Graphs, Good and Bad

1
Graphs, Good and Bad

• Chapter 10

2
Organizing Data

• How data are organized and presented is important
• Just as a writer organizes words into a coherent
  story, a statistician organizes and presents data
  to tell a clear story
• Too much data is hard to digest
• Too little data is uninformative
• Disorganized or sloppily presented data are hard
  to read
• Also just as a story can be manipulated to
  emphasize certain aspects, so can the
  organization and presentation of data be
  manipulated to stress of hide certain elements of
  the story

3
Organizing Data

• Distortion of this sort has nothing to do with
  Statistics per se and all to do with human nature

• Statistics is just another form of information
  and mode of communication that can be manipulated
  by those with a will to deceive
• Figures wont lie, but liars will figure

4
Getting rich

• There was a significant bull market at the end of
  the 1990s how big?
• Pictures are a very quick way of absorbing how
  big and putting it in perspective
• The next two graphs show
• The percentage change in the Standard Poors 500
  index from 1971 to 2003
• The percentage increase in value of 1,000
  invested in 1970

5
(No Transcript)
6
(No Transcript)
7
Data tables

• The Statistical Abstract of the United States is
  an annual volume filled with numerical data in
  tables, for example
• The number of schools in the US by type
• The number of students enrolled in each type of
  school
• The number of degrees granted by colleges of
  different types to students of different types
• The data are summarized in tables
• We dont want to look at the individual data for
  every school or college, rather we want an
  informative summary of those data

8
Example 1 What makes a clear table?

• How well educated are 30-something young adults?
• The table on the next slide answers that question
  and conforms to some good practices when making
  tables
• Clearly labeled, see the subject of the data at
  once
• Main heading gives general subject and date that
  data pertain to
• Labels in the table identify the variables and
  their units
• The source of the data is attributed at the foot
  of the table

9
(No Transcript)
10
Data tables

• Table 10.1 breaks down 30-somethings into levels
  of education and displays
• Counts at each educational level
• Rates or percentages of the total number of
  30-somethings at each educational level
• The total number of 30-somethings an the total of
  the percentages at the bottom
• The two columns with counts and percentages
  describe the distribution of 30-somethings
  according to education level
• Both columns are useful, the first gives the
  total size of each group, the second how much of
  the total each group is

11
Data tables

• If you check Table 10.1 for consistency you will
  see that the total is 20,521, but if you add up
  all the counts you get 20,522
• What happened?
• The entries are rounded to the nearest thousand
• They are totaled before they are rounded and then
  the total is rounded separately ? may not match
  perfectly

12
Pie charts and bar graphs

• Pie charts show how a whole is divided into parts
• The point of a pie chart is to show the
  composition of a total percentages
• Pie charts can only display a few pieces of the
  whole before they become hard to read and
  confusing
• We can make a pie chart of the distribution in
  Table 10.1
• Start by drawing a circle, this represents the
  whole all the 30-somethings
• Wedges within the circle represent the parts,
  with the angle spanned by a wedge in proportion
  to the size of the part

13
Pie charts and bar graphs

• For example, 22.4 of the 30-somethings have a
  bachelors degree but not an advanced degree
• So, the bachelors degree wedge spans 22.4 of
  the 360 degrees of the total
• 0.224 x 360 81 degrees
• Pie charts force us to see that the parts
  together make a whole, but its hard to read
  the angles and get an exact sense of the
  distribution represented by a pie chart
• In most cases the actual percentage are included
  as labels in the wedges, as we have done in
  Figure 10.3 on the next slide

14
(No Transcript)
15
Pie charts and bar graphs

• A bar graph addresses the fact that pie charts
  can be hard to read precisely
• Figure 10.4 is a bar graph of the same data in
  Table 10.1 and the pie chart in Figure 10.3
• The height of each bar shows the percentage of
  30-somethings with each education level
• Now we can easily read that just less than 15
  dont have a high school degree
• A bar graph allows us to readily compare the
  percentages in each category by comparing the
  heights of the bars

16
(No Transcript)
17
Pie charts and bar graphs

• As we think about graphs, it is useful to
  distinguish
• Variables that have a meaningful numerical scale
  such as height or SAT scores,
• Variables that place individuals into categories
  like sex, education or occupation
• Pie charts and bar graphs are best for
  categorical variables of the second type

18
Pie charts and bar graphs

• Bar graphs are also useful for other things
• Bar graphs can also compare quantities that are
  not part of a whole

19
Example 3 High taxes?

• Figure 10.5 displays the level of taxation in
  eight democratic nations
• The height of the bars shows the percentage of
  each nations GDP that is taken in taxes
• Turns out we Americans arent taxed as heavily as
  we think when compared to other nations

20
(No Transcript)
21
Beware the pictogram

• Bar graphs compare quantities by comparing the
  heights of the bars
• Our eyes react to both the height and the area of
  the bars, so if two bars are of similar height
  but one is wider, our eyes will emphasize the
  wider one
• For this reason its important to keep all the
  bars the same width, so that we compare them just
  on height and not on area too
• Its sometimes tempting to replace the bars with
  pictures
• Its hard to make pictures all the same width
  without distorting them ? leads to the area
  problem
• Avoid using pictures!

