Algorithms Analysis lecture 11 Greedy Algorithms

1
Algorithms Analysislecture 11 Greedy
Algorithms
2
Greedy Algorithms

• Activity Selection Problem
• Knapsack Problem
• Huffman Problem

3
Greedy Algorithms

• Similar to dynamic programming, but simpler
  approach
• Also used for optimization problems
• Idea Make a locally optimal choice in hope of
  getting a globally optimal solution

4
Greedy Algorithms

• ?? For optimization problems
• ?? Dynamic programming
• ?? determine the best choices is overkill
• ?? Greedy algorithm
• ?? makes the choice that looks best at the moment
  in order to get optimal solution.
• ?? Optimistic ??????
• ?? Almost always but do not always yield optimal
  solutions.
• ?? We will have the Activity selection example
  and we will solve it using both algorithms

5
Activity Selection

• Schedule n activities that require exclusive use
  of a common resource
• S a1, . . . , an set of activities
• ai needs resource during period si , fi)
• si start time and fi finish time of activity
  ai
• 0 ? si lt fi lt ?
• Activities ai and aj are compatible if the
  intervals si , fi) and sj, fj) do not overlap

fj ? si
fi ? sj
i
j
j
i
6
Activity Selection Problem

• Select the largest possible set of non-
  overlapping (mutually compatible) activities.
• E.g.

• Activities are sorted in increasing order of
  finish times
• A subset of mutually compatible activities a3,
  a9, a11
• sets of mutually compatible activities
• a1, a4, a8, a11 and a2, a4, a9, a11

7
Activity-selection UsingDynamic Programming,
step 1
8
Optimal Substructure, step 1

• Define the space of subproblems
• Sij ak ? S fi sk lt fk sj
• activities that start after ai finishes and
  finish before aj starts

9
Representing the Problem, step 1

• Range for Sij is 0 ? i, j ? n 1
• In a set Sij we assume that activities are sorted
  in increasing order of finish times
• f0 ? f1 ? f2 ? ? fn lt fn1
• What happens if i j ?
• For an activity ak ? Sij fi ? sk lt fk ? sj lt fj
• contradiction with fi ? fj!
• ? Sij ? (the set Sij must be empty!)
• We only need to consider sets Sij with 0 ? i lt j
  ? n 1

10
Optimal Substructure, step 1

• Subproblem
• Select a maximum size subset of mutually
  compatible activities from set Sij
• Assume that a solution to the above subproblem
  includes activity ak (Sij is non-empty)
• Solution to Sij (Solution to Sik) ? ak ?
  (Solution to Skj)
• ?Solution to Sij ? ?Solution to Sik ? 1
  ?Solution to Skj ?

11
Optimal Substructure (cont.)

• Suppose Aij Optimal solution to Sij
• Claim Sets Aik and Akj must be optimal solutions

• Assume ? Aik that includes more activities than
  Aik
• SizeAij SizeAik 1 SizeAkj gt
  SizeAij
• ? Contradiction we assumed that Aij is the
  maximum of activities taken from Sij

12
Recursive Solution, step 2

• Any optimal solution (associated with a set Sij)
  contains within it optimal solutions to
  subproblems Sik and Skj
• ci, j size of maximum-size subset of mutually
  compatible activities in Sij
• If Sij ? ? ci, j 0 (i j)

13
Recursive Solution, step 2

• If Sij ? ? and if we consider that ak is used in
  an optimal solution (maximum-size subset of
  mutually compatible activities of Sij)
• ci, j

ci,k ck, j 1
14
Recursive Solution, step 2

• 0 if Sij ?
• ci, j max ci,k ck, j 1 if Sij ? ?
• There are j i 1 possible values for k
• k i1, , j 1
• ak cannot be ai or aj (from the definition of
  Sij)
• Sij ak ? S fi sk lt fk sj
• We check all the values and take the best one
• We could now write a tabular, bottom-up dynamic
  programming algorithm

i lt k lt j ak ? Sij
15
Converting to a greedy solution
16
Theorem

• Let Sij ? ? and am be the activity in Sij with
  the earliest finish time
• fm min fk ak ? Sij
• Then
• am is used in some maximum-size subset of
  mutually compatible activities of Sij
• There exists some optimal solution that contains
  am
• Sim ?
• Choosing am leaves Smj the only non-empty
  subproblem

17
Proof

• Assume ? ak ? Sim
• fi ? sk lt fk ? sm lt fm
• ? fk lt fm contradiction !
• am did not have the earliest finish time
• ? There is no ak ? Sim ? Sim ?

