Chapter9 Failure

1
Chapter-9 Failure
2
Goals Why study Failure?

• Design of a structure should be done with a
  damage tolerance design concept that is a design
  engineer assumes that there are damages (flaws)
  present in the structure and is going to fail by
  one of the failure modes.

3
Goals Why study Failure?

• Thus by learning all the failure modes ( i.e
  fracture, fatigue, creep etc) a design engineer
  can design more effectively.
• For example if the fatigue life of an airplane is
  20000 cycles then it is recommended to run that
  airplane for 20000 cycles or less.

4
Learning objectives

• Define stress concentration factor, stress
  intensity factor and fracture toughness.
• Define impact testing and ductile to brittle
  transition.

5
Learning objectives

• Define fatigue failure, fatigue life time,
  fatigue limit and fatigue strength.
• Define Creep, steady state creep rate and rupture
  life time

6

• Fracture
• When a structure breaks at a stress level lower
  than the yield strength of the material that is
  called fracture.

7

• Fundamentals of

  fracture
• Fracture of a structure could be ductile or
  brittle.
• When the structure undergoes a large amount of
• plastic deformation before fracture that is a
  ductile fracture.

8
Fundamentals of fracture

• On the other hand fracture without any plastic
  deformation is a brittle fracture (Figures 9.1,
  9.2, and 9.3).
• Ductile fracture -
• Ductile fracture is explained in Fig 9.2.

9
Fig 9.1 (a) Highly ductile fracture (b)
Moderate ductile fracture (c) Brittle
fracture
10
Fig 9.2 (a) Initial necking (b) Small cavity
formation (c) Coalescence of cavities to form a
crack (d) Crack propagation (e) Final shear
fracture
11
Fig 9.3 (a) Cup and cone fracture in
aluminium(b) Brittle fracture in mild steel
Ductile fracture
Brittle Fracture
12

• Fracture Toughness
• The critical stress for crack propagation, ?c, is
  related to crack length through the following
  equation
• KC Y ?c ?(?a)
• Where KC is defined as the fracture toughness and
  it is a measure of materials resistance to
  fracture.

13
Fig 9.11 Schematic representation of (a) An
interior crack in a plate of finite width (b) An
edge crack in a plate of semi-finite width
?c
?c
14
Fracture Toughness

• The higher the value of KC, greater is the
  materials resistance to fracture.
• Y is a factor that depends on crack and specimen
  size and geometry.

15
Fracture Toughness

• When the specimen is thick and pulled under pure
  tension (Fig 9.9(a).) then the corresponding
  fracture toughness is called KIC.

16
Fracture Toughness

• Then the critical stress for crack propagation,
  ?c, is related to crack length through the
  following equation
• KIC Y ?c ?(?a)

17
Stress Intensity Factor

• If the applied stress s lt ?c , the corresponding
  stress intensity factor, K, is
• K Y ? ?(?a)

18

• Design using fracture mechanics
• KIC is a material parameter and is listed in
  design handbooks. Thus the design stress can be
  calculated if the flaw size in the structure is
  known as following
• KIC Y ?f ?(?a)
• Or ?f KIC / (Y ?(?a))
• Y, a, KIC are known

19
Design using fracture mechanics

• On the other hand, if the design stress is fixed
  then the allowable flaw size in the structure can
  be calculated as
• KIC Y ?f ?(?ac)
• ?ac KIC/(Y ?f ??)
• or ac 1/? (KIC/ Y ?f )2
• Y, ?f , KIC are known

20
Design using fracture mechanics

• Periodic examination of the crack is done by
  using non destructive inspection methods. When a
  ? ac that structure is discarded.

21
(No Transcript)
22

• Impact Fracture Testing
• Impact testing is performed to find out if the
  fracture is a brittle or ductile fracture.
• Impact testing techniques
• In impact testing a sample with a v shaped
  notch is used. A pendulum is released from a
  height h to strike the sample.

23
(a) Specimen used for charpy and Izod impact
tests. (b) A schematic drawing of an impact
testing apparatus.
24
Impact Fracture Testing

• The pendulum reaches a final height h after it
  hits the sample.
• Then the impact energy imparted to the sample
• mgh - mgh
• where m is the mass of the pendulum.

25

• Ductile to brittle transition
• The impact test is performed at different
  temperatures and impact energy is plotted against
  temperature.
• The low impact energy at low temp indicates a
  brittle fracture and high impact energy at higher
  temperature indicates a ductile fracture.

26
Ductile to brittle transition

• The temperature at which the fracture behavior
  changes from ductile to brittle is the ductile
  brittle transition temperature (DBTT).

