The HARP Experiment

1
The HARP Experiment

• Physics goals and motivations
• Summary of the experimental program
• Detector overview and performance
• Large angle
• Forward region
• Towards physics analysis
• Alessandra Tonazzo, Università Roma Tre
• On behalf of the HARP Collaboration

2
HARP physics goals

• Precise (2-3 error) measurement of
• d2s/dpTdpL
• for secondary HAdRon Production by incident p
  and p with
• Beam momentum from 1.5 to 15 GeV/c
• Large range of target materials
• Acceptance over the full solid angle
• Final state particle identification

3
Motivation 1 Neutrino Factory

• Aim maximize p production rate (/proton/GeV)
• Optimize
• target material and geometry
• primary beam energy
• collection scheme
• Existing simulation packages show large
  discrepancies on pion yields and distributions
• Experimental data are poor (small acceptance, few
  materials) and old (Allaby et al.1970, Eichten et
  al. 1972)
• Measure pT distribution with high precision (lt5)

? Thick target program high Z, large p
4
Motivation 2 Input to MC generators

• Lack of experimental data and large uncertainties
  in the calculations,
• in particular for thick and high Z target
  materials

Differential distributions for pion production
NIMA451(2000)327
NIMA472(2001)557
NO DATA !
? Thin and thick targets, scan in Z
5
Motivation 3 Atmospheric neutrinos

• Calculation of neutrino fluxes for atmospheric
  neutrino experiments

• Main uncertainty (30) secondary hadron
  production
• Lack of experimental data

? Low Z materials cryogenic targets
6
Motivation 4 MiniBooNE and K2K
K2K case (by Issei Kato)
7
Motivation 4 MiniBooNE and K2K
K2K Near/Far ratio

• K2K Largest uncertainty (5) on neutrino fluxes
  arises from Near/Far spectrum ratio, mainly for
  Enlt1 GeV
• MiniBoone Large uncertainties on MC calculation
  of n fluxes
• Measure p and K fluxes in the forward direction
  with precision 3
• K2K Al target, 12.9 GeV/c protons
• MiniBooNE Be target, 8.9 GeV/c protons
• Official collaboration with
• K2K and MiniBoone

MiniBoone n spectrum
8
A byproductBeam related background of LSND
n
H2O target
p 1.46 GeV/c
LSND detector
__
__

• Expect nenm 7.5x10-4
• But LSND measures a signal of ne25x10-4
• 4.1s evidence for nm?ne oscillations?
• Try to verify the beam related backgrounds
• pp- production ratio (expect 81)
• Measure thin (10l) H2O target with 1.5 GeV/c
  protons (easy)
• ee- ratio look for anomalous m- decay in
  water target
• Measure thick (100l) H2O target with 1.5 GeV/c
  protons (need sensitivity 10-3)

__
__
__
9
Data taking summary
SOLID
n EXP
CRYOGENIC
K2K Al MiniBoone Be LSND H2O
5 50 100 Replica 5 50 100 Replica 10 100
12.9 GeV/c 8.9 GeV/c 1.5 GeV/c
10
Data taking summary
HARP has been taking data at the CERN East Hall
on the PS T9 beamline in 2001 and 2002

• Total
• 30 Tbytes of data
• 420 M events
• 13000 physics runs
• 300 settings
• High performance of DAQ system

11
The HARP experiment
12
The HARP experiment
13
The HARP detector layout
TRACKING PARTICLE ID at Large angle and Forward
14
Beam detectors
T9 beam

• Beam tracking with MWPCs
• 96 tracking efficiency using 3 planes out of 4
• Resolution lt100 mm

extrapolation to target
15
Beam particle selection

• Beam TOF
• separate p/K/p at low energy over 21m flight
  distance
• time resolution 170 ps after TDC and ADC
  equalization
• proton selection purity gt98.7

p
3 GeV/c beam
p
d
K
12.9 GeV/c beam

• Beam Cherenkov
• Identify electrons at low energy, p at high
  energy, K above 12 GeV
• 100 eff. in e-p tagging

p
K
16
Large angle region
17
TPC

• Diameter 82.0cm outer, 10.2cm inner
• Drift length 156 cm
• Magnetic field 0.7 T
• Electric field gradient 110 V/cm
• Gas Ar-CH4 91-9
• Drift velocity 5 cm/ms
• Total drift time 32 ms 320 time samples
• 3972 pads in 20 rows, 5.5x15mm2 each

• Efforts to understand the detector are going on
• dead/hot pads
• energy calibration
• cross-talk
• E and B field distrortions

18
TPC calibration

• Laser system (continuous)
• drift time monitoring
• drift velocity measurement
• study of distortions
• 83Kr (periodical injections)
• channel equalization (spread 25)
• energy calibration measured resolution lt14
• Dedicated runs with cosmics and X-ray sources
  (Fe,Kr) in summer 2003

Drift velocity vs time
83Kr specturm (few pads with similar response)
19
TPC cross-talk

• Due to capacitive coupling between the output of
  one preamplifier and the input of another
• Measurement
• Individual pulse
• injection in one sector
• Modelling
• Capacitive coupling preamp transfer function
• preamp signal
• Introduce in simulation and estimate effect
• Correct !
• Subtract cross-talked signal

Energy response Simulated Fe data
s9.6
s14.9
s9.8
correct
X-talk
Energy response Fe data 2003
correct
Preliminary !
20
TPC track reconstruction and resolution
Momentum resolution (at present)
3 GeV/c p on Ta target (100l)
Hot/dead pad and equalizations applied No X-talk
corrections
PL (GeV/c)
21
TPC dE/dx
Preliminary !
Cosmic data 2003 (1 run)
Protons
Muons and pions
Relativistic rise
Electrons?
22
RPCs

