Chapter 17: Additional Slides

1
Chapter 17 Additional Slides

• October 11, 2015

2
Outline

• Physical Data Management
• Fragments
• Distributed Query Processing
• Transactions
• Logical Data Management
• Transparency
• Conceptual Data Management

3
Physical Data ManagementFragments

• What is a Fragment?
• Vertical subset (project operation)
• Horizontal subset (restrict operation)
• Mixed Fragment (combination of project and
  restrict)
• A fragment may be allocated to a single or
  multiple sites
• Fragments may be replicated where
• there is a primary fragment as a single site
• Copies of the fragment are placed at multiple
  sites (secondary)

4
Physical Data ManagementDistributed Query
Processing

• Involves both local (intra site) and global
  (inter site) optimization.
• Multiple optimization objectives
• The weighting of communication costs versus local
  processing costs depends on network
  characteristics.
• There are many more possible access plans for a
  distributed query.

5
Physical Data ManagementDistributed Query
Processing contd

• Local vs. Global query processing
• In Local,
• Queries are performed at a central server
  (single site)
• In Global,
• Must decide which sites to access for the
  fragments
• May need to move fragments from site to site
• Multiple optimization is needed for Global
• Due to the multiple sites and access plans
• Many possible access plans for Global
• Choosing the best one may be difficult

6
Physical Data ManagementDistributed Query
Processing contd

• Communication Costs
• Communication Time (CT)
• Fixed Message Delay (MD)
• Variable Transmission Time (TT)
• CT MD TT
• MD Number of Messages Delay per message
• TT Number of bits/Data rate

7
Physical Data ManagementDistributed Query
Processing contd

• Global Query Example (p. 632)
• List the order number, order date, product
  number, product name, product price, and order
  quantity for eastern orders with a specified
  customer number, date range, and product color.
• Four possible access plans

8
Physical Data ManagementDistributed Query
Processing contd

• Access Plan 1
• Move the Product table to the Tulsa site where
  the query is processed

9
Physical Data ManagementDistributed Query
Processing contd

• Access Plan 2
• Restrict the Product table at the Denver Site
• Then move result to the Tulsa site to execute the
  remainder of the query

10
Physical Data ManagementDistributed Query
Processing contd

• Access Plan 3
• Perform join and restrictions of Eastern-Orders
  and Eastern Order-lines fragments at the Tulsa
  site
• Then move result to Denver site to join with
  Product Table

11
Physical Data ManagementDistributed Query
Processing contd

• Access Plan 4
• Restrict the Product table at the Denver site
• Move product numbers to Tulsa and do
  restrict/join
• Then move result back to Denver to combine with
  Product table to get product names

12
Physical Data ManagementDistributed Query
Processing contd

• Obviously many different access plans can be used
  to answer the same query
• Need to investigate
• actual network costs
• the local processing costs at each site to
  determine which access plan is the best

13
Physical Data ManagementTransactions 2 Phase
Commit Protocol

• 2 Phase Commit (2PC)
• Ensures that all transactions are Atomic
• One site is selected as a Coordinator while other
  sites are Participants
• Each Participant site execute a different part of
  the transaction
• Two phases Voting Phase and Decision Phase
• Figure 17.18, page 634

14
Physical Data ManagementTransactions 2 Phase
Commit Protocol

• Several Complications IF
• Failures during recovery and Timeouts
• Log records are lost
• Coordinator fails
• Etc.
• Several methods to resolve these, but out of
  scope for this class

15
Logical Data ManagementTransparency

• Transparency is related to data independence.
• With transparency, users can write queries with
  no knowledge of the distribution, and
  distribution changes will not cause changes to
  existing queries and transactions.
• Without transparency, users must reference some
  distribution details in queries and distribution
  changes can lead to changes in existing queries.

16
Logical Data ManagementFragmentation Transparency

• Fragmentation transparency provides the highest
  level of data independence.
• Users formulate queries and transactions without
  knowledge of fragments (locations, or local
  formats).
• If fragments change, queries and transactions are
  not affected.
• Table 17.6, p 626

17
Logical Data ManagementLocation Transparency

• Location transparency provides a lesser level of
  data independence than fragmentation
  transparency.
• Users need to reference fragments in formulating
  queries and transactions.
• However, knowledge of locations and local formats
  is not necessary.
• Table 17.7, p 627

18
Conceptual Data ManagementSchema Integration

• Multiple types of schemas may exist to describe
  the same dataset
• Integrate multiple schemas into a single schema
• Best explained using an Exercise

19
Conceptual Data ManagementSchema Integration -
Exercise
Engineering Database Relational Schema E(eno,
ename, title), p.k. eno J(jno, jname, budget,
loc, cname), p.k. jno G(eno, jno, resp, dur),
p.k. eno, jno S(title, sal), p.k. title
First, find the common entities and relationships
between schemas
Employee Database CODASYL Schema Department(dept
-name, budget, manager) Employee(e, name,
address, title, salary) Department Employs
Employee (1N relationship)

• Database III E/R Model
• Entities Engineer(Engineer No, name, title,
  salary) Project(PNo, project name, budget,
  location) Client(Client Name, Address)
• Relationships Engineer Works_In Project
  (Responsibility, Duration) Project Contract_By
  Client (Contract Date)

20
Conceptual Data ManagementSchema Integration -
Exercise
Engineering Database Relational Schema E(eno,
ename, title), p.k. eno J(jno, jname, budget,
loc, cname), p.k. jno G(eno, jno, resp, dur),
p.k. eno, jno S(title, sal), p.k. title
Second, draw the conceptual diagram for the
common entities and relationships
Employee Database CODASYL Schema Department(dept
-name, budget, manager) Employee(e, name,
address, title, salary) Department Employs
Employee (1N relationship)

• Database III E/R Model
• Entities Engineer(Engineer No, name, title,
  salary) Project(PNo, project name, budget,
  location) Client(Client Name, Address)
• Relationships Engineer Works_In Project
  (Responsibility, Duration) Project Contract_By
  Client (Contract Date)

21
Conceptual Data ManagementSchema Integration

• No single correct solution to this exercise
• It may be seen that there are multiple solutions
  to this problem
• Considered a very HARD problem
• Often hard to find the best synonyms especially
  from a large set of schemas

22
Weekly Exercise

• Questions 2, 4, and 5
