Exploiting Level Sensitive Latches in Wire Pipelining

1
Exploiting Level Sensitive Latches in Wire
Pipelining

• Vikram Seth
• Department of EE
• Texas AM University

Min Zhao Freescale Semiconductor Inc.
Jiang Hu Department of EE Texas AM University
2
Outline

• Technology trend and wire pipelining
• Previous works
• Advantages and challenges of using latches
• Concurrent repeater, flip-flop and latch
  insertion
• Experimental results
• Conclusion

3
Technology Trend

• Wire delay increase
• Clock period decrease
• Chip size increase
• Multiple clock cycles for long distance signal
  propagation

4
Wire Pipelining
Delay lt 1 clock cycle
Repeater
5
Design Implications

• Minimizing delay is inadequate
• Latency number of clocked repeaters along a
  source-sink path
• Latency needs to be minimized or latency
  constraint needs to be satisfied
• More power dissipations
• Clocked repeaters are generally larger than
  unclocked repeaters
• Extra load to clock network
• Greater vulnerability to variations
• Dependence on clock skew

6
Previous Work I Concurrent Repeater and
Flip-flop Insertion

• Cocchini, Hassoun-Alpert-Thiagarajan, ICCAD 02
• Given
• Steiner tree, candidate repeater locations on the
  tree
• Repeater library repeaters edge triggered
  flip-flops
• Clock skew
• MiLa
• Find repeater solution to Minimize the max
  Latency
• GiLa
• Find min cost repeater solution to satisfy Given
  Latency constraint at each sink

7
Previous Work II Wave Pipelining

• L. Zhang, Y. Hu and C. C.-P. Chen, TAU 2004
• Wave pipelining
• Signals are allowed to propagated over
  multi-cycles without synchronous elements
• Advantages
• No setup time and skew overhead
• Weakness
• Complicated recovery circuits at receiver

8
Spectrum of Synchronization Effort
Flip-flop based pipelining
Latches
Wave pipelining
Loose synchronization Avoidable setup
time Tolerance to skew No recovery circuit
Strong synchronization Setup time overhead Skew
overhead
Zero synchronization Recovery circuit overhead
9
Area and Power Advantages of Using Latches

• A flip-flop is usually composed by two latches
• Replacing each flip-flop with one latch may
  reduce
• Area
• Dynamic power
• Leakage power
• Load to clock network

10
Timing Flexibility of Latches
FF2
FF1
Delay
t1
t2
Clock source
Delay lt T
Depart
T
t1
Arrive
t2
11
Advantage of Latches on Handling Blockages
Delay T
Delay T
Negative edge triggered flip-flops
12
Marginal Wave Pipelining
Delay T - Tp
Delay T Tp
F1
F2
L
F1
F2
Clock
L
Remark by Dr. Cocchini

• Sometimes there are two signals between L and F2
• Insert repeaters between L and F2 gt one signal
  may not overwrite the other
• Turn off during inactive clock level gt avoid
  signal loss

13
Advantages of Latches in Tree
Delay T
Delay T
Negative edge triggered flip-flops
Delay T
14
ChallengeTight Short Path Constraint
FF2
FF1
Delay
t1
t2
Clock
th lt Delay lt T - ts
T
Depart
t1
Arrive
ts
th
t2
15
Assumptions

• Flip-flop latch based wire pipelining is
  applied in a flip-flop based circuit design
• Single phase clock for flip-flops and latches
• Flip-flops are negative edge triggered
• Latches are positive level sensitive
• Timing reference point is aligned with falling
  egde of the clock signal

16
Problem Formulation

• Given
• Steiner tree, candidate repeater locations on the
  tree
• Repeater library repeaters flip-flops
  latches
• MiLa find repeater solution to Minimize the max
  Latency
• GiLa find min cost repeater solution to satisfy
  Given Latency constraint at each sink
• Both long path and short path constraints are
  satisfied for flip-flops and latches
• Gate RC switch model, wire Elmore delay model

17
Algorithm Overview
Candidate locations
Driver
Sink
Candidate solutions are propagated from sinks
toward the driver
Sink
18
Candidate Solutions

• Each candidate solution is associated with a node
  in tree, and is characterized by
• c downstream cap seen from the node
• r required arrival time
• y latency
• a repeater assignment
• At each sink node j, initial candidate solution (
  cj, rj, 0, 0 )

19
REPEAT Insert Buffer
(c1, r1, y1, 0)

• r1r r1 Rrc1
• If r1r lt -Tp, drop this solution
• c1r Cr
• y1r y1
• Cr repeater input capacitance
• Rr repeater output resistance

