XQuery to XAT

1
XQuery to XAT

• Xin Zhang

2
Outline

• XAT Data Model.
• XAT Operator Design.
• XQuery Block Identification.
• Equivalent Rewriting Rules.
• Computation Pushdown
• Navigation Pushdown
• Groupby Operator Simplification

3
Data Model

• An Ordered Table in two dimensions
• Tuple order
• Column order.
• Every cell has its own domain, e.g.
• SQL domains.
• XML Fragment.
• Can be a list of XML elements.
• Every column binds to one variable.
• Comparison are done by values
• Note When values are handles, the comparison
  are done by deference of handles.

4
Data Model Examples

• Table of XML Fragments.
• Table Types
• Regular Relations.
• Table with XML Elements.
• Table with XML Fragments.
• Table with Variable Binding.
• Table with Path Navigation.

invoice_id carrier


ltcarriergt carrier lt/carrier
carrier_entry


ltcarriergt carrier lt/carrier ltcarriergt
carrier lt/carriergt .
carriers


rate


/ /invoice /invoice/account_number


5
Column Names

• A String
• name
• A Variable Binding
• var
• Operators with their parameters
• op(p1, p2, ..., pn)
• A XPath with Entry Point Notation.
• /, /invoice, /invoice/book
• invoice/, bookinvoice/

6
Operators

• SQL like (9)
• Project, Select, Join (Theta, Outer, Semi),
  Groupby, Orderby, Union (Node, Outer), CO
• XML like (3)
• Tagger
• Navigate
• Aggregate Groupby without by-column.
• Special (5)
• SQL, Function, Source, Name, FOR

7
SQL like Operators (9)
Operator Syntax Description
Project Pi(col)s Project out multiple columns from source s.
Select Theta(c)s Filter source s by condition c.
Theta Join Join(c)l, r Join two sources l and r under condition c.
Outer Join LOJ(c)l, r ROJ(c)l, r Left (right) outer join sources l and r by condition c.
Semi Join LSJ(c)l, r RSJ(c)l, r Left (right) semi join sources l and r by condition c.
Groupby GB(col, F (col))s Groupby multiple columns by multiple aggregation functions F() of columns over source s.
Orderby OB(col)s Sort source s by multiple columns.
Union Us Union multiple sources together.
Outer Union OUs Outer union multiple sources together.
COp COp(col, Op)s1, s2 Correlated Operator on columns col. s1 is outer query, s2 is inner query.
8
XML like Operators
Operator Syntax Description
Tagger Tag(p)s Taggering source s by pattern p.
Navigate Nav(path)s Navigate from source s through a XPath.
Aggregate Agg(F (col))s Aggregate source s by multiple aggregate functions F() of columsn over source s.
9
Special Operators
Operator Parameters Description
SQL SQL(stmt)s One SQL query statement stmt over multiple sources.
Function F(param)s User defined function over multiple sources with multiple parameters.
Source s(desc) Identify a data source by description desc.
Name Rho(col1, col2)s Rho(s2)s1 Rename column col1 of source s into name col2. Rename source s1 into s2.
FOR FOR(col)s1, s2 FOR operator iterate over sources s1 and execute subquery s2 with variable binding columns col1..n.
10
Project Pi(col1..n)s

• Input
• table s
• Output
• table s
• Logic
• Same as SQL.
• Order Handling
• Keep original tuple order, the schema order is
  reordered as the col1..n in the project operator.
• Requirement
• The col1..n should be in source s.

11
Select Theta(c)s

• Input
• table s
• Output
• table s
• Logic
• Same as SQL.
• Order Handling
• Keep original tuple order, keep original schema
  order.
• Requirement
• Condition c should be only reference to the
  source s.

12
Theta Join Join(c)l, r

• Input
• table l, and table r.
• Output
• One table (with temporary table name)
• Logic
• Same as SQL.
• Order Handling
• The schema order of the output table is columns
  of table l followed by the columns of table r.
• The tuple order of the output table is iteration
  of tuples in r over the iteration of tuples in l,
  e.g., ltl1, r1gt, ltl1, r2gt, ltl2, r1gt, ltl2, r2gt
• Requirement
• Condition c should be relates to both tables l
  and r.

13
Outer Join LOJ(c)l, r

• Input
• table l, and table r.
• Output
• One table (with temporary table name)
• Logic
• Same as SQL.
• Order Handling
• The schema order of the output table is columns
  of table l followed by the columns of table r.
• The tuple order of the output table is iteration
  of tuples in r over the iteration of tuples in l,
  e.g., ltl1, r1gt, ltl1, r2gt, ltl2, nullgt, ltl3, r1gt,
  ltl3, r3gt
• Requirement
• Condition c should be relates to both tables l
  and r.

14
Outer Join ROJ(c)l, r

• Input
• table l, and table r.
• Output
• One table (with temporary table name)
• Logic
• Same as SQL. (Similar to LOJ)
• Order Handling
• The schema order of the output table is columns
  of table l followed by the columns of table r.
• The tuple order of the output table is iteration
  of tuples in l over the iteration of tuples in r,
  e.g.,ltnull, r1gt, ltnull, r2gt, ltl1, r1gt, ltl1, r2gt,
  ltl2, r1gt, ltl2, r3gt, null is at the beginning
  of the output.
• Requirement
• Condition c should be relates to both tables l
  and r.

