• Pack 216 Design Performance Workshop

3
What Youll Get Today

• Ideas for cars
• Rules Review
• Performance Advice
• Race Day Tips

4
Some Questions to Ask

• What Do Real Race Cars Look Like?
• Why Dont All Race Cars Look Alike?
• How Can I Design a Cool Looking Car?
• How Can I Design a Fast Car That Wins?

5
Todays Logo Contest
6
Name That Logo Contest

• At different times today,you will seea logo
  for acar model ormanufacturer.
• First one to shout out the CORRECTname gets a
  prize.

You ShoutFORD!
7
Name That Logo
8
Name That Logo
9
Designing a Race Car

• The Rules Determine The Car

10
Race Car Design Open Wheel vs. Closed Wheel
Closed Wheel
11
Race Car Design Open Wheel vs. Closed Wheel
Open Wheel
12

• Lets Look at Some Race Cars

13
Race Car Design Open Wheel vs. Closed Wheel
Grand Prix de Monaco Open Wheel
14
Race Car Design Open Wheel vs. Closed Wheel
LeMans 24 Hour Road Race Closed Wheel
15
Race Car Design Open Wheel vs. Closed Wheel
Dirt Track Midget Car Open Wheel
16
Race Car Design Open Wheel vs. Closed Wheel
NASCAR Stock Car Closed Wheel
17
Race Car Design Open Wheel vs. Closed Wheel
Performance Drag Racer Open Wheel
18
Race Car Design Open Wheel vs. Closed Wheel
Funny Car Dragster Closed Wheel
19
Race Car Design Open Wheel vs. Closed Wheel
Supermodified Open Wheel
20
Race Car Design Open Wheel vs. Closed Wheel
Demolition Derby Closed Wheel
21
Race Car Design Open Wheel vs. Closed Wheel
Open Wheel
Closed Wheel
22
Pinewood Derby Cars

• Pinewood rules say if you can have either open
  or closed wheel cars.
• Pinewood Derby is easier to do as an open wheel
  car.

23
Name That Logo
24
Designs Old and New
25
All Racecars were Open Wheel
1911 Indy Car 32 The Wasp
26
Idea File 1 Past Indy Cars
1952 Ferrari 12
1955 Kurtis Kraft 4
1960 Watson 56
1964 AJ Foyt 1
27
Race Car Design Open Wheel Evolves
28
Name That Logo (Model)
29
Grand Prix Ferrari from front
30
Grand Prix Toyota From Above
31
Name That Logo
32
Create a Performance Car

• How Fast is Fast?

33
Pinewood Speeds

• Typical Finish Line Speeds
• 1.0 Seconds 10 inches on track
• .01 Seconds 1.0 inches on the track
• .001 Seconds 0.1 inches on the track

34
Create a Performance Car

• Study Your Race Rules
• What is allowed?
• What is not allowed?
• Follow Your Race Rules! (No Cheating!)
• Track Matters

35
Official Pinewood Rules

• Width Overall width of the car shall not exceed
  2 3/4 inches.
• Length Overall length of the car shall not
  exceed 7 inches.
• Weight The weight of the car shall not exceed 5
  ounces. No loose materials of any kind are
  permitted in the car. The car may be hollowed out
  and built up to the maximum weight by the
  addition of wood or metal only, provided any
  additional material is securely built into the
  body.
• Wheel bearings, washers, and bushings are
  prohibited.
• Springing The car shall not ride on any type of
  springs.
• Details Details such as the steering wheel,
  driver, decals, painting, and interior detail are
  permissible as long as these details do not
  exceed the maximum length, width, and weight
  specifications.
• Attachments The car must be freewheeling, with
  no starting devices.
• Inspection Each car must pass inspection by the
  official inspection committee before it will be
  allowed to compete. The inspectors have the right
  to disqualify those cars that do not meet these
  specifications.

36
Create a Performance Car Track Matters

• What type of track do you race on?
• Slope Run vs. Flat Run

Constant Slope
Long Slope
Short Slope
37
Create a Winning Car

• Plan, Plan, Plan!
• Three Magic Variables
• Aerodynamics
• Weight
• Wheels
• We will talk about all threeof these.

38
Name That Logo
39
Design for Performance

• Aerodynamics / Streamlining

40
Create a Performance Car Aerodynamics

• Low Profile
• Streamlined

41
Create a Performance Car Aerodynamics

• Low Profile
• Streamlined

42
Name That Logo
43
Design for Performance

• Weight

44
How Much Does a Car Weigh?

• Official Weight for Pinewood Derby
• 5 Ounces

45
Create a Performance Car Weight Position

• Back, middle or front?
• Side or center?

46
Create a Performance Car Weight side or center?

• Using the Moment of Inertia (Rotational Mass /
  Angular Momentum)

47
Name That Logo
48
Design for Performance

• Wheels and Axles

49
Create a Performance Car Wheels

• Pick the Best Wheels
• True the Wheels
• Polish the Axles
• Graphite Saturation
• Spin for 20 Seconds at least
• Three is Better than Four

50
Name That Logo (Model)
51
Race to Win
52
This is Cheating

• Doing these could get your car
• DISQUALIFIED!
• Using precut car bodies
• Thinning or changing the wheels
• Changing the wheelbase
• Using special axles
• Having your Dad make your car

53
Design to Win

• Draw your design on paper
• Try several designs, and pick the best

54
Design to Win

• Draw your design on paper
• Try several designs, and pick the best

55
Use Decals To Customize
56
Name That Logo (Model)
57
Prepare to Win
58
At Home To Do List

• Insure that your car is tracking (steering) in a
  straight line before you check-in your car.
• Check your wheels for freedom. Can you spin all
  the wheels and have them spin 20 seconds before
  they come to a stop?
• Don't roll your car in the dirt or on concrete
  surfaces. It's a sure way to ruin the wheels and
  axles.

59
Pre-Race To Do List

• Finish decorating your car 1 week before the
  race.
• Thoroughly lubricate your car before the
  check-in.
• If your car doesn't do very well rolling forward
  try racing it backwards. Cars will run faster one
  way than another.

60
Protect Your Car!

• Always handle your car by the body NOT the
  wheels.
• Dont let anyone else touch your car.
• Don't run while carrying you car. You may to drop
  it which may break something you cannot repair

61
Race Day To Do List

• You car should be finished BEFORE you arrive!
• Get to the track early for check in
• Place your car on the track with the wheels
  spaced so that the wheels do not touch the lane
  guide.
• Take your time in placing the car on the track.
  Point it straight down the track.

62
Name That Logo
63
Pinewood Idea File

• Fun Designs

64
Race Car Design Idea Files Wild Cars
65
Race Car Design Idea Files Food Cars
66
Race Car Design Idea Files Wild Cars
67
Race Car Design Idea Files Fun Cars
68
Race Car Design Idea Files Fast Cars
69
Pinewood Idea File

• Speed Designs

70
Race Car Design Idea Files The Wedge
71
Race Car Design Idea Files The Rail
72
Race Car Design Idea Files The Flying Spatula
73
Do Your Best
74
Race Car Design Idea Files Pinewood Ferrari F1
Pinewood Ferrari
Real Ferrari
75
Race Car Design Idea Files Pinewood Ferrari F1
76
Name That Logo
77
Name That Logo
78
What We Learned
79
What We Learned Today

• History of Race Cars
• What Real Race Cars Look Like
• Why All Race Cars Dont Look Alike
• Ideas for Designing a Cool Looking Car
• Ideas for Designing a Fast Car That Wins

80
Gentlemen, Start Designing Your Cars!