27
Temperature dependence of Charpy V-notch impact
energy (curve A) and percent shear fracture
(curve B) for an A283 steel.
Ductile Brittle Transition Temperature
28
Fig 9.21 Photograph of fracture surfaces of A36
steel Charpy V-notch specimens tested at
indicated temperatures.
29
Ductile to brittle transition

• Application
• Ships and off shore oil drilling platforms are
  made out of steel.
• The steel used should not be brittle when the
  temperature gets cold.

30
Ductile to brittle transition

• Fig 9.22 shows that as the amount of carbon
  increases DBTT increases.
• Thus the steel to be used in the cold weather
  should have as little carbon as possible.

31
Fig 9.22 Influence of carbon content on the
charpy V-notch energy-versus-temperature behavior
for steel.
32

• Fatigue
• Failure of a machine or a structure under dynamic
  and fluctuating stress is defined as fatigue
  failure.
• The fatigue failure occurs at a stress level much
  lower than the yield strength of materials.

33
Variation of stress with time that accounts for
fatigue failures.(a) Reversed stress cycle
34
Repeated stress cycle.
35
Schematic diagram of fatigue testing for making
rotating-bending tests.
36

• Cyclic stress
• The fluctuating stress could be simply sinusoidal
  which is repeated many times.
• The maximum tensile stress is
• defined as ?max
• The minimum stress is ?min
• Then the stress range, ?r, is defined as
• ?r ?max-?min

37
Cyclic stress

• Stress amplitude, ?a, is defined as
• ?a ?r /2 (?max-?min) /2
• Stress ratio, R, is defined as
• R (?min/?max)
• The mean stress, ?m, is defined as
• ?m (?max ?min)/2

38

• The S-N curve
• Fatigue testing can be done under simple tensile
  compression sinusoidal loads.
• Different samples are subjected to different
  stress levels to failure.

39
The S-N curve

• Then the stress against number of cycles to
  failure is plotted.
• The curve is called S-N curve.
• If the S-N curve becomes horizontal at lower
  stress level, that stress is called fatigue
  limit.

40
The S-N curve

• The structure would not fail if fatigue limit
  stress is used.
• If the S-N curve does not become horizontal the
  stress corresponding to 107 cycle is defined as
  the fatigue strength.

41
The S-N curve

• Fatigue life at a particular stress, S1, is the
  number of cycles to cause failure at
• that stress level.

42
Stress amplitude (S) versus logarithm of the
number of cycles to fatigue failure (N) for (a) a
material that displays a fatigue limit.
Fatigue Life
43
A material that does not display a fatigue limit.
44

• Crack initiation and propagation
• Fatigue failure is characterized by three
  distinct steps crack initiation, crack
  propagation and final failure.
• Crack initiation
• The crack initiates at some point on the surface
  of the structure where there is maximum stress
  concentration.

45

• Crack propagation
• Crack propagation forms two types of marking on
  the fracture surface beach markings and
  striations.
• Beach markings are formed when there is
  interruption in the crack propagation stage.
• Striations are formed during the propagation of
  the crack during each stress cycle.

46
Fracture surface of a rotating steel shaft that
experienced fatigue failure.
Origin
Final failure
47
Crack length versus the number of cycles at
stress levels s1 and s2 for fatigue studies.
48
Schematic representation of logarithm fatigue
crack propagation rate da /dN versus logarithm
stress intensity factor range ?K.
49

• Surface effects
• The fatigue crack starts on the surface of a
  structure at a stress concentration site.
• Various surfaces treatments are done to improve
  the fatigue life.
• Carburizing treatment (case hardening) you
  learned in chapter 5 is one such treatment.
• Other treatment done is shot peening.

50
Demonstration of how design can reduce stress
amplification.(a) poor design sharp corner(b)
Good design
51
Schematic S-N fatigue curves for normal and shot-
peened steel.
52

• Creep
• Deformation of materials subjected to high
  temperature (0.4 Tm) and stress at the same time
  is called creep.
• Turbine rotors in jet engines and steam generator
  are under that environment.

53

• Generalized creep behavior
• A typical creep curve of strain vs. time under
  constant load and constant temperature is shown
  in the next Fig.
• The curve has three distinct regions Primary,
  Secondary and tertiary.
• In the primary region after an instantaneous
  deformation
• the creep rate ?e/ ?t, (Slope of the curve)
  decreases.

54
Generalized creep behavior

• In the secondary region the creep rate is
  constant.
• In the tertiary region the creep rate increase
  and then final fracture occurs.

55
Typical creep curve of strain versus time at
constant stress and constant elevated
temperature.
56
Influence of stress, s and temperature, T on
creep behavior.
57
Stress versus rupture life time for a low carbon-
Ni alloy at 3 temperatures.
58
Logarithm stress versus the Larson-Miller
parameter for an S-590 iron.