15
Semi Join LSJ(c)l, r

• Input
• table l, and table r.
• Output
• table l.
• Logic
• Same as SQL.
• Order Handling
• The schema order of the output table same as
  table l.
• The tuple order of the output table is same as
  table l.
• Requirement
• Condition c should be relates to both tables l
  and r.

16
Semi Join RSJ(c)l, r

• Input
• table l, and table r.
• Output
• table r.
• Logic
• Same as SQL.
• Order Handling
• The schema order of the output table same as
  table r.
• The tuple order of the output table is same as
  table r.
• Requirement
• Condition c should be relates to both tables l
  and r.

17
Groupby GB(col1..n, F1..m(col))s

• Input
• table s.
• Output
• table s.
• Logic
• Same as SQL.
• Order Handling
• The schema order of the output table is col1..n
  followed by F1..m(col). F1..m(col) can be nested
  operators, e.g., a subquery.
• The tuple order of the output table is same as
  table s.
• Requirement
• col1..n and all the col in the F1..m should be in
  table s.

18
Groupby Example

• Input
• S (a, b, c)
• Operator
• GB (b, a, avg(c), count(c))
• Output
• S (b, a, avg(c), count(c))

19
Orderby OB(col1..n)s

• Input
• table s.
• Output
• table s.
• Logic
• Same as SQL.
• Order Handling
• The schema order of the output table is same as
  table s.
• The tuple order of the output table is as
  specified.
• Requirement
• col1..n should be in table s.

20
Union Us1..n

• Input
• Multiple tables s1..n.
• Output
• One table (with temporary name).
• Logic
• Same as SQL.
• Order Handling
• The schema order of the output table is same as
  table s1.
• The tuple order of the output table is in the
  order of table s1..n.
• Requirement
• All tables s1..n have same schema.

21
Outer Union OUs1..n

• Input
• Multiple tables s1..n.
• Output
• One table (with temporary name).
• Logic
• Same as SQL.
• Order Handling
• The schema order of the output table is
  un-decidable, it depends on implementation. The
  schema order should be ensured by another
  projection node.
• The tuple order of the output table is in the
  order of table s1..n.
• Requirement
• N/A.

22
Tagger Tag(p)s

• Input
• Table s.
• Output
• Table s.
• Logic
• One additional column is added with tagged
  information.
• Pattern p is only one level.
• Order Handling
• The tagged column is added to the end.
• The tuple order of the output table is same as
  table s.
• Requirement
• The columns used in pattern p should be in table
  s.

23
Navigate Nav(path)s

• Input
• Table s.
• Output
• Table s.
• Logic
• One additional column is added with navigation
  information.
• Tuples are multiplied if there are more than one
  results in the navigation.
• If the navigation result is empty, put NULL in
  the new column.
• Order Handling
• The navigation column is added to the end.
• The tuple order of the output table is same as
  table s and the navigation order.
• Requirement
• N/A

24
Aggregate Agg(F1..m(col))s

• Input
• table s.
• Output
• table s.
• Logic
• Merge all tuples in that table into one, and
  apply functions on those columns.
• If there is no functions, then just merge all the
  content.
• Order Handling
• The schema order of the output table is
  F1..m(col).
• There is only one tuple.
• Requirement
• All the col in the F1..m should be in table s.

25
SQL SQL(stmt)s1..n

• Input
• Multiple tables s1..n.
• Output
• Temporary table.
• Logic
• Execute stmt over the multiple tables and output
  the result. It is assumed to be executed by a RDB
  engine. Usually, its the operator right above
  the source (e.g., table) operator.
• Order Handling
• The schema order of the output table is depends
  on the underlying implementation. The schema
  order can be reconfirmed by additional projection
  node.
• The tuple order is un-decidable. The tuple order
  can be reconfirmed by additional orderby node.
• Requirement
• N/A.

26
Function F(param1..m)s1..n

• Input
• Multiple tables s1..n.
• Output
• Temporary table.
• Logic
• Execute some user defined function on the data
  sources.
• Or used to represent a recursive query.
• Order Handling
• Schema and tuple orders are depends on the
  implementation.
• They can be reconfirmed by projection and orderby
  nodes.
• Requirement
• N/A.

27
Source s(desc)

• Input
• N/A
• Output
• A table with a given name.
• Logic
• Identify following sources view, xml document,
  or a table.
• Order Handling
• Depends on the implementation.
• Keep original schema and tuple order as much as
  possible.
• Requirement
• N/A.

28
Name Rho(col1, col2)s

• Input
• Table s.
• Output
• Table s.
• Logic
• Rename col1 in table s into col2.
• Order Handling
• Keep all the schema and tuple orders.
• Requirement
• Col1 in table s.

29
Name Rho(s2)s1

• Input
• Table s1.
• Output
• Table s2.
• Logic
• Rename table s1 to table s2.
• Order Handling
• Keep all the schema and tuple orders.
• Requirement
• N/A.

