for the parsing process
• Simple parsing operation ( Lexical Syntax
  analysis)
• Parsing Validation/Creation (Semantic analysis
  ).

18
Prototype 1

• Analyze the source
• Lexicon
• Syntax
• Then Visualize the APT,
• JTree with AptNode

context( extent( )
19
Further Architecture Details
Classic Recognizer
20
Application

• Features
• Lexical, Syntax Semantic Analysis
• Visitor for
• Validating
• Formal Context Building
• Inverse Source Building

context( extent( )
21
Process Subsystems

• Process
• Iterative incremental (XP)
• UML modeling
• Documentation
• Coding
• Tools
• Developing
• Eclipse allaround tool
• ANT for build jar,javadocs ..
• UML
• JUDE free

22
Future Developement

• Language Extension
• A context should contain more concepts
• Visitor Extension
• Shoul be a visitor that design a line diagram
• after lanfuage extension -gt nested line diagrams
• Knowledge base Change
• Why not use Prolog as a Knowledge base?
• Artificial Intelligence Extension
• Why not extend the standard AI model

23
Applications

• E-learning
• Taxonomy Engeenering
• Knowledge representation
• Custom Trails of learning
• Data Base Applications
• Web Search
• Data-Mining
• Other ..