Sij
sm
fm
ak
am
18
Proof
Greedy Choice Property

• am is used in some maximum-size subset of
  mutually compatible activities of Sij
• Aij optimal solution for activity selection
  from Sij
• Order activities in Aij in increasing order of
  finish time
• Let ak be the first activity in Aij ak,
• If ak am Done!
• Otherwise, replace ak with am (resulting in a set
  Aij)
• since fm ? fk the activities in Aij will
  continue to be compatible
• Aij will have the same size with Aij ? am is
  used in some maximum-size subset

Sij
19
Why is the Theorem Useful?
2 subproblems Sik, Skj
1 subproblem Smj Sim ?
1 choice the activity with the earliest finish
time in Sij
j i 1 choices

• Making the greedy choice (the activity with the
  earliest finish time in Sij)
• Reduce the number of subproblems and choices
• Solve each subproblem in a top-down fashion

20
Greedy Approach

• To select a maximum size subset of mutually
  compatible activities from set Sij
• Choose am ? Sij with earliest finish time (greedy
  choice)
• Add am to the set of activities used in the
  optimal solution
• Solve the same problem for the set Smj
• From the theorem
• By choosing am we are guaranteed to have used an
  activity included in an optimal solution
• ? We do not need to solve the subproblem Smj
  before making the choice!
• The problem has the GREEDY CHOICE property

21
Characterizing the Subproblems

• The original problem find the maximum subset of
  mutually compatible activities for S S0, n1
• Activities are sorted by increasing finish time
• a0, a1, a2, a3, , an1
• We always choose an activity with the earliest
  finish time
• Greedy choice maximizes the unscheduled time
  remaining
• Finish time of activities selected is strictly
  increasing

22
A Recursive Greedy Algorithm

• Alg. REC-ACT-SEL (s, f, i, j)
• m ? i 1
• while m lt j and sm lt fi ?Find first activity in
  Sij
• do m ? m 1
• if m lt j
• then return am ? REC-ACT-SEL(s, f, m, j)
• else return ?
• Activities are ordered in increasing order of
  finish time
• Running time ?(n) each activity is examined
  only once
• Initial call REC-ACT-SEL(s, f, 0, n1)

ai
fi
23
Example
k sk fk
a1
m1
a0
a2
a3
a1
a4
m4
a1
a5
a4
a1
a6
a1
a4
a1
a7
a1
a4
a8
m8
a4
a1
a9
a1
a4
a8
a10
a4
a1
a8
a11
m11
a1
a4
a8
a11
a1
a4
a8
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
24
An Iterative Greedy Algorithm

• Alg. GREEDY-ACTIVITY-SELECTOR(s, f)
• n ? lengths
• A ? a1
• i ? 1
• for m ? 2 to n
• do if sm fi ? activity am is
  compatible with ai
• then A ? A ? am
• i ? m ? ai is most recent addition to
  A
• return A
• Assumes that activities are ordered in increasing
  order of finish time
• Running time ?(n) each activity is examined
  only once

am
fm
am
fm
am
fm
ai
fi
25
Activity Selection
B (1)
C (2)
A (3)
E (4)
D (5)
F (6)
G (7)
H (8)
Time
0
1
2
3
4
5
6
7
8
9
10
11
0
1
2
3
4
5
6
7
8
9
10
11
26
Activity Selection
B (1)
C (2)
A (3)
E (4)
D (5)
F (6)
G (7)
H (8)
Time
0
1
2
3
4
5
6
7
8
9
10
11
B
0
1
2
3
4
5
6
7
8
9
10
11
27
Activity Selection
B (1)
C (2)
C (2)
A (3)
E (4)
D (5)
F (6)
G (7)
H (8)
Time
0
1
2
3
4
5
6
7
8
9
10
11
B
E
H
0
1
2
3
4
5
6
7
8
9
10
11
28
Steps Toward Our Greedy Solution

• Determine the optimal substructure of the problem
• Develop a recursive solution
• Prove that one of the optimal choices is the
  greedy choice
• Show that all but one of the subproblems resulted
  by making the greedy choice are empty
• Develop a recursive algorithm that implements the
  greedy strategy
• Convert the recursive algorithm to an iterative
  one

29
Another Example The Knapsack Problem- two
version

• The 0-1 knapsack problem
• A thief robbing a store finds n items the i-th
  item is worth vi dollars and weights wi pounds
  (vi, wi integers)
• The thief can only carry W pounds in his knapsack
• Items must be taken entirely(1) or left behind
  (0)
• Which items should the thief take to maximize the
  value of his load?
• The fractional knapsack problem
• Similar to above
• The thief can take fractions of items

30
The 0-1 Knapsack Problem

• Thief has a knapsack of capacity W
• There are n items for i-th item value vi and
  weight wi
• Goal
• find xi such that for all xi 0, 1, i 1, 2,
  .., n
• ? wixi ? W and
• ? xivi is maximum

31
0-1 Knapsack - Greedy Strategy
50
50

• E.g.