30
Correlated OuputFOR(col)s1, s2

• Input
• Tables s1 and s2.
• Output
• Evaluation of subquery s2 for each tuple in
  subquery s1..
• Logic
• Its a FOR iteration operator. For value in the
  columns col of table s1, evaluate the sub-query
  that generates the table s2.
• Order Handling
• Schema order is output table s2.
• Tuple order is similar to the join operator
  without the left part.
• Requirement
• N/A.

31
Steps in Translation

• XQuery ? XML Algebra Tree
• User View ? XML Algebra Tree
• View Composition
• Computation Pushdown
• Optimization
• Execution

32
Example of Telephone Bill
lt?xml version1.0 encodingUS-ASCII ?gt
lt!DOCTYPE invoice lt!ELEMENT invoice
(account_number, bill_period, carrier,
itemized_call, total)gt lt!ELEMENT
account_number (PCDATA)gt lt!ELEMENT bill_period
(PCDATA)gt lt!ELEMENT carrier (PCDATA)gt lt!ELEMENT
itemized_call EMPTYgt lt!ATTLIST itemized_call no
ID REQUIRED date CDATA REQUIRED number_called
CDATA REQUIRED time CDATA REQUIRED rate
(NIGHTDAY) REQUIRED min CDATA REQUIRED amount
CDATA REQUIREDgt lt!ELEMENT total (PCDATA)gt gt
ltinvoicegt ltaccount_numbergt555 777-3158 573 234
3lt/account_numbergt ltbill_periodgtJun 9 - Jul 8,
2000lt/bill_periodgt ltcarriergtSprintlt/carriergt
ltitemized_call no1 dateJUN 10
number_called973 555-8888 time1017pm
rateNIGHT min1 amount0.05 /gt
ltitemized_call no2 dateJUN 13
number_called973 650-2222 time1019pm
rateDAY min1 amount0.15 /gt
ltitemized_call no3 dateJUN 15
number_called206 365-9999 time1025pm
rateNIGHT min3 amount0.15 /gt
lttotalgt0.35lt/totalgt lt/invoicegt
33
Example XQuery

• User XQuery
• ltsummarygt
• FOR
• rate IN distinct(document(invoice)/invoice/item
  ized_call_at_rate)
• LET
• itemized_call document(invoice)/invoice/item
  ized_call_at_raterate
• WHERE
• itemized_call/_at_number_called LIKE 973
• RETURN
• ltrategtratelt/rategt
• ltnumber_of_callsgtcount(itemized_call)lt/number_of_
  callsgt
• lt/summarygt

Count number of itemized_calls in calling area
973 grouped by the calling rate.
34
XQuery ? XML Algebra Tree

• Translate XQuery into XAT by grammar.
• Convert each query block into XAT.
• Identify correlated operators.
• Identify query blocks.
• Query decorrelation.

35
XAT Graph Notation

• Unordered Graph.
• Nodes
• Operators with its parameters.
• If there is only one source name, we ignore it.
• Blocks (subqueries)
• We can use block name as the alias of the table
  name out of that block.
• Terminals

V3Tagger(ltsummarygt V2 lt/summarygt)
B2
36
XAT Example
V1Tagger(ltrategtratelt/rategtltnumber_of_callsgt
count(itemized_call)lt/number_of_callsgt)
V2 Tagger(ltsummarygtV1 lt/summarygt)
Select(count(itemized_call))
Aggregate
Select(_at_number_calleditemized_call like
973)
FOR(rate)
Navigate(itemized_call, _at_number_called)
rate Select(distinct(invoice/itemized_call/_at_r
ate/))
Select(_at_rateitemized_call rate)
Navigate(/, invoice/itemized_call/_at_rate)
Navigate(itemized_call, _at_rate)
T1 Source(invoice.xml)
itemized_call Navigate(/,
invoice/itemized_call)
T2 Source(invoice.xml)
37
XQuery Block Identification

• Every query block has only one input point and
  one output point.
• Potential Query Block Separation Point
• Independent sources.
• Correlated Operators.
• Block is used for query optimization, e.g.,
  cutting.

38
Identification of Blocks
B1
B3
V1Tagger(ltrategtratelt/rategtltnumber_of_callsgt
count(itemized_call)lt/number_of_callsgt)
V3 Tagger(ltsummarygtV1 lt/summarygt)
Select(count(itemized_call))
Aggregate
Select(_at_number_calleditemized_call like
973)
FOR(rate)
Navigate(itemized_call, _at_number_called)
rate Select(distinct(invoice/itemized_call/_at_r
ate/))
Select(_at_rateitemized_call rate)
Navigate(/, invoice/itemized_call/_at_rate)
Navigate(itemized_call, _at_rate)
T1 Source(invoice.xml)
itemized_call Navigate(/,
invoice/itemized_call)
T2 Source(invoice.xml)
B2
B4
39
XAT Block Tree
B1
B2
B3
B4
40
Equivalent Rewriting Rules

• Navigation Pushdown
• Swap navigation operator down.
• Computation Pushdown
• Swap SQL operator down.
• Groupby Operator Simplification
• Pull functions (subqueries) out of Groupby
  function.
