Title: Intelligent Sensing and Sensor Web: Design and Deployment Experiences


1
Intelligent Sensing and Sensor Web Design and
Deployment Experiences
IEEE SIMA 2008 Nov. 18, 2008
WenZhan Song Washington State University
2
Background - Sensorweb
3
Sensor Web Enablement Framework
4
Sensor Web Desires
  • Quickly discover sensors (secure or public) that
    can meet my needs location, observables,
    quality, ability to task
  • Obtain sensor information in a standard encoding
    that is understandable by me and my software
  • Readily access sensor observations in a common
    manner, and in a form specific to my needs
  • Task sensors, when possible, to meet my specific
    needs
  • Subscribe to and receive alerts when a sensor
    measures a particular phenomenon

5
OASIS System OverviewOptimized Autonomous Space
In-situ Sensorweb
  • OASIS will have two-way communication capability
    between ground and space assets, use both space
    and ground data for optimal allocation of limited
    power and bandwidth resources on the ground, and
    use smart management of competing demands for
    limited space assets.
  • 1. In-situ sensor-web autonomously determines
    network topology, bandwidth and power allocation.
  • 2. Activity level rises causing self-organization
    of in-situ network topology and a request for
    re-tasking of space assets.
  • 3. High-resolution remote-sensing data is
    acquired and fed back to the control center.
  • 4. In-situ sensor-web ingests remote sensing data
    and re-organizes accordingly. Data are publicly
    available at all stages.

6
Why Study Volcano?
  • Volcanoes are everywhere - on Earth and beyond
  • Magmatism is of fundamental importance to
    planetary evolution and essential to life as we
    know it
  • On Earth, volcanic risk is increasing rapidly as
    human population increases
  • Volcanic Earthquakes
  • Directed Blast
  • Tephra
  • Volcanic Gases
  • Lava Flows
  • Debris Avalanches, Landslides, and Tsunamis
  • Pyroclastic Surge
  • Pyroclastic Flows
  • Lahars

7
Mount St. Helens an active volcano
8
Mount St. Helens an active volcano
9
Volcano Crater a harsh environment
10
Volcano Crater a harsh environment
Camera and gas sampler spider shown
pre-positioned at Sugar Bowl on 14 January 2005.
Shortly after this picture was taken, spider was
deployed within 100 m of extrusion site.
So we need smarter sensors and networks to ensure
continuous, spatially dense monitoring in
hazardous areas (OASIS)
11
Old Stations Technology
  • Several types of systems in place
  • Dual frequency GPS with digital store and forward
    telemetry when polled not continuous!
  • Short period seismic stations with geophones and
    analog telemetry not digital
  • Broad band seismic stations with digital
    telemetry cost above 10K and several days to
    deploy
  • Microphones for explosion detection added to the
    short period seismic stations

12
Application Characteristics
  • Challenging environment
  • Extreme weathers temperature (baking/freezing),
    wind, snow, rain,
  • Dynamic environment rock avalanche, land
    sliding, gas/steam emissions, volcanic eruptions,
    earthquake
  • Battery is the only reliable energy source. Solar
    panel is possible in summer, but frequently
    covered by ashes
  • Stations are frequently destroyed, some hot spot
    can only be accessed through air drop
  • Low signal noise ratio of both communication and
    sampling
  • High data rate, and require network synchronized
    sampling
  • Seismic sensor 100-200Hz, 16 bit/sample
  • Infrasonic sensor 100-200Hz, 16 bit/sample
  • Lightning sensor 1Hz, 16 bit/sample
  • GPS raw data 200-300 bytes/10 seconds

13
Outline
  • System Design
  • System Deployment
  • Lessons

14
System Design
15
OASIS System Overview
16
Ground Segment Overview
17
Ground Segment Overview
  • In-Situ Sensor Web architecture
  • 1. Sensor-nodes are self-organized to form
    network data flow forms a dynamic data diffusion
    tree rooted at gateway.
  • 2. Smart bandwidth and power management according
    to environmental changes and mission needs.
  • 3. Remote control center manages network and
    data, and interacts with space assets and
    Internet.

