Validation of a Quantitative Analytical Procedure Accuracy total error profile

1
Validation of a Quantitative Analytical
Procedure Accuracy (total error) profile
Federaal Agentschap voor de Veiligheid van de
Voedselketen

• Dr. Jacques O. DE BEER
• Workshop IPH 27th April 2007
• Scientific Institute of Public Health - Brussels
  (Belgium)

2
Method Validation General Concepts

• Different regulations relating to GLP, GMP, GCP
  (OECD, EU)
• Normative or Regulatory documents (ISO 17025,
  ICH, EMEA, FDA, dir. 2002/657/EG)
• ? both suggest that analytical procedures have
  to comply to certain acceptance criteria.
• This request imposes that these procedures are to
  be validated.
• - Some documents define the validation criteria
• - No proposals on experimental approaches !!
• - Limited to general concepts !!

3
Introduction - Definition

• Method Validation is the confirmation by
  examination and the provision of objective
  evidence that the particular requirements for a
  specific intended use are fulfilled. EN ISO/IEC
  17025 5.4.5.1
• Methods need to be validated or revalidated
• before introduction into routine application
• whenever conditions change for which the method
  has been validated (e.g. Instrument with
  different characteristics)
• whenever the method is modified and modifications
  are outside original scope of the method.

4
European and International regulatory bodies and
their guidelines on different aspects of QA
5
Objectives of an analytical procedure

• Able to quantify as accurately as possible each
  unknown quantity to be determined.
• After analysis the difference between returned
  result x and the unknown true value µT be small
  or lt acceptance limit ?
• -? lt x - µT lt ? ? ?x - µT ? lt ? (eq.1)
• ? depends on objective of analytical procedure
  e.g. 1-2 on bulk, 5 on pharmaceuticals, 15
  for biological samples ? previously defined

6
Objectives of an analytical procedure

• Analytical procedures characterized by (cfr.
  def.)
• true bias dM systematic error (unknown)
• true precision s²M random error measured by a
  standard deviation or variance (unknown)
• Estimates of bias and precision obtained by
  experiments during the validation
• Reliability of these estimates depends on
  adequacy of experiments on known samples (Valid.
  Stds), experimental design, number of
  experiments
• These estimates ? an intermediary but obligatory
  step to evaluate if procedure is likely or not to
  quantify with sufficient accuracy the unknown
  quantities not objectives per se

7
Examples of procedures having the same acceptance
limits l 15
Procedure 1
Procedure 2
Bias 7 RSD 3
Bias 1 RSD 8
Procedure 3
Procedure 4
Bias 0 RSD 20
Bias 7 RSD 12
8
Objectives of an analytical procedure

• Figure 4 different (hypothetical) methods giving
  the distribution of 95 of the measures
• Each method has a true bias dM , a true precision
  s²M , a common acceptance limit ? ( 15 ?
  bioanalytical procedure)
• Procedure 3 negligible bias (0) unsatisfactory
  precision (20 CV) too many measures beyond /-
  15 of the true value does not fulfill objective
• Procedure 4 bias (7) precision (12)
  important proportion outside acceptance limits
  does not fulfill objective but both lt 15
  required by Washington Conf.
• Procedures 1 and 2 fulfill (valid) at least 95
  of results inside acceptance limits

9
Objectives of an analytical procedure

• Procedure 1 presents a bias ( 7), but is very
  precise (3 CV)
• Procedure 2 presents a negligible bias ( 1),
  but is less precise (8 CV)
• FIRST CONCLUSION
• Differences between these two procedures dont
  matter since results are never too far from true
  values of the sample to quantify.
• Quality of results is far more important than
  the intrinsic characteristic properties of
  procedure in terms of bias or precision.

10
Objectives of an analytical procedure

• To develop a procedure without bias and error ?
  considerable cost not acceptable strategy
• Analyst has to take minimal risks, compatible
  with the analytical objectives (within reasonable
  time!!)
• Set up acceptable maximum proportion of
  measurements that might be outside acceptance
  limits (?)
• e.g. 5 or 20 of measurements outside (?) as
  maximum risk.
• inside triangles (next fig.) ? space of
  acceptable procedures characterized by true
  bias dM and a true precision s²M
• Acceptable procedures 95, 80, 66 of
  measurements within 15 limits (recommendations
  Washington Conference) ? proportion depends on
  objectives!!!

