Chapter 5: Magma And Volcanoes

1
Chapter 5 Magma And Volcanoes
2
Introduction Earths Internal Thermal Engine

• Magma is molten rock beneath Earths surface.
• Because liquid magma is less dense than
  surrounding solid rock, and obviously more
  mobile, magma, once formed, rises toward the
  surface.
• Magma that reaches the surface does so by
  erupting through vents we call volcanoes.

3
Volcanoes

• The term volcano comes from the name of the Roman
  god of fire, Vulcan.
• There are different types of volcanoes.
• Eruption vary from gentle flows (Hawaii and
  Iceland) to catastrophic explosions (Mount St.
  Helens, Mt. Pinatubo, Soufriere Hills).
• The majority of eruption never make the news
  because they occur beneath the ocean, unobserved.

4
Magma

• Magma has a wide range of compositions, but
  silica (SiO2) always dominates the mix.
• Magma has high temperatures.
• Magma is fluidit has the ability to flow. Most
  magma actually is a mixture of liquid (often
  referred to as melt) and solid mineral grains.

5
Composition of Magmas and Lavas

• The composition of magmas and lavas is controlled
  by the most abundant elements in the EarthSi,
  Al, Fe, Ca, Mg, Na, K, H, and O.
• Three distinct types of magma are more common
  than others
• Basaltic, containing about 50 percent SiO2.
• Andesitic, about 60 percent SiO2.
• Rhyolitic, about 70 percent SiO2.

6
Figure 5.1
7
Basaltic Magmas

• Basaltic magmas are erupted by approximately 80
  percent of volcanoes worldwide (the seafloor
  worldwide is mostly basalt).
• Magma from Hawaiian volcanoes such as Kilauea and
  Mauna Loa is basaltic.
• The entire island of Iceland is basaltic.

8
Andesitic and Rhyolitic Magmas

• Andesitic magmas are about 10 percent of the
  total magma.
• Magma from Mount St. Helens in Washington State
  and Krakatau in Indonesia is usually andesitic.
• Rhyolitic magmas are about 10 percent of the
  total magma.
• Magmas erupted from volcanoes that once were
  active at Yellowstone Park are mostly rhyolitic.

9
Figure 5.3
10
Figure 5.5
11
Gases Dissolved in Magma

• Small amounts of gas (0.2 to 3 by weight) are
  dissolved in all magma.
• The principal gas in water vapor, which, together
  with carbon dioxide, accounts for more than 98
  percent of all gases emitted from volcanoes.

12
Temperature of Magmas and Lavas

• Magma temperatures range from 1000o to 1200oC.
• Magma temperatures can reach 1400oC under some
  conditions.

13
Viscosity of Magmas and Lavas (1)

• The internal property of a substance that offers
  resistance to flow is called viscosity.
• The more viscous a magma, the less easily it
  flows.
• Viscosity of a magma depends on temperature and
  composition (especially the silica and
  dissolved-gas contents).

14
Viscosity of Magmas and Lavas (2)

• The higher the temperature, the lower the
  viscosity, and the more readily magma flows.
• The smooth, ropy-surfaced lava in Hawaii, formed
  from a very hot, very fluid lava is called
  pahoehoe.
• The rough-looking lava formed from a cooler lava
  having a high viscosity is called aa (ah ah).

15
Viscosity of Magmas and Lavas (3)

• The greater the silica content, the larger is the
  polymerized group.
• For this reason, rhyolitic magma (70 silica) is
  always more viscous than basaltic magma (50
  silica).
• Andesitic magma has a viscosity that is
  intermediate between the two (60 silica).

16
How Buoyant Magma Erupts on the Surface (1)

• Magma is less dense than the solid rock from
  which it forms.
• The pressure is proportional to depth (thickness
  of overlying rock).
• Therefore, as magma rises upward, the pressure on
  it decreases.

17
How Buoyant Magma Erupts on the Surface (2)

• Pressure controls the amount of gas a magma can
  dissolvemore at high pressure, less at low.
• Gas dissolved in an upward-moving magma comes out
  of solution and forms bubbles.