18
802.15.4 antenna
GPS antenna
old spider design
accelerometer in sandbox as a seismometer
New spider design
19
Hardware Design
iMote2
UBlox GPS
MDA320
  • Seismic
  • Infrasonic
  • Lightning

20
Hardware Design
  • Controller Intel Mote2
  • CPU PXA271 13-416MHz with Dynamic Voltage
    Scaling. 13MHz operates at a low voltage (0.85V)
  • Storage 256kB SRAM, 32MB SDRAM, 32MB Flash
  • 802.15.4 radio CC2420
  • Other Hardware Components
  • Seismic low noise MEMS accelerometer (Silicon
    Designs Model 1221J-002)
  • Infrasonic low range differential pressure
    sensor (All Sensors's Millivolt Output Pressure
    Sensors Model 1 INCH-D-MV)
  • Lightning (for ash detection) custom USGS/CVO
    RF pulse detector
  • GPS (for deformation measurement) L1 GPS (Ublox
    model LEA-4T)
  • Customized SmartAmp 2.4GHz, 250mW, amplify -3dBm
    input to 20dBm output.
  • Antenna 12 dB omni, withstand extreme wind
    speeds in excess of 130 MPH
  • Battery a bundle of Cegasa air-alkaline
    industrial batteries

21
Lab Environment Setup
22
Lab Environment Setup
GPS receiver and distributor
DAC for data input
Lab Mini-net
23
Ground Segment Software Components
  • In-Situ Sensor Web Components Relationship
  • 1. Topology Management Routing, Bandwidth
    Management and Power Management runs autonomously
    to meet mission needs and optimize the resource
    usage.
  • 2. Network Management module enable network
    status monitoring and external command control
    from Space element, users or scientific agent
    softwares.
  • 3. Situation Awareness middleware learns
    environment situations and allocates network
    communication and computation resources
    accordingly..

24
Data Management
  • Port to USGS existing tools (e.g., EARTHWORM,
    VALVE, SWARM)
  • database for real-time data storage
  • web tools for seismic, GPS data visualization
  • Sensor web services for Ground lt-gt Space Linkage
    and future inter-geo-system data sharing

25
Network Management
  • Monitor the network status
  • Network topology
  • Node battery status
  • Packet delivery ratio
  • Sensor status and sampling rate
  • Command Control
  • Inject feedback from space asset, user, and
    scientific agent software
  • Network adjust resource allocation accordingly
  • Programming over the air
  • Upgrade software without risky and expensive
    field retrieval

26
Node Software Architecture
27
Intelligent Sensing Features
  • Online Configurable Sensing
  • Environment Situation Awareness
  • Node Situation Awareness
  • Situation-driven Synchronization
  • Situation-driven Networking

28
Online Configurable Sensing
29
Online Configurable Sensing
  • Configurable Parameters
  • Change sampling rate
  • Add/Delete sensor
  • Change data priority
  • Change node priority
  • Parameter will be saved to Flash in case node
    reboots.
  • Platform Independent
  • Support for different hardware platforms
  • Support for different applications

30
Online Configurable Sensing
  • Configurable Data Processing Tasks
  • RSAM calculation
  • STA/LTA event
  • detection
  • Threshold based
  • event detection
  • Prioritization
  • Compression

31
Online Configurable Sensing
  • Light-weight Remote Procedure Call Mechanism
  • Module designers decide which interface or
    command to be allowed to call remotely, by simply
    adding _at_rpc()
  • interface SensingConfig _at_rpc()
  • It will translated to XML
  • ltSmartSensingM.SensingConfig.setSamplingRate
    commandID"23" componentName"SmartSensingM"
    functionName"setSamplingRate" functionType"comma
    nd" interfaceName"SensingConfig"
    interfaceType"SensingConfig" numParams"2"
    provided"1" signature" command result_t
    SmartSensingM.SensingConfig.setSamplingRate (
    uint8_t type, uint16_t samplingRate ) "gt
  • ltparamsgt
  • ltparam0 name"type"gt
  • lttype typeClass"unknown"
    typeDecl"uint8_t" typeName"uint8_t" /gt
  • lt/param0gt
  • ltparam1 name"samplingRate"gt
  • lttype typeClass"unknown"
    typeDecl"uint16_t" typeName"uint16_t" /gt
  • lt/param1gt
  • lt/paramsgt
  • ltreturnType typeClass"unknown"
    typeDecl"result_t" typeName"result_t" /gt
  • lt/SmartSensingM.SensingConfig.setSamplingRategt