11
measurements within 15 bias-precision limits
Proc.3
20
(0,20)
15
Proc.4
True precision ()
66
(7,12)
10
(1,8)
80
Proc.2
5
95
(7,3)
-10
-5
0
10
5
0
Proc.1
True bias ()
12
Objectives of an analytical procedure

• Interior triangle area of all analytical
  procedures of which 95 of result X should be
  included within acceptance limits (?), set
  according constraints of analytical domain
• 2 other triangles proportions of 80 and 66 of
  measurements included within ? (accept. limits)
• ? procedure with true bias 0 true precision
  15 only 66 will fall within acceptance limits
  (?)
• ? procedure with true bias 0 true precision
  8 95 will fall within acceptance limits (?)

13
Objectives of an analytical procedure

• Figure procedures 1 and 2 located inside region
  of acceptance
• this region guarantees that at least resp. 95
  and 80 of the results are within acceptance
  limits (?)
• for the same risk of the measurements outside
  acceptance limits, procedures 3 and 4 not
  considered as valid
• for more important risk, procedures 3 and 4 could
  be valid.

14
Objectives of an analytical procedure

• FURTHER CONCLUSION
• Procedure qualified as acceptable if
• it guarantees that the difference between
  every sample measurement (x) and its true value
  (µT) is inside the predefined acceptance limits
  ( l)
• In equation P(?x - µT ? lt l) ? b (eq.
  2)
• b proportion of measurements inside acceptance
  limits
• l acceptance limit, fixed a priori according
  objectives of the method
• Expected proportion of measurements falling
  outside the acceptance limits ? risk of an
  analytical procedure

15
Objective of the validation

• What ?
• to give to the laboratories as well to the
  regulatory bodies guarantees that every single
  measurement performed in routine is close enough
  to the unknown true value of the sample ?x -
  µT ? lt acceptable limit l
• Objective of validation not simply to obtain
  estimates of bias and precision it is to
  evaluate these guarantees and risks
• These estimates of bias and precision are
  required to evaluate risks

16
Objective of the validation

• With respect to this objective, 2 basic notions
  should be considered
• close enough (eq. 1) meaning that routine
  measure will be less than the acceptance limit ?
  from its unknown true value
• guaranteed, (eq. 2) meaning that it is very
  likely that analysis result will be close enough
  to the true unknown value.

17
Objective of the validation

• decision tools are needed giving guarantees
  that future measurements are reasonably inside
  acceptance limits ?

18
Decision rules

• Current position with respect to the decision
  rules used in the phase of validation ? most of
  them based on use of the null hypothesis
• H0 bias 0 ? H0 relative bias 0 ? H0
  recovery 100
• Bias x - µT
• Relative bias 100 (x - µT)/µT
• Recovery 100 x/µT
• A procedure wrongly declared adequate when the
  95 C.I. of the average bias includes 0
• Test inadequate in validation context of
  analytical procedures because decision based on
  computation of rejection criterion of Student
  t-test

19
Test based on H0 bias 0
20

(0,20)
Proc.3
PROCEDURES VALID
15
(7,12)
Proc.4
10
True precision ()
(1,8)
Proc.2
5
(7,3)
Proc.1
NOT VALID
0
-10
-5
10
5
-15
15
0
True bias ()
20
Decision rules

• According to the decision rule based on the null
  hypothesis H0 in fig. procedures 2, 3 and 4 are
  valid and procedure 1 is rejected
• But procedure 1 shows reduced bias ( 7) and a
  small RSD (3) ? outside triangle rejected !!
• procedure 3 has high RSD (20), procedure 4 has
  bias of 7 and RSD of 12 ? accepted !!
• ? bad precision ? large C.I. ? contains 0 as
  bias value ? method accepted
• ? good precision ? small C.I. ? may not contain 0
  as bias value ? method rejected
• null hypothesis H0 inadequate in analyt.
  validation

21
Test based on acceptance limits ( 15)
20

(0,20)
Proc.3
PROCEDURES NOT VALID
15
Proc.4
(7,12)
10
True precision ()
(1,8)
Proc.2
5
ß 80
(7,3)
0
-10
-5
10
5
-15
15
0
Proc.1
True bias ()
22
Decision rules

