John V' Thomas, PhD

1
Transportation Policy and Placemaking in Tysons
Corner
John V. Thomas, PhD US EPA, Office of Policy
Economics and Innovation June 26th, 2007
2
The Core Transportation Issues

• Street Design Challenges
• Accommodating traffic while creating a high
  quality pedestrian environment
• Addressing assumptions about technical standards
• Analytical Challenges
• Forecasting the baseline traffic
• The net effect of a new land use and transit
  environment is a difficult analytical question
• Appropriately evaluating the tradeoffs
• Metrics are key
• Details matter
• Finding creative solutions

3
Design Challenges
4
Context Sensitive Street Design
5
Evaluating Cross-Sections
6
Design Tradeoffs

• Parking
• Sidewalk Width
• Vehicle Capacity
• Large Vehicle Accommodation
• Pedestrian Crossing Width
• Left turn lanes
• Landscaped Median
• Pedestrian Amenities
• Reduced Speeds
• Minimize Right of Way Acquisition

Across the planning area, the relative weight
assigned to each criteria will vary
7
Why Design Speeds are Critical
Source- ICF International, Spokanes University
District Policy Options for a New Urban Center.
Based on data from Karger, Teige et al (2000)
Relationship between impact velocity and
injuries in fatal pedestrian-car collisions
International Journal of Legal Medicine.
8
Innovative Ways to Minimize Tradeoffs

• Better crossing conditions across major roads
• Curb bump-outs at key intersections
• Median space as a pedestrian refuge
• Flexible Infrastructure
• Mountable medians and curbs
• Access management and parallel routes

9
Curb Bump-out
10
Median Refuge
11
Design Details Matter
12
Mountable Median
13
Some Relevant Examples

• 28th Street Boulder, CO
• 30,000 to 50,000 vehicles per day
• Up to 7 lanes
• Multi-year redesign effort
• http//www.bouldercolorado.gov/files/Transportatio
  n/Projects/28th_tnp.pdf
• El Camino Real San Mateo County, CA
• Route 29 Trenton, NJ

14
El Camino Redesign
Source Marcy McInelly, Urbsworks and Phil
Erickson, Community Design Architecture
15
El Camino Redesign
Source Marcy McInelly, Urbsworks and Phil
Erickson, Community Design Architecture
16
Source Marcy McInelly, Urbsworks and Phil
Erickson, Community Design Architecture
17
Source Marcy McInelly, Urbsworks and Phil
Erickson, Community Design Architecture
18
Source Mark Stout NJ DOT, Smart Growth and Smart
Transportation, The NJDOT Experience
19
Source Mark Stout NJ DOT, Smart Growth and Smart
Transportation, The NJDOT Experience
20
Source Mark Stout NJ DOT, Smart Growth and Smart
Transportation, The NJDOT Experience
21
Source Mark Stout NJ DOT, Smart Growth and Smart
Transportation, The NJDOT Experience
22
Source Mark Stout NJ DOT, Smart Growth and Smart
Transportation, The NJDOT Experience
23
Source Mark Stout NJ DOT, Smart Growth and Smart
Transportation, The NJDOT Experience
24
Source Mark Stout NJ DOT, Smart Growth and Smart
Transportation, The NJDOT Experience
25
Analytical Challenges
26
Forecasting Future Traffic Critical Questions

• New development new trips
• What share will be by car?
• What policies would increase transit use,
  walking, and biking?

27
How will greater accessibility, diversity of
activities and better urban design change trips
currently made within Tysons?
Source Lewis Grim, Cambridge Systematics,
Presentation to the Tysons Corner Coordinating
Committee (2005)
28
Evaluation Metrics

• Intersection Level of Service (LOS) for vehicles
  is the most common metric
• Butit presents a limited picture
• Corridor LOS, corridor travel time, or volume to
  capacity measures are somewhat better
• Other more comprehensive measures are still in
  very early stages of development

29
Pedestrian Level of ServiceFlorida DOT example

• Sidewalks (10 points)
• Continuous on one side 4
• Both sides 6
• At least 5 ft 1
• More than 5 ft 2
• Off street parallel trail 1
• Conflicts (4 points)
• Medians 1
• Access management 1
• Reduced turn conflict 0.5

• Amenities (2 points)
• Buffer gt 3 ½ ft. 1
• Shade trees 0.5
• Benches 0.5
• Traffic Flow (2 points)
• LOS E/F gt 6 lanes 0
• LOS D lt 6 lanes 1
• LOS C lt 6 lanes 2

30
Other design concepts
31
Thinking out of the box
Source City of El Cerrito, CA
32
Rail ROW Could Double as a Greenway
33
Source Teri Musser, Charlier Associates
