CAPWAP Working GroupMIB documentsIETF 65

• David T. Perkins

2
MIB Work

• From the CAPWAP charter
• Deliverable - A MIB Document to support the
  CAPWAP protocol
• Mar 2006 - Issue first Internet-Draft of CAPWAP
  MIB
• Aug 2006 - WGLC for CAPWAP MIB
• Sep 2006 - Submit CAPWAP MIB to IESG as Proposed
  Standard RFC
• Observations
• First I-D for CAPWAP protocol has been issued
• No discussions yet on the WG mailing list on MIB
  work
• The "CAPWAP Objectives" document does not
  directly address MIB requirements

3
Dilemma

• Have milestone at end of month, but do not have
  requirements.
• Have not seen WG mailing list discussions, nor
  have seen posting of MIB modules from CAPWAP
  vendors, which are needed to move forward.
• Can create a MIB module (or modules), but may
  cause thrashing on WG mailing list.
• However, need MIB requirements because they will
  affect definition of CAPWAP protocol.

4
Suggested Approach

• Ask for vendor submission of MIB modules, and
  post on www.capwap.org WEB site (or post URLs to
  documents)
• Post a list of relevant MIB modules (such as IEEE
  802.11, IETF Entity, IETF Interface, etc) on
  www.capwap.org WEB site
• Creation of two documents
• CAPWAP management model, which describes use of
  existing MIB modules
• CAPWAP MIB module, which defines new objects and
  notifications

5
Proposed CAPWAP Tables

• Configured WTPs containing configuration
  attributes
• Radios for configured WTPs containing
  configuration attributes
• Current and past WTP connections containing
  current status, statistics, and running
  configuration
• Radios on connected WTPs containing current
  status, statistics, and running configuration
• Configuration for each WLAN

6
Tables (continued)

• For each WTP, for each radio, each WLAN, the
  status, statistics, and running configuration
• STA sessions containing current status,
  statistics, and configuration
• Configured STA identifiers (user or MAC)
  containing configuration attributes
• Configured neighbor and rogue APs and STAs
• Detected rogue, neighbor, and unknown APs and
  STAs containing current status, statistics, and
  configuration

7
Proposed CAPWAP Notifications

• WTP session (started, stopped, failed)
• STA session (started, stopped, failed)
• Rogue AP detected
• Rogue STA detected
• Power and/or Channel changed on WTP radio(s)

8
Wrap up

• Questions
• Suggestions
