Realtime System Fundamentals : Scheduling

1
Realtime System Fundamentals Scheduling

• B. Ramamurthy

2
Realtime scheduling

• We discussed realtime system scheduling
• Earliest deadline scheduling (EDS)
• Starting deadline
• Completion deadline
• Dynamic priority scheduling
• Rate monotonic scheduling (RMS)
• Periodic tasks are prioritized by the frequency
  of repetition (high priority to tasks with
  shorter periods)
• Preemptive scheduling
• Fixed priority scheduling
• Schedulability according to RMS
• S(Ci/Ti) lt n(21/n-1)
• Cyclic executives (pre-scheduled) (later next
  class?)
• Concepts of cycle, slot and frame
• Repeated execution
• times

3
Critical sections and Semaphores

• When multiples tasks are executing there may be
  sections where only one task could execute at a
  given time critical region or critical section
• There may be resources which can be accessed only
  be one of the processes critical resource
• Semaphores can be used to ensure mutual exclusion
  to critical sections and critical resources

4
Semaphores

• See semaphore.h of xinu

5
Semaphores in exinu

• include ltkernel.hgt
• include ltqueue.hgt /lt queue.h must define
  of sem queues /
• / Semaphore state definitions /
• define SFREE 0x01 /lt this semaphore is
  free /
• define SUSED 0x02 /lt this semaphore is
  used /
• / type definition of "semaphore" /
• typedef ulong semaphore
• / Semaphore table entry /
• struct sentry
• char state /lt the state SFREE
  or SUSED /
• short count /lt count for this
  semaphore /
• queue queue /lt requires q.h.
  /

6
Semaphores in exinu (contd.)

• extern struct sentry semtab
• /
• isbadsem - check validity of reqested
  semaphore id and state
• _at_param s id number to test NSEM is declared
  to be 100 in kernel.h
• A system typically has a predetermined
  limited number of semaphores
• /
• define isbadsem(s) (((ushort)(s) gt NSEM)
  (SFREE semtabs.state))
• / Semaphore function declarations /
• syscall wait(semaphore)
• syscall signal(semaphore)
• syscall signaln(semaphore, short)
• semaphore newsem(short)
• syscall freesem(semaphore)
• syscall scount(semaphore)

7
Definition of Semaphores functions

• static semaphore allocsem(void)
• /
• newsem - allocate and initialize a new
  semaphore.
• _at_param count - number of resources available
  without waiting.
• example count 1 for mutual exclusion lock
• _at_return new semaphore id on success, SYSERR on
  failure
• /
• semaphore newsem(short count)
• irqmask ps
• semaphore sem
• ps disable() /
  disable interrupts /
• sem allocsem() /
  request new semaphore /
• if ( sem ! SYSERR count gt 0 ) /
  safety check /
• semtabsem.count count
  / initialize count /
• restore(ps)
  / restore interrupts /
• return sem
  / return semaphore id /

8
Semaphore newsem contd.

• /
• allocsem - allocate an unused semaphore and
  return its index.
• Scan the global semaphore table for a free
  entry, mark the entry
• used, and return the new semaphore
• _at_return available semaphore id on success,
  SYSERR on failure
• /
• static semaphore allocsem(void)
• int i 0
• while(i lt NSEM) /
  loop through semaphore table /
• /
  to find SFREE semaphore /
• if( semtabi.state SFREE )
• semtabi.state SUSED
• return i
• i
• return SYSERR

9
Semaphore wait()

• /
• wait - make current process wait on a
  semaphore
• _at_param sem semaphore for which to wait
• _at_return OK on success, SYSERR on failure
• /
• syscall wait(semaphore sem)
• irqmask ps
• struct sentry psem
• pcb ppcb
• ps disable() / disable
  interrupts /
• if ( isbadsem(sem) ) / safety
  check /
• restore(ps)
• return SYSERR
• ppcb proctabcurrpid / retrieve
  pcb from process table /
• psem semtabsem / retrieve
  semaphore entry /
• if( --(psem-gtcount) lt 0 ) / if
  requested resource is unavailable /