18
Eruption StyleNonexplosive or Explosive? (1)

• Nonexplosive eruptions occur notably in Hawaii,
  Iceland, and the seafloor.
• They are relatively safe.
• The difference between nonexplosive and explosive
  eruptions depends largely on magma viscosity and
  dissolved-gas content.
• Low viscosity magmas and low dissolved gas
  contents produce nonexplosive eruptions.

19
Eruption StyleNonexplosive or Explosive? (2)

• Nonexplosive eruptions may appear violent during
  their initial stages.
• The reason is that gas bubbles in a low-viscosity
  basaltic magma will rise rapidly upward, like the
  gas bubbles in a glass of soda.
• If a basaltic magma rises rapidly, spectacular
  lava fountains will occur.

20
Eruption StyleNonexplosive or Explosive? (3)

• Because heat is lost quickly at the surface of
  the flowing lava, the surface solidifies into a
  crust, beneath which the liquid lava continues to
  flow in well-defined channels called lava tubes.
• The very fluid lava initially forms thin pahoehoe
  flows.
• With increasing viscosity the rate of movement
  slows and the stickier lava may be transformed
  into a rough surfaced aa flow that moves very
  slowly.

21
Vesicles and Amygdules

• When lava finally solidified to rock, the
  last-formed bubbles become trapped these bubble
  preserved in the rock are called vesicles.
• Vesicles filled by secondary minerals are called
  amygdules.

22
Explosive Eruptions (1)

• In viscous andesitic or rhyolitic magmas, gas
  bubbles can rise only very slowly.
• When confining pressure drops quickly, the gas in
  a magma expand into a froth of innumerable
  glass-walled bubbles called pumice.

23
Explosive Eruptions (2)

• In many instances, instead of forming pumice,
  small bubbles expanding within a huge mass of
  sufficiently gas-rich, viscous magma will shatter
  the magma into tiny fragments called volcanic
  ash.
• Volcanic ash is the most abundant product of
  explosive eruptions.

24
Eruption Columns and Tephra Falls (1)

• The largest and the most violent eruptions are
  associated with silica-rich magmas having a high
  dissolved-gas content.
• This hot, turbulent mixture rises rapidly in the
  cooler air above the vent to form an eruption
  column that may tower as high as 45 km in the
  atmosphere.

25
Eruption Columns and Tephra Falls (2)

• A violent eruption of this kind is called a
  plinian eruption, named after the Roman author
  and statesman, Pliny, who lost his life in the
  A.D. 79 eruption of Mt. Vesuvius.
• The particles of debris rain down in a tephra
  fall and eventually accumulate on the ground as
  tephra deposits.

26
Pyroclastic Flows (1)

• When the mixture of hot gases and pyroclasts is
  more dense than the atmosphere, the turbulent
  mixture flows down the side of the volcano rather
  than forming an eruption column.
• A hot, highly mobile flow of tephra that rushes
  down the flank of a volcano during a major
  eruption is called a pyroclastic flow (the most
  devastating and lethal forms of volcanic
  eruption).

27
Pyroclastic Flows (2)

• Pyroclastic flows are also known as nuée ardente
  (glowing cloud).
• Historic observations indicate that pyroclastic
  flows can reach velocities of more than 700 km/h.
• In 1902, a pyroclastic flow rushed down the
  flanks of Mont Pelee Volcano at an estimated
  speed of 200 KM/h, instantly killing 29,000
  people.

28
Lateral BlastMount St. Helens

• In 1980, Mount St. Helens, a volcano in
  Washington, erupted violently.
• As magma rose under the volcano, the mountains
  north flank began to bulge upward and outward.
• The initial blast was sideways rather than
  upward.
• 600 km2 of trees in the once-dense forest were
  leveled.

29
Figure 5.10
30
Volcanoes

• There are two broad families of volcanoes
• Those formed by eruptions from a central vent.
• Those that erupt through a long fissure.
• Central-vent eruptions build mounds of the kind
  most people associate with volcanoes.
• Fissure eruptions build plateaus.