• According to the decision rule based on use of
  acceptance limits ? triangle in fig. with
  acceptible valid procedures
• Triangle in fig. corresponds to procedures with
  measurement proportion inside acceptance limits
  (?) a priori chosen proportion (e.g. 80) as
  given by equation P(?x - µT ? lt l) ? b (eq. 2)
• ? more sensible decision rule procedures with
  good precision ? accepted
• bad precision ? rejected
• Biased procedure ? small variance acceptable !!
• Procedure with higher variance ? needs small bias


23
Decision rules Accuracy profile

• easy and visual decision rule use of the
  accuracy profile within the acceptance limits (
  l)
• Accuracy profile constructed from the
  ß-expectation intervals on the expected
  measurements
• - allows to decide on capability of analytical
  procedure to give results inside l
• - describes dosage interval (range) in which the
  procedure is able to quantify with known accuracy
  and a fixed risk at the end of the validation
• e.g. risk of 5 ? guarantee that 95/100 future
  measurements will be included in acceptance
  limits, fixed according requirements (1-2 on
  bulk, 5 on pharmaceut., 15 in bioanalysis)

24
Decision rules

• Accuracy profile by concentration level (C1, C2,
  ...) obtained by computing ß-expectation
  tolerance interval ? allows evaluating the
  proportion of expected measurements inside
  acceptance limits
• This interval is obtained from available
  validated estimates of the bias and precision of
  the procedure (by concentration level)
• This interval of measurements expected within
  level b ( proportion of measurements inside l)
  has b-expectation confidence limits

25
Decision rules

• If for each concentration level j ß-expectation
  tolerance interval are included within acceptance
  limits ? method accepted!
• Tolerance interval calculation
• - what matters is the guarantee of the results,
  expected in the future by the same analytical
  procedure in routine
• - estimation of µj, s²B,j, s²W,j at every conc.
  j are used to estimate the expected proportion of
  observations within the predifined acceptance
  limits -l,l, i.e.
• Eµ,s P?x - µT ? lt ldM, sM ? b

26
Calculation of ß-expectation tolerance interval

• estimated bias (mean added
  concentrations minus mean calculated
  concentrations)
• j conc. level
• these statistical parameters (trueness,
  within/between precision) might be calculated for
  each concentration level from validation
  standards.

27
Calculation of ß-expectation tolerance interval

• Calculation of the interval in which a proportion
  ß of all samples with a certain real
  concentration is observed (method of Mee) ß
  expectation tolerance interval

ISO 5725-2 calculation of within and between
variance
28
Calculation of ß-expectation tolerance interval

• n degrees of freedom (Satterthwaite)
• p number of series (days)
• n number of replicates per series

Qt ß quantile of the Students t-distribution
with ? degrees of freedom
29
Calculation of ß-expectation tolerance interval

• interval representing in the region containing
  ß of analysis results for a certain
  concentration level j

after rearrangement
30
Calculation of ß-expectation tolerance interval

• Interval consists of two terms
• bias /- coefficient of variation for
  intermediate precision expression of method
  accuracy
• method is accurate for this concentration level
  if obtained tolerance interval is included within
  acceptance limits -?,?

31
Accuracy profile
bias ()
l
mean relat. bias
0
acceptance limits
concentration
bias limits of confidence
- l
C1
C2
C3
C4
LLQ
ULQ
RANGE
dosage interval
32
Decision rules

• Estimates of bias and variance are essential to
  compute evaluation of the expected proportion of
  measurements within acceptance limits
• Accuracy profile obtained by connecting the lower
  or upper limits of confidence (cfr. fig)
• If a subsection (concentration range) falls
  outside the acceptance limits ? new limits of
  quantification be defined and a new dosage
  interval (Upper and Lower Limits of
  Quantification)

33
Decision rules (conclusion)

• Accuracy profile represents limits ULQ and LLQ
  in agreement with definition of criterion
• LLQ smallest quantity of the substance that
  can be measured with defined accuracy
• Accuracy profile as single decision tool
• Allows reconciling the objectives of the
  procedure and those of the validation
• Allows to visually grasp the capacity of the
  procedure to fulfill its analytical objective