20
REPEAT Insert Flip-flop
(c1, r1, y1, 0)

• If r1 Rfc1 lt 0
• Skip the REPEAT to enforce long path constraint
• c1f Cf
• r1f T - tsetup
• y1f y1 1
• Cf flip-flop input capacitance
• Rf flip-flop output resistance

21
REPEAT Insert Latch
(c1, r1, y1, 0)

• r r1 RLc1
• If rlt -Tp, quit ( long path constraint )
• r lt delay padding ( short path constraint )
• c1L CL
• r1L min(T tsetup , T r )
• y1L y1 1
• CL latch input capacitance
• RL latch output resistance

r lt tsetup implies time borrowing
22
Delay Padding

• Short path violation can be fixed by delay padding

Extra load
23
Uniform Delay Padding

• If delay gt Tp thold, there is
  no short path violation
• Pad delay if delay lt Tp thold when insert latch
• If r gt T tsetup Tp thold
  pad delay of r T tsetup Tp thold

tsetup
r
Delay
0
T
24
Pessimism of Uniform Delay Padding
Latch A
Latch B
Delay

• Even if delay lt Tp thold , short path
  constraint may be satisfied when signal arrival
  time is late
• Uniform delay padding may cause unnecessary
  padding
• Arrival time is not known in bottom-up solution
  propagation!

Delay
Early arrival
Clock
Arrival time at A
25
Deferred Delay Padding

• Along with solution propagation
• Note potential delay padding
• Defer actual padding till arrival information is
  available

26
Additional Characteristics for Solutions

• Earliest required arrival time r
• r lt RAT lt r
• Large r implies more chance of actual padding
• Potential delay padding p associated with a
  specific short path
• Each solution is characterized by (c,
  r, y, a, r, p )
• At sink j, solution is (cj, rj, 0, 0, rj T, 0 )

27
JOIN Operation for Deferred Delay Padding
(cl , rl , yl , al , rl , pl)
(cr , rr , yr , ar , rr , pr)

• cjoin cl cr
• rjoin min(rl , rr)
• yjoin max(yl , yr)
• ajoin al ? ar
• rjoin max(rl , rr)
• pjoin pl ? pr
• If rjoin gt rjoin , pad delay

28
Latch Insertion Revisited
(c1, r1, y1, 0, r1, p1)
(c1L, r1fL, y1L, a1L, r1L, p1L)

• r r1 RLc1
• If rlt -Tp, quit ( long path constraint )
• r lt deferred delay padding, decide
• Potential delay padding p
• Any part of p needs to be instantiated
• Update r
• c1L CL
• r1L min(T tsetup , T r )
• y1L y1 1

r lt tsetup implies time borrowing
29
DDP Generating Potential Delay Padding

• If -Tp lt r lt 0, generate p r Tp, propagate r
  through latch
• Neglect setup/hold time for simplicity

b
c
a
Dbc 2
0
4
8
At c
r 8 r 0 p 0
30
DDP Small Earliest RAT

• If r lt -Tp, arrival time can be arbitrarily early
  without causing short path violation
• No padding, p 0, r 0 after latch insertion

b
c
a
Dbc 2
Dab 11
No short path violation even without padding
0
4
8
r 8 r 6 p 2
At b
31
DDP Medium Earliest RAT

• If -Tp lt r lt 0, r Tp lt p, update p, propagate
  r, no actual padding,

b
c
a
Dbc 2
Dab 9
4
16
0
8
r 8 r 6 p 2
At b
p min ( previous r Tp, previous p ),
potential padding on (a, b)
32
DDP Large Earliest RAT

• If r gt p gt 0, instantiate padding of amount p !
  reset p and r

b
c
a
Dbc 2
Dab 3
r 8 r 6 p 2
r 5 r 3 p 2
WIRE ab
At b
4
0
8
33
Experiment MiLa without Blockages
Latency
sinks/net 117 Runtime 0.010.07 s
34
Experiment MiLa with Blockages
Latency
No feasible solutions with only FF
blockages 340
35
Experiment GiLa without Blockages
No feasible solutions with only FF
Area
36
Experiment GiLa with Blockages
No feasible solutions with only FF
Area
37
Conclusions

• Wire pipelining becomes a necessity and requests
  more on timing and power/area
• Advantages of using latches area and timing
  flexibility
• Short path constraint can be solved
• Mixed latch and flip-flop
• Proper delay padding
• Timing advantage of latch can be traded to
  variation tolerance

38
Thank You!
