Tidal Power

• Low duty cycle but feasible in certain
  topologically favorable locations

2
Natural Tidal Bottlenecks - Wales
Boyle, Renewable Energy, Oxford University Press
(2004)
3
In Nova Scotia
4
1. Tidal Turbine Farms Challenge its to optimize
turbine design
300 KW Turbine
5
State of the Art Design
1.5 MW 1350 Tons
6
Tidal Fence

• Array of vertical axis tidal turbines
• No effect on tide levels
• Less environmental impact than a barrage
• 1000 MW peak (600 MW average) fences soon

Boyle, Renewable Energy, Oxford University Press
(2004)
7
Tidal Turbines (MCT Seagen)

• 750 kW 1.5 MW
• 15 20 m rotors
• 3 m high Pile
• 10 20 RPM
• Deployed in multi-unit farms or arrays
• Like a wind farm, but
• Water 800x denser than air
• Smaller rotors
• More closely spaced

MCT Seagen Pile
http//www.marineturbines.com/technical.htm
8
Tidal Turbines (Swanturbines)

• Direct drive to generator
• No gearboxes
• Gravity base
• Versus a bored foundation
• Fixed pitch turbine blades
• Improved reliability
• But trades off efficiency

http//www.darvill.clara.net/altenerg/tidal.htm
9
Deeper Water Current Turbine
Boyle, Renewable Energy, Oxford University Press
(2004)
10
Oscillating Tidal Turbine

• Oscillates up and down
• 150 kW prototype operational (2003)
• Plans for 3 5 MW prototypes

http//www.engb.com
Boyle, Renewable Energy, Oxford University Press
(2004)
11
Polo Tidal Turbine

• Vertical turbine blades
• Rotates under a tethered ring
• 50 m in diameter
• 20 m deep
• 600 tonnes
• Max power 12 MW
• Much better power per ton ratio than Power Buoys

Boyle, Renewable Energy, Oxford University Press
(2004)
12
Advantages of Tidal Turbines

• Low Visual Impact
• Mainly, if not totally submerged.
• Low Noise Pollution
• Sound levels transmitted are very low
• High Predictability
• Tides predicted years in advance, unlike wind
• High Power Density
• Much smaller turbines than wind turbines for the
  same power

13
Disadvantages of Tidal Turbines

• High maintenance costs
• High power distribution costs
• Somewhat limited upside capacity ? less than 100
  GW worldwide
• Intermittent power generation over 24 hour day
• Fish bumping (but not chopping due to low RPM)

14
2. Tidal Barrage Schemes ? impound tides to
create a damn resevoir
15
Potential Tidal Barrage Sites
Only about 20 sites in the world have been
identified as possible tidal barrage stations
Boyle, Renewable Energy, Oxford University Press
(2004)
16
Schematic of Tidal Barrage
Boyle, Renewable Energy, Oxford University Press
(2004)
17
Cross Section of La Rance Barrage
http//www.calpoly.edu/cm/studpage/nsmallco/clapp
er.htm
18
La Rance Tidal Power Barrage

• Rance River estuary, Brittany (France)
• Largest in world 750 m dike
• Completed in 1966
• 2410 MW bulb turbines (240 MW)
• 5.4 meter diameter
• Capacity factor of 33
• Electric cost 3.7/kWh

Tester et al., Sustainable Energy, MIT Press, 2005
Boyle, Renewable Energy, Oxford University Press
(2004)
19
La Rance Turbine Exhibit
20
La Rance River, Saint Malo
21
Tidal Barrage Energy Calculations

• R range (height) of tide (in m)
• A area of tidal pool (in km2)
• m mass of water
• g 9.81 m/s2 gravitational constant
• 1025 kg/m3 density of seawater
• ? 0.33 capacity factor (20-35)

kWh per tidal cycle
Assuming 706 tidal cycles per year (12 hrs 24 min
per cycle)
Tester et al., Sustainable Energy, MIT Press, 2005
22
La Rance Barrage Example

• 33
• R 8.5 m
• A 22 km2

GWh/yr
Tester et al., Sustainable Energy, MIT Press, 2005
23
Proposed Severn Barrage (1989)
Never constructed, but instructive
Boyle, Renewable Energy, Oxford University Press
(2004)
24
Proposed Severn Barrage (1989) ? Impressive Scale

• Severn River estuary (Border between Wales and
  England)
• 216 40 MW turbine generators (9.0m dia)
• 8,640 MW total capacity
• 16 km (9.6 mi) total barrage length
• 8.2 (15) billion estimated cost (1988)

25
Severn Barrage ProposalCapital Costs
Boyle, Renewable Energy, Oxford University Press
(2004)
Tester et al., Sustainable Energy, MIT Press, 2005
26
Tidal Barrage Environmental Factors

• Changes in estuary ecosystems
• Less variation in tidal range
• Fewer mud flats
• Less turbidity clearer water
• More light, more life
• Accumulation of silt
• Concentration of pollution in silt
• Visual clutter

27
Advantages of Tidal Barrages

• High predictability
• Tides predicted years in advance, unlike wind
• Similar to low-head dams
• Known technology
• Protection against floods
• Benefits for transportation (bridge)
• Some environmental benefits

http//ee4.swan.ac.uk/egormeja/index.htm
28
Disadvantages of Tidal Barrages

• High capital costs
• Few attractive tidal power sites worldwide
• Intermittent power generation
• Silt accumulation behind barrage
• Accumulation of pollutants in mud
• Changes to estuary ecosystem

29
Promising Tidal Energy Sites
But Bottom Line Sum is only about 70 GW ? BFD?


Country Location TWh/yr GW
Canada Fundy Bay 17 4.3
  Cumberland 4 1.1
USA Alaska 6.5 2.3
  Passamaquody 2.1 1
Argentina San Jose Gulf 9.5 5
Russia Orkhotsk Sea 125 44
India Camby 15 7.6
  Kutch 1.6 0.6
Korea   10
Australia   5.7 1.9
http//europa.eu.int/comm/energy_transport/atlas/h
tmlu/tidalsites.html
30
Local Sites

• Tacoma Narrows
• Deception Pass (Oceana Energy has Permit)
• San Francisco Bay (Golden Gate)
• Straits of Juan De Fuca (twice the scale to that
  of Severn Barge)