34
Validation Protocols Life Cycle

• Validation has to be considered as an element
  intervening after the development of a new
  analytical procedure
• Objective of procedure to be used in routine
• Usage in routine must be coupled with a quality
  control (QC) of which the 2 objectives are
• the validity of the found results on the unknown
  samples
• the assessment of the continuity of the
  performances of the procedure at the time of its
  exploitation

35
Protocols in validation phase

• Main objectives in validation phase
• demonstrate specificity/selectivity
• validate the response function (or calibration
  model used in routine)
• estimate precision (repeatability and
  intermediate precision), trueness, accuracy
• validate the quantitation limits, validate the
  range (dosage interval) cfr. accuracy profile!
• assess linearity of the analytical procedure
  (results directly proportional to concentration
  in the sample cfr. definitions)

36
Protocols in validation phase

• ?preparation of calibration standards (CS) with
  fixed number of concentration levels and
  repetitions by level
• ?preparation of the validation standards (VS) in
  the matrix are independent samples
• VS prepared and treated independenly as future
  samples ? essential for good estimation of
  between-series variance.
• To estimate intermediate precision, VS analyzed
  on different days, equipment and by different
  operators.
• Validation phase is ultimate stage before
  exploitation ? allows to estimate procedures
  performances in the expected experimental
  conditions
• ? allows to check procedures capability to
  quantify unknown sample

37
Protocols in validation phase

• Question whether or not presence of a matrix
  effect.
• If no matrix effect, question is which
  concentration levels will be used for calibration
  ? apply described validation protocols (V1 and
  V2)
• Evidence of matrix effect apply protocol V5
• In case of doubt apply protocols V3 and V4
  according to calibration levels (cfr.Table)
• Which types of standards (CS and VS),
  concentration levels?
• VS prepared in matrix and independent must
  similate future samples

38
Choise of number of CS and VS depending on
selected protocol
39
Description of protocol V1
Series 1
Series 2
Series 3
R
Calibration standards
Validation standards
(1)
(1)
Additional validation standards (linearity ICH)
(1)
Conc
40
Description of protocol V2
Series 1
Series 2
Series 3
R
Calibration standards
)
(
(
)
)
(
Validation standards
(1)
(1)
Additional validation standards (linearity ICH)
(1)
Conc
41
Description of protocol V3
Series 1
Series 2
Series 3
Calibration Standards without matrix
R
Calibration Standards within matrix
Validation standards
(1)
(1)
Additional validation standards (linearity ICH)
(1)
Conc
42
Possible concentation levels by type of procedure
(e.g. 6 comparative procedures)

• Determination of single chemical substance
  reference available or determination of active
  ingredient in a pharmaceutical speciality
  (matrix)
• Determination of available synthesis impurity in
  an active substance or pharmaceutical speciality
  (matrix) at concentration levels gt LOQ
• Determination of available synthesis impurity in
  an active substance or pharmaceutical speciality
  (matrix) around impurity limit (impurity limit gt
  LOQ)
• Simultaneous determination of chemical substance
  and one of its non-available impurities in this
  substance or pharmaceutical speciality (use
  substance as tracer to allowed maximum
  concentration of impurity)

43
Possible concentation levels by type of procedure
(e.g. 6 comparative procedures)

• Determination of active substance for measuring
  dissolution kinetics for a dry dosage form
  (matrix)
• Determination of active ingredient and its
  metabolites in plasma (drugs), drug residues, ...

• WHICH CONCENTRATION LEVELS ?
• ? cfr. TABLE

44
Examples of possible concentration levels by type
of procedure
LA admitted limit Cmax max. conc. Cmin
min. conc.
45
Protocols in validation phase

• Identify relationship between response Y and
  concentration X using calibration standards
  (response function).
• Regression models are fitted, accuracy profiles
  calculated, one model selected ? decision about
  validity of the procedure of interest.
• Model depends on ? procedure type
  (pharmaceutical, bio-analytical, immuno-assay)
  ? fixed method objectives
• Linear regression (origin or not) envisaged.
• Mathematical transformations applied on X and Y
• Quadratic regression may be useful

46
Protocols in validation phase

• Back-calculation of estimated VS concentrations
  by series by ? calibration curve equations
• For each concentration level ? estimation of
  trueness and precision
• ? calculation of limits for accuracy cfr. CIj
  (bias) (include large proportion of results)
• ? accuracy profile for each fitted model
• Accuracy profile ? visual decision tool to
  evaluate capability of the method ? if not within
  pre-fixed acceptance limits
• - restrict dosis range ? new limits of
  quantification
• - extend acceptance limits (possible??)