32
Online Configurable Sensing
  • Compiling time XML file generation
  • Run-time memory address access
  • Run-time function call

Marionette, IPSN 2006
33
Online Configurable Sensing
  • Cascades reliable fast flooding protocol
  • Opportunistic broadcast flow
  • Parent-children monitoring
  • Explicit and implicit ACK
  • Retry and request

34
Online Configurable Sensing
  • 1000 packets injected
  • 2 sec interval
  • 15 nodes
  • 967 vs. 1735

35
Online Configurable Sensing
  • 1000 packets injected
  • 2 sec interval
  • 15 nodes
  • 303.4 ms vs. 344.1 ms

36
Environment Situation Awareness
  • Learn environment situations through data
    processing and correlations, with the guide of
    domain sciences
  • Changes of volcanic activity will cause sensors
    to adjust sampling autonomously. For instance,
    active seismic activity trigger sampling rate
    increases of gas sensors
  • Situation-driven data prioritization
  • Priority of sensor types. For instance, during
    eruption, gas sensor reading is more useful than
    seismic reading on the other hand, during
    background activity level, seismic reading is
    more important.
  • Priority of node locations. If we can not get
    data from all sensors, we shall be able to
    automatically identify the minimum set of sensors
    that will provide mission critical data.

37
Environment Situation Awareness
38
Environment Situation Awareness
  • Threshold based event detection
  • Compare raw data to threshold
  • Lightning sensor data
  • STA/LTA event detection
  • Short-Term Average and Long-Term Average data are
    compared
  • Event is triggered when ratio is over threshold

39
Environment Situation Awareness
  • RSAM value calculation - Real-Time
    Seismic-Amplitude Measurement
  • RSAM period 1 sec
  • STA window 8 sec
  • LTA window 30 sec
  • Trigger ratio 2

40
Environment Situation Awareness
41
Environment Situation Awareness
  • Prioritization
  • Assigning priorities based on data and event type
  • Assigning retransmission opportunities based on
    priorities

42
Node Situation Awareness
  • Fault Detection
  • Sensor board disconnection
  • All value are 0xFFFF
  • Sensor broken (including GPS)
  • Sensing value are much different from other nodes
  • System error
  • Low battery, low memory space

43
Node Situation Awareness
  • Watchdog mechanism to restart nodes
  • If watchdog timer was not reset for certain time
    periods.
  • If radio did not send or receive for 5 minutes
    (when the network data rate is high).
  • If some memory buffer is full and never get
    cleared for 5 minutes.
  • Those are crucial for a long-term deployed
    system
  • Our network has been continuously running after
    deployed, never died till now.

44
Situation-driven Time Synchronization
  • Design goal
  • Synchronize with UTC time
  • Synchronized sampling different nodes sample
    channels at same time point, 1ms resolution
  • Hybrid Time Synchronization
  • Stay synchronized with GPS if GPS is good
  • Switch to modified FTSP (Flooding Time
    Synchronization Protocol, Maróti, Sensys 2004)
    when GPS is disconnected

45
Situation-driven Time Synchronization
  • Modified FTSP
  • Dynamic root selection
  • Smallest node id with GPS connected
  • Smallest node id if none has GPS

2
1
root
1
1
root
2
3
2
3
6
6
5
4
5
4
7
7
46
Situation-driven Time Synchronization
  • GPS Time Synchronization
  • Not trivial due to OS delays

47
Situation-driven Time Synchronization
48
Situation-driven Networking
  • Self-organizing and Self-healing routing
  • Link metrics based on cc2420 LQI (Link Quality
    Indicator)
  • Fast switch and fast recovery
  • Qos-aware packet scheduling
  • VWFQ (Variable Weighted Fair Queue)
  • Energy-efficient, traffic-adaptive (supports
    high-throughput), and scalable MAC protocol
  • TreeMAC localized TDMA for energy-efficient
    high-rate data collection