10
Semaphore wait()

• ppcb-gtsem sem / record semaphore id in pcb /
• enqueue(currpid, psem-gtqueue)
• resched() / place
  in wait queue and reschedule /
• restore(ps) / restore
  interrupts /
• return OK

11
Semaphore signal()

• /signal - signal a semaphore, releasing one
  waiting process, and block
• _at_param sem id of semaphore to signal
• _at_return OK on success, SYSERR on failure
• /
• syscall signal(semaphore sem)
• irqmask ps
• register struct sentry psem
• ps disable() / disable
  interrupts /
• if ( isbadsem(sem) ) / safety
  check /
• restore(ps)
• return SYSERR
• psem semtabsem /
  retrieve semaphore entry /
• if ( (psem-gtcount) lt 0 ) / release
  one process from wait queue /
• ready(dequeue(psem-gtqueue),
  RESCHED_YES)
• restore(ps) / restore
  interrupts /

12
Semaphore usage

• Problem 1
• Create 3 tasks that each sleep for a random time
  and update a counter.
• Counter is the critical resources shared among
  the processes.
• Only one task can update the counter at a time so
  that counter value is correct.
• Problem 2
• Create 3 tasks task 1 updates the counter by 1
  and then signal task 2 that updates the counter
  by 2 and then signals task 3 to update the
  counter by 3.

13
Problem 1

• include lt..gt
• //declare semaphore
• semaphore mutex1 newsem(1)
• int counter 0
• //declare functions proc1,proc1, proc3
• ready(create((void )proc1, INITSTK, INITPRIO,
  PROC1",, 2, 0, NULL), RESCHED_NO)
• ready(create((void )proc2, INITSTK, INITPRIO,
  PROC2",, 2, 0, NULL), RESCHED_NO)
• ready(create((void )proc3, INITSTK, INITPRIO,
  PROC3",, 2, 0, NULL), RESCHED_NO)

14
Problem 1 multi-tasks

• void proc1()
• while (1)
• sleep (rand()10)
• wait(mutex1)
• counter
• signal(mutex1)
• void proc2()
• while (1)
• sleep (rand()10)
• wait(mutex1)
• counter
• signal(mutex1)
• //similarly proc3
• Simulation of this

15
Problem 1
Task 1
Task 2
Counter1
Task 3
16
Problem 2

• semaphore synch12 newsem(0)
• semaphore synch23 newsem(0)
• semaphore synch31 newsem(0)
• ready(create((void )proc1, INITSTK, INITPRIO,
  PROC1",, 2, 0, NULL), RESCHED_NO)
• ready(create((void )proc2, INITSTK, INITPRIO,
  PROC2",, 2, 0, NULL), RESCHED_NO)
• ready(create((void )proc3, INITSTK, INITPRIO,
  PROC3",, 2, 0, NULL), RESCHED_NO)
• signal(synch31)

17
Task flow
18
Priority Inversion

• When we allow concurrent task to execute and with
  semaphore and mailboxes and other synchronization
  primitives, it is possible that a low priority
  task may come to block a high priority task. This
  situation is known as priority inversion.

19
Priority inversion (Priority t1gtt2gtt3)
task2
task3
20
Problem Priority inversion Solution1 Priority
Inheritance
blocked
task1
Task 2 delayed
task2
Priority of t1 inherited
Critical section
Priority reverted To t3
task3
0 1 2 3 4 5 6
7 8 9 10
time
21
Solution2Priority Ceiling Protocol
CS Used by Priority Ceiling
S1 t1,t2 P(t1)
S2 t1,t2,t3 P(t1)
S3 t3 P(t3)
Acquire S1
Release S1
task1
Attempt to Acquire S1
Acquire S1
Acquire S2
No way
task2
Acquire S2
Release S2
Critical section
task3
0 1 2 3 4 5 6
7 8 9 10
time