22
(No Transcript)
23
A misleading pictogram

• Figure 10.6 on the previous slide is misleading
• The numbers on the graph indicate that
  advertising spending at Time is 1.64 times that
  at Newsweek
• Why does the graph suggest that Time is so much
  farther ahead?
• To magnify the image, the artist increases both
  height and width thus making the area Times
  image 1.64 x 1.64 2.7 times Newsweeks image
• Our eyes respond to both the area and the height
  and see a much bigger difference between Time and
  Newsweek than really exists

24
Change over time line graphs

• Many quantitative variables are measured over
  intervals of time
• The height of growing child at the end of each
  month
• The value of the stock market at the end of each
  day
• In these cases our main interest is change over
  time
• Change over time is displayed using a line graph

25
Example 5 The price of gasoline

• How has the price of gasoline changed over time?
• Figure 10.7 on the next slide is a line graph
  showing the average price of regular unleaded
  gasoline across the US each month from January
  1994 to July 2004
• There are 115 data points on this line graph
• It would be very difficult to read down a table
  with 120 rows and see patterns in the average
  price of gasoline
• Reading the line charge quickly reveals some
  patterns
• What are they?

26
(No Transcript)
27
Change over time line graphs

• Look for an overall pattern. A trend is a
  long-term upward or downward movement. From 94
  to 99 there was no trend, but from 99 to 04
  there was an upward trend
• Look for striking deviations from the overall
  pattern. There is a striking dip in 01 that
  deviates from the upward trend.
• Look for regular variation or seasonal variation.
  Gasoline prices are usually highest in the
  summer when people drive more and lower in winter.

28
Change over time line graphs

• Seasonal variation is often removed from time
  series because it does not convey important
  information and may confuse the interpretation of
  the time series
• For example, using the unemployment rate we want
  to see changes that correspond to actual
  (unexpected) changes in the employment rate
• We dont want to see the normal expected seasonal
  variation in the unemployment rate that has
  nothing to do with the labor market and all to do
  with timing of the holiday season and the weather

29
Change over time line graphs
30
Watch those scales!

• Graphs speak strongly and can easily mislead
• One should always note the scale of the axes in a
  line graph
• The graphs on the next slide plot the number of
  unmarried-couples households in the US
• The one on the left indicates a moderate increase

• The one on the right suggests a thundering
  increase
• The difference is the scales of both axes
• On the left the vertical (count) axis is short an
  horizontal (time) axis is long
• On the right, the reverse is true which
  exaggerates the rate of increase

31
(No Transcript)
32
Watch those scales!

• When plotting the change in a value over time, it
  is often more accurate and informative to plot
  the percentage increase from period to period
• Figure 10.1 of the stock market (next slide) that
  we have already seen does this
• While the actual value of an investment, plotted
  in Figure 10.2, changes dramatically in the
  latter years, the increase from year-to-year
  during this period was not much more than it was
  in the 70s
• This is because the value of the investment was
  relatively small in the 70s, so actual value
  added per percentage change was small

33
(No Transcript)
34
(No Transcript)
35
Making good graphs

• Graphs are the most effective way to communicate
  using data
• A good graph can easily reveal fact about the
  data that would be hard to detect from a table of
  numbers
• Good graphing principles
• Use good labels and legends that tell what
  variables are plotted, the units used and the
  source of the data
• Make the data stand out most not the
  background, labels, grids or unnecessary artwork
• Pay attention to what the eye sees dont use
  pictograms, choose scales carefully, and dont
  use 3-D effects that confuse the eye without
  adding information

36
Example 7 The rise in college education

• Figure 10.9 on the next slide shows the rise in
  the percentage of women 25 and older who have at
  least a bachelors degree
• Its a cluttered mess
• No axis labels
• Confusing grid lines
• Unnecessary pictures
• Strangely formatted and positioned title
• A good graph uses only as much ink as necessary
• Decorations are generally not advised!

37
(No Transcript)
38
Example 8 High taxes, reconsidered

• In the bar graph we saw in Figure 10.5, countries
  are arranged along the horizontal axis
  alphabetically
• It is clearer to order them by tax burden so that
  we can easily pick out the highest and lowest and
  which countries are in between
• Ordering the countries by tax burden improves the
  graph by making it clear where a country stands
  in the group of eight that are plotted

39
(No Transcript)
40
Summary

• To see what data say, use graphs
• The choice of graph depends on the type of data
• To display a distribution of categorical data,
  use a pie chart or a bar graph
• Pie charts always show the parts of some whole
• Bar graphs can compare any set of numbers
  measured in the same units
• To show how a quantitative variable changes over
  time use a line graph that plots values on the
  vertical axis and time against the horizontal axis

41
Summary

• Graphs can mislead the eye
• Avoid pictograms
• Pay attention to scales