49
Situation-driven Networking TreeMAC
  • Most of existing sensor MAC protocol assume low
    duty-cycle applications (e.g., sample every 5
    minutes or so)
  • Periodic wakeup, sense and sleep to reduce idle
    listening energy waste
  • Until recently, some attention has been paid to
    high data-rate application needs
  • Z-MAC (SenSys 2005)
  • Funneling-MAC (SenSys 2006)
  • In fact, many applications have high data (102
    to 105 Hz sampling rate), including industrial
    monitoring, civil infrastructure, medial
    monitoring, industrial process control,
    structural health monitoring, fluid pipelining
    monitoring, geological environment monitoring.
  • Needs an Energy-efficient, traffic-adaptive, and
    scalable MAC protocol for data collection
  • Support high-throughput if traffic is heavy
  • Conserve energies if traffic is light

50
Situation-driven Networking TreeMAC
  • TreeMAC is inspired from the following key
    observations
  • The majority data flows are from sensors to sink
    or from sink to sensors, not random any-to-any
    communication tree-based routing.
  • Existing MAC protocols (including CSMA-based and
    Z-MAC) tend to give every node equal channel
    access opportunity, which is not fair for data
    collection the node closer to the gateway
    forwards more data, and shall gain more channel
    access opportunity.

51
Situation-driven Networking TreeMAC
  • Time divided to cycles
  • Cycle divided to N frames (predefined, e.g., 16
    in the illustration).
  • Frame divided to 3 slots
  • Slot 0 red Slot 1 green Slot 2 blue
  • Each node picks slot according to its tree-level
    only (e.g., level3)
  • Each node can send only in picked slot per frame,
    listen/sleep in the other two
  • Mitigate vertical 2-hop interference
  • Each node assign its childrens frames in the
    beginning of each cycle, such that childrens
    frames does not overlap/conflict with each other.
  • Mitigate horizontal 2-hop interference

52
Situation-driven Networking TreeMAC
1
0
1
0
0
1
1
1
2
2
2
0
0
0
0
1
Every node get number of slots proportional to
its bandwidth demand
53
Situation-driven Networking TreeMAC
54
Deployment Experiences
  • On Oct. 15, 2008, 5 stations air-dropped into the
    crater of Mount St. Helens

55
(No Transcript)
56
SEP
NED
VALT
http//van-database.vancouver.wsu.edu
57
(No Transcript)
58
10/15/08
59
Deployment Experiences
  • On Oct. 16, Node 15 disappears

60
Node 15 disappears in 18 hours, because
Node 15
15 minutes after the helicopter left, it
disappears again
10/22/08
61
Fix it by repairing the voltage regulator circuit
and added more stones to prevent
2 days later, volcano cowboys hike to find the
mystery
10/24/08
62
Wind speed peaks at 120 miles/hour
Infrasonic sensor records the unusual gust
63
Weather affects link quality
64
48-Hour Period Starting 5PM 11/4 Forward 2
Days
65
Magnitude 1 Earthquake
  • Mount St. Helens
  • 3 km depth
  • November 4, 2008

66
OASIS 2 Hz geophone
67
OASIS MEMS accelerometer
68
CVO 2 Hz geophoneanalog
69
CVO piezo accelerometer
70
CVO digital broadband
71
Deployment Lessons
  • Hardware verification is as important as software
    verification, and shall be done earlier too.
  • One month before the deployment, we start to look
    at how to make the transmission range longer than
    300 meters
  • CC2420 radio has at most 0 dBm output, some nodes
    only achieve -3dBm after signal attenuation by
    circuit. There is no commercial 802.15.4
    amplifier supports input less than 0 dBm.
  • Customized SmartAmp 2.4GHz, 250mW, accept -3dBm
    input.

72
Deployment Lessons
  • Quantitative measurement is essential, do not
    just trust experiences
  • Some articles saying there is a correlation
    between RSSI and LQI it is NOT true!
  • After we added RF amplified, the measurement
    device (e.g., Anritsu S332D Site Master) shows it
    has strong RSSI even 400 meters away, but the
    network just does not connect well.
  • We decided to write our RSSI and LQI measurement
    program TOSBaseLQI it shows LQI is below 70
    (90-110 means good), though RSSI is -30 dBm (well
    above -90 dBm receiver sensitivity threshold).

