Chapter 21 Downbursts

1
Chapter 21Downbursts

• Guest Lecturer Pedro Mulero
• Atmospheric and Oceanic Sciences

2
What is a Downburst?

• Strong downdraft that develops and intensifies
  within the lower part of a cumulus cloud or
  thunderstorm
• Associated with strong straight-line winds as the
  downward-directed air crashes onto the ground
• Two types (based on length scale)
• microburst (most common)
• lt 4km diameter
• less than 5 min
• winds up to 270 km/h (170mph)
• macroburst
• gt 4km diameter
• 5-30 min
• winds up to 188 km/h (117mph)

3
Mechanisms of Formation (1)

• Evaporation (most important)
• very dry (low RH) air below the cloud enhances
  evaporation
• latent heat of evaporation/melting is transferred
  from the unsaturated air into the droplets/ice
  crystals or hail
• Colder, denser air sinking at great speeds

4
Mechanisms of Formation (2)

• Precipitation drag
• force associated with the push of million of
  raindrops of air downward
• Colder, denser air accelerating downward even
  faster!! (with speeds of 64-96 km/h or 40-60 mph)

5
Favorable Environment for Downburst Formation (1)

• Large environmental lapse rate below the cloud
  (close to dry adiabatic lapse rate)
• found in areas where air is well-mixed
• conduction-dry convection mechanism mixes air
  well up to several km and increases the lapse
  rate (especially in the early afternoon when
  surface heating reaches a maximum)

6
Favorable Environment for Downburst Formation (2)

• Dry air below cloud base
• the drier, the greater the evaporation rate
• Shallow moist air layer near surface
• moist air is less dense than dry air
• Below-freezing temperatures in much of the cloud
  (capable of ice-crystal formation)
• more heat supplied by the air (latent heat of
  evaporation plus latent heat of fusion/melting)
  producing further cooling

7
Wet or Dry??

• Dry microbursts
• No measurable precipitation
• Not easy to detect except maybe when ground is
  dry
• More common in the West and Great Plains
• Environment thick dry air layer below cloud base
  (inverted-V sounding)

8
Wet or Dry??

• Wet microbursts
• measurable precipitation (0.01 or more)
• more easily seen
• Environment
• dry air above the cloud, lower cloud base

9
Wet or Dry??
10
Dry Microburst
11
Dry Microburst
12
Dry Microburst
13
Wet Microburst
14
Wet Microburst
15
Wet Microburst
16
Wet Microburst
17
Wet Microburst
18
Microbursts and Airplanes

• What provides the lift to aircrafts?
• the shape of the wings!
• But how?
• Bernoulli principle
• air speeds up over top of the wing low pressure
• high pressure under the bottom of the wing
• pressure gradient force upward (lift)

L
H
19
Microbursts and Airplanes

• Lift depends on the air moving across the wing
• Lift speed of plane relative to ground actual
  wind
• If you want to lift the airplane... increase the
  ground-relative speed!
• If you want to descend... reduce the
  ground-relative speed, but dont forget to lower
  the wing flaps!!
• if actual wind is headwind, lift increases
• if actual wind is tailwind, lift decreases
  (heres when it gets dangerous!!)

20
Danger to Airplanes!!

• A critical speed across the wings must be
  maintained to remain in the air
• When the speed is below the critical value a
  potentially dangerous situation
  unfolds,...,especially near the ground!!

21
Detection of Microbursts

• Terminal Doppler Weather Radar (TDWR)
• microbursts, wind shear, severe winds

22
Detection of Microbursts
23
Detection of Microbursts
divergence
convergence
24
Detection of Microbursts

• Low-level Wind-Shear Alert System
• network of anemometers that detect wind shear

25
Forecasting Microbursts

• Wind Index (WI) identifies the location and
  magnitude of strong winds associated with
  microbursts
• ELR below melting level
• height of melting level
• moisture content in the lowest km
• moisture content at melting level