47
ACCURACY PROFILES with same VALIDATION PROTOCOL
(0.01 5.0 ng/ml)
A
B
15
15
quadratic regression
Bias ()
Bias ()
weighed linear regression
-15
-15
C
D
15
15
Bias ()
Bias ()
-15
linear regression
-15
linear regression throug 0
linear regression on log transformed data
E
F
linear regression on square root transformed data
15
15
Bias ()
Bias ()
-15
-15
Concentration
Concentration
1
2
3
4
5
0
0
1
2
3
4
5
48
Protocols in validation phase

• Figure Accuracy profiles for validation of
  dosing procedure of chemical substance in
  biological matrix.
• Protocol V5 applied some concentration levels
• Essentially low levels ? good estimation of LOQ
• 2 of 6 response functions (A quadratic regress.
  B weighed regression) answer objective
  acceptance limits 15
• ? accuracy profile allows to decide about method
  capability
• Quantifiable dosing range with known accuracy
  0.01 5.0 ng/ml at risk ? 5

49
CONCLUSIONS

• Lack of generalisation between different
  validation protocols ? harmonized approach
• Proposal to review objectives of the validation
  according to objectives of the analytical
  procedure
• Distinction between diagnosis rules and decision
  rules
• Objectives of validation not simply to obtain
  estimates of bias and precision but also
• To evaluate risks or confidences that any single
  measurement is close enough to unknown true value
• Trueness, precision, linearity, ..., no longer
  sufficient to make these guarantees.

50
CONCLUSIONS

• Adapted decision tool ? accuracy profile of the
  analytical procedure, based on
• ?-expectation tolerance interval at each
  concentration level
• concept of total error (bias standard
  deviation)
• Allows to bring together objectives of the
  procedure and those of validation
• Allows to visually grasp the capacity of the
  procedure ? to fulfil its objectives
• ? to control risk associated with its
  use in routine

51
References

• C. Hartmann et al., An analysis of the Washington
  Conference Report on bioanalytical method
  validation
• J. Pharm. Biomed. Anal., 12(11) (1994) 1337-1343
• Ph. Hubert et al., The SFSTP guide on the
  validation of chromatographic methods for drug
  bioanalysis from the Washington Conference to
  the laboratory.
• Anal. Chim. Acta, 391 (1999) 135-148
• P. Chiap et al., Validation of an automated
  method for the liquid chromatographic
  determination of atenolol in plasma application
  of a new validation protocol.
• Anal. Chim. Acta, 391 (1999) 227-238

52
References

• B. Boulanger et al., An analysis of the SFSTP
  guide on validation of chromatographic
  bioanalytical methods progress and limitations.
• J. Pharm. Biomed. Anal., 32 (2003) 753-765
• Ph. Hubert et al., Validation des procédures
  analytiques quantitatives. Harmonisation des
  démarches.
• STP Pharma Pratiques, 13(3) (2003) 101-138
• Ph. Hubert et al., Harmonization of strategies
  for the validation of quantitative analytical
  procedures. A SFSTP proposal part I
• J. Pharm. Biomed. Anal., 36 (2004) 579-586

53
References

• Ph. Hubert et al., Validation des procédures
  analytiques quantitatives. Harmonisation des
  démarches. Partie II - Statstiques
• STP Pharma Pratiques, 16(1) (2006) 28 58
• Ph. Hubert et al., Validation des procédures
  analytiques quantitatives. Harmonisation des
  démarches. Partie III Exemples dapplication
• STP Pharma Pratiques, 16(2) (2006) 87 121
• M. Feinberg et al., New advances in method
  validation and measurement uncertainty aimed at
  improving the quality of chemical data
• Anal. Bioanal. Chem 380 (2004) 502-514
• M. Feinberg et al., A global approach to method
  validation and measurement uncertainty
• Accred. Qual. Assur 11 (2006) 3-9