73
Deployment Lessons
  • Open for any possibility need critical thinking
    skills.
  • RSSI is high but LQI is low with the
    TOSBaseLQIs help, we tried to change everything,
    almost think nothing is trustable ? Eventually,
    we found that the small L-connector between
    CC2420 radio and amplifier adds sufficient noises
    to make S/N ratio too low before amplification.
  • Some iMote2 with 4-digit serial number will die
    after 8 hours running unknown reasons, while
    those with 7-dgit serial number are okay.
  • One node (node 10)s signal quality will decrease
    during 1PM-6PM sunny days (when temperature is
    high)
  • Unbelievable after we changed the high-quality
    antenna cables (LMR_at_-400-ULTRAFLEX COAXIAL CABLE
    TIMES MICROWAVE SYSTEMS) to some lower quality
    lab cables (BELDEN 8262M17/155-00001 MIL-C-17
    16428 2137 1922 ROHS), the problem is gone. This
    problem does not happen in other nodes.
  • During deployment, USGS replaced the cables back
    to the high quality one the problem did not
    repeat in field so far.
  • Still do not know exact reasons though it must
    be related to temperature!

74
Sensor Data Quality
VALT BHZ
VALT 24 bit broad-band (the gold standard) in a
quiet location. It costs more than 10K and is
deeply buried in the ground, which takes several
days to deploy this station.
SEP EHZ2 Hz geophoneanalogburied, vertical
NED EHZpiezo accelerometerburied, vertical
75
Sensor Data Quality
N10 EHZ2Hz geophones, buried, vertical
N14 EHZ MEMS accelerometers in sandbox
N15 EHZMEMS accelerometers, buried, vertical
76
Sensor Data Quality
N16 EHZMEMS accelerometers, buried, vertical
N18 EHZ 2Hz geophones, buried, vertical
77
Management Lessons
78
Management Lessons
  • Developing a complete system for 1-year running
    is very different from writing research paper
  • Management overheads
  • Wiki, SVN, Mailinglist, Google docs and Citeulike
    are useful
  • Testbed setup, simulation and debug tools need to
    be invented.
  • Not just simulations
  • Not just piece by piece when put together,
    things are different
  • Black box test and end-to-end performance test.

79
Management Lessons
  • Benefit from the defined design philosophy for
    the team
  • TinyOS 1.x open source sensor network OS.
    Learning curve is sharp, due to few
    documentations
  • Programming philosophy and tips need to be
    accumulated and shared
  • http//sensorweb.vancouver.wsu.edu/wiki/index.php/
    Tips
  • Lacks of test in real deployment lots of bugs
    to fix
  • http//sensorweb.vancouver.wsu.edu/wiki/index.php/
    Bugs
  • Sanity check is necessary everywhere code
    review among group is helpful
  • link layer checksum not working
  • byte-alignment problems without _packed
    attribute)
  • Array bound check, null pointer check, even you
    are sure it will not happen.
  • Backup message header before it sends to radio
    we found sometime radio will corrupt messages
    when sending.
  • Not well designed for high-data rate applications

80
Acknowledgement
  • NASA ESTO AIST and USGS Volcano Hazard Program
  • A multidisciplinary team involves
  • computer scientists (Washington State University)
  • WenZhan Song (Assistant Professor, WSU)
  • Behrooz Shirazi (Chair Professor, EECS director,
    WSU)
  • Students team
  • space scientists (Jet Propulsion Laboratory)
  • Steve Chien (Principal Computer Scientist, JPL)
  • Sharon Kedar (Geophysicist, JPL)
  • Frank Webb (Principal Manager, JPL)
  • Danniel Tran (Software Engineer, JPL)
  • Joshua Doubleday (Software Engineer, JPL)
  • earth scientists (USGS Cascade Volcano
    Observatory)
  • Rick LaHusen (Senior Instrumentation Engineer,
    CVO)
  • Cynthia Gardener (Science-in-charge, CVO)
  • John Pallister (Geologist, CVO)
  • Dan Dzurisin (Geophysicist, CVO)
  • Seth Moran (Seismologist , CVO)
  • Mike Lisowski (Geophysicist , CVO)

81
IEEE SIMA 2008 Nov. 18, 2008
Thank You!WenZhan SongEmail songwz_at_wsu.edu
Deployment video http//www.youtube.com/watch?vIb
CpioUlF0I More information, visit http//sensorw
eb.vancouver.wsu.edu
82
SEP
NED
VALT
83
Ground Segment Overview
84
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