• TOF measurement in the large angle region for
  particle identification when TPC dE/dx cannot
  distinguish
• e/p(K,p) lt300 (500,1000) MeV/c
• 30 barrel 16 forward chambers 8m2
• 4-gap glass stack with 0.1 mm gap

Time (35 ps)
Slewing corrections
Charge (0.1 fC)

• Studies on 12 GeV p- beam
• Time-charge dependence of response
• Response vs impact position
• Calibration from physics tracks
• absolute time scale for each channel spread 100
  ps
• Charge resol. vs impact point
• Time resolution in overlaps
• Efficiency (in progress)

Width of RPC
Time response (ps)
Small charges
Very large charges
PA
PA
Vertical impact point position (mm)
23
RPCs
Time difference of two RPCs hit by same particle

• Performance
• Single track efficiency
• gt97
• Time resolution
• 180 ps
• independent of impact point position
• Preliminary PID results

Horizontal scan
Efficiency
Impact point position (strip)
Impact point position (mm)
24
Next physics analysis goalneutrino experiments

• K2K needs measurement of p with
• Egt1 GeV
• Elt4.5 GeV
• qlt300 mrad
• Forward region
• Tracks reaching forward PID detectors
• p/p separation with TOF and Cherenkov
• Focus on forward detectors
• Efficient tracking
• Calibration
• PID

Dip from neutrino oscillations in K2K
they come from decay of these pions
25
Forward region
26
Forward region
CHERENKOV
ECAL
NDC4
TOF
NDC1
NDC2
NDC5
MAGNET
NDC3
27
Forward acceptance
K2K interest
MC
NDC2
NDC1
dipole
K2K interest
B
x
P gt 1 GeV
z
28
Forward Tracking NDC
P 3,5,8,15 GeV/c High intensity

• Reused NOMAD Drift Chambers
• 12 planes per chamber, wires at 0,5 w.r.t.
  vertical
• Hit efficiency 80 (limited by non-flammable gas
  mixture)
• stable in time
• lowered by high particle flux
• recovered between spills
• correctly reproduced in the simulation
• Alignment with cosmics and beam muons
• gt drift distance resolution 340 mm

Side modules
nominal
Eff. vs time in spill
Plane efficiencies
29
Forward track reconstruction
Track segment eff
Hit eff

• Entirely new track reconstruction method
  developed to achieve high efficiency for track
  reconstruction in spite of low hit efficiency
• Algorithm based on plane segments rather than
  triplets testing all possible combinations of
  matching objects, with the help of Kalman
  algorithm
• Matching of segments before/after dipole magnet ?
  track with momentum determination

Data MC
Track eff 95 for all momenta and angles
Lower at borders due to large angular bias
30
Forward tracking performance
Momentum resolution
5
K2K interest
eloss?
P (GeV)
K2K requirements
Data MC
15 mrads
Angular resolution dq2.5 mrad at p2 GeV/c
P (GeV)
31
Forward tracking performance
Matching to other subdetectors
NDC - TPC
NDC - ECAL
NDC - TOF
32
Cherenkov

• Separate p/p at large momenta
• 31 m3 filled with C4F10 (n1.0014)
• Light collection mirrorsWinston cones ? 38 PMTs
  in 2 rows
• LED flashing system for calibration

nominal threshold
Number of photoelectrons
Npe ? 21
p mass is a free parameter
p (GeV/c)
33
TOF Wall
Variation of equalization constants 2001-2002
cosmics vs laser

• Separate p/p (K/p) at low momenta
• 42 slabs of fast scintillator read at both ends
  by PMTs

PMT response to Laser vs time

• Calibration
• Cosmic ray runs (every 2-3 months)
• Laser (continuous monitor stability)
• Equalization gt
• overall time resolution 210 ps
• gt3s separation of p/p (K/p)
• up to 4.5 (2.4) GeV/c

34
Electron identifier

• Pb/fibre 4/1
• EM1 62 modules, 4 cm thick
• EM2 80 modules, 8 cm thick
• Total 16 X0
• Reused from CHORUS
• Calibration with cosmic rays
• Measurement of attenuation length in fibers
• Module equalization

• Energy resolution 23/sqrt(E)
• intrinsic resolution 15/sqrt(E)
• convoluted with beam spread at detector entrance

35
Forward particle identification
Calorimeter
5 GeV electrons DATA
5 GeV electrons MC
TOF 3 GeV/c
Associated ECAL Energy (GeV)
p
p
Track momentum (GeV/c)
Cherenkov vs Ecal
electrons
E(EM1)/E(Ecal)
electrons
Nphel
Ecal Energy (a.u.)
pions
all
36
Conclusions

• The HARP data taking programme has been
  successfully completed in 2002
• Large angle
• Reconstruction chain ready
• Focus on understanding of TPC
• Forward region
• All detectors calibrated and understood
• Preliminary PID
• On the road to results for K2K/MiniBoone

37
RPC PID electrons
Electron enriched sample photon conversion
candidates 2 tracks with same production angle
and coming from same origin
1.4
1
0.6
8 GeV/c 0.05 l Be target
0.2
38
LSND

• pN?Xp / pN?Xp- 8/1
• p?mnm / p-?m-nm 1/0.05
• m?enmne / m-?e-nmne 1/0.12
• nenm e-e 1/8 x 0.05 x 0.12 7.5x10-4