Item 3
30
20
Item 2
100
20
Item 1
10
10
60
60
100
120
160
6/pound
5/pound
4/pound

• None of the solutions involving the greedy choice
  (item 1) leads to an optimal solution
• The greedy choice property does not hold

32
0-1 Knapsack - Dynamic Programming

• P(i, w) the maximum profit ??? that can be
  obtained from items 1 to i, if the knapsack has
  size w
• Case 1 thief takes item i
• P(i, w)
• Case 2 thief does not take item i
• P(i, w)

vi P(i - 1, w-wi)
P(i - 1, w)
33
0-1 Knapsack - Dynamic Programming
34
(No Transcript)
35
Reconstructing the Optimal Solution
36
Optimal Substructure

• Consider the most valuable load that weights at
  most W pounds
• If we remove item j from this load
• The remaining load must be the most valuable
  load weighing at most W wj that can be taken
  from the remaining n 1 items

37
Fractional Knapsack Problem

• Knapsack capacity W
• There are n items the i-th item has value vi and
  weight wi
• Goal
• find xi such that for all 0 ? xi ? 1, i 1, 2,
  .., n
• ? wixi ? W and
• ? xivi is maximum

38
Example
39
Fractional Knapsack Problem

• Greedy strategy
• Pick the item with the maximum value per pound
  vi/wi
• If the supply of that element is exhausted and
  the thief can carry more take as much as
  possible from the item with the next greatest
  value per pound
• It is good to order items based on their value
  per pound

40
Fractional Knapsack Problem

• Alg. Fractional-Knapsack (W, vn, wn)
• While w gt 0 and as long as there are items
  remaining
• pick item with maximum vi/wi
• remove item i from list
• w ? w xiwi
• w the amount of space remaining in the knapsack
  (w W)
• Running time ?(n) if items already ordered else
  ?(nlgn)

41
Fractional Knapsack - Example
50
20 --- 30
50

• E.g.

80
Item 3
30
20
Item 2
100
20
Item 1
10
10
60
60
100
120
240
6/pound
5/pound
4/pound
42
Huffman Code Problem

• Huffmans algorithm achieves data compression by
  finding the best variable length binary encoding
  scheme for the symbols that occur in the file to
  be compressed.

43
Huffman Code Problem

• The more frequent a symbol occurs, the shorter
• should be the Huffman binary word representing
• it.
• The Huffman code is a prefix-free code. No
  prefix of a code word is equal to another
  codeword.

44
Overview

• Huffman codes compressing data (savings of 20
  to 90)
• Huffmans greedy algorithm uses a table of the
  frequencies of occurrence of each character to
  build up an optimal way of representing each
  character as a binary string

45
Example

• Assume we are given a data file that contains
  only 6 symbols, namely
• a, b, c, d, e, f
• With the following frequency table
• Find a variable length prefix-free encoding
  scheme that compresses this data file as much as
  possible?

46
Huffman Code Problem
Left tree represents a fixed length encoding
scheme Right tree represents a Huffman
encoding scheme
47
Example
48
Huffman Code Problem
49
Constructing A Huffman Code
Total computation time O(n lg n)
O(lg n)
O(lg n)
O(lg n)
O(lg n)
50
Cost of a Tree T

• For each character c in the alphabet C
• let f(c) be the frequency of c in the file
• let dT(c) be the depth of c in the tree
• It is also the length of the codeword. Why?
• Let B(T) be the number of bits required to encode
  the file (called the cost of T)

51
Huffman Code Problem

• In the pseudocode that follows
• ?? we assume that C is a set of n characters and
  that each character c C is an object with a
  defined frequency f c.
• ?? The algorithm builds the tree T corresponding
  to the optimal code
• ?? A min-priority queue Q, is used to identify
  the two least-frequent objects to merge together.
• ?? The result of the merger of two objects is a
  new object whose frequency is the sum of the
  frequencies of the two objects that were merged.

52
Running time of Huffman's algorithm

• The running time of Huffman's algorithm assumes
  that Q
• is implemented as a binary min-heap.
• ?? For a set C of n characters, the
  initialization of Q in line 2 can be performed in
  O (n) time using the BUILD-MINHEAP
• ?? The for loop in lines 3-8 is executed exactly
  n - 1 times, and since each heap operation
  requires time O (lg n), the loop contributes O (n
  lg n) to the running time. Thus, the total
  running time of HUFFMAN on a set of n characters
  is O (n lg n).

53
Prefix Code

• Prefix(-free) code no codeword is also a prefix
  of some other codewords (Un-ambiguous)
• An optimal data compression achievable by a
  character code can always be achieved with a
  prefix code
• Simplify the encoding (compression) and decoding
• Encoding abc ? 0 . 101. 100 0101100
• Decoding 001011101 0. 0. 101. 1101 ? aabe
• Use binary tree to represent prefix codes for
  easy decoding
• An optimal code is always represented by a full
  binary tree, in which every non-leaf node has two
  children
• C leaves and C-1 internal nodes Cost

54
Huffman Code

• Reduce size of data by 20-90 in general
• If no characters occur more frequently than
  others, then no advantage over ASCII
• Encoding
• Given the characters and their frequencies,
  perform the algorithm and generate a code. Write
  the characters using the code
• Decoding
• Given the Huffman tree, figure out what each
• character is (possible because of prefix property)

55
Application on Huffman code

• Both the .mp3 and .jpg file formats use Huffman
  coding at one stage of the compression