31
Central-vent Volcanoes

• Based on their size and shape, there are three
  broad classes of central-vent volcanoes
• Shield volcanoes.
• Tephra cones.
• Stratovolcanoes.

32
Shield Volcanoes (1)

• A shield volcano produces a broad, dome-shaped
  mountain with an average surface slope of only a
  few degrees.
• Low-viscosity basaltic lavas can flow for
  kilometers down gentle slopes.
• The accumulated lava from repeated eruptions of
  low-viscosity lava build a shield volcano.

33
Shield Volcanoes (2)

• The farther lava flows down the flank, the cooler
  and more viscous it becomes, so the steeper the
  slope must be for it to flow.
• Large shield volcanoes rise as islands in the
  ocean (Hawaiian Islands, Tahiti, Samoa, the
  Galapagos, and many others).

34
Figure 5.11
35
Figure 5.13
36
Shield Volcanoes (3)

• Mauna Loa volcano, for example, rises to a height
  of 4169 m above sea level, but if measured from
  the seafloor the height is 10,000 m, making Mauna
  Loa the tallest mountain on Earth.

37
Tephra Cones

• Tephra cone is built by shower of pyroclastic
  debris around a volcanic vent.
• The slopes of tephra cones are steep, typically
  about 30o.

38
Statovolcanoes (1)

• Some volcanoes (andesitic composition) emit both
  viscous lava flows and tephra.
• The emissions tend to alternate, forming
  alternating strata of lava and tephra, building a
  stratovolcano.
• Stratovolcanoes are
• Large.
• Conical.
• Steep-sided.

39
Statovolcanoes (2)

• Near the summit, a stratovolcanos slope may
  reach 40o.
• Toward the base, the slope flattens to about 6o
  to 10o.
• As a stratovolcano develops, lava flows act as a
  cap to slow erosion of the loose tephra.

40
Statovolcanoes (3)

• The volcano becomes much larger and steeper than
  a typical tephra cone.
• Mount Fuji (Japan), Mount Rainier, Mount Baker in
  Washington State, Mount Hood in Oregon, Mt Mayon
  in the Philippines are stratovolcanoes.

41
Other Features of Central Eruptions (1)

• Craters
• Funnel-shaped depressions with steep-sided walls
  that open upward.
• Craters form in two ways
• By the collapse of the steep sides of the vent.
• By an explosive eruption.
• In subsequent eruptions, pressure blasts open the
  vent, removing both the solidified magma from the
  previous eruption and part of the crater wall.
• A crater can grow slowly larger, eruption by
  eruption.

42
Other Features of Central Eruptions (2)

• Lava domes
• If the magma is very viscous (as in a rhyolitic
  or andesitic magma), it squeezes out to form a
  lava dome.

43
Figure 5.16
44
Other Features of Central Eruptions (3)

• Calderas
• Caldera is from the Spanish word for cauldron.
• A roughly circular, steep-walled basin about a
  kilometer in diameter or larger.
• Calderas are created by collapse of the surface
  rock following an eruption and partial emptying
  of the underlying magma chamber.
• Crater lake in Oregon occupies a circular caldera
  8 km in diameter.

45
Figure 5.19
46
Other Features of Central Eruptions (4)

• Resurgent domes
• Often, more magma enters the chamber and lifts
  the collapsed caldera floor to form a resurgent
  dome.
• Diatremes
• Volcanic pipes filled with a rubbles of broken
  rock.
• The walls are vertical, or very nearly so.
• A famous diatreme is the diamond mine in
  Kimberly, South Africa.

47
Fissure Eruptions (1)

• Fissure eruptions extrude lava along an elongate
  fracture in the crust.
• When fissure eruptions occur on land, the
  low-viscosity basaltic lava tends to spread
  widely and to create flat lava plains.
• Such lavas are called plateau basalts.

48
Figure 5.21
49
Fissure Eruptions (2)

• The Laki eruption, in Iceland in1783, occurred
  along a 32 km long fracture. Lava from it flowed
  64 km from one side of the fracture and nearly 48
  km from the other, covering 588 km2.
• The Laki eruption is the largest lava flow of any
  kind in historic times.
• Famine followed and more than 9000 died (20
  percent of the Icelandic population).

50
Fissure Eruptions (3)

• Pillow basalts
• When the basaltic magma erupts under the ocean,
  seawater cools it so rapidly that pillow-shaped
  masses of basalt, ranging from a few centimeters
  to a meter or more in greatest dimension form.
• Fissure eruptions of andesitic or rhyolitic
  magma are much less common than fissure eruptions
  of basaltic lava.

51
Figure 5.18
52
Fissure Eruptions (4)

• Sometimes the pyroclasts in the tephra are so hot
  that the fragments form welded tuff.
• Some 40 to 50 million years ago, huge ash-flow
  eruptions happened in Nevada.
• The erupted product covered an area in excess of
  200,000 km2.

53
Figure 5.22
54
Posteruption effects

• When active volcanism finally ceases, rock in and
  near an old magma chamber may remain hot for
  hundreds of thousands of years.
• Thermal spring at many volcanic sites (Italy,
  Japan, and New Zealand) have become famous health
  spas and sources of energy.
• A thermal spring that intermittently erupts water
  and steam is a geyser.
• Most of the worlds geysers outside Iceland are
  in New Zealand and in Yellowstone National Park.

55
Figure B5.2
56
Figure B5.3
57
Volcanic Hazards (1)

• Volcanic eruptions are not rare on land, and are
  essentially continuous on the seafloor.
• Every year about 50 volcanoes erupt on the
  Earths continents.
• Most eruptions are basaltic.
• Tephra eruptions from andesitic or rhyolitic
  stratovolcanoes like Mount St. Helens and
  Krakatau can be disastrous.

58
Volcanic Hazards (2)

• Eruptions present five kinds of hazards
• Hot, rapidly moving pyroclastic flows and
  laterally directed blasts can overwhelm people
  before they can evacuate.
• Mont Pelee in 1902 and Mount St. Helens in 1980.
• Tephra and hot poisonous gases can bury or
  suffocate people.
• 79 Mount Vesuvius in A.D. 79.

59
Volcanic Hazards (3)

• Mudflows, called lahars, can be devastating.
• In 1985, the Colombian volcano Nevado del Ruiz
  experienced a small, nonthreatening eruption.
  But, when glaciers at the summit melted, massive
  mudflows of volcanic debris moved swiftly down
  the mountain , killing 20,000.
• Violent undersea eruptions can cause powerful sea
  waves called tsunamis.
• Krakatau, in 1883, killed more than 36,000 on
  Java and nearby Indonesia islands.
• A tephra eruption can disrupt agriculture,
  creating a famine.

60
Figure 5.24
61
Figure 5.25
62
Plates and Volcanoes (1)

• The distribution of active volcanoes around the
  world is strongly influenced by plate margins.
• Most of the worlds volcanism happen beneath the
  sea, along the 64,000 km midocean ridge.
• About 15 percent of all active volcanoes are
  located along spreading centers.
• Iceland, the Azores, and the East African Rift
  Valley.

63
Plates and Volcanoes (2)

• Most of the worlds visible and active volcanoes
  are located where two plates collide and one is
  subducted beneath the other.
• Water released from the subducted plate leads to
  the formation of andesitic magma by wet partial
  melting of mantle rock.

64
Plates and Volcanoes (3)

• The Pacific Ocean is ringed on three sides by
  subducting plate margins.
• About 5 percent of all active volcanoes are
  located in the interiors of plates.
• Hawaiian volcanoes.

65
Submarine Volcanism and the Composition of
Seawater

• Magnesium and sulfur are removed from seawater by
  the hot rocks.
• Calcium and the other chemical elements are
  added.
• The hot rocks of the midocean ridge are a major
  factor in maintaining the composition of seawater.
